Page 1 ES-4124 Intelligent Layer 3+ Switch User’s Guide Version 3.70 8/2006...
Page 3: Copyright
Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others.
Page 4: Certifications
ES-4124 User’s Guide Certifications Federal Communications Commission (FCC) Interference Statement This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operations.
Page 5 ES-4124 User’s Guide 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. Certifications...
Page 6: Safety Warnings
ES-4124 User’s Guide Safety Warnings For your safety, be sure to read and follow all warning notices and instructions. • Do NOT use this product near water, for example, in a wet basement or near a swimming pool. • Do NOT expose your device to dampness, dust or corrosive liquids.
Page 7 ES-4124 User’s Guide This product is recyclable. Dispose of it properly. Safety Warnings...
Page 8: Zyxel Limited Warranty
Any replacement will consist of a new or re-manufactured functionally equivalent product of equal or higher value, and will be solely at the discretion of ZyXEL. This warranty shall not apply if the product has been modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions.
Page 9: Customer Support
ES-4124 User’s Guide Customer Support Please have the following information ready when you contact customer support. • Product model and serial number. • Warranty Information. • Date that you received your device. • Brief description of the problem and the steps you took to solve it.
Page 10 ES-4124 User’s Guide METHOD SUPPORT E-MAIL TELEPHONE WEB SITE REGULAR MAIL SALES E-MAIL FTP SITE LOCATION support@zyxel.no +47-22-80-61-80 www.zyxel.no ZyXEL Communications A/S Nils Hansens vei 13 NORWAY sales@zyxel.no +47-22-80-61-81 0667 Oslo Norway info@pl.zyxel.com +48 (22) 333 8250 www.pl.zyxel.com ZyXEL Communications ul.
Page 11: Table Of Contents
ES-4124 User’s Guide Table of Contents Copyright ........................1 Certifications ......................2 Safety Warnings ....................... 4 ZyXEL Limited Warranty..................6 Customer Support....................7 Table of Contents ..................... 9 List of Figures ......................21 List of Tables ......................25 Preface ........................29 Chapter 1 Getting to Know Your Switch ................
Page 12 ES-4124 User’s Guide 3.1.2.1 Default Ethernet Settings ..............40 3.1.3 Mini-GBIC Slots ..................41 3.1.3.1 Transceiver Installation ..............41 3.1.3.2 Transceiver Removal ..............42 3.2 Rear Panel ......................42 3.2.1 Power Connector ..................43 3.2.2 External Backup Power Supply Connector ..........43 3.3 LEDs ......................44 Chapter 4 The Web Configurator....................
Page 13 ES-4124 User’s Guide 7.5 Switch Setup Screen ..................74 7.6 IP Setup ......................75 7.6.1 IP Interfaces .....................76 7.7 Port Setup ......................78 Chapter 8 VLAN ........................81 8.1 Introduction to IEEE 802.1Q Tagged VLANs ..........81 8.1.1 Forwarding Tagged and Untagged Frames ..........81 8.2 Automatic VLAN Registration ................82...
Page 14 ES-4124 User’s Guide 11.3 Configure Rapid Spanning Tree Protocol ............104 11.4 Rapid Spanning Tree Protocol Status ............107 11.5 Configure Multiple Rapid Spanning Tree Protocol ........108 11.6 Multiple Rapid Spanning Tree Protocol Status .........110 Chapter 12 Bandwidth Control ....................113 12.1 Bandwidth Control Overview ................113 12.1.1 CIR and PIR ..................113...
Page 15 ES-4124 User’s Guide Chapter 18 Classifier ....................... 135 18.1 About the Classifier and QoS .................135 18.2 Configuring the Classifier ................135 18.3 Viewing and Editing Classifier Configuration ..........138 18.4 Classifier Example ..................139 Chapter 19 Policy Rule......................141 19.1 Policy Rules Overview ..................141 19.1.1 DiffServ ....................141...
Page 16 ES-4124 User’s Guide 22.5.1 Types of MVR Ports ................164 22.5.2 MVR Modes ..................164 22.5.3 How MVR Works ..................165 22.6 General MVR Configuration ................165 22.7 MVR Group Configuration ................167 22.7.1 MVR Configuration Example ..............169 Chapter 23 Static Route ......................171 23.1 Configuring Static Routing ................171 Chapter 24 RIP ........................
Page 17 ES-4124 User’s Guide 27.4 Default DVMRP Timer Values ...............192 Chapter 28 IP Multicast ......................193 28.1 IP Multicast Overview ..................193 28.2 Configuring Multicast ..................193 Chapter 29 Differentiated Services ..................195 29.1 DiffServ Overview ..................195 29.1.1 DSCP and Per-Hop Behavior ..............195 29.1.2 DiffServ Network Example ..............195...
Page 18 ES-4124 User’s Guide Chapter 32 Maintenance ......................215 32.1 The Maintenance Screen ................215 32.2 Load Factory Default ..................216 32.3 Save Configuration ..................216 32.4 Reboot System ....................217 32.5 Firmware Upgrade ..................217 32.6 Restore a Configuration File ...............218 32.7 Backup a Configuration File ................218...
Page 19 ES-4124 User’s Guide Chapter 35 Syslog ........................237 35.1 Syslog Overview ....................237 35.2 Syslog Setup ....................237 35.3 Syslog Server Setup ..................238 Chapter 36 Cluster Management .................... 241 36.1 Clustering Management Status Overview .............241 36.2 Cluster Management Status ................242 36.2.1 Cluster Member Switch Management ..........243 36.2.1.1 Uploading Firmware to a Cluster Member Switch .....244...
Page 20 ES-4124 User’s Guide 42.2.1 The Console Port ..................259 42.2.1.1 Initial Screen ................260 42.3 The Login Screen ..................260 42.4 Command Syntax Conventions ..............260 42.5 Changing the Password .................261 42.6 Privilege Levels ....................261 42.7 Command Modes ...................262 42.8 Getting Help ....................263 42.8.1 List of Available Commands ..............264 42.9 Using Command History ................265...
Page 21 ES-4124 User’s Guide 44.4 no Command Examples .................309 44.4.1 Disable Commands ................309 44.4.2 Resetting Commands ................309 44.4.3 Re-enable commands ................309 44.4.4 Other Examples of no Commands ............310 44.4.4.1 no trunk ..................310 44.4.4.2 no port-access-authenticator ............311 44.4.4.3 no ssh ..................311 44.5 Queuing Method Commands .................312 44.6 Static Route Commands ................312...
Page 22 ES-4124 User’s Guide 46.2.3 GVRP Timer ..................329 46.2.4 Enable GVRP ..................329 46.2.5 Disable GVRP ..................329 46.3 Port VLAN Commands ...................329 46.3.1 Set Port VID ..................330 46.3.2 Set Acceptable Frame Type ..............330 46.3.3 Enable or Disable Port GVRP ...............330 46.3.4 Modify Static VLAN ................331 46.3.4.1 Modify a Static VLAN Table Example ..........331...
Page 23: List Of Figures
ES-4124 User’s Guide List of Figures Figure 1 Backbone Application ................31 Figure 2 Bridging Application ................32 Figure 3 High Performance Switched Workgroup Application ......33 Figure 4 Shared Server Using VLAN Example ............. 33 Figure 5 Attaching Rubber Feet ................35 Figure 6 Attaching the Mounting Brackets ............
Page 24 ES-4124 User’s Guide Figure 39 Port Based VLAN Setup (All Connected) ..........93 Figure 40 Port Based VLAN Setup (Port Isolation) ..........94 Figure 41 Static MAC Forwarding ................. 98 Figure 42 Filtering ....................99 Figure 43 MRSTP Network Example ..............103 Figure 44 Spanning Tree Protocol RSTP and MRSTP ..........
Page 25 ES-4124 User’s Guide Figure 82 OSPF Router Election Example ............. 177 Figure 83 OSPF Status ..................178 Figure 84 OSPF Configuration: Activating and General Settings ......180 Figure 85 OSPF Configuration: Area Setup ............181 Figure 86 OSPF Configuration: Summary Table ........... 182 Figure 87 OSPF Interface ..................
Page 26 ES-4124 User’s Guide Figure 125 Firmware Upgrade ................217 Figure 126 Restore Configuration ................. 218 Figure 127 Backup Configuration ................218 Figure 128 Access Control ..................221 Figure 129 SNMP Management Model ..............222 Figure 130 Access Control: SNMP ............... 224 Figure 131 Access Control: Logins ...............
Page 27: List Of Tables
ES-4124 User’s Guide List of Tables Table 1 Panel Connections ................... 39 Table 2 LEDs ......................44 Table 3 Navigation Panel Sub-links Overview ............49 Table 4 Web Configurator Screen Sub-links Details ..........50 Table 5 Navigation Panel Links ................50 Table 6 Status ......................
Page 28 ES-4124 User’s Guide Table 39 Port Authentication: 802.1x ..............128 Table 40 Port Security ................... 132 Table 41 Classifier ....................136 Table 42 Classifier: Summary Table ..............138 Table 43 Common Ethernet Types and Protocol Number ........138 Table 44 Common IP Ports ................... 139 Table 45 Policy ......................
Page 29 Table 92 Syslog Severity Levels ................237 Table 93 Syslog ..................... 238 Table 94 Syslog: Server Setup ................239 Table 95 ZyXEL Clustering Management Specifications ........241 Table 96 Cluster Management: Status ..............243 Table 97 FTP Upload to Cluster Member Example ..........245 Table 98 Clustering Management Configuration ...........
Page 30 ES-4124 User’s Guide Table 125 Subnet 2 ....................359 Table 126 Subnet 1 ....................359 Table 127 Subnet 2 ....................360 Table 128 Subnet 3 ....................360 Table 129 Subnet 4 ....................360 Table 130 Eight Subnets ..................361 Table 131 Class C Subnet Planning ..............361 Table 132 Class B Subnet Planning ..............
Page 31: Preface
• For brevity’s sake, we will use “e.g.,” as a shorthand for “for instance”, and “i.e.,” for “that is” or “in other words” throughout this manual. • The ES-4124 Ethernet Switch may be referred to as “the switch”, “the router” or “the device” in this User’s Guide.
Page 32: User Guide Feedback
User Guide Feedback Help us help you. E-mail all User Guide-related comments, questions or suggestions for improvement to techwriters@zyxel.com.tw or send regular mail to The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. Thank you.
Page 33: Getting To Know Your Switch
This chapter introduces the main features and applications of the switch. 1.1 Introduction The ES-4124 is a stand-alone layer 3 Ethernet switch with 24 10/100Mbps ports, two RJ-45 Gigabit ports for stacking and 2 GbE dual personality interfaces for uplink as well as a console port and a management port for local management.
Page 34: Bridging Example
ES-4124 User’s Guide 1.1.2 Bridging Example In this example application the switch connects different company departments (RD and Sales) to the corporate backbone. It can alleviate bandwidth contention and eliminate server and network bottlenecks. All users that need high bandwidth can connect to high-speed department servers via the switch.
Page 35: Ieee 802.1Q Vlan Application Examples
ES-4124 User’s Guide Figure 3 High Performance Switched Workgroup Application 1.1.4 IEEE 802.1Q VLAN Application Examples A VLAN (Virtual Local Area Network) allows a physical network to be partitioned into multiple logical networks. Stations on a logical network belong to one group. A station can belong to more than one group.
Page 36 ES-4124 User’s Guide Chapter 1 Getting to Know Your Switch...
Page 37: Hardware Installation And Connection
ES-4124 User’s Guide H A P T E R Hardware Installation and Connection This chapter shows you how to install and connect the switch. 2.1 Freestanding Installation 1 Make sure the switch is clean and dry. 2 Set the switch on a smooth, level surface strong enough to support the weight of the switch and the connected cables.
Page 38: Mounting The Switch On A Rack
ES-4124 User’s Guide 2.2 Mounting the Switch on a Rack This section lists the rack mounting requirements and precautions and describes the installation steps. 2.2.1 Rack-mounted Installation Requirements • Two mounting brackets. • Eight M3 flat head screws and a #2 Philips screwdriver.
Page 39: Figure 7 Mounting The Switch On A Rack
ES-4124 User’s Guide Figure 7 Mounting the Switch on a Rack 2 Using a #2 Philips screwdriver, install the M5 flat head screws through the mounting bracket holes into the rack. 3 Repeat steps to attach the second mounting bracket on the other side of the rack.
Page 40 ES-4124 User’s Guide Chapter 2 Hardware Installation and Connection...
Page 41: Chapter 3 Hardware Overview
ES-4124 User’s Guide H A P T E R Hardware Overview This chapter describes the front panel and rear panel of the switch and shows you how to make the hardware connections. 3.1 Panel Connections The figure below shows the front panel of the switch.
Page 42: Console Port
ES-4124 User’s Guide Table 1 Panel Connections (continued) CONNECTOR DESCRIPTION Console Port Only connect this port if you want to configure the switch using the command line interface (CLI) via the console port. Management Connect to a computer using an RJ-45 Ethernet cable for local configuration of the Port switch.
Page 43: Mini-Gbic Slots
ES-4124 User’s Guide 3.1.3 Mini-GBIC Slots These are slots for mini-GBIC (Gigabit Interface Converter) transceivers. A transceiver is a single unit that houses a transmitter and a receiver. The switch does not come with transceivers. You must use transceivers that comply with the SFP Transceiver MultiSource Agreement (MSA).
Page 44: Transceiver Removal
ES-4124 User’s Guide Figure 10 Installed Transceiver 3.1.3.2 Transceiver Removal Use the following steps to remove a mini GBIC transceiver (SFP module). 1 Open the transceiver’s latch (latch styles vary). Figure 11 Opening the Transceiver’s Latch Example 2 Pull the transceiver out of the slot.
Page 45: Power Connector
Make sure you are using the correct power source as shown on the panel. To connect the power to the ES-4124 AC unit, insert the female end of power cord to the power receptacle on the rear panel. Connect the other end of the supplied power cord to a 100~240V AC, 1.5A power outlet.
Page 46: Leds
ES-4124 User’s Guide 3.3 LEDs The following table describes the LEDs. Table 2 LEDs COLOR STATUS DESCRIPTION Green Blinking The system is receiving power from the backup power supply. The backup power supply is connected and active. The backup power supply is not ready or not active.
Page 47 ES-4124 User’s Guide Table 2 LEDs (continued) COLOR STATUS DESCRIPTION Green Blinking The system is transmitting/receiving to/from an Ethernet device. The port is connected at 10 Mbps. The port is not connected at 10 Mbps or to an Ethernet device.
Page 48 ES-4124 User’s Guide Chapter 3 Hardware Overview...
Page 49: The Web Configurator
ES-4124 User’s Guide H A P T E R The Web Configurator This section introduces the configuration and functions of the web configurator. 4.1 Introduction The web configurator is an HTML-based management interface that allows easy switch setup and management via Internet browser. Use Internet Explorer 6.0 and later or Netscape Navigator 7.0 and later versions.
Page 50: The Status Screen
ES-4124 User’s Guide 4 Click OK to view the first web configurator screen. 4.3 The Status Screen The Status screen is the first screen that displays when you access the web configurator. The following figure shows the navigating components of a web configurator screen.
Page 51: Table 3 Navigation Panel Sub-Links Overview
ES-4124 User’s Guide In the navigation panel, click a main link to reveal a list of submenu links. Table 3 Navigation Panel Sub-links Overview ADVANCED BASIC SETTING IP APPLICATION MANAGEMENT APPLICATION Chapter 4 The Web Configurator...
Page 52: Table 4 Web Configurator Screen Sub-Links Details
ES-4124 User’s Guide The following table lists the various web configurator screens within the sub-links. Table 4 Web Configurator Screen Sub-links Details ADVANCED BASIC SETTING IP APPLICATION MANAGEMENT APPLICATION System Info VLAN Static Routing Maintenance General Setup VLAN Status Firmware Upgrade...
Page 53 ES-4124 User’s Guide Table 5 Navigation Panel Links (continued) LINK DESCRIPTION Switch Setup This link takes you to a screen where you can set up global switch parameters such as VLAN type, MAC address learning, IGMP snooping, GARP and priority queues.
Page 54: Change Your Password
ES-4124 User’s Guide Table 5 Navigation Panel Links (continued) LINK DESCRIPTION IGMP This link takes you to a screen where you can configure the IGMP settings. DVMRP This link takes you to a screen where you can configure the DVMRP (Distance Vector Multicast Routing Protocol) settings.
Page 55: Saving Your Configuration
ES-4124 User’s Guide Figure 17 Change Administrator Login Password 4.4 Saving Your Configuration When you are done modifying the settings in a screen, click Apply to save your changes back to the run-time memory. Settings in the run-time memory are lost when the switch’s power is turned off.
Page 56: Resetting The Switch
ES-4124 User’s Guide Note: Be careful not to lock yourself and others out of the switch. If you do lock yourself out, try using out-of-band management (via the management port) to configure the switch. 4.6 Resetting the Switch If you lock yourself (and others) from the switch or forget the administrator password, you will need to reload the factory-default configuration file or reset the switch back to the factory defaults.
Page 57: Logging Out Of The Web Configurator
ES-4124 User’s Guide Figure 18 Resetting the Switch: Via the Console Port Bootbase Version: V0.8 | 03/14/2006 RAM:Size = 64 Mbytes FLASH: Intel 32M ZyNOS Version: V3.70(AIF.0)b1 | 06/17/2006 Press any key to enter debug mode within 3 seconds.....
Page 58 ES-4124 User’s Guide Chapter 4 The Web Configurator...
Page 59: Initial Setup Example
ES-4124 User’s Guide H A P T E R Initial Setup Example This chapter shows how to set up the switch for an example network. 5.1 Overview The following lists the configuration steps for the example network: • Configure an IP interface •...
Page 60: Configuring Dhcp Server Settings
ES-4124 User’s Guide 2 Open your web browser and enter 192.168.0.1 (the default MGMT port IP address) in the address bar to access the web configurator. See Section 4.2 on page 47 for more information. 3 Click Basic Setting and IP Setup in the navigation panel.
Page 61: Creating A Vlan
ES-4124 User’s Guide 5.1.3 Creating a VLAN VLANs confine broadcast frames to the VLAN group in which the port(s) belongs. You can do this with port-based VLAN or tagged static VLAN with fixed port members. In this example, you want to configure port 1 as a member of VLAN 2.
Page 62: Setting Port Vid
ES-4124 User’s Guide 3 Since the VLAN2 network is connected to port 1 on the switch, select Fixed to configure port 1 to be a permanent member of the VLAN only. 4 To ensure that VLAN-unaware devices (such as computers and hubs) can receive frames properly, clear the TX Tagging check box to set the switch to remove VLAN tags before sending.
Page 63 ES-4124 User’s Guide 2 Select Both in the Direction field to set the switch to broadcast and receive routing information. 3 In the Version field, select RIP-1 for the RIP packet format that is universally supported. 4 Click Apply to save your changes back to the run-time memory.
Page 64 ES-4124 User’s Guide Chapter 5 Initial Setup Example...
Page 65: System Status And Port Statistics
ES-4124 User’s Guide H A P T E R System Status and Port Statistics This chapter describes the system status (web configurator home page) and port details screens. 6.1 Overview The home screen of the web configurator displays a port statistical summary with links to each port showing statistical details.
Page 66: Status: Port Details
ES-4124 User’s Guide Table 6 Status (continued) LABEL DESCRIPTION State If STP (Spanning Tree Protocol) is enabled, this field displays the STP state of the port (see Section 11.1.3 on page 102 for more information). If STP is disabled, this field displays FORWARDING if the link is up, otherwise, it displays STOP.
Page 67: Figure 24 Status: Port Details
ES-4124 User’s Guide Figure 24 Status: Port Details The following table describes the labels in this screen. Table 7 Status: Port Details LABEL DESCRIPTION Port Info Port NO. This field displays the port number you are viewing. Name This field displays the name of the port.
Page 68 ES-4124 User’s Guide Table 7 Status: Port Details (continued) LABEL DESCRIPTION Tx KB/s This field shows the number kilobytes per second transmitted on this port. Rx KB/s This field shows the number of kilobytes per second received on this port.
Page 69 ES-4124 User’s Guide Table 7 Status: Port Details (continued) LABEL DESCRIPTION 128-255 This field shows the number of packets (including bad packets) received that were between 128 and 255 octets in length. 256-511 This field shows the number of packets (including bad packets) received that were between 256 and 511 octets in length.
Page 70 ES-4124 User’s Guide Chapter 6 System Status and Port Statistics...
Page 71: Chapter 7 Basic Setting
ES-4124 User’s Guide H A P T E R Basic Setting This chapter describes how to configure the System Info, General Setup, Switch Setup, IP Setup and Port Setup screens. 7.1 Overview The System Info screen displays general switch information (such as firmware version number) and hardware polling information (such as fan speeds).
Page 72: Figure 25 System Info
ES-4124 User’s Guide Figure 25 System Info The following table describes the labels in this screen. Table 8 System Info LABEL DESCRIPTION System Name This field displays the descriptive name of the switch for identification purposes. ZyNOS F/W This field displays the version number of the switch 's current firmware including the Version date created.
Page 73: General Setup
ES-4124 User’s Guide Table 8 System Info (continued) LABEL DESCRIPTION Fan Speed A properly functioning fan is an essential component (along with a sufficiently (RPM) ventilated, cool operating environment) in order for the device to stay within the temperature threshold. Each fan has a sensor that is capable of detecting and reporting if the fan speed falls below the threshold shown.
Page 74: Figure 26 General Setup
ES-4124 User’s Guide Figure 26 General Setup The following table describes the labels in this screen. Table 9 General Setup LABEL DESCRIPTION System Name Choose a descriptive name for identification purposes. This name consists of up to 64 printable characters; spaces are allowed.
Page 75: Introduction To Vlans
ES-4124 User’s Guide Table 9 General Setup (continued) LABEL DESCRIPTION Use Time Server Enter the time service protocol that your timeserver uses. Not all time servers when Bootup support all protocols, so you may have to use trial and error to find a protocol that works.
Page 76: Switch Setup Screen
ES-4124 User’s Guide Note: VLAN is unidirectional; it only governs outgoing traffic. Chapter 8 on page 81 for information on port-based and 802.1Q tagged VLANs. 7.5 Switch Setup Screen Click Basic Setting and then Switch Setup in the navigation panel to display the screen as shown.
Page 77: Ip Setup
ES-4124 User’s Guide Table 10 Switch Setup (continued) LABEL DESCRIPTION Join Timer Join Timer sets the duration of the Join Period timer for GVRP in milliseconds. Each port has a Join Period timer. The allowed Join Time range is between 100 and 65535 milliseconds;...
Page 78: Ip Interfaces
ES-4124 User’s Guide 7.6.1 IP Interfaces The switch needs an IP address for it to be managed over the network. The factory default IP address is 192.168.1.1. The subnet mask specifies the network number portion of an IP address. The factory default subnet mask is 255.255.255.0.
Page 79: Table 11 Ip Setup
ES-4124 User’s Guide The following table describes the labels in this screen. Table 11 IP Setup LABEL DESCRIPTION Default Enter the IP address of the default outgoing gateway in dotted decimal notation, for Gateway example 192.168.1.254. Domain Name DNS (Domain Name System) is for mapping a domain name to its corresponding IP Server address and vice versa.
Page 80: Port Setup
ES-4124 User’s Guide Table 11 IP Setup (continued) LABEL DESCRIPTION Delete Click Delete to remove the selected entry from the summary table. Note: Deleting all IP subnets locks you out from the switch. Cancel Click Cancel to clear the Delete check boxes.
Page 81 ES-4124 User’s Guide Table 12 Port Setup (continued) LABEL DESCRIPTION Name Enter a descriptive name that identifies this port. You can enter up to 64 alpha- numerical characters. Note: Due to space limitation, the port name may be truncated in some web configurator screens.
Page 82 ES-4124 User’s Guide Chapter 7 Basic Setting...
Page 83: Chapter 8 Vlan
ES-4124 User’s Guide H A P T E R VLAN The type of screen you see here depends on the VLAN Type you selected in the Switch Setup screen. This chapter shows you how to configure 802.1Q tagged and port-based VLANs.
Page 84: Automatic Vlan Registration
ES-4124 User’s Guide 8.2 Automatic VLAN Registration GARP and GVRP are the protocols used to automatically register VLAN membership across switches. 8.2.1 GARP GARP (Generic Attribute Registration Protocol) allows network switches to register and de- register attribute values with other GARP participants within a bridged LAN. GARP is a protocol that provides a generic mechanism for protocols that serve a more specific application, for example, GVRP.
Page 85: Port Vlan Trunking
ES-4124 User’s Guide Table 13 IEEE 802.1Q VLAN Terminology (continued) VLAN PARAMETER TERM DESCRIPTION VLAN Port Port VID This is the VLAN ID assigned to untagged frames that this port received. Acceptable Frame You may choose to accept both tagged and untagged...
Page 86: Static Vlan
ES-4124 User’s Guide Figure 31 Switch Setup: Select VLAN Type 8.5 Static VLAN Use a static VLAN to decide whether an incoming frame on a port should be • sent to a VLAN group as normal depending on its VLAN tag.
Page 87: Static Vlan Details
ES-4124 User’s Guide Table 14 VLAN: VLAN Status (continued) LABEL DESCRIPTION Status This field shows how this VLAN was added to the switch; dynamic - using GVRP, static - added as a permanent entry or other - added using Multicast VLAN Registration (MVR).
Page 88: Figure 34 Vlan: Static Vlan
ES-4124 User’s Guide Figure 34 VLAN: Static VLAN The following table describes the related labels in this screen. Table 16 VLAN: Static VLAN LABEL DESCRIPTION ACTIVE Select this check box to activate the VLAN settings. Name Enter a descriptive name for the VLAN group for identification purposes. This name consists of up to 64 printable characters;...
Page 89: Configure Vlan Port Settings
ES-4124 User’s Guide Table 16 VLAN: Static VLAN (continued) LABEL DESCRIPTION Click Add to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 90: Protocol Based Vlans
ES-4124 User’s Guide The following table describes the labels in this screen. Table 17 VLAN: VLAN Port Setting LABEL DESCRIPTION GVRP GVRP (GARP VLAN Registration Protocol) is a registration protocol that defines a way for switches to register necessary VLAN members on ports across the network.
Page 91: Configuring Protocol Based Vlan
ES-4124 User’s Guide Note: Protocol based VLAN applies to un-tagged packets and is applicable only when you use IEEE 802.1Q tagged VLAN. For example, port 1, 2, 3 and 4 belong to static VLAN 100, and port 4, 5, 6, 7 belong to static VLAN 120.
Page 92: Figure 37 Protocol Based Vlan
ES-4124 User’s Guide Figure 37 Protocol Based VLAN The following table describes the labels in this screen. Table 18 Protocol Based VLAN Setup LABEL DESCRIPTION Active Check this box to activate this protocol based VLAN. Port Type a port to be included in this protocol based VLAN.
Page 93: Create An Ip-Based Vlan Example
ES-4124 User’s Guide Table 18 Protocol Based VLAN Setup (continued) LABEL DESCRIPTION This field shows the VLAN ID of the port. Priority This field shows the priority which is assigned to frames belonging to this protocol based VLAN. Delete Click this to delete the protocol based VLANs which you marked for deletion.
Page 94: Port-Based Vlan Setup
ES-4124 User’s Guide 8.9 Port-based VLAN Setup Port-based VLANs are VLANs where the packet forwarding decision is based on the destination MAC address and its associated port. Port-based VLANs require allowed outgoing ports to be defined for each port. Therefore, if...
Page 95: Figure 39 Port Based Vlan Setup (All Connected)
ES-4124 User’s Guide Figure 39 Port Based VLAN Setup (All Connected) Chapter 8 VLAN...
Page 96: Figure 40 Port Based Vlan Setup (Port Isolation)
ES-4124 User’s Guide Figure 40 Port Based VLAN Setup (Port Isolation) Chapter 8 VLAN...
Page 97: Table 19 Port Based Vlan Setup
ES-4124 User’s Guide The following table describes the labels in this screen. Table 19 Port Based VLAN Setup LABEL DESCRIPTION Setting Wizard Choose All connected or Port isolation. All connected means all ports can communicate with each other, that is, there are no virtual LANs.
Page 98 ES-4124 User’s Guide Chapter 8 VLAN...
Page 99: Static Mac Forward Setup
ES-4124 User’s Guide H A P T E R Static MAC Forward Setup Use these screens to configure static MAC address forwarding. 9.1 Overview This chapter discusses how to configure forwarding rules based on MAC addresses of devices on your network.
Page 100: Figure 41 Static Mac Forwarding
ES-4124 User’s Guide Figure 41 Static MAC Forwarding The following table describes the labels in this screen. Table 20 Static MAC Forwarding LABEL DESCRIPTION Active Select this check box to activate your rule. You may temporarily deactivate a rule without deleting it by clearing this check box.
Page 101: Chapter 10 Filtering
ES-4124 User’s Guide H A P T E R Filtering This chapter discusses MAC address port filtering. 10.1 Configure a Filtering Rule Filtering means sifting traffic going through the switch based on the source and/or destination MAC addresses and VLAN group (ID).
Page 102 ES-4124 User’s Guide Table 21 FIltering (continued) LABEL DESCRIPTION Action Select Discard source to drop frame from the source MAC address (specified in the MAC field). The switch can still send frames to the MAC address. Select Discard destination to drop frames to the destination MAC address (specified in the MAC address).
Page 103: Spanning Tree Protocol
ES-4124 User’s Guide H A P T E R Spanning Tree Protocol The switch supports Spanning Tree Protocol (STP) and Rapid Spanning Tree Protocol (RSTP) as defined in the following standards. • IEEE 802.1D Spanning Tree Protocol • IEEE 802.1w Rapid Spanning Tree Protocol The switch also allows you to set up multiple STP configurations (or trees).
Page 104: How Stp Works
ES-4124 User’s Guide Table 22 STP Path Costs RECOMMENDED LINK SPEED RECOMMENDED VALUE ALLOWED RANGE RANGE Path Cost 16Mbps 40 to 400 1 to 65535 Path Cost 100Mbps 10 to 60 1 to 65535 Path Cost 1Gbps 3 to 10...
Page 105: Multiple Rstp
11.1.4 Multiple RSTP MRSTP (Multiple RSTP) is ZyXEL’s proprietary feature that is compatible with RSTP and STP. With MRSTP, you can have more than one spanning tree on your switch and assign port(s) to each tree. Each spanning tree operates independently with its own bridge information.
Page 106: Configure Rapid Spanning Tree Protocol
ES-4124 User’s Guide Figure 44 Spanning Tree Protocol RSTP and MRSTP The following table describes the labels in this screen. Table 24 Spanning Tree Protocol: Status LABEL DESCRIPTION RSTP This link takes you to the Rapid Spanning Tree Protocol configuration screen. See Section 11.3 on page...
Page 107: Figure 45 Rstp: Configuration
ES-4124 User’s Guide Figure 45 RSTP: Configuration Chapter 11 Spanning Tree Protocol...
Page 108: Table 25 Rstp: Configuration
ES-4124 User’s Guide The following table describes the labels in this screen. Table 25 RSTP: Configuration LABEL DESCRIPTION Status Click Status to display the RSTP Status screen (see Figure 46 on page 107). Active Select this check box to activate RSTP. Clear this checkbox to disable RSTP.
Page 109: Rapid Spanning Tree Protocol Status
ES-4124 User’s Guide Table 25 RSTP: Configuration (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 110: Configure Multiple Rapid Spanning Tree Protocol
ES-4124 User’s Guide Table 26 Rapid Spanning Tree Protocol: Status (continued) LABEL DESCRIPTION Forwarding Delay This is the time (in seconds) the root switch will wait before changing states (that (second) is, listening to learning to forwarding). Cost to Bridge This is the path cost from the root port on this switch to the root switch.
Page 111: Table 27 Mrstp: Configuration
ES-4124 User’s Guide The following table describes the labels in this screen. Table 27 MRSTP: Configuration LABEL DESCRIPTION Status Click Status to display the MRSTP Status screen (see Figure 46 on page 107). Tree This is a read only index number of the STP trees.
Page 112: Multiple Rapid Spanning Tree Protocol Status
ES-4124 User’s Guide Table 27 MRSTP: Configuration (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 113 ES-4124 User’s Guide Table 28 Spanning Tree Protocol: Status (continued) LABEL DESCRIPTION Max Age (second) This is the maximum time (in seconds) a switch can wait without receiving a configuration message before attempting to reconfigure. Forwarding Delay This is the time (in seconds) the root switch will wait before changing states (that (second) is, listening to learning to forwarding).
Page 114 ES-4124 User’s Guide Chapter 11 Spanning Tree Protocol...
Page 115: Chapter 12 Bandwidth Control
ES-4124 User’s Guide H A P T E R Bandwidth Control This chapter shows you how you can cap the maximum bandwidth using the Bandwidth Control screen. 12.1 Bandwidth Control Overview Bandwidth control means defining a maximum allowable bandwidth for incoming and/or out- going traffic flows on a port.
Page 116: Figure 49 Bandwidth Control
ES-4124 User’s Guide Figure 49 Bandwidth Control The following table describes the related labels in this screen. Table 29 Bandwidth Control LABEL DESCRIPTION Active Select this check box to enable bandwidth control on the switch. Port This field displays the port number.
Page 117: Broadcast Storm Control
ES-4124 User’s Guide H A P T E R Broadcast Storm Control This chapter introduces and shows you how to configure the broadcast storm control feature. 13.1 Broadcast Storm Control Setup Broadcast storm control limits the number of broadcast, multicast and destination lookup failure (DLF) packets the switch receives per second on the ports.
Page 118: Figure 50 Broadcast Storm Control
ES-4124 User’s Guide Figure 50 Broadcast Storm Control The following table describes the labels in this screen. Table 30 Broadcast Storm Control LABEL DESCRIPTION Active Select this check box to enable traffic storm control on the switch. Clear this check box to disable this feature.
Page 119: Chapter 14 Mirroring
ES-4124 User’s Guide H A P T E R Mirroring This chapter discusses port mirroring setup screens. 14.1 Port Mirroring Setup Port mirroring allows you to copy a traffic flow to a monitor port (the port you copy the traffic to) in order that you can examine the traffic from the monitor port without interference.
Page 120: Figure 51 Mirroring
ES-4124 User’s Guide Figure 51 Mirroring The following table describes the labels in this screen. Table 31 Mirroring LABEL DESCRIPTION Active Select this check box to activate port mirroring on the switch. Clear this check box to disable the feature.
Page 121: Chapter 15 Link Aggregation
ES-4124 User’s Guide H A P T E R Link Aggregation This chapter shows you how to logically aggregate physical links to form one logical, higher- bandwidth link. 15.1 Link Aggregation Overview Link aggregation (trunking) is the grouping of physical ports into one logical higher-capacity link.
Page 122: Link Aggregation Id
ES-4124 User’s Guide 15.2.1 Link Aggregation ID LACP aggregation ID consists of the following information Table 32 Link Aggregation ID: Local Switch SYSTEM PRIORITY MAC ADDRESS PORT PRIORITY PORT NUMBER 0000 00-00-00-00-00 0000 0000 Table 33 Link Aggregation ID: Peer Switch...
Page 123: Link Aggregation Setup
ES-4124 User’s Guide Figure 52 Link Aggregation Control Protocol Status The following table describes the labels in this screen. Table 34 Link Aggregation Control Protocol Status LABEL DESCRIPTION Index This field displays the trunk ID to identify a trunk group, that is, one logical link containing multiple ports.
Page 124: Figure 53 Link Aggregation Control Protocol: Configuration
ES-4124 User’s Guide Figure 53 Link Aggregation Control Protocol: Configuration The following table describes the labels in this screen. Table 35 Link Aggregation Control Protocol: Configuration LABEL DESCRIPTION Link Aggregation Control Protocol Active Select this checkbox to enable Link Aggregation Control Protocol (LACP).
Page 125 ES-4124 User’s Guide Table 35 Link Aggregation Control Protocol: Configuration (continued) LABEL DESCRIPTION Port This field displays the port number. Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 126 ES-4124 User’s Guide Chapter 15 Link Aggregation...
Page 127: Chapter 16 Port Authentication
ES-4124 User’s Guide H A P T E R Port Authentication This chapter describes the 802.1x authentication method and RADIUS server connection setup. See Section 44.9 on page 315 for information on how to use the commands to configure additional Radius server settings as well as multiple Radius server configuration.
Page 128: Tunnel Protocol Attribute
ES-4124 User’s Guide Note: Refer to the documentation that comes with your RADIUS server on how to configure a VSA. The following table describes the VSAs supported on the switch. Table 36 Supported VSA FUNCTION ATTRIBUTE Ingress Bandwidth Vendor-Id = 890...
Page 129: Configuring Radius Server Settings
ES-4124 User’s Guide Click Advanced Application, Port Authentication in the navigation panel to display the screen as shown. Figure 55 Port Authentication 16.2.1 Configuring RADIUS Server Settings Use this screen to configure your RADIUS server settings. See Section 16.1.1 on page 125 more information on RADIUS servers.
Page 130: Activate Ieee 802.1X Security
ES-4124 User’s Guide 16.2.2 Activate IEEE 802.1x Security Use this screen to activate IEEE 802.1x security. From the Port Authentication screen, display the configuration screen as shown. Figure 57 Port Authentication: 802.1x The following table describes the labels in this screen.
Page 131 ES-4124 User’s Guide Table 39 Port Authentication: 802.1x (continued) LABEL DESCRIPTION Reauthentication Specify how often a client has to re-enter his or her username and password to stay Timer connected to the port. Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses...
Page 132 ES-4124 User’s Guide Chapter 16 Port Authentication...
Page 133: Port Security
ES-4124 User’s Guide H A P T E R Port Security This chapter shows you how to set up port security. 17.1 About Port Security Port security allows only packets with dynamically learned MAC addresses and/or configured static MAC addresses to pass through a port on the switch. The switch can learn up to 16K MAC addresses in total with no limit on individual ports other than the sum cannot exceed 16K.
Page 134: Figure 58 Port Security
ES-4124 User’s Guide Figure 58 Port Security The following table describes the labels in this screen. Table 40 Port Security LABEL DESCRIPTION Active Select this option to enable port security on the switch. Port This field displays a port number.
Page 135 ES-4124 User’s Guide Table 40 Port Security (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 136: Table 40 Port Security
ES-4124 User’s Guide Chapter 17 Port Security...
Page 137: Chapter 18 Classifier
ES-4124 User’s Guide H A P T E R Classifier This chapter introduces and shows you how to configure the packet classifier on the switch. 18.1 About the Classifier and QoS Quality of Service (QoS) refers to both a network's ability to deliver data with minimum delay, and the networking methods used to control the use of bandwidth.
Page 138: Figure 59 Classifier
ES-4124 User’s Guide Figure 59 Classifier The following table describes the labels in this screen. Table 41 Classifier LABEL DESCRIPTION Active Select this option to enable this rule. Name Enter a descriptive name for this rule for identifying purposes. Packet Specify the format of the packet.
Page 139 ES-4124 User’s Guide Table 41 Classifier (continued) LABEL DESCRIPTION Priority Select Any to classify traffic from any priority level or select the second option and specify a priority level in the field provided. Ethernet Select an Ethernet type or select Other and enter the Ethernet type number in Type hexadecimal value.
Page 140: Viewing And Editing Classifier Configuration
ES-4124 User’s Guide Table 41 Classifier (continued) LABEL DESCRIPTION Cancel Click Cancel to reset the fields back to your previous configuration. Clear Click Clear to set the above fields back to the factory defaults. 18.3 Viewing and Editing Classifier Configuration To view a summary of the classifier configuration, scroll down to the summary table at the bottom of the Classifier screen.
Page 141: Classifier Example
ES-4124 User’s Guide Table 43 Common Ethernet Types and Protocol Number ETHERNET TYPE PROTOCOL NUMBER X.25 Level 3 0805 XNS Compat 0807 Banyan Systems 0BAD BBN Simnet 5208 IBM SNA 80D5 AppleTalk AARP 80F3 Some of the most common IP ports are:...
Page 142: Figure 61 Classifier: Example
ES-4124 User’s Guide Figure 61 Classifier: Example Chapter 18 Classifier...
Page 143: Chapter 19 Policy Rule
ES-4124 User’s Guide H A P T E R Policy Rule This chapter shows you how to configure policy rules. 19.1 Policy Rules Overview A classifier distinguishes traffic into flows based on the configured criteria (refer to Chapter 18 on page 135 for more information).
Page 144: Configuring Policy Rules
ES-4124 User’s Guide 19.2 Configuring Policy Rules You must first configure a classifier in the Classifier screen. Refer to Section 18.2 on page for more information. Click Advanced Applications and then Policy Rule in the navigation panel to display the screen as shown.
Page 145: Figure 62 Policy
ES-4124 User’s Guide Figure 62 Policy The following table describes the labels in this screen. Table 45 Policy LABEL DESCRIPTION Active Select this option to enable the policy. Name Enter a descriptive name for identification purposes. Classifier(s) This field displays the active classifier(s) you configure in the Classifier screen.
Page 146 ES-4124 User’s Guide Table 45 Policy (continued) LABEL DESCRIPTION Parameters Set the fields below for this policy. You only have to set the field(s) that is related to the action(s) you configure in the Action field. General VLAN ID Specify a VLAN ID number.
Page 147: Viewing And Editing Policy Configuration
ES-4124 User’s Guide Table 45 Policy (continued) LABEL DESCRIPTION Outgoing Select Send the packet to the mirror port to send the packet to the mirror port. Select Send the packet to the egress port to send the packet to the egress port.
Page 148: Policy Example
ES-4124 User’s Guide Table 46 Policy: Summary Table (continued) LABEL DESCRIPTION Delete Click Delete to remove the selected entry from the summary table. Cancel Click Cancel to clear the Delete check boxes. 19.4 Policy Example The figure below shows an example Policy screen where you configure a policy to limit...
Page 149: Figure 64 Policy Example
ES-4124 User’s Guide Figure 64 Policy Example Chapter 19 Policy Rule...
Page 150 ES-4124 User’s Guide Chapter 19 Policy Rule...
Page 151: Chapter 20 Queuing Method
ES-4124 User’s Guide H A P T E R Queuing Method This chapter introduces the queuing methods supported. 20.1 Queuing Method Overview Queuing is used to help solve performance degradation when there is network congestion. Use the Queuing Method screen to configure queuing algorithms for outgoing traffic. See also Priority Queue Assignment in Switch Setup and 802.1p Priority in Port Setup for related...
Page 152: Weighted Round Robin Scheduling (Wrr)
ES-4124 User’s Guide 20.1.3 Weighted Round Robin Scheduling (WRR) Round Robin Scheduling services queues on a rotating basis and is activated only when a port has more traffic than it can handle. A queue is a given an amount of bandwidth irrespective of the incoming traffic on that port.
Page 153: Figure 65 Queuing Method
ES-4124 User’s Guide Figure 65 Queuing Method Chapter 20 Queuing Method...
Page 154: Table 47 Queuing Method
ES-4124 User’s Guide The following table describes the labels in this screen. Table 47 Queuing Method LABEL DESCRIPTION Method Select SPQ (Strictly Priority Queuing), WFQ (Weighted Fair Queuing) or WRR (Weighted Round Robin). Strictly Priority services queues based on priority only. When the highest priority queue empties, traffic on the next highest-priority queue begins.
Page 155: Chapter 21 Vlan Stacking
ES-4124 User’s Guide H A P T E R VLAN Stacking This chapter shows you how to configure VLAN stacking on your switch. See the chapter on VLANs for more background information on Virtual LAN 21.1 VLAN Stacking Overview A service provider can use VLAN stacking to allow it to distinguish multiple customers VLANs, even those with the same (customer-assigned) VLAN ID, within its network.
Page 156: Vlan Stacking Port Roles
ES-4124 User’s Guide Figure 66 VLAN Stacking Example 21.2 VLAN Stacking Port Roles Each port can have three VLAN stacking “roles”, Normal, Access Port and Tunnel (the latter is for Gigabit ports only). • Select Normal for “regular” (non-VLAN stacking) IEEE 802.1Q frame switching.
Page 157: Frame Format
ES-4124 User’s Guide Type is a standard Ethernet type code identifying the frame and indicates that whether the frame carries IEEE 802.1Q tag information. SP TPID (Service Provider Tag Protocol Identifier) is the service provider VLAN stacking tag type. Many vendors use 0x8100 or 0x9100.
Page 158: Configuring Vlan Stacking
ES-4124 User’s Guide 21.4 Configuring VLAN Stacking Click Advanced Applications and then VLAN Stacking to display the screen as shown. Figure 67 VLAN Stacking The following table describes the labels in this screen. Table 51 VLAN Stacking LABEL DESCRIPTION Active Select this checkbox to enable VLAN stacking on the switch.
Page 159 ES-4124 User’s Guide Table 51 VLAN Stacking (continued) LABEL DESCRIPTION Role Select Normal to have the switch ignore frames received (or transmitted) on this port with VLAN stacking tags. Anything you configure in SPVID and Priority are ignored. Select Access Port to have the switch add the SP TPID tag to all incoming frames received on this port.
Page 160: Table 51 Vlan Stacking
ES-4124 User’s Guide Chapter 21 VLAN Stacking...
Page 161: Chapter 22 Multicast
ES-4124 User’s Guide H A P T E R Multicast This chapter shows you how to configure various multicast features. 22.1 Multicast Overview Traditionally, IP packets are transmitted in one of either two ways - Unicast (1 sender to 1 recipient) or Broadcast (1 sender to everybody on the network).
Page 162: Multicast Status
ES-4124 User’s Guide The switch forwards multicast traffic destined for multicast groups (that it has learned from IGMP snooping or that you have manually configured) to ports that are members of that group. IGMP snooping generates no additional network traffic, allowing you to significantly reduce multicast traffic passing through your switch.
Page 163: Figure 69 Multicast: Setting
ES-4124 User’s Guide Figure 69 Multicast: Setting The following table describes the labels in this screen. Table 53 Multicast Setting LABEL DESCRIPTION IGMP Snooping Use these settings to configure IGMP Snooping. Active Select Active to enable IGMP Snooping to forward group multicast traffic only to ports that are members of that group.
Page 164 ES-4124 User’s Guide Table 53 Multicast Setting (continued) LABEL DESCRIPTION Reserved Multicast addresses (224.0.0.0 to 224.0.0.255) are reserved for the local scope. Multicast Group For examples, 224.0.0.1 is for all hosts in this subnet, 224.0.0.2 is for all multicast routers in this subnet, etc. A router will not forward a packet with the destination IP address within this range.
Page 165: Igmp Filtering Profile
ES-4124 User’s Guide 22.4 IGMP Filtering Profile IGMP filter profiles allow you to control access to IGMP multicast groups. This allows you to have a service available to a specific IGMP multicast group. You can configure an IGMP filter profile for an IGMP multicast group that has access to a service (like a SIP server for example).
Page 166: Mvr Overview
ES-4124 User’s Guide Table 54 Multicast: IGMP Filtering Profile (continued) LABEL DESCRIPTION Delete To delete the profile(s) and all the accompanying rules, select the profile(s) that you want to remove in the Delete Profile column, then click the Delete button.
Page 167: How Mvr Works
ES-4124 User’s Guide In dynamic mode, the switch sends IGMP leave and join reports to the other multicast devices (such as multicast routers or servers) in the multicast VLAN. This allows the multicast devices to update the multicast forwarding table to forward or not forward multicast traffic to the receiver ports.
Page 168: Figure 73 Multicast: Setting: Mvr
ES-4124 User’s Guide Note: You can create up to three multicast VLANs and up to 256 multicast rules on the switch. Your switch automatically creates a static VLAN (with the same VID) when you create a multicast VLAN in this screen.
Page 169: Mvr Group Configuration
ES-4124 User’s Guide Table 55 MVR (continued) LABEL DESCRIPTION Port This field displays the port number on the switch. Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 170: Figure 74 Mvr: Group Configuration
ES-4124 User’s Guide Figure 74 MVR: Group Configuration The following table describes the labels in this screen. Table 56 MVR: Group Configuration LABEL DESCRIPTION Multicast Select a multicast VLAN ID (that you configured in the MVR screen) from the drop- VLAN ID down list box.
Page 171: Mvr Configuration Example
ES-4124 User’s Guide 22.7.1 MVR Configuration Example The following figure shows a network example where ports 1, 2 and 3 on the switch belong to VLAN 1. In addition, port 7 belongs to the multicast group with VID 200 to receive multicast traffic (the News and Movie channels) from the remote streaming media server, S.
Page 172: Figure 77 Mvr Group Configuration Example
ES-4124 User’s Guide Figure 77 MVR Group Configuration Example Figure 78 MVR Group Configuration Example Chapter 22 Multicast...
Page 173: Chapter 23 Static Route
ES-4124 User’s Guide H A P T E R Static Route This chapter shows you how to configure static routes. 23.1 Configuring Static Routing Static routes tell the switch how to forward IP traffic when you configure the TCP/IP parameters manually.
Page 174 ES-4124 User’s Guide Table 57 Static Routing (continued) LABEL DESCRIPTION Metric The metric represents the “cost” of transmission for routing purposes. IP routing uses hop count as the measurement of cost, with a minimum of 1 for directly connected networks. Enter a number that approximates the cost for this link. The number need not be precise, but it must be between 1 and 15.
Page 175: Chapter 24 Rip
ES-4124 User’s Guide H A P T E R This chapter shows you how to configure RIP (Routing Information Protocol). 24.1 RIP Overview RIP (Routing Information Protocol) allows a routing device to exchange routing information with other routers. The Direction field controls the sending and receiving of RIP packets.
Page 176 ES-4124 User’s Guide Figure 80 RIP The following table describes the labels in this screen. Table 58 RIP LABEL DESCRIPTION Active Select this check box to enable RIP on the switch. Index This field displays the index number of an IP interface.
Page 177: Chapter 25 Ospf
ES-4124 User’s Guide H A P T E R OSPF This chapter describes the OSPF (Open Shortest Path First) routing protocol and shows you how to configure OSPF. 25.1 OSPF Overview OSPF (Open Shortest Path First) is a link-state protocol designed to distribute routing information within an autonomous system (AS).
Page 178: How Ospf Works
ES-4124 User’s Guide The following figure depicts an OSPF network example. The backbone is area 0 with a backbone router. The internal routers are in area 1 and 2. The area border routers connect area 1 and 2 to the backbone.
Page 179: Configuring Ospf
ES-4124 User’s Guide In most cases the default DR/BDR election is fine, but in some situations it must be controlled. In the following figure only router A has direct connectivity with all the other routers on the network segment. Routers B and C do not have a direct connection with each other. Therefore they should not be allowed to become DR or BDR.
Page 180: Figure 83 Ospf Status
ES-4124 User’s Guide Figure 83 OSPF Status The following table describes the labels in this screen. Table 61 OSPF Status LABEL DESCRIPTION OSPF This field displays whether OSPF is activated (Running) or not (Down). Interface The text box displays the OSPF status of the interface(s) on the switch.
Page 181: Ospf Configuration
ES-4124 User’s Guide Table 62 OSPF Status: Common Output Fields (continued) FIELD DESCRIPTION Area This field displays the area ID. Router ID This field displays the unique ID of the switch. Transmit Delay This field displays the transmission delay in seconds.
Page 182: Figure 84 Ospf Configuration: Activating And General Settings
ES-4124 User’s Guide Figure 84 OSPF Configuration: Activating and General Settings The follow table describes the related labels in this screen. Table 63 OSPF Configuration: Activating and General Settings LABEL DESCRIPTION Active OSPF is disabled by default. Select this option to enable it.
Page 183: Configure Ospf Areas
ES-4124 User’s Guide 25.4 Configure OSPF Areas To ensure that the switch receives only routing information from a trusted layer 3 devices, activate authentication. The OSPF supports three authentication methods: • None – no authentication is used. • Simple – authenticate link state updates using an 8 printable ASCII character password.
Page 184: View Ospf Area Information Table
ES-4124 User’s Guide Table 64 OSPF Configuration: Area Setup (continued) LABEL DESCRIPTION Authentication Select an authentication method (Simple or MD5) to activate authentication. Select None (default) to disable authentication. Usually interface(s) and virtual interface(s) should use the same authentication method as the associated area.
Page 185: Configuring Ospf Interfaces
ES-4124 User’s Guide 25.5 Configuring OSPF Interfaces To configure an OSPF interface, first create an IP routing domain in the IP Setup screen (see Section 7.6 on page 75 for more information). Once you create an IP routing domain, an OSPF interface entry is automatically created.
Page 186: Ospf Virtual-Links
ES-4124 User’s Guide Table 66 OSPF Interface (continued) LABEL DESCRIPTION When you select Simple in the Authentication field, enter a password eight-character long. Characters after the eighth character will be ignored. When you select MD5 in the Authentication field, enter a password 16-character long.
Page 187: Figure 88 Ospf Virtual Link
ES-4124 User’s Guide Figure 88 OSPF Virtual Link The following table describes the related labels in this screen. Table 67 OSPF Virtual Link LABEL DESCRIPTION Name Enter a descriptive name (up to 32 printable ASCII characters) for identification purposes. Area ID Select the area ID (that uses the format of an IP address in dotted decimal notation) of an area to associate the interface to that area.
Page 188 ES-4124 User’s Guide Table 67 OSPF Virtual Link (continued) LABEL DESCRIPTION Clear Click Clear to set the above fields back to the factory defaults. Index This field displays an index number of an entry. Name This field displays a descriptive name of a virtual link.
Page 189: Chapter 26 Igmp
ES-4124 User’s Guide H A P T E R IGMP This chapter shows you how to configure IGMP. 26.1 IGMP Overview IGMP (Internet Group Multicast Protocol) is a session-layer protocol used to establish membership in a multicast group - it is not used to carry user data. Refer to RFC 1112 and RFC 2236 for information on IGMP versions 1 and 2 respectively.
Page 190: Table 68 Igmp
ES-4124 User’s Guide Table 68 IGMP (continued) LABEL DESCRIPTION Network This field displays the IP domain configured on the switch. Refer to Section 7.6 on page 75 for more information on configuring IP domains. Version Select an IGMP version from the drop-down list box. Choices are IGMP-v1, IGMP-v2 and None.
Page 191: Chapter 27 Dvmrp
ES-4124 User’s Guide H A P T E R DVMRP This chapter introduces DVMRP and tells you how to configure it. 27.1 DVMRP Overview DVMRP (Distance Vector Multicast Routing Protocol) is a protocol used for routing multicast data within an autonomous system (AS). This DVMRP implementation is based on draft-ietf- idmr-dvmrp-v3-10.
Page 192: Dvmrp Terminology
ES-4124 User’s Guide Figure 90 How DVMRP Works 27.2.1 DVMRP Terminology DVMRP probes are used to discover other DVMRP Neighbors on a network. DVMRP reports are used to exchange DVMRP source routing information. These packets are used to build the DVMRP multicast routing table that is used to build source trees and also perform Reverse Path Forwarding (RPF) checks on incoming multicast packets.
Page 193: Dvmrp Configuration Error Messages
ES-4124 User’s Guide Table 69 DVMRP LABEL DESCRIPTION Active Select Active to enable DVMRP on the switch. You should do this if you want the switch to act as a multicast router. Threshold Threshold is the maximum time to live (TTL) value. TTL is used to limit the scope of multicasting.
Page 194: Default Dvmrp Timer Values
ES-4124 User’s Guide Figure 94 DVMRP: Duplicate VID Error Message 27.4 Default DVMRP Timer Values The following are some default DVMRP timer values. These may be changed using line commands. Please see the commands chapter later in this User's Guide.
Page 195: Chapter 28 Ip Multicast
ES-4124 User’s Guide H A P T E R IP Multicast This chapter shows you how to configure the IP Multicast screen. 28.1 IP Multicast Overview Traditionally, IP packets are transmitted in one of either two ways - Unicast (one sender to one recipient) or Broadcast (one sender to everybody on the network).
Page 196: Table 71 Ip Multicast
ES-4124 User’s Guide Table 71 IP Multicast LABEL DESCRIPTION Port This read-only field displays the port number. Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 197: Chapter 29 Differentiated Services
ES-4124 User’s Guide H A P T E R Differentiated Services This chapter shows you how to configure Differentiated Services (DiffServ) on the switch. 29.1 DiffServ Overview Quality of Service (QoS) is used to prioritize source-to-destination traffic flows. All packets in the flow are given the same priority.
Page 198: Activating Diffserv
ES-4124 User’s Guide Figure 97 DiffServ Network Example Switch A marks traffic flowing into the network based on the configured marking rules. Intermediary network devices 1 and 2 allocate network resources (such as bandwidth) by mapping the DSCP values and the associated policies.
Page 199: Dscp-To-Ieee802.1P Priority Settings
ES-4124 User’s Guide Table 72 DiffServ (continued) LABEL DESCRIPTION Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 200: Figure 99 Diffserv: Dscp Setting
ES-4124 User’s Guide Figure 99 DiffServ: DSCP Setting The following table describes the labels in this screen. Table 74 DiffServ: DSCP Setting LABEL DESCRIPTION 0 … 63 This is the DSCP classification identification number. To set the IEEE802.1p priority mapping, select the priority level from the drop-down list box.
Page 201: Chapter 30 Dhcp
ES-4124 User’s Guide H A P T E R DHCP This chapter shows you how to configure the DHCP feature. 30.1 DHCP Overview DHCP (Dynamic Host Configuration Protocol RFC 2131 and RFC 2132) allows individual computers to obtain TCP/IP configuration at start-up from a server. You can configure the switch as a DHCP server or disable it.
Page 202: Configuring Dhcp Server
ES-4124 User’s Guide Figure 100 DHCP: DHCP Server Status The following table describes the labels in this screen. Table 75 DHCP: DHCP Server Status LABEL DESCRIPTION Index This is the index number. This field displays the ID number of the VLAN group to which this DHCP settings apply.
Page 203: Figure 101 Dhcp: Server
ES-4124 User’s Guide Figure 101 DHCP: Server The following table describes the labels in this screen. Table 76 DHCP: Server LABEL DESCRIPTION Enter the ID number of the VLAN group to which this DHCP settings apply. Client IP Pool Specify the first of the contiguous addresses in the IP address pool.
Page 204: Dhcp Server Configuration Example
ES-4124 User’s Guide 30.3.1 DHCP Server Configuration Example The follow figure shows a network example where the switch is used to assign network information to the DHCP clients in the RD and Sales network. Figure 102 DHCP Server Network Example In the DHCP Server screen, configure two DHCP client IP address pools for the two networks.
Page 205: Dhcp Relay Agent Information
ES-4124 User’s Guide 30.4.1 DHCP Relay Agent Information The switch can add information to client DHCP requests that it relays to a DHCP server. This helps provide authentication about the source of the requests. You can also specify additional information for the switch to add to the client DHCP requests that it relays to the DHCP server.
Page 206: Dhcp Relay Configuration Example
ES-4124 User’s Guide Table 77 DHCP: Relay (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 207: Chapter 31 Vrrp
ES-4124 User’s Guide H A P T E R VRRP This chapter shows you how to configure and monitor the Virtual Router Redundancy Protocol (VRRP) on the switch. 31.1 VRRP Overview Each host on a network is configured to send packets to a statically configured default gateway (this switch).
Page 208: Vrrp Status
ES-4124 User’s Guide Figure 107 VRRP: Example 1 172.21.1.1 172.21.1.100 172.21.1.10 If switch A (the master router) is unavailable, switch B takes over. Traffic is then processed by switch B. 31.2 VRRP Status Click IP Application, VRRP in the navigation panel to display the VRRP Status screen as shown next.
Page 209: Vrrp Configuration
ES-4124 User’s Guide Figure 108 VRRP Status The following table describes the labels in this screen. Table 78 VRRP Status LABEL DESCRIPTION Index This field displays the index number of a rule. Network This field displays the IP address and the subnet mask bits of an IP routing domain that is associated to a virtual router.
Page 210: Figure 109 Vrrp Configuration: Ip Interface
ES-4124 User’s Guide Click IP Application, VRRP and click the Configuration link to display the VRRP Configuration screen as shown next. Note: You can only configure VRRP on interfaces with unique VLAN IDs. Routing domains with the same VLAN ID are not displayed in the table indicated.
Page 211: Vrrp Parameters
ES-4124 User’s Guide Table 79 VRRP Configuration: IP Interface (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 212: Configuring Vrrp Parameters
ES-4124 User’s Guide Figure 110 VRRP Configuration: VRRP Parameters The following table describes the labels in this screen. Table 80 VRRP Configuration: VRRP Parameters LABEL DESCRIPTION Active Select this option to enable this VRRP entry. Name Enter a descriptive name (up to 32 printable ASCII characters) for identification purposes.
Page 213: Vrrp Configuration Examples
ES-4124 User’s Guide Figure 111 VRRP Configuration: Summary The following table describes the labels in this screen. Table 81 VRRP Configuring: VRRP Parameters LABEL DESCRIPTION Index This field displays the index number of an entry. Active This field shows whether a VRRP entry is enabled (Yes) or disabled (No).
Page 214: Figure 112 Vrrp Configuration Example: One Virtual Router Network
ES-4124 User’s Guide Figure 112 VRRP Configuration Example: One Virtual Router Network 172.21.1.1 172.21.1.100 172.21.1.10 You want to set switch A as the master router. Configure the VRRP parameters in the VRRP Configuration screens on the switches as shown in the figures below.
Page 215: Two Subnets Example
ES-4124 User’s Guide Figure 115 VRRP Example 1: VRRP Status on Switch A Figure 116 VRRP Example 1: VRRP Status on Switch B 31.4.2 Two Subnets Example The following figure depicts an example in which two switches share the network traffic.
Page 216: Figure 118 Vrrp Example 2: Vrrp Parameter Settings For Vr2 On Switch A
ES-4124 User’s Guide Figure 118 VRRP Example 2: VRRP Parameter Settings for VR2 on Switch A Figure 119 VRRP Example 2: VRRP Parameter Settings for VR2 on Switch B After configuring and saving the VRRP configuration, the VRRP Status screens for both switches are shown next.
Page 217: Chapter 32 Maintenance
ES-4124 User’s Guide H A P T E R Maintenance This chapter explains how to configure the maintenance screens that let you maintain the firmware and configuration files. 32.1 The Maintenance Screen Use this screen to manage firmware and your configuration files. Click Management, Maintenance in the navigation panel to open the following screen.
Page 218: Load Factory Default
ES-4124 User’s Guide Table 82 Maintenance (continued) LABEL DESCRIPTION Save Click Config 1 to save the current configuration settings to Configuration 1 on the Configuration switch. Click Config 2 to save the current configuration settings to Configuration 2 on the switch.
Page 219: Reboot System
ES-4124 User’s Guide 32.4 Reboot System Reboot System allows you to restart the switch without physically turning the power off. It also allows you to load configuration one (Config 1) or configuration two (Config 2) when you reboot. Follow the steps below to reboot the switch.
Page 220: Restore A Configuration File
ES-4124 User’s Guide 32.6 Restore a Configuration File Restore a previously saved configuration from your computer to the switch using the Restore Configuration screen. Figure 126 Restore Configuration Type the path and file name of the configuration file you wish to restore in the File Path text box or click Browse to display the Choose File screen (below) from which you can locate it.
Page 221: Ftp Command Line
ZyNOS (ZyXEL Network Operating System sometimes referred to as the “ras” file) is the system firmware and has a “bin” filename extension.
Page 222: Ftp Command Line Procedure
ES-4124 User’s Guide 32.8.2 FTP Command Line Procedure 1 Launch the FTP client on your computer. 2 Enter , followed by a space and the IP address of your switch. open 3 Press [ENTER] when prompted for a username. 4 Enter your password as requested (the default is “1234”).
Page 223: Chapter 33 Access Control
ES-4124 User’s Guide H A P T E R Access Control This chapter describes how to control access to the switch. 33.1 Access Control Overview A console port and FTP are allowed one session each, Telnet and SSH share four sessions, up to five Web sessions (five different usernames and passwords) and/or limitless SNMP access control sessions are allowed.
Page 224: About Snmp
ES-4124 User’s Guide 33.3 About SNMP Simple Network Management Protocol (SNMP) is an application layer protocol used to manage and monitor TCP/IP-based devices. SNMP is used to exchange management information between the network management system (NMS) and a network element (NE). A manager station can manage and monitor the switch through the network via SNMP version one (SNMPv1) and/or SNMP version 2c.
Page 225: Supported Mibs
ES-4124 User’s Guide Table 85 SNMP Commands COMMAND DESCRIPTION Allows the manager to set values for object variables within an agent. Trap Used by the agent to inform the manager of some events. 33.3.1 Supported MIBs MIBs let administrators collect statistics and monitor status and performance.
Page 226: Configuring Snmp
ES-4124 User’s Guide 33.3.3 Configuring SNMP From the Access Control screen, display the SNMP screen. You can click Access Control to go back to the Access Control screen. Figure 130 Access Control: SNMP The following table describes the labels in this screen.
Page 227: Figure 131 Access Control: Logins
ES-4124 User’s Guide • A non-administrator (username is something other than admin) is someone who can view but not configure switch settings. Click Access Control from the navigation panel and then click Logins from this screen. Figure 131 Access Control: Logins The following table describes the labels in this screen.
Page 228: Ssh Overview
ES-4124 User’s Guide Table 88 Access Control: Logins (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 229: Ssh Implementation On The Switch
ES-4124 User’s Guide Figure 133 How SSH Works 1 Host Identification The SSH client sends a connection request to the SSH server. The server identifies itself with a host key. The client encrypts a randomly generated session key with the host key and server key and sends the result back to the server.
Page 230: Requirements For Using Ssh
ES-4124 User’s Guide 33.6.1 Requirements for Using SSH You must install an SSH client program on a client computer (Windows or Linux operating system) that is used to connect to the switch over SSH. 33.7 Introduction to HTTPS HTTPS (HyperText Transfer Protocol over Secure Socket Layer, or HTTP over SSL) is a web protocol that encrypts and decrypts web pages.
Page 231: Https Example
ES-4124 User’s Guide 33.8 HTTPS Example If you haven’t changed the default HTTPS port on the switch, then in your browser enter “https://switch IP Address/” as the web site address where “switch IP Address” is the IP address or domain name of the switch you wish to access.
Page 232: The Main Screen
ES-4124 User’s Guide Figure 136 Security Certificate 1 (Netscape) Figure 137 Security Certificate 2 (Netscape) 33.8.3 The Main Screen After you accept the certificate and enter the login username and password, the switch main screen appears. The lock displayed in the bottom right of the browser status bar denotes a secure connection.
Page 233: Service Port Access Control
ES-4124 User’s Guide Figure 138 Example: Lock Denoting a Secure Connection 33.9 Service Port Access Control Service Access Control allows you to decide what services you may use to access the switch. You may also change the default service port and configure “trusted computer(s)” for each service in the Remote Management screen (discussed later).
Page 234: Remote Management
ES-4124 User’s Guide Figure 139 Access Control: Service Access Control The following table describes the fields in this screen. Table 89 Access Control: Service Access Control LABEL DESCRIPTION Services Services you may use to access the switch are listed here.
Page 235: Figure 140 Access Control: Remote Management
ES-4124 User’s Guide Figure 140 Access Control: Remote Management The following table describes the labels in this screen. Table 90 Access Control: Remote Management LABEL DESCRIPTION Entry This is the client set index number. A “client set” is a group of one or more “trusted computers”...
Page 236 ES-4124 User’s Guide Chapter 33 Access Control...
Page 237: Chapter 34 Diagnostic
ES-4124 User’s Guide H A P T E R Diagnostic This chapter explains the Diagnostic screen. 34.1 Diagnostic Click Management, Diagnostic in the navigation panel to open this screen. Use this screen to check system logs, ping IP addresses or perform port tests.
Page 238 ES-4124 User’s Guide Chapter 34 Diagnostic...
Page 239: Chapter 35 Syslog
ES-4124 User’s Guide H A P T E R Syslog This chapter explains the syslog screens. 35.1 Syslog Overview The syslog protocol allows devices to send event notification messages across an IP network to syslog servers that collect the event messages. A syslog-enabled device can generate a syslog message and send it to a syslog server.
Page 240: Syslog Server Setup
ES-4124 User’s Guide Figure 142 Syslog The following table describes the labels in this screen. Table 93 Syslog LABEL DESCRIPTION Syslog Select Active to turn on syslog (system logging) and then configure the syslog setting Logging Type This column displays the names of the categories of logs that the device can generate.
Page 241: Figure 143 Syslog: Server Setup
ES-4124 User’s Guide Figure 143 Syslog: Server Setup The following table describes the labels in this screen. Table 94 Syslog: Server Setup LABEL DESCRIPTION Active Select this check box to have the device send logs to this syslog server. Clear the check box if you want to create a syslog server entry but not have the device send logs to it (you can edit the entry later).
Page 242 ES-4124 User’s Guide Chapter 35 Syslog...
Page 243: Chapter 36 Cluster Management
Table 95 ZyXEL Clustering Management Specifications Maximum number of cluster members 24 Cluster Member Models Must be compatible with ZyXEL cluster management implementation. Cluster Manager The switch through which you manage the cluster member switches.
Page 244: Cluster Management Status
ES-4124 User’s Guide Figure 144 Clustering Application Example 36.2 Cluster Management Status Click Management, Cluster Management in the navigation panel to display the following screen. Note: A cluster can only have one manager. Chapter 36 Cluster Management...
Page 245: Cluster Member Switch Management
ES-4124 User’s Guide Figure 145 Cluster Management: Status The following table describes the labels in this screen. Table 96 Cluster Management: Status LABEL DESCRIPTION Status This field displays the role of this switch within the cluster. Manager Member (you see this if you access this screen in the cluster member switch directly...
Page 246: Uploading Firmware To A Cluster Member Switch
ES-4124 User’s Guide Figure 146 Cluster Management: Cluster Member Web Configurator Screen 36.2.1.1 Uploading Firmware to a Cluster Member Switch You can use FTP to upload firmware to a cluster member switch through the cluster manager switch as shown in the following example.
Page 247: Clustering Management Configuration
ES-4124 User’s Guide Figure 147 Example: Uploading Firmware to a Cluster Member Switch C:\>ftp 192.168.1.1 Connected to 192.168.1.1. 220 switch FTP version 1.0 ready at Thu Jan 1 00:58:46 1970 User (192.168.0.1:(none)): admin 331 Enter PASS command Password: 230 Logged in ftp>...
Page 248: Figure 148 Clustering Management Configuration
ES-4124 User’s Guide Figure 148 Clustering Management Configuration The following table describes the labels in this screen. Table 98 Clustering Management Configuration LABEL DESCRIPTION Clustering Manager Active Select Active to have this switch become the cluster manager switch. A cluster can only have one manager.
Page 249 ES-4124 User’s Guide Table 98 Clustering Management Configuration (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 250 ES-4124 User’s Guide Chapter 36 Cluster Management...
Page 251: Chapter 37 Mac Table
ES-4124 User’s Guide H A P T E R MAC Table This chapter introduces the MAC Table screen. 37.1 MAC Table Overview The MAC Table screen (a MAC table is also known as a filtering database) shows how frames are forwarded or filtered across the switch’s ports. It shows what device MAC address,...
Page 252: Viewing The Mac Table
ES-4124 User’s Guide 37.2 Viewing the MAC Table Click Management, MAC Table in the navigation panel to display the following screen. Figure 150 MAC Table The following table describes the labels in this screen. Table 99 MAC Table LABEL DESCRIPTION...
Page 253: Chapter 38 Ip Table
ES-4124 User’s Guide H A P T E R IP Table This chapter introduces the IP table. 38.1 IP Table Overview The IP Table screen shows how packets are forwarded or filtered across the switch’s ports. It shows what device IP address, belonging to what VLAN group (if any) is forwarded to which port(s) and whether the IP address is dynamic (learned by the switch) or static (belonging to the switch).
Page 254: Viewing The Ip Table
ES-4124 User’s Guide 38.2 Viewing the IP Table Click Management, IP Table in the navigation panel to display the following screen. Figure 152 IP Table The following table describes the labels in this screen. Table 100 IP Table LABEL DESCRIPTION...
Page 255: Chapter 39 Arp Table
ES-4124 User’s Guide H A P T E R ARP Table This chapter introduces ARP Table. 39.1 ARP Table Overview Address Resolution Protocol (ARP) is a protocol for mapping an Internet Protocol address (IP address) to a physical machine address, also known as a Media Access Control or MAC address, on the local area network.
Page 256: Figure 153 Arp Table
ES-4124 User’s Guide Figure 153 ARP Table The following table describes the labels in this screen. Table 101 ARP Table LABEL DESCRIPTION Index This is the ARP Table entry number. IP Address This is the learned IP address of a device connected to a switch port with corresponding MAC address below.
Page 257: Chapter 40 Routing Table
ES-4124 User’s Guide H A P T E R Routing Table This chapter introduces the routing table. 40.1 Overview The routing table contains the route information to the network(s) that the switch can reach. The switch automatically updates the routing table with the RIP information received from other Ethernet devices.
Page 258 ES-4124 User’s Guide Chapter 40 Routing Table...
Page 259: Chapter 41 Configure Clone
ES-4124 User’s Guide H A P T E R Configure Clone This chapter shows you how you can copy the settings of one port onto other ports. 41.1 Configure Clone Cloning allows you to copy the basic and advanced settings from a source port to a destination port or ports.
Page 260 ES-4124 User’s Guide Table 103 Configure Clone (continued) LABEL DESCRIPTION Advanced Select which port settings (you configured in the Advanced Application menus) Application should be copied to the destination ports. Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses...
Page 261: Chapter 42 Introducing Commands
ES-4124 User’s Guide H A P T E R Introducing Commands This chapter introduces commands and gives a summary of commands available. 42.1 Overview In addition to the web configurator, you can use commands to configure the switch. Use commands for advanced switch diagnosis and troubleshooting. If you have problems with your switch, customer support may request that you issue some of these commands to assist them in troubleshooting.
Page 262: Initial Screen
You can view the initialization information using the console port. After the initialization, the login screen displays (refer to Section 42.3 on page 260). Copyright (c) 1994 - 2006 ZyXEL Communications Corp. initialize mgmt, ethernet address: 00:13:49:00:00:01 initialize switch, ethernet address: 00:13:49:00:00:02 Initializing switch unit 0...
Page 263: Changing The Password
ES-4124 User’s Guide means that the contact and location fields are optional. • “Command” refers to a command used in the command line interface (CI command). • The | symbol means “or”. • The entry <cr> in the command lines refers to carriage return. Press [ENTER] or carriage return after a command to execute the command.
Page 264: Command Modes
ES-4124 User’s Guide Syntax: logins username <username> password <password> logins username <username> privilege <0-14> where Specifies a new user (up to 32 alphanumeric characters). Enter username <username> a user name to change the settings of an existing account. Specifies the new password (up to 32 alphanumeric password <password>...
Page 265: Getting Help
ES-4124 User’s Guide Table 104 Command Interpreter Mode Summary (continued) HOW TO LOGIN/ MODE DESCRIPTION PROMPT ACCESS config Config Commands available in this mode Type sysname(config)# allow you to configure settings that enable mode. affect the switch globally. Command modes that follow are sub-modes of the config mode and can only be accessed from within the config mode.
Page 266: List Of Available Commands
ES-4124 User’s Guide 42.8.1 List of Available Commands Enter “ ” to display a list of available commands and the corresponding sub commands. help sysname> help Commands available: help logout exit history enable show ip <cr> show hardware-monitor <C|F> show system-information ping <ip|host-name>...
Page 267: Using Command History
ES-4124 User’s Guide Enter to display detailed help information about the sub commands and <command> ? parameters. sysname> ping ? <ip|host-name> destination ip address help Description of ping help sysname> 42.9 Using Command History The switch keeps a list of recently used commands available to you for reuse. You can use any...
Page 268: Logging Out
ES-4124 User’s Guide • Use the same configuration file to set all switches (of the same model) in your network to the same settings. Note: You may also edit a configuration file using a text editor. Make sure you use valid commands. The switch rejects configuration files with invalid or incomplete commands.
Page 269: Enable Mode
ES-4124 User’s Guide Table 105 Command Summary: User Mode (continued) COMMAND DESCRIPTION PRIVILEGE Sends Ping request to an Ethernet device in the <IP|host-name> [vlan specified VLAN(s) with the specified parameters. <vlan-id>] [size <0-1472>] [-t] Displays command help information. help Determines the path a packet takes to a device.
Page 270 ES-4124 User’s Guide Table 106 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Restores firmware via TFTP. flash <ip> <remote-file> Exits Enable (or privileged) mode. disable Accesses Enable (or privileged) enable mode. Resets to the factory default erase running-config settings.
Page 271 ES-4124 User’s Guide Table 106 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Displays the configuration of the members config cluster member(s). Displays the status of the cluster member mac <mac- member(s). addr> Displays DHCP relay settings. dhcp relay Displays DHCP server settings.
Page 272: Ospf Interface
ES-4124 User’s Guide Table 106 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Displays DVMRP group dvmrp group information. Displays DVMRP interface dvmrp interface information. Displays DVMRP neighbour dvmrp neighbour information. Displays the DVMRP prune dvmrp prune information. Displays the DVMRP routes.
Page 273: Table 55 Mvr
ES-4124 User’s Guide Table 106 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Displays multiple rapid spanning mrstp <tree- tree configuration for the specified index> tree. Displays multicast settings. multicast Displays multi-login information multi-login DIsplays all MVR settings. Displays the specified MVR group <VID>...
Page 274 ES-4124 User’s Guide Table 106 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Displays service control settings. service-control Displays SNMP settings. snmp-server Displays Spanning Tree Protocol spanning-tree config (STP) settings. Displays general SSH settings. known-hosts Displays known SSH hosts information.
Page 275: General Configuration Mode
ES-4124 User’s Guide Table 106 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Saves current configuration to the write memory configuration file the switch is currently using. Saves current configuration to the <index> specified configuration file on the switch. 42.11.3 General Configuration Mode The following table lists the commands in Configuration (or Config) mode.
Page 276 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Configures a classifier. A classifier <name> <[packet- classifier groups traffic into data format flows according to specific criteria <802.3untag|802.3 such as the source address, tag| destination address, source port...
Page 277 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Specifies through which traffic default- <in-band|out-of- flow the switch is to send management band> packets. Enables DHCP relay. dhcp relay Sets the IP addresses of up to 3 helper-address DHCP servers.
Page 278 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Enables IGMP snooping. igmp- snooping Sets the 802.1p priority for 8021p-priority <0-7> outgoing igmp snooping packets. Sets the host timeout value. host-timeout <1-16711450> Sets the leave timeout value leave-timeout <1-16711450>...
Page 279 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Exits from the CLI. logout Sets learned MAC aging time. mac-aging- <10-3000> time Configures a static MAC address mac-filter name <name> mac port filtering rule. <mac-addr> vlan <vlan-id>...
Page 280 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables the classifier. Each classifier <name> classifier has one rule. If you disable a classifier you cannot use policy rule related information. Enables a classifier. <name> inactive...
Page 281 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables the link aggregation lacp control protocol (dynamic trunking) on the switch. Disables login access to the logins <name> specified name. Enables the specified MAC-filter mac-filter name <name>...
Page 282 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables port security on the <port-list> specified ports. Enables MAC address learning <port-list> on the specified ports. learn inactive Disables the use of radius-server <index> authentication from the specified RADIUS server.
Page 283 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables the secure shell server encryption key. Your switch <rsa1|rsa|dsa> supports SSH versions 1 and 2 using RSA and DSA authentication. Removes the specified remote known-hosts hosts from the list of all known <host-ip>...
Page 284 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Configures a policy. A classifier policy <name> classifier distinguishes traffic into flows <classifier-list> based on the configured criteria. < A policy rule ensures that a traffic [vlan<vlan-id>]...
Page 285 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Specifies how often a client has reauth-period to re-enter the username and <reauth- password to stay connected to period> the specified port(s). Enables port security on the port- device.
Page 286 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Enables MD5 authentication for area <area-id> the area. authentication message-digest Sets the cost to the area. area <area-id> default-cost <0-16777214> Sets a descriptive name for the area <area-id>...
Page 287 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Sets the area to use the default no area <area- cost (15). id> default- cost Disables stub network settings in no area <area- the area. id> stub Sets the area to send LSAs (Link no area <area-...
Page 288 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Sets the interface to be passive. passive-iface A passive interface does not send <ip-addr/bits> or receive OSPF traffic. Enables and enters the RIP configuration mode. Leaves the RIP configuration exit mode.
Page 289 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Allows ICMP management icmp packets. Allows SNMP management. snmp Allows SSH access on the ssh <socket- specified service port. number> Allows Telnet access on the telnet <socket- specified service port.
Page 290 ES-4124 User’s Guide Table 107 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables syslog logging to the server <ip- inactive specified syslog server. address> Sets the IP address of the syslog level [0 ~ 7] server and the severity level.
Page 291: Interface Port-Channel Commands
ES-4124 User’s Guide 42.11.4 interface port-channel Commands The following table lists the commands in configuration mode. interface port-channel Use these commands to configure the ports. Table 108 interface port-channel Commands COMMAND DESCRIPTION PRIVILEGE Enables a port or a list of ports for interface configuration.
Page 292 ES-4124 User’s Guide Table 108 interface port-channel Commands (continued) COMMAND DESCRIPTION PRIVILEGE Choose to accept both tagged and frame-type untagged incoming frames, just <all|tagged|unt tagged incoming frames or just agged> untagged incoming frames on a port. Enables strict priority queuing ge-spq <q0|q1|...|q7>...
Page 293 ES-4124 User’s Guide Table 108 interface port-channel Commands (continued) COMMAND DESCRIPTION PRIVILEGE Sets how many multicast packets <pkt/s> the port(s) receives per second. Sets a name for the port(s). Enter name <port- a descriptive name (up to nine name-string> printable ASCII characters).
Page 294: Interface Route-Domain Commands
ES-4124 User’s Guide Table 108 interface port-channel Commands (continued) COMMAND DESCRIPTION PRIVILEGE Disables VLAN trunking on the vlan-trunking port(s). Creates a protocol based VLAN protocol-based- with the specified parameters. vlan name <name> ethernet-type <ethernet-type> vlan <vid> priority <0-7> Disables the protocol based VLAN. 13...
Page 295: Table 109 Interface Route-Domain Commands
ES-4124 User’s Guide Use these commands to configure the IP routing domains. Table 109 interface route-domain Commands PRIVILEG COMMAND DESCRIPTION interface Enables a routing domain for configuration. route-domain <ip-address>/ <mask-bits> Exits from the interface routing- exit domain command mode. Enables this function to permit...
Page 296: Config-Vlan Commands
ES-4124 User’s Guide Table 109 interface route-domain Commands (continued) PRIVILEG COMMAND DESCRIPTION Disables DVMRP in this routing ip dvmrp domain. ip igmp Disables IP IGMP in this routing domain. Disables OSPF authentication ip ospf key settings in this routing authentication-key domain.
Page 297: Mvr Commands
ES-4124 User’s Guide Table 110 Command Summary: config-vlan Commands (continued) COMMAND DESCRIPTION PRIVILEGE Sets the default gateway IP default gateway address in this VLAN. <ip-address> Specifies a name for name <name-str> identification purposes. Sets fixed port(s) to normal fixed <port-list>...
Page 298 ES-4124 User’s Guide Table 111 Command Summary: mvr Commands (continued) COMMAND DESCRIPTION PRIVILEGE Sets the MVR name for name <name-str> identification purposes. Disables all MVR group group settings. Disables the specified MVR group <name-str> group setting. Enables MVR. inactive receiver-port Disables the receiver port(s).An...
Page 299: Chapter 43 User And Enable Mode Commands
ES-4124 User’s Guide H A P T E R User and Enable Mode Commands This chapter describes some commands which you can perform in the User and Enable modes. 43.1 Overview The following command examples show how you can use User and Enable modes to diagnose and manage your switch.
Page 300: Show Ip
ES-4124 User’s Guide 43.2.2 show ip Syntax: show ip This command displays the IP related information (such as IP address and subnet mask) on all switch interfaces. The following figure shows the default interface settings. sysname> show Out-of-band Management IP Address = 192.168.0.1 Management IP Address IP[192.168.0.1], Netmask[255.255.255.0], VID[0]...
Page 301: Show Mac Address-Table
ES-4124 User’s Guide This command displays statistics of a port. The following example shows that port 2 is up and the related information. sysname# show interface 2 Port Info Port NO. Link :100M/F Status :FORWARDING LACP :Disabled TxPkts RxPkts Errors Tx KBs/s :0.0...
Page 302: Ping
ES-4124 User’s Guide This command displays the MAC address(es) stored in the switch. The following example shows the static MAC address table. sysname# show mac address-table static Port VLAN ID MAC Address Type 00:a0:c5:01:23:46 Static sysname# 43.3 ping Syntax: ping <ip|host-name> < [in-band|out-of-band|vlan <vlan-id> ] [ size ->...
Page 303: Copy Port Attributes
ES-4124 User’s Guide where The IP address or host name of an Ethernet device. <ip|host-name> Specifies the network interface or the VLAN ID to which the [in-band|out-of- band|vlan <vlan- Ethernet device belongs. id> ] Specifies the Time To Live (TTL) period.
Page 304: Configuration File Maintenance
ES-4124 User’s Guide where copy running-config Copies all of the possible attributes from one port to another port interface port- or ports. channel <port> <port-list> Copies only the specified port attributes from one port to another copy running-config interface port- port or ports.
Page 305: Resetting To The Factory Default
ES-4124 User’s Guide 43.6.2 Resetting to the Factory Default Follow the steps below to reset the switch back to the factory defaults. 1 Enter to reset the current running configuration. erase running config 2 Enter to save the changes to the current configuration file. If you want to...
Page 306 ES-4124 User’s Guide Chapter 43 User and Enable Mode Commands...
Page 307: Configuration Mode Commands
ES-4124 User’s Guide H A P T E R Configuration Mode Commands This chapter describes how to enable and configure your switch’s features using commands. For more background information, see the feature specific chapters which proceed the commands chapters. 44.1 Enabling IGMP Snooping To enable IGMP snooping on the switch.
Page 308: Configure Igmp Filter
ES-4124 User’s Guide An example is shown next. • Enable IGMP snooping on the switch. • Set the values to 30 seconds host-timeout leave-timeout • Set the switch to drop packets from unknown multicast groups. sysname(config)# igmp-snooping sysname(config)# igmp-snooping host-timeout 30...
Page 309: Enabling Stp
ES-4124 User’s Guide 44.3 Enabling STP Use the or the commands to enable and configure STP on the switch. spanning-tree mrstp The difference between the commands is that only allows you to set up one spanning-tree spanning tree configuration and the command allows you to set up multiple ones.
Page 310 ES-4124 User’s Guide Specifies the maximum time (in seconds) a switch can wait maximum-age <6-40> without receiving a BPDU before attempting to reconfigure. All switch ports (except for designated ports) should receive BPDUs at regular intervals. Any port that ages out STP information (provided in the last BPDU) becomes the designated port for the attached LAN.
Page 311: No Command Examples
ES-4124 User’s Guide 44.4 no Command Examples These are the commonly used command examples that belong to the group of commands. group commands are commands which are preceded by keyword . This command negates the intended action of the command. In most cases the command disables, resets or clears settings.
Page 312: Other Examples Of No Commands
ES-4124 User’s Guide where Re-enables an ip route with the specified IP address and <ip> <mask> inactive subnet mask. An example is shown next. • Enable the IP route with the IP address of 192.168.11.1 and subnet mask of 255.255.255.0. This ip route must have already been created and made inactive prior to re-enable command being applied.
Page 313: No Port-Access-Authenticator
ES-4124 User’s Guide 44.4.4.2 no port-access-authenticator Syntax: no port-access-authenticator no port-access-authenticator <port-list> reauthenticate no port-access-authenticator <port-list> where Disables port authentication on the switch. Disables the re-authentication mechanism on the listed port(s). <port-list> reauthenticate Disables authentication on the listed ports. <port-list>...
Page 314: Queuing Method Commands
ES-4124 User’s Guide • Disable the secure shell RSA1 encryption key. • Remove the remote host with IP address 172.165.1.8 from the list of known hosts. • Remove the remote host with IP address 172.165.1.9 and with an SSH-RSA encryption key from the list of known hosts.
Page 315: Enabling Mac Filtering
ES-4124 User’s Guide Syntax: ip route <ip> <mask> <next-hop-ip> ip route <ip> <mask> <next-hop-ip> [metric <metric>][name <name>] --> [inactive] where Specifies the network IP address of the final destination. <ip> Specifies the subnet mask of this destination. <mask> Specifies the IP address of the gateway. The gateway is an <next-hop-ip>...
Page 316: Enabling Trunking
ES-4124 User’s Guide where Names the filtering rule. name <name> Specifies the MAC address you want to filter. mac <mac-addr> Specifies which VLAN this rule applies to. vlan <vlan-id> Selects the behavior of the rule. drop <src/dst/both> • src - drop packets coming from the specified MAC address •...
Page 317: Enabling Port Authentication
ES-4124 User’s Guide • Create trunk 1 on the switch. • Place ports 5-8 in trunk 1. • Enable dynamic link aggregation (LACP) on trunk 1. sysname(config)# trunk t1 sysname(config)# trunk t1 interface 5-8 sysname(config)# trunk t1 lacp 44.9 Enabling Port Authentication To enable a port authentication, you need to specify your RADIUS server details and select the ports which require external authentication.
Page 318: Port Authentication Settings
ES-4124 User’s Guide Specifies the timeout period (in seconds) the switch radius-server timeout <1- 1000> will wait for a response from a RADIUS server. If 2 RADIUS servers are configured, this is the total time the switch will wait for a response from either server.
Page 319 ES-4124 User’s Guide An example is shown next. • Specify RADIUS server 1 with IP address 10.10.10.1, port 1890 and the string secretKey as the password. See Section 44.9.1 on page 315 for more information on RADIUS server commands. • Specify the timeout period of 30 seconds that the switch will wait for a response from the RADIUS server.
Page 320 ES-4124 User’s Guide Chapter 44 Configuration Mode Commands...
Page 321: Chapter 45 Interface Commands
ES-4124 User’s Guide H A P T E R Interface Commands These are some commonly used configuration commands that belong to the interface group of commands. 45.1 Overview The interface commands allow you to configure the switch on a port by port basis.
Page 322: Broadcast-Limit
ES-4124 User’s Guide where Type to process any BPDUs received on these ports. <peer|tunnel|discard| peer network> Type to forward BPDUs received on these ports. tunnel Type to drop any BPDUs received on these ports. discard Type to process a BPDU with no VLAN tag and network forward a tagged BPDU.
Page 323: Mirror
ES-4124 User’s Guide Syntax: bandwidth-limit bandwidth-limit pir <Kbps> bandwidth-limit cir <Kbps> bandwidth-limit egress <Kbps> where Sets the maximum bandwidth allowed for incoming traffic. pir <Kbps> Sets the guaranteed bandwidth allowed for incoming traffic. cir <Kbps> Sets the maximum bandwidth allowed for outgoing traffic egress <Kbps>...
Page 324: Gvrp
ES-4124 User’s Guide • Enable ports 1, 4, 5 and 6 for configuration. • Enable port mirroring on the ports. • Enable port mirroring for outgoing traffic. Traffic is copied from ports 1, 4, 5 and 6 to port three in order to examine it in more detail without interfering with the traffic flow on the original ports.
Page 325: Frame-Type
ES-4124 User’s Guide • Enable ingress checking on the interface. sysname(config)# interface port-channel 1,3-5 sysname(config-interface)# ingress-check 45.2.8 frame-type Syntax: frame-type <all|tagged|untagged> where Choose to accept both tagged and untagged incoming frames, just <all|tagged|u ntagged> tagged incoming frames or just untagged incoming frames on a port.
Page 326: Egress Set
ES-4124 User’s Guide • Set the queue weights from Q0 to Q7. sysname# configure sysname(config)# wfq sysname(config)# interface port-channel 2,6-8 sysname(config-interface)# weight 8 7 6 5 4 3 2 1 45.2.10 egress set Syntax: egress set <port-list> where Sets the outgoing traffic port list for a port-based VLAN.
Page 327: Name
ES-4124 User’s Guide 45.2.12 name Syntax: name <port-name-string> where Sets a name for your port interface(s). <port-name-string> An example is shown next. • Enable ports one, three, four and five for configuration. • Set a name for the ports. sysname(config)# interface port-channel 1,3-5 sysname(config-interface)# name Test 45.2.13 speed-duplex...
Page 328: Interface No Command Examples
ES-4124 User’s Guide An example is shown next. • Select ports 3-6 for internal loopback test. • Execute the test command. • View the results. sysname(config)# interface port-channel 3-6 sysname(config-interface)# test 3-6 Testing internal loopback on port 3 :Passed! Ethernet Port 3 Test ok.
Page 329: Ieee 802.1Q Tagged Vlan Commands
ES-4124 User’s Guide H A P T E R IEEE 802.1Q Tagged VLAN Commands This chapter describes the IEEE 802.1Q Tagged VLAN and associated commands. 46.1 Configuring Tagged VLAN The following procedure shows you how to configure tagged VLAN. 1 Use the IEEE 802.1Q tagged VLAN commands to configure tagged VLAN for the switch.
Page 330: Global Vlan1Q Tagged Vlan Configuration Commands
ES-4124 User’s Guide 46.2 Global VLAN1Q Tagged VLAN Configuration Commands This section shows you how to configure and monitor the IEEE 802.1Q Tagged VLAN. 46.2.1 GARP Status Syntax: show garp This command shows the switch’s GARP timer settings, including the join, leave and leave all timers.
Page 331: Gvrp Timer
ES-4124 User’s Guide Switches join VLANs by making a declaration. A declaration is made by issuing a Join message using GARP. Declarations are withdrawn by issuing a Leave message. A Leave All message terminates all registrations. GARP timers set declaration timeout values.
Page 332: Set Port Vid
ES-4124 User’s Guide 46.3.1 Set Port VID Syntax: pvid <VID> where Specifies the VLAN number between 1 and 4094. <VID> This command sets the default VLAN ID on the port(s). The following example sets the default VID to 200 on ports 1 to 5.
Page 333: Modify Static Vlan
ES-4124 User’s Guide 46.3.4 Modify Static VLAN Use the following commands in the config-vlan mode to configure the static VLAN table. Syntax: vlan <vlan-id> fixed <port-list> forbidden <port-list> name <name-str> normal <port-list> untagged <port-list> no fixed <port-list> no forbidden <port-list>...
Page 334: Delete Vlan Id
ES-4124 User’s Guide 3 The switch notes what the SVLAN table says (that is, the SVLAN tells the switch whether or not to forward a frame and if the forwarded frames should have tags). 4 Then the switch applies the port filter to finish the forwarding decision. This means that frames may be dropped even if the SVLAN says to forward them.
Page 335: Disable Vlan
ES-4124 User’s Guide 46.5 Disable VLAN Syntax: vlan <vlan-id> inactive This command disables the specified VLAN ID in the SVLAN (Static VLAN) table. 46.6 Show VLAN Setting Syntax: show vlan This command shows the IEEE 802.1Q Tagged SVLAN (Static VLAN) table.
Page 336 ES-4124 User’s Guide Chapter 46 IEEE 802.1Q Tagged VLAN Commands...
Page 337: Chapter 47 Multicast Vlan Registration Commands
ES-4124 User’s Guide H A P T E R Multicast VLAN Registration Commands This chapter shows you how to use Multicast VLAN Registration (mvr) commands. 47.1 Overview Use the mvr commands in the configuration mode to create and configure multicast VLANs.
Page 338 ES-4124 User’s Guide A name to identify the MVR IP multicast group. group name <name-str> Specifies the starting IP multicast address of the multicast group in start-address <ip> dotted decimal notation. Specifies the ending IP multicast address of the multicast group in end-address <ip>...
Page 339: Routing Domain Command Examples
ES-4124 User’s Guide H A P T E R Routing Domain Command Examples 48.0.1 interface route-domain Syntax: interface route-domain <ip-address>/<mask-bits> where = This is the IP address of the switch in the routing domain. Specify the IP <ip-address> address is dotted decimal notation. For example, 192.168.1.1.
Page 340 ES-4124 User’s Guide Chapter 48 Routing Domain Command Examples...
Page 341: Chapter 49 Troubleshooting
ES-4124 User’s Guide H A P T E R Troubleshooting This chapter covers potential problems and possible remedies. 49.1 Problems Starting Up the Switch Table 112 Troubleshooting the Start-Up of Your Switch PROBLEM CORRECTIVE ACTION None of the LEDs Check the power connection and make sure the power source is turned on.
Page 342: Pop-Up Windows, Javascripts And Java Permissions
ES-4124 User’s Guide 49.2.1 Pop-up Windows, JavaScripts and Java Permissions In order to use the web configurator you need to allow: • Web browser pop-up windows from your device. • JavaScripts (enabled by default). • Java permissions (enabled by default).
Page 343: Figure 158 Internet Options
ES-4124 User’s Guide Figure 158 Internet Options 3 Click Apply to save this setting. 49.2.1.1.2 Enable pop-up Blockers with Exceptions Alternatively, if you only want to allow pop-up windows from your device, see the following steps. 1 In Internet Explorer, select Tools, Internet Options and then the Privacy tab.
Page 344: Figure 159 Internet Options
ES-4124 User’s Guide Figure 159 Internet Options 3 Type the IP address of your device (the web page that you do not want to have blocked) with the prefix “http://”. For example, http://192.168.1.1. 4 Click Add to move the IP address to the list of Allowed sites.
Page 345: Javascripts
ES-4124 User’s Guide Figure 160 Pop-up Blocker Settings 5 Click Close to return to the Privacy screen. 6 Click Apply to save this setting. 49.2.1.2 JavaScripts If pages of the web configurator do not display properly in Internet Explorer, check that JavaScripts are allowed.
Page 346: Figure 161 Internet Options
ES-4124 User’s Guide Figure 161 Internet Options 2 Click the Custom Level... button. 3 Scroll down to Scripting. 4 Under Active scripting make sure that Enable is selected (the default). 5 Under Scripting of Java applets make sure that Enable is selected (the default).
Page 347: Java Permissions
ES-4124 User’s Guide Figure 162 Security Settings - Java Scripting 49.2.1.3 Java Permissions 1 From Internet Explorer, click Tools, Internet Options and then the Security tab. 2 Click the Custom Level... button. 3 Scroll down to Microsoft VM. 4 Under Java permissions make sure that a safety level is selected.
Page 348: Figure 163 Security Settings - Java
ES-4124 User’s Guide Figure 163 Security Settings - Java 49.2.1.3.1 JAVA (Sun) 1 From Internet Explorer, click Tools, Internet Options and then the Advanced tab. 2 make sure that Use Java 2 for <applet> under Java (Sun) is selected. 3 Click OK to close the window.
Page 349: Problems With The Password
ES-4124 User’s Guide Figure 164 Java (Sun) 49.3 Problems with the Password Table 114 Troubleshooting the Password PROBLEM CORRECTIVE ACTION Cannot access the The password field is case sensitive. Make sure that you enter the correct switch. password using the proper casing.
Page 350 ES-4124 User’s Guide Chapter 49 Troubleshooting...
Page 351: Product Specifications
ES-4124 User’s Guide P P E N D I X Product Specifications This section describes the general software features of the switch. Table 115 Firmware Features FEATURE DESCRIPTION IP Routing Domain An IP interface (also known as an IP routing domain) is not bound to a physical port.
Page 352 Use the web configurator to easily configure the rich range of features on the switch. Firmware Upgrade Download new firmware (when available) from the ZyXEL web site and use the web configurator, CLI or an FTP/TFTP tool to put it on the switch. Note: Only upload firmware for your specific model! Configuration Backup &...
Page 353: Table 116 General Product Specifications
ES-4124 User’s Guide The following tables list the product specifications. Table 116 General Product Specifications Interface 24 10/100 Base-Tx ports 2 GbE Dual Personality interfaces (Each interface has one 1000Base-T copper port and one Small Form-Factor Pluggable (SFP) fiber port, with one port active at a time.)
Page 354: Table 117 Management Specifications
ES-4124 User’s Guide Table 116 General Product Specifications (continued) Layer 3 IP Capability IPV4 support Features 64 IP routing domains 4K IP address table Wire speed IP forwarding Routing Unicast: RIP-V1/V2, OSPF V2 protocols Multicast: DVMRP, IGMP V1/V2 Static Routing...
Page 355: Table 118 Physical And Environmental Specifications
ES-4124 User’s Guide Table 118 Physical and Environmental Specifications LEDs Main switch: BPS, PWR, SYS, ALM, LNK/ACT, FDX Per Gigabit port: LNK/ACT, FDX Per mini-GBIC port: LNK, ACT Per Management port: 10, 100 Dimension Standard 19” rack mountable 438 mm (W) x 270 mm (D) x 44.45 mm (H) Weight 3.6 Kg...
Page 356 ES-4124 User’s Guide Appendix A Product Specifications...
Page 357: Ip Addresses And Subnetting
ES-4124 User’s Guide P P E N D I X IP Addresses and Subnetting This appendix introduces IP addresses, IP address classes and subnet masks. You use subnet masks to subdivide a network into smaller logical networks. Introduction to IP Addresses An IP address has two parts: the network number and the host ID.
Page 358: Table 119 Classes Of Ip Addresses
ES-4124 User’s Guide The following table shows the network number and host ID arrangement for classes A, B and Table 119 Classes of IP Addresses IP ADDRESS OCTET 1 OCTET 2 OCTET 3 OCTET 4 Class A Network number Host ID...
Page 359: Table 121 "Natural" Masks
ES-4124 User’s Guide Subnet Masks A subnet mask is used to determine which bits are part of the network number, and which bits are part of the host ID (using a logical AND operation). A subnet mask has 32 bits. If a bit in the subnet mask is a “1” then the corresponding bit in the IP address is part of the network number.
Page 360: Table 123 Two Subnets Example
ES-4124 User’s Guide Table 122 Alternative Subnet Mask Notation (continued) SUBNET MASK SUBNET MASK “1” BITS LAST OCTET BIT VALUE DECIMAL 255.255.255.240 1111 0000 255.255.255.248 1111 1000 255.255.255.252 1111 1100 The first mask shown is the class “C” natural mask. Normally if no mask is specified it is understood that the natural mask is being used.
Page 361: Table 125 Subnet 2
ES-4124 User’s Guide Table 124 Subnet 1 (continued) LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER VALUE Subnet Address: 192.168.1.0 Lowest Host ID: 192.168.1.1 Broadcast Address: Highest Host ID: 192.168.1.126 192.168.1.127 Table 125 Subnet 2 IP/SUBNET MASK NETWORK NUMBER LAST OCTET BIT VALUE IP Address 192.168.1.
Page 362: Table 127 Subnet 2
ES-4124 User’s Guide Table 126 Subnet 1 (continued) LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER VALUE Subnet Address: 192.168.1.0 Lowest Host ID: 192.168.1.1 Broadcast Address: Highest Host ID: 192.168.1.62 192.168.1.63 Table 127 Subnet 2 LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER...
Page 363: Table 130 Eight Subnets
ES-4124 User’s Guide The following table shows class C IP address last octet values for each subnet. Table 130 Eight Subnets BROADCAST SUBNET SUBNET ADDRESS FIRST ADDRESS LAST ADDRESS ADDRESS The following table is a summary for class “C” subnet planning.
Page 364: Table 132 Class B Subnet Planning
ES-4124 User’s Guide The following table is a summary for class “B” subnet planning. Table 132 Class B Subnet Planning NO. “BORROWED” HOST NO. HOSTS PER SUBNET MASK NO. SUBNETS BITS SUBNET 255.255.128.0 (/17) 32766 255.255.192.0 (/18) 16382 255.255.224.0 (/19) 8190 255.255.240.0 (/20)
Page 365: Index
ES-4124 User’s Guide Index Numerics 802.1P priority back up, configuration file Backbone Router (BR) backbone, routing Backup Designated Router(BDR), and OSPF bandwidth control basic settings access control BDR (Backup Designated Router) limitations BPDUs (Bridge Protocol Data Units) login account Bridge Protocol Data Units (BPDUs)
Page 366 ES-4124 User’s Guide Command Line Interface setup introduction DHCP (Dynamic Host Configuration Protocol) Command Line Interface (CLI) diagnostics Command Line Interface, See also commands Ethernet port test accessing ping system log commands accessing Differentiated Service (DiffServ) and configuration file DiffServ...
Page 367 ES-4124 User’s Guide history in command interpreter HTTPS fan speed certificates FCC interference statement implementation feature summary public keys, private keys file transfer using FTP HTTPS example command example filename convention, configuration configuration file names filtering rules IEEE 802.1p, priority filtering database, MAC table IEEE 802.1x...
Page 368 ES-4124 User’s Guide current configuration main screen management Java permissions Management Information Base (MIB) management interface, See also CLI management port metric and SNMP LACP supported MIBs system priority MIB (Management Information Base) timeout MIBs layer 2 features mini GBIC ports...
Page 369 ES-4124 User’s Guide network management port authentication and RADIUS 125, 127 network management system (NMS) and VSA no commands examples IEEE802.1x NTP (RFC-1305) port based VLAN type port cloning advanced settings basic settings port details port isolation 88, 95 OSPF...
Page 370 ES-4124 User’s Guide RSTP See also STP rubber feet and classifier queue weight queuing safety certifications safety warnings queuing method 149, 152 save configuration 53, 216 screen summary Secure Shell See SSH security service access control service port RADIUS advantages...
Page 371 ES-4124 User’s Guide OSPF temperature indicator port time port details current power time zone 107, 110 Time (RFC-868) VLAN time server VRRP time service protocol 101, 351 format bridge ID 107, 110 Time To Live (TTL) bridge priority 106, 109...
Page 372 84, 85 tagged trunking 83, 88 type 74, 83 VLAN (Virtual Local Area Network) VLAN commands examples VLAN number ZyNOS (ZyXEL Network Operating System) VLAN stacking 153, 155 configuration example frame format port roles 154, 157 priority VLAN, protocol based, See protocol based VLAN...

ZyXEL Communications ES-4124 User Manual

Chapter 1 Getting to Know Your Switch

Chapter 2 Hardware Installation and Connection

Chapter 3 Hardware Overview

Chapter 4 The Web Configurator

Chapter 5 Initial Setup Example

Chapter 6 System Status and Port Statistics

Chapter 7 Basic Setting

Chapter 8 VLAN

Chapter 9 Static MAC Forward Setup

Chapter 10 Filtering

Chapter 11 Spanning Tree Protocol

Chapter 12 Bandwidth Control

Chapter 13 Broadcast Storm Control

Chapter 14 Mirroring

Chapter 15 Link Aggregation

Chapter 16 Port Authentication

Chapter 17 Port Security

Chapter 18 Classifier

Chapter 19 Policy Rule

Chapter 20 Queuing Method

Chapter 21 VLAN Stacking

Chapter 22 Multicast

Quick Links

Troubleshooting

Related Manuals for ZyXEL Communications ES-4124

Summary of Contents for ZyXEL Communications ES-4124
