Page 1 ES-2724 Intelligent Layer 3 Switch User’s Guide Version 3.70 9/2006...
Page 4: Certifications
ES-2724 User’s Guide Certifications Federal Communications Commission (FCC) Interference Statement This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operations.
Page 5 ES-2724 User’s Guide 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. Certifications...
Page 6: Safety Warnings
ES-2724 User’s Guide Safety Warnings For your safety, be sure to read and follow all warning notices and instructions. • Do NOT use this product near water, for example, in a wet basement or near a swimming pool. • Do NOT expose your device to dampness, dust or corrosive liquids.
Page 7 ES-2724 User’s Guide This product is recyclable. Dispose of it properly. Safety Warnings...
Page 8: Zyxel Limited Warranty
ES-2724 User’s Guide ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two years from the date of purchase. During...
Page 9: Customer Support
ES-2724 User’s Guide Customer Support Please have the following information ready when you contact customer support. • Product model and serial number. • Warranty Information. • Date that you received your device. • Brief description of the problem and the steps you took to solve it.
Page 10 ES-2724 User’s Guide METHOD SUPPORT E-MAIL TELEPHONE WEB SITE REGULAR MAIL SALES E-MAIL FTP SITE LOCATION support@zyxel.no +47-22-80-61-80 www.zyxel.no ZyXEL Communications A/S Nils Hansens vei 13 NORWAY sales@zyxel.no +47-22-80-61-81 0667 Oslo Norway info@pl.zyxel.com +48 (22) 333 8250 www.pl.zyxel.com ZyXEL Communications ul.
Page 11: Table Of Contents
ES-2724 User’s Guide Table of Contents Copyright ........................1 Certifications ......................2 Safety Warnings ....................... 4 ZyXEL Limited Warranty..................6 Customer Support....................7 Table of Contents ..................... 9 List of Figures ......................21 List of Tables ......................25 Preface ........................29 Chapter 1 Getting to Know Your Switch ................
Page 12 ES-2724 User’s Guide 3.1.2.1 Default Ethernet Settings ..............40 3.1.3 Mini-GBIC Slots ..................41 3.1.3.1 Transceiver Installation ..............41 3.1.3.2 Transceiver Removal ..............42 3.2 Rear Panel ......................42 3.2.1 Power Connector ..................43 3.2.2 External Backup Power Supply Connector ..........43 3.3 LEDs ......................44 Chapter 4 The Web Configurator....................
Page 13 ES-2724 User’s Guide 7.5 Switch Setup Screen ..................74 7.6 IP Setup ......................75 7.6.1 IP Interfaces .....................76 7.7 Port Setup ......................78 Chapter 8 VLAN ........................81 8.1 Introduction to IEEE 802.1Q Tagged VLANs ..........81 8.1.1 Forwarding Tagged and Untagged Frames ..........81 8.2 Automatic VLAN Registration ................82...
Page 14 ES-2724 User’s Guide 11.3 Configure Rapid Spanning Tree Protocol ............104 11.4 Rapid Spanning Tree Protocol Status ............107 11.5 Configure Multiple Rapid Spanning Tree Protocol ........108 11.6 Multiple Rapid Spanning Tree Protocol Status .........110 Chapter 12 Bandwidth Control ....................113 12.1 Bandwidth Control Overview ................113 12.1.1 CIR and PIR ..................113...
Page 15 ES-2724 User’s Guide Chapter 18 Classifier ....................... 135 18.1 About the Classifier and QoS .................135 18.2 Configuring the Classifier ................135 18.3 Viewing and Editing Classifier Configuration ..........138 18.4 Classifier Example ..................139 Chapter 19 Policy Rule......................141 19.1 Policy Rules Overview ..................141 19.1.1 DiffServ and DSCP ................141...
Page 16 ES-2724 User’s Guide 22.5.2 MVR Modes ..................162 22.5.3 How MVR Works ..................163 22.6 General MVR Configuration ................163 22.7 MVR Group Configuration ................165 22.7.1 MVR Configuration Example ..............167 Chapter 23 Static Route ......................169 23.1 Configuring Static Routing ................169 Chapter 24 RIP ........................
Page 17 ES-2724 User’s Guide 28.4.2 Configuring DHCP Relay ..............185 28.4.3 DHCP Relay Configuration Example ............186 Chapter 29 Maintenance ......................189 29.1 The Maintenance Screen ................189 29.2 Load Factory Default ..................190 29.3 Save Configuration ..................190 29.4 Reboot System ....................191 29.5 Firmware Upgrade ..................191...
Page 18 ES-2724 User’s Guide Chapter 32 Syslog ........................211 32.1 Syslog Overview ....................211 32.2 Syslog Setup ....................211 32.3 Syslog Server Setup ..................212 Chapter 33 Cluster Management .................... 215 33.1 Clustering Management Status Overview .............215 33.2 Cluster Management Status ................216 33.2.1 Cluster Member Switch Management ..........217 33.2.1.1 Uploading Firmware to a Cluster Member Switch .....218...
Page 19 ES-2724 User’s Guide 39.2.1 The Console Port ..................233 39.2.1.1 Initial Screen ................234 39.3 The Login Screen ..................234 39.4 Command Syntax Conventions ..............234 39.5 Changing the Password .................235 39.6 Privilege Levels ....................235 39.7 Command Modes ...................236 39.8 Getting Help ....................237 39.8.1 List of Available Commands ..............238 39.9 Using Command History ................239...
Page 20 ES-2724 User’s Guide 41.4 no Command Examples .................279 41.4.1 Disable Commands ................279 41.4.2 Resetting Commands ................279 41.4.3 Re-enable commands ................279 41.4.4 Other Examples of no Commands ............280 41.4.4.1 no trunk ..................280 41.4.4.2 no port-access-authenticator ............281 41.4.4.3 no ssh ..................281 41.5 Queuing Method Commands .................282 41.6 Static Route Commands ................282...
Page 21 ES-2724 User’s Guide 43.2.3 GVRP Timer ..................299 43.2.4 Enable GVRP ..................299 43.2.5 Disable GVRP ..................299 43.3 Port VLAN Commands ...................299 43.3.1 Set Port VID ..................300 43.3.2 Set Acceptable Frame Type ..............300 43.3.3 Enable or Disable Port GVRP ...............300 43.3.4 Modify Static VLAN ................301 43.3.4.1 Modify a Static VLAN Table Example ..........301...
Page 22 ES-2724 User’s Guide Table of Contents...
Page 23: List Of Figures
ES-2724 User’s Guide List of Figures Figure 1 Backbone Application ................31 Figure 2 Bridging Application ................32 Figure 3 High Performance Switched Workgroup Application ......33 Figure 4 Shared Server Using VLAN Example ............. 33 Figure 5 Attaching Rubber Feet ................35 Figure 6 Attaching the Mounting Brackets ............
Page 24 ES-2724 User’s Guide Figure 39 Port Based VLAN Setup (All Connected) ..........93 Figure 40 Port Based VLAN Setup (Port Isolation) ..........94 Figure 41 Static MAC Forwarding ................. 98 Figure 42 Filtering ....................99 Figure 43 MRSTP Network Example ..............103 Figure 44 Spanning Tree Protocol RSTP and MRSTP ..........
Page 25 ES-2724 User’s Guide Figure 82 IP Multicast ................... 175 Figure 83 DiffServ: Differentiated Service Field ............. 177 Figure 84 DiffServ Network Example ..............178 Figure 85 DiffServ ....................178 Figure 86 DiffServ: DSCP Setting ................. 180 Figure 87 DHCP: DHCP Server Status ..............182 Figure 88 DHCP: Server ..................
Page 26 ES-2724 User’s Guide Figure 125 ARP Table ................... 228 Figure 126 Routing Table Status ................229 Figure 127 Configure Clone .................. 231 Figure 128 no port-access-authenticator Command Example ......281 Figure 129 Pop-up Blocker ..................310 Figure 130 Internet Options .................. 311 Figure 131 Internet Options ...................
Page 27: List Of Tables
ES-2724 User’s Guide List of Tables Table 1 Panel Connections ................... 39 Table 2 LEDs ......................44 Table 3 Navigation Panel Sub-links Overview ............49 Table 4 Web Configurator Screen Sub-links Details ..........50 Table 5 Navigation Panel Links ................50 Table 6 Status ......................
Page 28 ES-2724 User’s Guide Table 39 Port Authentication: 802.1x ..............128 Table 40 Port Security ................... 132 Table 41 Classifier ....................136 Table 42 Classifier: Summary Table ..............138 Table 43 Common Ethernet Types and Protocol Number ........138 Table 44 Common IP Ports ................... 139 Table 45 Policy ......................
Page 29 ES-2724 User’s Guide Table 82 FTP Upload to Cluster Member Example ..........219 Table 83 Clustering Management Configuration ........... 220 Table 84 MAC Table ....................224 Table 85 IP Table ....................226 Table 86 ARP Table ....................228 Table 87 Routing Table Status ................229 Table 88 Configure Clone ..................
Page 30 ES-2724 User’s Guide List of Tables...
Page 31: Preface
ES-2724 User’s Guide Preface Congratulations on your purchase of the ES-2724 Ethernet Switch. This preface introduces you to the ES-2724 Ethernet Switch and discusses the conventions of this User’s Guide. It also provides information on other related documentation. About This User's Guide This manual is designed to guide you through the installation and configuration of your switch for its various applications.
Page 32: User Guide Feedback
Help us help you. E-mail all User Guide-related comments, questions or suggestions for improvement to techwriters@zyxel.com.tw or send regular mail to The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. Thank you.
Page 33: Getting To Know Your Switch
This chapter introduces the main features and applications of the switch. 1.1 Introduction The ES-2724 is a stand-alone layer 3 Ethernet switch with 24 10/100Mbps ports, two RJ-45 Gigabit ports for stacking and 2 GbE dual personality interfaces for uplink as well as a console port and a management port for local management.
Page 34: Bridging Example
ES-2724 User’s Guide 1.1.2 Bridging Example In this example application the switch connects different company departments (RD and Sales) to the corporate backbone. It can alleviate bandwidth contention and eliminate server and network bottlenecks. All users that need high bandwidth can connect to high-speed department servers via the switch.
Page 35: Ieee 802.1Q Vlan Application Examples
ES-2724 User’s Guide Figure 3 High Performance Switched Workgroup Application 1.1.4 IEEE 802.1Q VLAN Application Examples A VLAN (Virtual Local Area Network) allows a physical network to be partitioned into multiple logical networks. Stations on a logical network belong to one group. A station can belong to more than one group.
Page 36 ES-2724 User’s Guide Chapter 1 Getting to Know Your Switch...
Page 37: Hardware Installation And Connection
ES-2724 User’s Guide H A P T E R Hardware Installation and Connection This chapter shows you how to install and connect the switch. 2.1 Freestanding Installation 1 Make sure the switch is clean and dry. 2 Set the switch on a smooth, level surface strong enough to support the weight of the switch and the connected cables.
Page 38: Mounting The Switch On A Rack
ES-2724 User’s Guide 2.2 Mounting the Switch on a Rack This section lists the rack mounting requirements and precautions and describes the installation steps. 2.2.1 Rack-mounted Installation Requirements • Two mounting brackets. • Eight M3 flat head screws and a #2 Philips screwdriver.
Page 39: Figure 7 Mounting The Switch On A Rack
ES-2724 User’s Guide Figure 7 Mounting the Switch on a Rack 2 Using a #2 Philips screwdriver, install the M5 flat head screws through the mounting bracket holes into the rack. 3 Repeat steps to attach the second mounting bracket on the other side of the rack.
Page 40 ES-2724 User’s Guide Chapter 2 Hardware Installation and Connection...
Page 41: Chapter 3 Hardware Overview
ES-2724 User’s Guide H A P T E R Hardware Overview This chapter describes the front panel and rear panel of the switch and shows you how to make the hardware connections. 3.1 Panel Connections The figure below shows the front panel of the switch.
Page 42: Console Port
ES-2724 User’s Guide Table 1 Panel Connections (continued) CONNECTOR DESCRIPTION Console Port Only connect this port if you want to configure the switch using the command line interface (CLI) via the console port. Management Connect to a computer using an RJ-45 Ethernet cable for local configuration of the Port switch.
Page 43: Mini-Gbic Slots
ES-2724 User’s Guide 3.1.3 Mini-GBIC Slots These are slots for mini-GBIC (Gigabit Interface Converter) transceivers. A transceiver is a single unit that houses a transmitter and a receiver. The switch does not come with transceivers. You must use transceivers that comply with the SFP Transceiver MultiSource Agreement (MSA).
Page 44: Transceiver Removal
ES-2724 User’s Guide Figure 10 Installed Transceiver 3.1.3.2 Transceiver Removal Use the following steps to remove a mini GBIC transceiver (SFP module). 1 Open the transceiver’s latch (latch styles vary). Figure 11 Opening the Transceiver’s Latch Example 2 Pull the transceiver out of the slot.
Page 45: Power Connector
Make sure you are using the correct power source as shown on the panel. To connect the power to the ES-2724 AC unit, insert the female end of power cord to the power receptacle on the rear panel. Connect the other end of the supplied power cord to a 100~240V AC, 1.5A power outlet.
Page 46: Leds
ES-2724 User’s Guide 3.3 LEDs The following table describes the LEDs. Table 2 LEDs COLOR STATUS DESCRIPTION Green Blinking The system is receiving power from the backup power supply. The backup power supply is connected and active. The backup power supply is not ready or not active.
Page 47 ES-2724 User’s Guide Table 2 LEDs (continued) COLOR STATUS DESCRIPTION Green Blinking The system is transmitting/receiving to/from an Ethernet device. The port is connected at 10 Mbps. The port is not connected at 10 Mbps or to an Ethernet device.
Page 48 ES-2724 User’s Guide Chapter 3 Hardware Overview...
Page 49: The Web Configurator
ES-2724 User’s Guide H A P T E R The Web Configurator This section introduces the configuration and functions of the web configurator. 4.1 Introduction The web configurator is an HTML-based management interface that allows easy switch setup and management via Internet browser. Use Internet Explorer 6.0 and later or Netscape Navigator 7.0 and later versions.
Page 50: The Status Screen
ES-2724 User’s Guide 4 Click OK to view the first web configurator screen. 4.3 The Status Screen The Status screen is the first screen that displays when you access the web configurator. The following figure shows the navigating components of a web configurator screen.
Page 51: Table 3 Navigation Panel Sub-Links Overview
ES-2724 User’s Guide In the navigation panel, click a main link to reveal a list of submenu links. Table 3 Navigation Panel Sub-links Overview ADVANCED BASIC SETTING IP APPLICATION MANAGEMENT APPLICATION Chapter 4 The Web Configurator...
Page 52: Table 4 Web Configurator Screen Sub-Links Details
ES-2724 User’s Guide The following table lists the various web configurator screens within the sub-links. Table 4 Web Configurator Screen Sub-links Details ADVANCED BASIC SETTING IP APPLICATION MANAGEMENT APPLICATION System Info VLAN Static Routing Maintenance General Setup VLAN Status Firmware Upgrade...
Page 53 ES-2724 User’s Guide Table 5 Navigation Panel Links (continued) LINK DESCRIPTION Switch Setup This link takes you to a screen where you can set up global switch parameters such as VLAN type, MAC address learning, IGMP snooping, GARP and priority queues.
Page 54: Change Your Password
ES-2724 User’s Guide Table 5 Navigation Panel Links (continued) LINK DESCRIPTION IP Multicast This link takes you to a screen where you can configure the switch to remove VLAN tags from IP multicast packets on an out-going port. DiffServ This link takes you to screens where you can enable DiffServ, configure marking rules and set DSCP-to-IEEE802.1p mappings.
Page 55: Saving Your Configuration
ES-2724 User’s Guide Figure 17 Change Administrator Login Password 4.4 Saving Your Configuration When you are done modifying the settings in a screen, click Apply to save your changes back to the run-time memory. Settings in the run-time memory are lost when the switch’s power is turned off.
Page 56: Resetting The Switch
ES-2724 User’s Guide Note: Be careful not to lock yourself and others out of the switch. If you do lock yourself out, try using out-of-band management (via the management port) to configure the switch. 4.6 Resetting the Switch If you lock yourself (and others) from the switch or forget the administrator password, you will need to reload the factory-default configuration file or reset the switch back to the factory defaults.
Page 57: Logging Out Of The Web Configurator
ES-2724 User’s Guide Figure 18 Resetting the Switch: Via the Console Port Bootbase Version: V0.8 | 03/14/2006 RAM:Size = 64 Mbytes FLASH: Intel 32M ZyNOS Version: V3.70(AIF.0)b1 | 06/17/2006 Press any key to enter debug mode within 3 seconds.....
Page 58 ES-2724 User’s Guide Chapter 4 The Web Configurator...
Page 59: Initial Setup Example
ES-2724 User’s Guide H A P T E R Initial Setup Example This chapter shows how to set up the switch for an example network. 5.1 Overview The following lists the configuration steps for the example network: • Configure an IP interface •...
Page 60: Configuring Dhcp Server Settings
ES-2724 User’s Guide 2 Open your web browser and enter 192.168.0.1 (the default MGMT port IP address) in the address bar to access the web configurator. See Section 4.2 on page 47 for more information. 3 Click Basic Setting and IP Setup in the navigation panel.
Page 61: Creating A Vlan
ES-2724 User’s Guide 5.1.3 Creating a VLAN VLANs confine broadcast frames to the VLAN group in which the port(s) belongs. You can do this with port-based VLAN or tagged static VLAN with fixed port members. In this example, you want to configure port 1 as a member of VLAN 2.
Page 62: Setting Port Vid
ES-2724 User’s Guide 3 Since the VLAN2 network is connected to port 1 on the switch, select Fixed to configure port 1 to be a permanent member of the VLAN only. 4 To ensure that VLAN-unaware devices (such as computers and hubs) can receive frames properly, clear the TX Tagging check box to set the switch to remove VLAN tags before sending.
Page 63 ES-2724 User’s Guide 2 Select Both in the Direction field to set the switch to broadcast and receive routing information. 3 In the Version field, select RIP-1 for the RIP packet format that is universally supported. 4 Click Apply to save your changes back to the run-time memory.
Page 64 ES-2724 User’s Guide Chapter 5 Initial Setup Example...
Page 65: System Status And Port Statistics
ES-2724 User’s Guide H A P T E R System Status and Port Statistics This chapter describes the system status (web configurator home page) and port details screens. 6.1 Overview The home screen of the web configurator displays a port statistical summary with links to each port showing statistical details.
Page 66: Status: Port Details
ES-2724 User’s Guide Table 6 Status (continued) LABEL DESCRIPTION State If STP (Spanning Tree Protocol) is enabled, this field displays the STP state of the port (see Section 11.1.3 on page 102 for more information). If STP is disabled, this field displays FORWARDING if the link is up, otherwise, it displays STOP.
Page 67: Figure 24 Status: Port Details
ES-2724 User’s Guide Figure 24 Status: Port Details The following table describes the labels in this screen. Table 7 Status: Port Details LABEL DESCRIPTION Port Info Port NO. This field displays the port number you are viewing. Name This field displays the name of the port.
Page 68 ES-2724 User’s Guide Table 7 Status: Port Details (continued) LABEL DESCRIPTION Tx KB/s This field shows the number kilobytes per second transmitted on this port. Rx KB/s This field shows the number of kilobytes per second received on this port.
Page 69 ES-2724 User’s Guide Table 7 Status: Port Details (continued) LABEL DESCRIPTION 128-255 This field shows the number of packets (including bad packets) received that were between 128 and 255 octets in length. 256-511 This field shows the number of packets (including bad packets) received that were between 256 and 511 octets in length.
Page 70 ES-2724 User’s Guide Chapter 6 System Status and Port Statistics...
Page 71: Chapter 7 Basic Setting
ES-2724 User’s Guide H A P T E R Basic Setting This chapter describes how to configure the System Info, General Setup, Switch Setup, IP Setup and Port Setup screens. 7.1 Overview The System Info screen displays general switch information (such as firmware version number) and hardware polling information (such as fan speeds).
Page 72: Figure 25 System Info
ES-2724 User’s Guide Figure 25 System Info The following table describes the labels in this screen. Table 8 System Info LABEL DESCRIPTION System Name This field displays the descriptive name of the switch for identification purposes. ZyNOS F/W This field displays the version number of the switch 's current firmware including the Version date created.
Page 73: General Setup
ES-2724 User’s Guide Table 8 System Info (continued) LABEL DESCRIPTION Fan Speed A properly functioning fan is an essential component (along with a sufficiently (RPM) ventilated, cool operating environment) in order for the device to stay within the temperature threshold. Each fan has a sensor that is capable of detecting and reporting if the fan speed falls below the threshold shown.
Page 74: Figure 26 General Setup
ES-2724 User’s Guide Figure 26 General Setup The following table describes the labels in this screen. Table 9 General Setup LABEL DESCRIPTION System Name Choose a descriptive name for identification purposes. This name consists of up to 64 printable ASCII characters; spaces are allowed.
Page 75: Introduction To Vlans
ES-2724 User’s Guide Table 9 General Setup (continued) LABEL DESCRIPTION Use Time Server Enter the time service protocol that your timeserver uses. Not all time servers when Bootup support all protocols, so you may have to use trial and error to find a protocol that works.
Page 76: Switch Setup Screen
ES-2724 User’s Guide Note: VLAN is unidirectional; it only governs outgoing traffic. Chapter 8 on page 81 for information on port-based and 802.1Q tagged VLANs. 7.5 Switch Setup Screen Click Basic Setting and then Switch Setup in the navigation panel to display the screen as shown.
Page 77: Ip Setup
ES-2724 User’s Guide Table 10 Switch Setup (continued) LABEL DESCRIPTION Join Timer Join Timer sets the duration of the Join Period timer for GVRP in milliseconds. Each port has a Join Period timer. The allowed Join Time range is between 100 and 65535 milliseconds;...
Page 78: Ip Interfaces
ES-2724 User’s Guide 7.6.1 IP Interfaces The switch needs an IP address for it to be managed over the network. The factory default IP address is 192.168.1.1. The subnet mask specifies the network number portion of an IP address. The factory default subnet mask is 255.255.255.0.
Page 79: Table 11 Ip Setup
ES-2724 User’s Guide The following table describes the labels in this screen. Table 11 IP Setup LABEL DESCRIPTION Default Enter the IP address of the default outgoing gateway in dotted decimal notation, for Gateway example 192.168.1.254. Domain Name DNS (Domain Name System) is for mapping a domain name to its corresponding IP Server address and vice versa.
Page 80: Port Setup
ES-2724 User’s Guide Table 11 IP Setup (continued) LABEL DESCRIPTION Delete Click Delete to remove the selected entry from the summary table. Note: Deleting all IP subnets locks you out from the switch. Cancel Click Cancel to clear the Delete check boxes.
Page 81 ES-2724 User’s Guide Table 12 Port Setup (continued) LABEL DESCRIPTION Name Enter a descriptive name that identifies this port. You can enter up to 64 alpha- numerical characters. Note: Due to space limitation, the port name may be truncated in some web configurator screens.
Page 82 ES-2724 User’s Guide Chapter 7 Basic Setting...
Page 83: Chapter 8 Vlan
ES-2724 User’s Guide H A P T E R VLAN The type of screen you see here depends on the VLAN Type you selected in the Switch Setup screen. This chapter shows you how to configure 802.1Q tagged and port-based VLANs.
Page 84: Automatic Vlan Registration
ES-2724 User’s Guide 8.2 Automatic VLAN Registration GARP and GVRP are the protocols used to automatically register VLAN membership across switches. 8.2.1 GARP GARP (Generic Attribute Registration Protocol) allows network switches to register and de- register attribute values with other GARP participants within a bridged LAN. GARP is a protocol that provides a generic mechanism for protocols that serve a more specific application, for example, GVRP.
Page 85: Port Vlan Trunking
ES-2724 User’s Guide Table 13 IEEE 802.1Q VLAN Terminology (continued) VLAN PARAMETER TERM DESCRIPTION VLAN Port Port VID This is the VLAN ID assigned to untagged frames that this port received. Acceptable Frame You may choose to accept both tagged and untagged...
Page 86: Static Vlan
ES-2724 User’s Guide Figure 31 Switch Setup: Select VLAN Type 8.5 Static VLAN Use a static VLAN to decide whether an incoming frame on a port should be • sent to a VLAN group as normal depending on its VLAN tag.
Page 87: Static Vlan Details
ES-2724 User’s Guide Table 14 VLAN: VLAN Status (continued) LABEL DESCRIPTION Status This field shows how this VLAN was added to the switch; dynamic - using GVRP, static - added as a permanent entry or other - added in another way such as via Multicast VLAN Registration (MVR).
Page 88: Figure 34 Vlan: Static Vlan
ES-2724 User’s Guide Figure 34 VLAN: Static VLAN The following table describes the related labels in this screen. Table 16 VLAN: Static VLAN LABEL DESCRIPTION ACTIVE Select this check box to activate the VLAN settings. Name Enter a descriptive name for the VLAN group for identification purposes. This name consists of up to 64 printable characters;...
Page 89: Configure Vlan Port Settings
ES-2724 User’s Guide Table 16 VLAN: Static VLAN (continued) LABEL DESCRIPTION Click Add to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 90: Protocol Based Vlans
ES-2724 User’s Guide The following table describes the labels in this screen. Table 17 VLAN: VLAN Port Setting LABEL DESCRIPTION GVRP GVRP (GARP VLAN Registration Protocol) is a registration protocol that defines a way for switches to register necessary VLAN members on ports across the network.
Page 91: Configuring Protocol Based Vlan
ES-2724 User’s Guide Note: Protocol based VLAN applies to un-tagged packets and is applicable only when you use IEEE 802.1Q tagged VLAN. For example, port 1, 2, 3 and 4 belong to static VLAN 100, and port 4, 5, 6, 7 belong to static VLAN 120.
Page 92: Figure 37 Protocol Based Vlan
ES-2724 User’s Guide Figure 37 Protocol Based VLAN The following table describes the labels in this screen. Table 18 Protocol Based VLAN Setup LABEL DESCRIPTION Active Check this box to activate this protocol based VLAN. Port Type a port to be included in this protocol based VLAN.
Page 93: Create An Ip-Based Vlan Example
ES-2724 User’s Guide Table 18 Protocol Based VLAN Setup (continued) LABEL DESCRIPTION This field shows the VLAN ID of the port. Priority This field shows the priority which is assigned to frames belonging to this protocol based VLAN. Delete Click this to delete the protocol based VLANs which you marked for deletion.
Page 94: Port-Based Vlan Setup
ES-2724 User’s Guide 8.9 Port-based VLAN Setup Port-based VLANs are VLANs where the packet forwarding decision is based on the destination MAC address and its associated port. Port-based VLANs require allowed outgoing ports to be defined for each port. Therefore, if...
Page 95: Figure 39 Port Based Vlan Setup (All Connected)
ES-2724 User’s Guide Figure 39 Port Based VLAN Setup (All Connected) Chapter 8 VLAN...
Page 96: Figure 40 Port Based Vlan Setup (Port Isolation)
ES-2724 User’s Guide Figure 40 Port Based VLAN Setup (Port Isolation) Chapter 8 VLAN...
Page 97: Table 19 Port Based Vlan Setup
ES-2724 User’s Guide The following table describes the labels in this screen. Table 19 Port Based VLAN Setup LABEL DESCRIPTION Setting Wizard Choose All connected or Port isolation. All connected means all ports can communicate with each other, that is, there are no virtual LANs.
Page 98 ES-2724 User’s Guide Chapter 8 VLAN...
Page 99: Static Mac Forward Setup
ES-2724 User’s Guide H A P T E R Static MAC Forward Setup Use these screens to configure static MAC address forwarding. 9.1 Overview This chapter discusses how to configure forwarding rules based on MAC addresses of devices on your network.
Page 100: Figure 41 Static Mac Forwarding
ES-2724 User’s Guide Figure 41 Static MAC Forwarding The following table describes the labels in this screen. Table 20 Static MAC Forwarding LABEL DESCRIPTION Active Select this check box to activate your rule. You may temporarily deactivate a rule without deleting it by clearing this check box.
Page 101: Chapter 10 Filtering
ES-2724 User’s Guide H A P T E R Filtering This chapter discusses MAC address port filtering. 10.1 Configure a Filtering Rule Filtering means sifting traffic going through the switch based on the source and/or destination MAC addresses and VLAN group (ID).
Page 102 ES-2724 User’s Guide Table 21 FIltering (continued) LABEL DESCRIPTION Action Select Discard source to drop frame from the source MAC address (specified in the MAC field). The switch can still send frames to the MAC address. Select Discard destination to drop frames to the destination MAC address (specified in the MAC address).
Page 103: Spanning Tree Protocol
ES-2724 User’s Guide H A P T E R Spanning Tree Protocol The switch supports Spanning Tree Protocol (STP) and Rapid Spanning Tree Protocol (RSTP) as defined in the following standards. • IEEE 802.1D Spanning Tree Protocol • IEEE 802.1w Rapid Spanning Tree Protocol The switch also allows you to set up multiple STP configurations (or trees).
Page 104: How Stp Works
ES-2724 User’s Guide Table 22 STP Path Costs RECOMMENDED LINK SPEED RECOMMENDED VALUE ALLOWED RANGE RANGE Path Cost 16Mbps 40 to 400 1 to 65535 Path Cost 100Mbps 10 to 60 1 to 65535 Path Cost 1Gbps 3 to 10...
Page 105: Multiple Rstp
ES-2724 User’s Guide Table 23 STP Port States PORT STATE DESCRIPTION Learning All BPDUs are received and processed. Information frames are submitted to the learning process but not forwarded. Forwarding All BPDUs are received and processed. All information frames are received and forwarded.
Page 106: Configure Rapid Spanning Tree Protocol
ES-2724 User’s Guide Figure 44 Spanning Tree Protocol RSTP and MRSTP The following table describes the labels in this screen. Table 24 Spanning Tree Protocol: Status LABEL DESCRIPTION RSTP This link takes you to the Rapid Spanning Tree Protocol configuration screen. See Section 11.3 on page...
Page 107: Figure 45 Rstp: Configuration
ES-2724 User’s Guide Figure 45 RSTP: Configuration Chapter 11 Spanning Tree Protocol...
Page 108: Table 25 Rstp: Configuration
ES-2724 User’s Guide The following table describes the labels in this screen. Table 25 RSTP: Configuration LABEL DESCRIPTION Status Click Status to display the RSTP Status screen (see Figure 46 on page 107). Active Select this check box to activate RSTP. Clear this checkbox to disable RSTP.
Page 109: Rapid Spanning Tree Protocol Status
ES-2724 User’s Guide Table 25 RSTP: Configuration (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 110: Configure Multiple Rapid Spanning Tree Protocol
ES-2724 User’s Guide Table 26 Rapid Spanning Tree Protocol: Status (continued) LABEL DESCRIPTION Forwarding Delay This is the time (in seconds) the root switch will wait before changing states (that (second) is, listening to learning to forwarding). Cost to Bridge This is the path cost from the root port on this switch to the root switch.
Page 111: Table 27 Mrstp: Configuration
ES-2724 User’s Guide The following table describes the labels in this screen. Table 27 MRSTP: Configuration LABEL DESCRIPTION Status Click Status to display the MRSTP Status screen (see Figure 46 on page 107). Tree This is a read only index number of the STP trees.
Page 112: Multiple Rapid Spanning Tree Protocol Status
ES-2724 User’s Guide Table 27 MRSTP: Configuration (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 113 ES-2724 User’s Guide Table 28 Spanning Tree Protocol: Status (continued) LABEL DESCRIPTION Max Age (second) This is the maximum time (in seconds) a switch can wait without receiving a configuration message before attempting to reconfigure. Forwarding Delay This is the time (in seconds) the root switch will wait before changing states (that (second) is, listening to learning to forwarding).
Page 114 ES-2724 User’s Guide Chapter 11 Spanning Tree Protocol...
Page 115: Chapter 12 Bandwidth Control
ES-2724 User’s Guide H A P T E R Bandwidth Control This chapter shows you how you can cap the maximum bandwidth using the Bandwidth Control screen. 12.1 Bandwidth Control Overview Bandwidth control means defining a maximum allowable bandwidth for incoming and/or out- going traffic flows on a port.
Page 116: Figure 49 Bandwidth Control
ES-2724 User’s Guide Figure 49 Bandwidth Control The following table describes the related labels in this screen. Table 29 Bandwidth Control LABEL DESCRIPTION Active Select this check box to enable bandwidth control on the switch. Port This field displays the port number.
Page 117: Broadcast Storm Control
ES-2724 User’s Guide H A P T E R Broadcast Storm Control This chapter introduces and shows you how to configure the broadcast storm control feature. 13.1 Broadcast Storm Control Setup Broadcast storm control limits the number of broadcast, multicast and destination lookup failure (DLF) packets the switch receives per second on the ports.
Page 118: Figure 50 Broadcast Storm Control
ES-2724 User’s Guide Figure 50 Broadcast Storm Control The following table describes the labels in this screen. Table 30 Broadcast Storm Control LABEL DESCRIPTION Active Select this check box to enable traffic storm control on the switch. Clear this check box to disable this feature.
Page 119: Chapter 14 Mirroring
ES-2724 User’s Guide H A P T E R Mirroring This chapter discusses port mirroring setup screens. 14.1 Port Mirroring Setup Port mirroring allows you to copy a traffic flow to a monitor port (the port you copy the traffic to) in order that you can examine the traffic from the monitor port without interference.
Page 120: Figure 51 Mirroring
ES-2724 User’s Guide Figure 51 Mirroring The following table describes the labels in this screen. Table 31 Mirroring LABEL DESCRIPTION Active Select this check box to activate port mirroring on the switch. Clear this check box to disable the feature.
Page 121: Chapter 15 Link Aggregation
ES-2724 User’s Guide H A P T E R Link Aggregation This chapter shows you how to logically aggregate physical links to form one logical, higher- bandwidth link. 15.1 Link Aggregation Overview Link aggregation (trunking) is the grouping of physical ports into one logical higher-capacity link.
Page 122: Link Aggregation Id
ES-2724 User’s Guide 15.2.1 Link Aggregation ID LACP aggregation ID consists of the following information Table 32 Link Aggregation ID: Local Switch SYSTEM PRIORITY MAC ADDRESS PORT PRIORITY PORT NUMBER 0000 00-00-00-00-00 0000 0000 Table 33 Link Aggregation ID: Peer Switch...
Page 123: Link Aggregation Setup
ES-2724 User’s Guide Figure 52 Link Aggregation Control Protocol Status The following table describes the labels in this screen. Table 34 Link Aggregation Control Protocol Status LABEL DESCRIPTION Index This field displays the trunk ID to identify a trunk group, that is, one logical link containing multiple ports.
Page 124: Figure 53 Link Aggregation Control Protocol: Configuration
ES-2724 User’s Guide Figure 53 Link Aggregation Control Protocol: Configuration The following table describes the labels in this screen. Table 35 Link Aggregation Control Protocol: Configuration LABEL DESCRIPTION Link Aggregation Control Protocol Active Select this checkbox to enable Link Aggregation Control Protocol (LACP).
Page 125 ES-2724 User’s Guide Table 35 Link Aggregation Control Protocol: Configuration (continued) LABEL DESCRIPTION Port This field displays the port number. Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 126 ES-2724 User’s Guide Chapter 15 Link Aggregation...
Page 127: Chapter 16 Port Authentication
ES-2724 User’s Guide H A P T E R Port Authentication This chapter describes the 802.1x authentication method and RADIUS server connection setup. See Section 41.9 on page 285 for information on how to use the commands to configure additional Radius server settings as well as multiple Radius server configuration.
Page 128: Tunnel Protocol Attribute
ES-2724 User’s Guide Note: Refer to the documentation that comes with your RADIUS server on how to configure a VSA. The following table describes the VSAs supported on the switch. Table 36 Supported VSA FUNCTION ATTRIBUTE Ingress Bandwidth Vendor-Id = 890...
Page 129: Configuring Radius Server Settings
ES-2724 User’s Guide Click Advanced Application, Port Authentication in the navigation panel to display the screen as shown. Figure 55 Port Authentication 16.2.1 Configuring RADIUS Server Settings Use this screen to configure your RADIUS server settings. See Section 16.1.1 on page 125 more information on RADIUS servers.
Page 130: Activate Ieee 802.1X Security
ES-2724 User’s Guide 16.2.2 Activate IEEE 802.1x Security Use this screen to activate IEEE 802.1x security. From the Port Authentication screen, display the configuration screen as shown. Figure 57 Port Authentication: 802.1x The following table describes the labels in this screen.
Page 131 ES-2724 User’s Guide Table 39 Port Authentication: 802.1x (continued) LABEL DESCRIPTION Reauthentication Specify how often a client has to re-enter his or her username and password to stay Timer connected to the port. Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses...
Page 132 ES-2724 User’s Guide Chapter 16 Port Authentication...
Page 133: Port Security
ES-2724 User’s Guide H A P T E R Port Security This chapter shows you how to set up port security. 17.1 About Port Security Port security allows only packets with dynamically learned MAC addresses and/or configured static MAC addresses to pass through a port on the switch. The switch can learn up to 16K MAC addresses in total with no limit on individual ports other than the sum cannot exceed 16K.
Page 134: Figure 58 Port Security
ES-2724 User’s Guide Figure 58 Port Security The following table describes the labels in this screen. Table 40 Port Security LABEL DESCRIPTION Active Select this option to enable port security on the switch. Port This field displays a port number.
Page 135 ES-2724 User’s Guide Table 40 Port Security (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 136: Table 40 Port Security
ES-2724 User’s Guide Chapter 17 Port Security...
Page 137: Chapter 18 Classifier
ES-2724 User’s Guide H A P T E R Classifier This chapter introduces and shows you how to configure the packet classifier on the switch. 18.1 About the Classifier and QoS Quality of Service (QoS) refers to both a network's ability to deliver data with minimum delay, and the networking methods used to control the use of bandwidth.
Page 138: Figure 59 Classifier
ES-2724 User’s Guide Figure 59 Classifier The following table describes the labels in this screen. Table 41 Classifier LABEL DESCRIPTION Active Select this option to enable this rule. Name Enter a descriptive name for this rule for identifying purposes. Packet Specify the format of the packet.
Page 139 ES-2724 User’s Guide Table 41 Classifier (continued) LABEL DESCRIPTION Priority Select Any to classify traffic from any priority level or select the second option and specify a priority level in the field provided. Ethernet Select an Ethernet type or select Other and enter the Ethernet type number in Type hexadecimal value.
Page 140: Viewing And Editing Classifier Configuration
ES-2724 User’s Guide Table 41 Classifier (continued) LABEL DESCRIPTION Cancel Click Cancel to reset the fields back to your previous configuration. Clear Click Clear to set the above fields back to the factory defaults. 18.3 Viewing and Editing Classifier Configuration To view a summary of the classifier configuration, scroll down to the summary table at the bottom of the Classifier screen.
Page 141: Classifier Example
ES-2724 User’s Guide Table 43 Common Ethernet Types and Protocol Number ETHERNET TYPE PROTOCOL NUMBER X.25 Level 3 0805 XNS Compat 0807 Banyan Systems 0BAD BBN Simnet 5208 IBM SNA 80D5 AppleTalk AARP 80F3 Some of the most common IP ports are:...
Page 142: Figure 61 Classifier: Example
ES-2724 User’s Guide Figure 61 Classifier: Example Chapter 18 Classifier...
Page 143: Policy Rule
ES-2724 User’s Guide H A P T E R Policy Rule This chapter shows you how to configure policy rules. 19.1 Policy Rules Overview A classifier distinguishes traffic into flows based on the configured criteria (refer to Chapter 18 on page 135 for more information).
Page 144: Figure 62 Policy
ES-2724 User’s Guide Figure 62 Policy The following table describes the labels in this screen. Table 45 Policy LABEL DESCRIPTION Active Select this option to enable the policy. Name Enter a descriptive name for identification purposes. Classifier(s) This field displays the active classifier(s) you configure in the Classifier screen.
Page 145 ES-2724 User’s Guide Table 45 Policy (continued) LABEL DESCRIPTION Parameters Set the fields below for this policy. You only have to set the field(s) that is related to the action(s) you configure in the Action field. General VLAN ID Specify a VLAN ID number.
Page 146: Viewing And Editing Policy Configuration
ES-2724 User’s Guide Table 45 Policy (continued) LABEL DESCRIPTION Outgoing Select Send the packet to the mirror port to send the packet to the mirror port. Select Send the packet to the egress port to send the packet to the egress port.
Page 147: Policy Example
ES-2724 User’s Guide Table 46 Policy: Summary Table (continued) LABEL DESCRIPTION Delete Click Delete to remove the selected entry from the summary table. Cancel Click Cancel to clear the Delete check boxes. 19.4 Policy Example The figure below shows an example Policy screen where you configure a policy to limit...
Page 148: Figure 64 Policy Example
ES-2724 User’s Guide Figure 64 Policy Example Chapter 19 Policy Rule...
Page 149: Chapter 20 Queuing Method
ES-2724 User’s Guide H A P T E R Queuing Method This chapter introduces the queuing methods supported. 20.1 Queuing Method Overview Queuing is used to help solve performance degradation when there is network congestion. Use the Queuing Method screen to configure queuing algorithms for outgoing traffic. See also Priority Queue Assignment in Switch Setup and 802.1p Priority in Port Setup for related...
Page 150: Weighted Round Robin Scheduling (Wrr)
ES-2724 User’s Guide 20.1.3 Weighted Round Robin Scheduling (WRR) Round Robin Scheduling services queues on a rotating basis and is activated only when a port has more traffic than it can handle. A queue is a given an amount of bandwidth irrespective of the incoming traffic on that port.
Page 151: Figure 65 Queuing Method
ES-2724 User’s Guide Figure 65 Queuing Method Chapter 20 Queuing Method...
Page 152: Table 47 Queuing Method
ES-2724 User’s Guide The following table describes the labels in this screen. Table 47 Queuing Method LABEL DESCRIPTION Method Select SPQ (Strictly Priority Queuing), WFQ (Weighted Fair Queuing) or WRR (Weighted Round Robin). Strictly Priority services queues based on priority only. When the highest priority queue empties, traffic on the next highest-priority queue begins.
Page 153: Chapter 21 Vlan Stacking
ES-2724 User’s Guide H A P T E R VLAN Stacking This chapter shows you how to configure VLAN stacking on your switch. See the chapter on VLANs for more background information on Virtual LAN 21.1 VLAN Stacking Overview A service provider can use VLAN stacking to allow it to distinguish multiple customers VLANs, even those with the same (customer-assigned) VLAN ID, within its network.
Page 154: Vlan Stacking Port Roles
ES-2724 User’s Guide Figure 66 VLAN Stacking Example 21.2 VLAN Stacking Port Roles Each port can have three VLAN stacking “roles”, Normal, Access Port and Tunnel (the latter is for Gigabit ports only). • Select Normal for “regular” (non-VLAN stacking) IEEE 802.1Q frame switching.
Page 155: Frame Format
ES-2724 User’s Guide Type is a standard Ethernet type code identifying the frame and indicates that whether the frame carries IEEE 802.1Q tag information. SP TPID (Service Provider Tag Protocol Identifier) is the service provider VLAN stacking tag type. Many vendors use 0x8100 or 0x9100.
Page 156: Configuring Vlan Stacking
ES-2724 User’s Guide 21.4 Configuring VLAN Stacking Click Advanced Applications and then VLAN Stacking to display the screen as shown. Figure 67 VLAN Stacking The following table describes the labels in this screen. Table 51 VLAN Stacking LABEL DESCRIPTION Active Select this checkbox to enable VLAN stacking on the switch.
Page 157 ES-2724 User’s Guide Table 51 VLAN Stacking (continued) LABEL DESCRIPTION Role Select Normal to have the switch ignore frames received (or transmitted) on this port with VLAN stacking tags. Anything you configure in SPVID and Priority are ignored. Select Access Port to have the switch add the SP TPID tag to all incoming frames received on this port.
Page 158: Table 51 Vlan Stacking
ES-2724 User’s Guide Chapter 21 VLAN Stacking...
Page 159: Chapter 22 Multicast
ES-2724 User’s Guide H A P T E R Multicast This chapter shows you how to configure various multicast features. 22.1 Multicast Overview Traditionally, IP packets are transmitted in one of either two ways - Unicast (1 sender to 1 recipient) or Broadcast (1 sender to everybody on the network).
Page 160: Multicast Status
ES-2724 User’s Guide The switch forwards multicast traffic destined for multicast groups (that it has learned from IGMP snooping or that you have manually configured) to ports that are members of that group. IGMP snooping generates no additional network traffic, allowing you to significantly reduce multicast traffic passing through your switch.
Page 161: Figure 69 Multicast: Setting
ES-2724 User’s Guide Figure 69 Multicast: Setting The following table describes the labels in this screen. Table 53 Multicast Setting LABEL DESCRIPTION IGMP Snooping Use these settings to configure IGMP Snooping. Active Select Active to enable IGMP Snooping to forward group multicast traffic only to ports that are members of that group.
Page 162 ES-2724 User’s Guide Table 53 Multicast Setting (continued) LABEL DESCRIPTION Reserved Multicast addresses (224.0.0.0 to 224.0.0.255) are reserved for the local scope. Multicast Group For examples, 224.0.0.1 is for all hosts in this subnet, 224.0.0.2 is for all multicast routers in this subnet, etc. A router will not forward a packet with the destination IP address within this range.
Page 163: Igmp Filtering Profile
ES-2724 User’s Guide 22.4 IGMP Filtering Profile IGMP filter profiles allow you to control access to IGMP multicast groups. This allows you to have a service available to a specific IGMP multicast group. You can configure an IGMP filter profile for an IGMP multicast group that has access to a service (like a SIP server for example).
Page 164: Mvr Overview
ES-2724 User’s Guide Table 54 Multicast: IGMP Filtering Profile (continued) LABEL DESCRIPTION Delete To delete the profile(s) and all the accompanying rules, select the profile(s) that you want to remove in the Delete Profile column, then click the Delete button.
Page 165: How Mvr Works
ES-2724 User’s Guide In dynamic mode, the switch sends IGMP leave and join reports to the other multicast devices (such as multicast routers or servers) in the multicast VLAN. This allows the multicast devices to update the multicast forwarding table to forward or not forward multicast traffic to the receiver ports.
Page 166: Figure 73 Multicast: Setting: Mvr
ES-2724 User’s Guide Figure 73 Multicast: Setting: MVR The following table describes the related labels in this screen. Table 55 MVR LABEL DESCRIPTION Active Select this check box to enable MVR to allow one single multicast VLAN to be shared among different subscriber VLANs on the network.
Page 167: Mvr Group Configuration
ES-2724 User’s Guide Table 55 MVR (continued) LABEL DESCRIPTION Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 168: Figure 74 Mvr: Group Configuration
ES-2724 User’s Guide Figure 74 MVR: Group Configuration The following table describes the labels in this screen. Table 56 MVR: Group Configuration LABEL DESCRIPTION Multicast Select a multicast VLAN ID (that you configured in the MVR screen) from the drop- VLAN ID down list box.
Page 169: Mvr Configuration Example
ES-2724 User’s Guide 22.7.1 MVR Configuration Example The following figure shows a network example where ports 1, 2 and 3 on the switch belong to VLAN 1. In addition, port 7 belongs to the multicast group with VID 200 to receive multicast traffic (the News and Movie channels) from the remote streaming media server, S.
Page 170: Figure 77 Mvr Group Configuration Example
ES-2724 User’s Guide Figure 77 MVR Group Configuration Example Figure 78 MVR Group Configuration Example Chapter 22 Multicast...
Page 171: Chapter 23 Static Route
ES-2724 User’s Guide H A P T E R Static Route This chapter shows you how to configure static routes. 23.1 Configuring Static Routing Static routes tell the switch how to forward IP traffic when you configure the TCP/IP parameters manually.
Page 172 ES-2724 User’s Guide Table 57 Static Routing (continued) LABEL DESCRIPTION Metric The metric represents the “cost” of transmission for routing purposes. IP routing uses hop count as the measurement of cost, with a minimum of 1 for directly connected networks. Enter a number that approximates the cost for this link. The number need not be precise, but it must be between 1 and 15.
Page 173: Chapter 24 Rip
ES-2724 User’s Guide H A P T E R This chapter shows you how to configure RIP (Routing Information Protocol). 24.1 RIP Overview RIP (Routing Information Protocol) allows a routing device to exchange routing information with other routers. The Direction field controls the sending and receiving of RIP packets.
Page 174: Table 58 Rip
ES-2724 User’s Guide Figure 80 RIP The following table describes the labels in this screen. Table 58 RIP LABEL DESCRIPTION Active Select this check box to enable RIP on the switch. Index This field displays the index number of an IP interface.
Page 175: Chapter 25 Igmp
ES-2724 User’s Guide H A P T E R IGMP This chapter shows you how to configure IGMP. 25.1 IGMP Overview IGMP (Internet Group Multicast Protocol) is a session-layer protocol used to establish membership in a multicast group - it is not used to carry user data. Refer to RFC 1112 and RFC 2236 for information on IGMP versions 1 and 2 respectively.
Page 176: Table 59 Igmp
ES-2724 User’s Guide Table 59 IGMP (continued) LABEL DESCRIPTION Network This field displays the IP domain configured on the switch. Refer to Section 7.6 on page 75 for more information on configuring IP domains. Version Select an IGMP version from the drop-down list box. Choices are IGMP-v1, IGMP-v2 and None.
Page 177: Chapter 26 Ip Multicast
ES-2724 User’s Guide H A P T E R IP Multicast This chapter shows you how to configure the IP Multicast screen. 26.1 IP Multicast Overview Traditionally, IP packets are transmitted in one of either two ways - Unicast (one sender to one recipient) or Broadcast (one sender to everybody on the network).
Page 178: Table 60 Ip Multicast
ES-2724 User’s Guide Table 60 IP Multicast LABEL DESCRIPTION Port This read-only field displays the port number. Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 179: Differentiated Services
ES-2724 User’s Guide H A P T E R Differentiated Services This chapter shows you how to configure Differentiated Services (DiffServ) on the switch. 27.1 DiffServ Overview Quality of Service (QoS) is used to prioritize source-to-destination traffic flows. All packets in the flow are given the same priority.
Page 180: Activating Diffserv
ES-2724 User’s Guide Figure 84 DiffServ Network Example Switch A marks traffic flowing into the network based on the configured marking rules. Intermediary network devices 1 and 2 allocate network resources (such as bandwidth) by mapping the DSCP values and the associated policies.
Page 181: Dscp-To-Ieee802.1P Priority Settings
ES-2724 User’s Guide Table 61 DiffServ (continued) LABEL DESCRIPTION Settings in this row apply to all ports. Use this row only if you want to make some settings the same for all ports. Use this row first to set the common settings and then make adjustments on a port-by-port basis.
Page 182: Figure 86 Diffserv: Dscp Setting
ES-2724 User’s Guide Figure 86 DiffServ: DSCP Setting The following table describes the labels in this screen. Table 63 DiffServ: DSCP Setting LABEL DESCRIPTION 0 … 63 This is the DSCP classification identification number. To set the IEEE802.1p priority mapping, select the priority level from the drop-down list box.
Page 183: Chapter 28 Dhcp
ES-2724 User’s Guide H A P T E R DHCP This chapter shows you how to configure the DHCP feature. 28.1 DHCP Overview DHCP (Dynamic Host Configuration Protocol RFC 2131 and RFC 2132) allows individual computers to obtain TCP/IP configuration at start-up from a server. You can configure the switch as a DHCP server or disable it.
Page 184: Configuring Dhcp Server
ES-2724 User’s Guide Figure 87 DHCP: DHCP Server Status The following table describes the labels in this screen. Table 64 DHCP: DHCP Server Status LABEL DESCRIPTION Index This is the index number. This field displays the ID number of the VLAN group to which this DHCP settings apply.
Page 185: Figure 88 Dhcp: Server
ES-2724 User’s Guide Figure 88 DHCP: Server The following table describes the labels in this screen. Table 65 DHCP: Server LABEL DESCRIPTION Enter the ID number of the VLAN group to which this DHCP settings apply. Client IP Pool Specify the first of the contiguous addresses in the IP address pool.
Page 186: Dhcp Server Configuration Example
ES-2724 User’s Guide 28.3.1 DHCP Server Configuration Example The follow figure shows a network example where the switch is used to assign network information to the DHCP clients in the RD and Sales network. Figure 89 DHCP Server Network Example In the DHCP Server screen, configure two DHCP client IP address pools for the two networks.
Page 187: Dhcp Relay Agent Information
ES-2724 User’s Guide 28.4.1 DHCP Relay Agent Information The switch can add information to client DHCP requests that it relays to a DHCP server. This helps provide authentication about the source of the requests. You can also specify additional information for the switch to add to the client DHCP requests that it relays to the DHCP server.
Page 188: Dhcp Relay Configuration Example
ES-2724 User’s Guide Table 66 DHCP: Relay (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 189: Figure 93 Dhcp Relay Configuration Example
ES-2724 User’s Guide Figure 93 DHCP Relay Configuration Example Chapter 28 DHCP...
Page 190 ES-2724 User’s Guide Chapter 28 DHCP...
Page 191: Chapter 29 Maintenance
ES-2724 User’s Guide H A P T E R Maintenance This chapter explains how to configure the maintenance screens that let you maintain the firmware and configuration files. 29.1 The Maintenance Screen Use this screen to manage firmware and your configuration files. Click Management, Maintenance in the navigation panel to open the following screen.
Page 192: Load Factory Default
ES-2724 User’s Guide Table 67 Maintenance (continued) LABEL DESCRIPTION Save Click Config 1 to save the current configuration settings to Configuration 1 on the Configuration switch. Click Config 2 to save the current configuration settings to Configuration 2 on the switch.
Page 193: Reboot System
ES-2724 User’s Guide 29.4 Reboot System Reboot System allows you to restart the switch without physically turning the power off. It also allows you to load configuration one (Config 1) or configuration two (Config 2) when you reboot. Follow the steps below to reboot the switch.
Page 194: Restore A Configuration File
ES-2724 User’s Guide 29.6 Restore a Configuration File Restore a previously saved configuration from your computer to the switch using the Restore Configuration screen. Figure 98 Restore Configuration Type the path and file name of the configuration file you wish to restore in the File Path text box or click Browse to display the Choose File screen (below) from which you can locate it.
Page 195: Ftp Command Line
ES-2724 User’s Guide 3 Choose a location to save the file on your computer from the Save in drop-down list box and type a descriptive name for it in the File name list box. Click Save to save the configuration file to your computer.
Page 196: Ftp Command Line Procedure
ES-2724 User’s Guide 29.8.2 FTP Command Line Procedure 1 Launch the FTP client on your computer. 2 Enter , followed by a space and the IP address of your switch. open 3 Press [ENTER] when prompted for a username. 4 Enter your password as requested (the default is “1234”).
Page 197: Chapter 30 Access Control
ES-2724 User’s Guide H A P T E R Access Control This chapter describes how to control access to the switch. 30.1 Access Control Overview A console port and FTP are allowed one session each, Telnet and SSH share four sessions, up to five Web sessions (five different usernames and passwords) and/or limitless SNMP access control sessions are allowed.
Page 198: About Snmp
ES-2724 User’s Guide 30.3 About SNMP Simple Network Management Protocol (SNMP) is an application layer protocol used to manage and monitor TCP/IP-based devices. SNMP is used to exchange management information between the network management system (NMS) and a network element (NE). A manager station can manage and monitor the switch through the network via SNMP version one (SNMPv1) and/or SNMP version 2c.
Page 199: Supported Mibs
ES-2724 User’s Guide Table 70 SNMP Commands COMMAND DESCRIPTION Allows the manager to set values for object variables within an agent. Trap Used by the agent to inform the manager of some events. 30.3.1 Supported MIBs MIBs let administrators collect statistics and monitor status and performance.
Page 200: Configuring Snmp
ES-2724 User’s Guide 30.3.3 Configuring SNMP From the Access Control screen, display the SNMP screen. You can click Access Control to go back to the Access Control screen. Figure 102 Access Control: SNMP The following table describes the labels in this screen.
Page 201: Figure 103 Access Control: Logins
ES-2724 User’s Guide • A non-administrator (username is something other than admin) is someone who can view but not configure switch settings. Click Access Control from the navigation panel and then click Logins from this screen. Figure 103 Access Control: Logins The following table describes the labels in this screen.
Page 202: Ssh Overview
ES-2724 User’s Guide Table 73 Access Control: Logins (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 203: Ssh Implementation On The Switch
ES-2724 User’s Guide Figure 105 How SSH Works 1 Host Identification The SSH client sends a connection request to the SSH server. The server identifies itself with a host key. The client encrypts a randomly generated session key with the host key and server key and sends the result back to the server.
Page 204: Requirements For Using Ssh
ES-2724 User’s Guide 30.6.1 Requirements for Using SSH You must install an SSH client program on a client computer (Windows or Linux operating system) that is used to connect to the switch over SSH. 30.7 Introduction to HTTPS HTTPS (HyperText Transfer Protocol over Secure Socket Layer, or HTTP over SSL) is a web protocol that encrypts and decrypts web pages.
Page 205: Https Example
ES-2724 User’s Guide 30.8 HTTPS Example If you haven’t changed the default HTTPS port on the switch, then in your browser enter “https://switch IP Address/” as the web site address where “switch IP Address” is the IP address or domain name of the switch you wish to access.
Page 206: The Main Screen
ES-2724 User’s Guide Figure 108 Security Certificate 1 (Netscape) Figure 109 Security Certificate 2 (Netscape) 30.8.3 The Main Screen After you accept the certificate and enter the login username and password, the switch main screen appears. The lock displayed in the bottom right of the browser status bar denotes a secure connection.
Page 207: Service Port Access Control
ES-2724 User’s Guide Figure 110 Example: Lock Denoting a Secure Connection 30.9 Service Port Access Control Service Access Control allows you to decide what services you may use to access the switch. You may also change the default service port and configure “trusted computer(s)” for each service in the Remote Management screen (discussed later).
Page 208: Remote Management
ES-2724 User’s Guide Figure 111 Access Control: Service Access Control The following table describes the fields in this screen. Table 74 Access Control: Service Access Control LABEL DESCRIPTION Services Services you may use to access the switch are listed here.
Page 209: Figure 112 Access Control: Remote Management
ES-2724 User’s Guide Figure 112 Access Control: Remote Management The following table describes the labels in this screen. Table 75 Access Control: Remote Management LABEL DESCRIPTION Entry This is the client set index number. A “client set” is a group of one or more “trusted computers”...
Page 210 ES-2724 User’s Guide Chapter 30 Access Control...
Page 211: Chapter 31 Diagnostic
ES-2724 User’s Guide H A P T E R Diagnostic This chapter explains the Diagnostic screen. 31.1 Diagnostic Click Management, Diagnostic in the navigation panel to open this screen. Use this screen to check system logs, ping IP addresses or perform port tests.
Page 212 ES-2724 User’s Guide Chapter 31 Diagnostic...
Page 213: Chapter 32 Syslog
ES-2724 User’s Guide H A P T E R Syslog This chapter explains the syslog screens. 32.1 Syslog Overview The syslog protocol allows devices to send event notification messages across an IP network to syslog servers that collect the event messages. A syslog-enabled device can generate a syslog message and send it to a syslog server.
Page 214: Syslog Server Setup
ES-2724 User’s Guide Figure 114 Syslog The following table describes the labels in this screen. Table 78 Syslog LABEL DESCRIPTION Syslog Select Active to turn on syslog (system logging) and then configure the syslog setting Logging Type This column displays the names of the categories of logs that the device can generate.
Page 215: Figure 115 Syslog: Server Setup
ES-2724 User’s Guide Figure 115 Syslog: Server Setup The following table describes the labels in this screen. Table 79 Syslog: Server Setup LABEL DESCRIPTION Active Select this check box to have the device send logs to this syslog server. Clear the check box if you want to create a syslog server entry but not have the device send logs to it (you can edit the entry later).
Page 216 ES-2724 User’s Guide Chapter 32 Syslog...
Page 217: Chapter 33 Cluster Management
ES-2724 User’s Guide H A P T E R Cluster Management This chapter introduces cluster management. 33.1 Clustering Management Status Overview Cluster Management allows you to manage switches through one switch, called the cluster manager. The switches must be directly connected and be in the same VLAN group so as to be able to communicate with one another.
Page 218: Cluster Management Status
ES-2724 User’s Guide Figure 116 Clustering Application Example 33.2 Cluster Management Status Click Management, Cluster Management in the navigation panel to display the following screen. Note: A cluster can only have one manager. Chapter 33 Cluster Management...
Page 219: Cluster Member Switch Management
ES-2724 User’s Guide Figure 117 Cluster Management: Status The following table describes the labels in this screen. Table 81 Cluster Management: Status LABEL DESCRIPTION Status This field displays the role of this switch within the cluster. Manager Member (you see this if you access this screen in the cluster member switch directly...
Page 220: Uploading Firmware To A Cluster Member Switch
ES-2724 User’s Guide Figure 118 Cluster Management: Cluster Member Web Configurator Screen 33.2.1.1 Uploading Firmware to a Cluster Member Switch You can use FTP to upload firmware to a cluster member switch through the cluster manager switch as shown in the following example.
Page 221: Clustering Management Configuration
ES-2724 User’s Guide Figure 119 Example: Uploading Firmware to a Cluster Member Switch C:\>ftp 192.168.1.1 Connected to 192.168.1.1. 220 switch FTP version 1.0 ready at Thu Jan 1 00:58:46 1970 User (192.168.0.1:(none)): admin 331 Enter PASS command Password: 230 Logged in ftp>...
Page 222: Figure 120 Clustering Management Configuration
ES-2724 User’s Guide Figure 120 Clustering Management Configuration The following table describes the labels in this screen. Table 83 Clustering Management Configuration LABEL DESCRIPTION Clustering Manager Active Select Active to have this switch become the cluster manager switch. A cluster can only have one manager.
Page 223 ES-2724 User’s Guide Table 83 Clustering Management Configuration (continued) LABEL DESCRIPTION Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these changes if it is turned off or loses power, so use the Save link on the top navigation panel to save your changes to the non-volatile memory when you are done configuring.
Page 224 ES-2724 User’s Guide Chapter 33 Cluster Management...
Page 225: Chapter 34 Mac Table
ES-2724 User’s Guide H A P T E R MAC Table This chapter introduces the MAC Table screen. 34.1 MAC Table Overview The MAC Table screen (a MAC table is also known as a filtering database) shows how frames are forwarded or filtered across the switch’s ports. It shows what device MAC address,...
Page 226: Viewing The Mac Table
ES-2724 User’s Guide 34.2 Viewing the MAC Table Click Management, MAC Table in the navigation panel to display the following screen. Figure 122 MAC Table The following table describes the labels in this screen. Table 84 MAC Table LABEL DESCRIPTION...
Page 227: Chapter 35 Ip Table
ES-2724 User’s Guide H A P T E R IP Table This chapter introduces the IP table. 35.1 IP Table Overview The IP Table screen shows how packets are forwarded or filtered across the switch’s ports. It shows what device IP address, belonging to what VLAN group (if any) is forwarded to which port(s) and whether the IP address is dynamic (learned by the switch) or static (belonging to the switch).
Page 228: Viewing The Ip Table
ES-2724 User’s Guide 35.2 Viewing the IP Table Click Management, IP Table in the navigation panel to display the following screen. Figure 124 IP Table The following table describes the labels in this screen. Table 85 IP Table LABEL DESCRIPTION...
Page 229: Chapter 36 Arp Table
ES-2724 User’s Guide H A P T E R ARP Table This chapter introduces ARP Table. 36.1 ARP Table Overview Address Resolution Protocol (ARP) is a protocol for mapping an Internet Protocol address (IP address) to a physical machine address, also known as a Media Access Control or MAC address, on the local area network.
Page 230: Figure 125 Arp Table
ES-2724 User’s Guide Figure 125 ARP Table The following table describes the labels in this screen. Table 86 ARP Table LABEL DESCRIPTION Index This is the ARP Table entry number. IP Address This is the learned IP address of a device connected to a switch port with corresponding MAC address below.
Page 231: Chapter 37 Routing Table
ES-2724 User’s Guide H A P T E R Routing Table This chapter introduces the routing table. 37.1 Overview The routing table contains the route information to the network(s) that the switch can reach. The switch automatically updates the routing table with the RIP information received from other Ethernet devices.
Page 232 ES-2724 User’s Guide Chapter 37 Routing Table...
Page 233: Chapter 38 Configure Clone
ES-2724 User’s Guide H A P T E R Configure Clone This chapter shows you how you can copy the settings of one port onto other ports. 38.1 Configure Clone Cloning allows you to copy the basic and advanced settings from a source port to a destination port or ports.
Page 234 ES-2724 User’s Guide Table 88 Configure Clone (continued) LABEL DESCRIPTION Advanced Select which port settings (you configured in the Advanced Application menus) Application should be copied to the destination ports. Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses...
Page 235: Chapter 39 Introducing Commands
ES-2724 User’s Guide H A P T E R Introducing Commands This chapter introduces commands and gives a summary of commands available. 39.1 Overview In addition to the web configurator, you can use commands to configure the switch. Use commands for advanced switch diagnosis and troubleshooting. If you have problems with your switch, customer support may request that you issue some of these commands to assist them in troubleshooting.
Page 236: Initial Screen
You can view the initialization information using the console port. After the initialization, the login screen displays (refer to Section 39.3 on page 234). Copyright (c) 1994 - 2006 ZyXEL Communications Corp. initialize mgmt, ethernet address: 00:13:49:00:00:01 initialize switch, ethernet address: 00:13:49:00:00:02 Initializing switch unit 0...
Page 237: Changing The Password
ES-2724 User’s Guide means that the contact and location fields are optional. • “Command” refers to a command used in the command line interface (CI command). • The | symbol means “or”. • The entry <cr> in the command lines refers to carriage return. Press [ENTER] or carriage return after a command to execute the command.
Page 238: Command Modes
ES-2724 User’s Guide Syntax: logins username <username> password <password> logins username <username> privilege <0-14> where Specifies a new user (up to 32 alphanumeric characters). Enter username <username> a user name to change the settings of an existing account. Specifies the new password (up to 32 alphanumeric password <password>...
Page 239: Getting Help
ES-2724 User’s Guide Table 89 Command Interpreter Mode Summary (continued) HOW TO LOGIN/ MODE DESCRIPTION PROMPT ACCESS config Config Commands available in this mode Type sysname(config)# allow you to configure settings that enable mode. affect the switch globally. Command modes that follow are sub-modes of the config mode and can only be accessed from within the config mode.
Page 240: List Of Available Commands
ES-2724 User’s Guide 39.8.1 List of Available Commands Enter “ ” to display a list of available commands and the corresponding sub commands. help sysname> help Commands available: help logout exit history enable show ip <cr> show hardware-monitor <C|F> show system-information ping <ip|host-name>...
Page 241: Using Command History
ES-2724 User’s Guide Enter to display detailed help information about the sub commands and <command> ? parameters. sysname> ping ? <ip|host-name> destination ip address help Description of ping help sysname> 39.9 Using Command History The switch keeps a list of recently used commands available to you for reuse. You can use any...
Page 242: Logging Out
ES-2724 User’s Guide • Use the same configuration file to set all switches (of the same model) in your network to the same settings. Note: You may also edit a configuration file using a text editor. Make sure you use valid commands. The switch rejects configuration files with invalid or incomplete commands.
Page 243: Enable Mode
ES-2724 User’s Guide Table 90 Command Summary: User Mode (continued) COMMAND DESCRIPTION PRIVILEGE Sends Ping request to an Ethernet device in the <IP|host-name> [vlan specified VLAN(s) with the specified parameters. <vlan-id>] [size <0-1472>] [-t] Displays command help information. help Determines the path a packet takes to a device.
Page 244 ES-2724 User’s Guide Table 91 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Restores firmware via TFTP. flash <ip> <remote-file> Exits Enable (or privileged) mode. disable Accesses Enable (or privileged) enable mode. Resets to the factory default erase running-config settings.
Page 245 ES-2724 User’s Guide Table 91 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Displays the configuration of the members config cluster member(s). Displays the status of the cluster member mac <mac- member(s). addr> Displays DHCP relay settings. dhcp relay Displays DHCP server settings.
Page 246: Table 55 Mvr
ES-2724 User’s Guide Table 91 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Displays the IP address table. You iptable all can sort the table based on the IP [IP|VID|PORT] address, VLAN ID or the port number. Displays the static IP address iptable static table.
Page 247 ES-2724 User’s Guide Table 91 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Displays port security settings on [port-list] the specified port(s). Displays RADIUS server settings. radius-server Displays all secured client remote- information. management Displays the specified secured [index] client information.
Page 248: General Configuration Mode
ES-2724 User’s Guide Table 91 Command Summary: Enable Mode (continued) COMMAND DESCRIPTION PRIVILEGE Connects to an SSH server with [command </>] the specified SSH version and addition commands to be executed on the server. Determines the path a packet traceroute <ip|host-name>...
Page 249 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Configures a classifier. A classifier <name> <[packet- classifier groups traffic into data format flows according to specific criteria <802.3untag|802.3 such as the source address, tag| destination address, source port...
Page 250 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Specifies through which traffic default- <in-band|out-of- flow the switch is to send management band> packets. Enables DHCP relay. dhcp relay Sets the IP addresses of up to 3 helper-address DHCP servers.
Page 251 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Enables IGMP snooping. igmp- snooping Sets the 802.1p priority for 8021p-priority <0-7> outgoing igmp snooping packets. Sets the host timeout value. host-timeout <1-16711450> Sets the leave timeout value leave-timeout <1-16711450>...
Page 252 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Exits from the CLI. logout Sets learned MAC aging time. mac-aging- <10-3000> time Configures a static MAC address mac-filter name <name> mac port filtering rule. <mac-addr> vlan <vlan-id>...
Page 253 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables the classifier. Each classifier <name> classifier has one rule. If you disable a classifier you cannot use policy rule related information. Enables a classifier. <name> inactive...
Page 254 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables the link aggregation lacp control protocol (dynamic trunking) on the switch. Disables login access to the logins <name> specified name. Enables the specified MAC-filter mac-filter name <name>...
Page 255 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables port security on the <port-list> specified ports. Enables MAC address learning <port-list> on the specified ports. learn inactive Disables the use of radius-server <index> authentication from the specified RADIUS server.
Page 256 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Removes remote known hosts known-hosts with the specified public key <host-ip> (1024-bit RSA1, RSA or DSA). [1024|ssh- rsa|ssh-dsa] Disables broadcast storm control. 13 storm-control Disables syslog logging.
Page 257 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Configures a policy. A classifier policy <name> classifier distinguishes traffic into flows <classifier-list> based on the configured criteria. < A policy rule ensures that a traffic [vlan<vlan-id>]...
Page 258: Figure 80 Rip
ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Specifies how often a client has reauth-period to re-enter the username and <reauth- password to stay connected to period> the specified port(s). Enables port security on the port- device.
Page 259 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Allows ICMP management icmp packets. Allows SNMP management. snmp Allows SSH access on the ssh <socket- specified service port. number> Allows Telnet access on the telnet <socket- specified service port.
Page 260 ES-2724 User’s Guide Table 92 Command Summary: Configuration Mode (continued) COMMAND DESCRIPTION PRIVILEGE Disables syslog logging to the server <ip- inactive specified syslog server. address> Sets the IP address of the syslog level [0 ~ 7] server and the severity level.
Page 261: Interface Port-Channel Commands
ES-2724 User’s Guide 39.11.4 interface port-channel Commands The following table lists the commands in configuration mode. interface port-channel Use these commands to configure the ports. Table 93 interface port-channel Commands COMMAND DESCRIPTION PRIVILEGE Enables a port or a list of ports for interface configuration.
Page 262 ES-2724 User’s Guide Table 93 interface port-channel Commands (continued) COMMAND DESCRIPTION PRIVILEGE Choose to accept both tagged and frame-type untagged incoming frames or just <all|tagged> tagged incoming frames on a port. Enables strict priority queuing ge-spq <q0|q1|...|q7> starting with the specified queue and subsequent higher queues on the Gigabit ports.
Page 263 ES-2724 User’s Guide Table 93 interface port-channel Commands (continued) COMMAND DESCRIPTION PRIVILEGE Sets a name for the port(s). Enter name <port- a descriptive name (up to nine name-string> printable ASCII characters). Disables bandwidth limit on the bandwidth-limit port(s). Disables cir bandwidth limits on bandwidth-limit the port(s).
Page 264: Interface Route-Domain Commands
ES-2724 User’s Guide Table 93 interface port-channel Commands (continued) COMMAND DESCRIPTION PRIVILEGE Creates a protocol based VLAN protocol-based- with the specified parameters. vlan name <name> ethernet-type <ethernet-type> vlan <vid> priority <0-7> Disables the protocol based VLAN. 13 inactive The default PVID is VLAN 1 for all pvid <1-4094>...
Page 265: Config-Vlan Commands
ES-2724 User’s Guide Use these commands to configure the IP routing domains. Table 94 interface route-domain Commands PRIVILEG COMMAND DESCRIPTION interface Enables a routing domain for configuration. route-domain <ip-address>/ <mask-bits> Exits from the interface routing- exit domain command mode. Enables IGMP in this routing igmp <v1|v2>...
Page 266: Mvr Commands
ES-2724 User’s Guide Table 95 Command Summary: config-vlan Commands (continued) COMMAND DESCRIPTION PRIVILEGE Specifies the port(s) you want to forbidden prohibit from joining this VLAN <port-list> group. Displays a list of available VLAN help commands. Disables the specified VLAN. inactive...
Page 267: Table 96 Command Summary: Mvr Commands
ES-2724 User’s Guide Table 96 Command Summary: mvr Commands COMMAND DESCRIPTION PRIVILEGE Enters the MVR (Multicast mvr <1- VLAN Registration) 4094> configuration mode. Exist from the MVR exit configuration mode. Sets the multicast group range group <name-str> for the MVR.
Page 268 ES-2724 User’s Guide Chapter 39 Introducing Commands...
Page 269: User And Enable Mode Commands
This command shows the general system information (such as the firmware version and system up time). An example is shown next. Copyright (c) 1994 - 2006 ZyXEL Communications Corp. sysname# show system-information System Name : ES-2724 System Contact...
Page 270: Show Ip
ES-2724 User’s Guide 40.2.2 show ip Syntax: show ip This command displays the IP related information (such as IP address and subnet mask) on all switch interfaces. The following figure shows the default interface settings. sysname> show Out-of-band Management IP Address = 192.168.0.1 Management IP Address IP[192.168.0.1], Netmask[255.255.255.0], VID[0]...
Page 271: Show Mac Address-Table
ES-2724 User’s Guide This command displays statistics of a port. The following example shows that port 2 is up and the related information. sysname# show interface 2 Port Info Port NO. Link :100M/F Status :FORWARDING LACP :Disabled TxPkts RxPkts Errors Tx KBs/s :0.0...
Page 272: Ping
ES-2724 User’s Guide This command displays the MAC address(es) stored in the switch. The following example shows the static MAC address table. sysname# show mac address-table static Port VLAN ID MAC Address Type 00:a0:c5:01:23:46 Static sysname# 40.3 ping Syntax: ping <ip|host-name> < [in-band|out-of-band|vlan <vlan-id> ] [ size ->...
Page 273: Copy Port Attributes
ES-2724 User’s Guide where The IP address or host name of an Ethernet device. <ip|host-name> Specifies the network interface or the VLAN ID to which the [in-band|out-of- band|vlan <vlan- Ethernet device belongs. id> ] Specifies the Time To Live (TTL) period.
Page 274: Configuration File Maintenance
ES-2724 User’s Guide where copy running-config Copies all of the possible attributes from one port to another port interface port- or ports. channel <port> <port-list> Copies only the specified port attributes from one port to another copy running-config interface port- port or ports.
Page 275: Resetting To The Factory Default
ES-2724 User’s Guide 40.6.2 Resetting to the Factory Default Follow the steps below to reset the switch back to the factory defaults. 1 Enter to reset the current running configuration. erase running config 2 Enter to save the changes to the current configuration file. If you want to...
Page 276 ES-2724 User’s Guide Chapter 40 User and Enable Mode Commands...
Page 277: Configuration Mode Commands
ES-2724 User’s Guide H A P T E R Configuration Mode Commands This chapter describes how to enable and configure your switch’s features using commands. For more background information, see the feature specific chapters which proceed the commands chapters. 41.1 Enabling IGMP Snooping To enable IGMP snooping on the switch.
Page 278: Configure Igmp Filter
ES-2724 User’s Guide An example is shown next. • Enable IGMP snooping on the switch. • Set the values to 30 seconds host-timeout leave-timeout • Set the switch to drop packets from unknown multicast groups. sysname(config)# igmp-snooping sysname(config)# igmp-snooping host-timeout 30...
Page 279: Enabling Stp
ES-2724 User’s Guide 41.3 Enabling STP Use the or the commands to enable and configure STP on the switch. spanning-tree mrstp The difference between the commands is that only allows you to set up one spanning-tree spanning tree configuration and the command allows you to set up multiple ones.
Page 280 ES-2724 User’s Guide Specifies the maximum time (in seconds) a switch can wait maximum-age <6-40> without receiving a BPDU before attempting to reconfigure. All switch ports (except for designated ports) should receive BPDUs at regular intervals. Any port that ages out STP information (provided in the last BPDU) becomes the designated port for the attached LAN.
Page 281: No Command Examples
ES-2724 User’s Guide 41.4 no Command Examples These are the commonly used command examples that belong to the group of commands. group commands are commands which are preceded by keyword . This command negates the intended action of the command. In most cases the command disables, resets or clears settings.
Page 282: Other Examples Of No Commands
ES-2724 User’s Guide where Re-enables an ip route with the specified IP address and <ip> <mask> inactive subnet mask. An example is shown next. • Enable the IP route with the IP address of 192.168.11.1 and subnet mask of 255.255.255.0. This ip route must have already been created and made inactive prior to re-enable command being applied.
Page 283: No Port-Access-Authenticator
ES-2724 User’s Guide 41.4.4.2 no port-access-authenticator Syntax: no port-access-authenticator no port-access-authenticator <port-list> reauthenticate no port-access-authenticator <port-list> where Disables port authentication on the switch. Disables the re-authentication mechanism on the listed port(s). <port-list> reauthenticate Disables authentication on the listed ports. <port-list>...
Page 284: Queuing Method Commands
ES-2724 User’s Guide • Disable the secure shell RSA1 encryption key. • Remove the remote host with IP address 172.165.1.8 from the list of known hosts. • Remove the remote host with IP address 172.165.1.9 and with an SSH-RSA encryption key from the list of known hosts.
Page 285: Enabling Mac Filtering
ES-2724 User’s Guide Syntax: ip route <ip> <mask> <next-hop-ip> ip route <ip> <mask> <next-hop-ip> [metric <metric>][name <name>] --> [inactive] where Specifies the network IP address of the final destination. <ip> Specifies the subnet mask of this destination. <mask> Specifies the IP address of the gateway. The gateway is an <next-hop-ip>...
Page 286: Enabling Trunking
ES-2724 User’s Guide where Names the filtering rule. name <name> Specifies the MAC address you want to filter. mac <mac-addr> Specifies which VLAN this rule applies to. vlan <vlan-id> Selects the behavior of the rule. drop <src/dst/both> • src - drop packets coming from the specified MAC address •...
Page 287: Enabling Port Authentication
ES-2724 User’s Guide • Create trunk 1 on the switch. • Place ports 5-8 in trunk 1. • Enable dynamic link aggregation (LACP) on trunk 1. sysname(config)# trunk t1 sysname(config)# trunk t1 interface 5-8 sysname(config)# trunk t1 lacp 41.9 Enabling Port Authentication To enable a port authentication, you need to specify your RADIUS server details and select the ports which require external authentication.
Page 288: Port Authentication Settings
ES-2724 User’s Guide Specifies the timeout period (in seconds) the switch radius-server timeout <1- 1000> will wait for a response from a RADIUS server. If 2 RADIUS servers are configured, this is the total time the switch will wait for a response from either server.
Page 289 ES-2724 User’s Guide An example is shown next. • Specify RADIUS server 1 with IP address 10.10.10.1, port 1890 and the string secretKey as the password. See Section 41.9.1 on page 285 for more information on RADIUS server commands. • Specify the timeout period of 30 seconds that the switch will wait for a response from the RADIUS server.
Page 290 ES-2724 User’s Guide Chapter 41 Configuration Mode Commands...
Page 291: Chapter 42 Interface Commands
ES-2724 User’s Guide H A P T E R Interface Commands These are some commonly used configuration commands that belong to the interface group of commands. 42.1 Overview The interface commands allow you to configure the switch on a port by port basis.
Page 292: Broadcast-Limit
ES-2724 User’s Guide where Type to process any BPDUs received on these ports. <peer|tunnel|discard| peer network> Type to forward BPDUs received on these ports. tunnel Type to drop any BPDUs received on these ports. discard Type to process a BPDU with no VLAN tag and network forward a tagged BPDU.
Page 293: Mirror
ES-2724 User’s Guide Syntax: bandwidth-limit bandwidth-limit pir <Kbps> bandwidth-limit cir <Kbps> bandwidth-limit egress <Kbps> where Sets the maximum bandwidth allowed for incoming traffic. pir <Kbps> Sets the guaranteed bandwidth allowed for incoming traffic. cir <Kbps> Sets the maximum bandwidth allowed for outgoing traffic egress <Kbps>...
Page 294: Gvrp
ES-2724 User’s Guide • Enable ports 1, 4, 5 and 6 for configuration. • Enable port mirroring on the ports. • Enable port mirroring for outgoing traffic. Traffic is copied from ports 1, 4, 5 and 6 to port three in order to examine it in more detail without interfering with the traffic flow on the original ports.
Page 295: Frame-Type
ES-2724 User’s Guide • Enable ingress checking on the interface. sysname(config)# interface port-channel 1,3-5 sysname(config-interface)# ingress-check 42.2.8 frame-type Syntax: frame-type <all|tagged> where Choose to accept both tagged and untagged incoming frames or just <all|tagged|u ntagged> tagged incoming frames on a port.
Page 296: Egress Set
ES-2724 User’s Guide • Set the queue weights from Q0 to Q7. sysname# configure sysname(config)# wfq sysname(config)# interface port-channel 2,6-8 sysname(config-interface)# weight 8 7 6 5 4 3 2 1 42.2.10 egress set Syntax: egress set <port-list> where Sets the outgoing traffic port list for a port-based VLAN.
Page 297: Name
ES-2724 User’s Guide 42.2.12 name Syntax: name <port-name-string> where Sets a name for your port interface(s). <port-name-string> An example is shown next. • Enable ports one, three, four and five for configuration. • Set a name for the ports. sysname(config)# interface port-channel 1,3-5 sysname(config-interface)# name Test 42.2.13 speed-duplex...
Page 298: Interface No Command Examples
ES-2724 User’s Guide An example is shown next. • Select ports 3-6 for internal loopback test. • Execute the test command. • View the results. sysname(config)# interface port-channel 3-6 sysname(config-interface)# test 3-6 Testing internal loopback on port 3 :Passed! Ethernet Port 3 Test ok.
Page 299: Ieee 802.1Q Tagged Vlan Commands
ES-2724 User’s Guide H A P T E R IEEE 802.1Q Tagged VLAN Commands This chapter describes the IEEE 802.1Q Tagged VLAN and associated commands. 43.1 Configuring Tagged VLAN The following procedure shows you how to configure tagged VLAN. 1 Use the IEEE 802.1Q tagged VLAN commands to configure tagged VLAN for the switch.
Page 300: Global Vlan1Q Tagged Vlan Configuration Commands
ES-2724 User’s Guide 43.2 Global VLAN1Q Tagged VLAN Configuration Commands This section shows you how to configure and monitor the IEEE 802.1Q Tagged VLAN. 43.2.1 GARP Status Syntax: show garp This command shows the switch’s GARP timer settings, including the join, leave and leave all timers.
Page 301: Gvrp Timer
ES-2724 User’s Guide Switches join VLANs by making a declaration. A declaration is made by issuing a Join message using GARP. Declarations are withdrawn by issuing a Leave message. A Leave All message terminates all registrations. GARP timers set declaration timeout values.
Page 302: Set Port Vid
ES-2724 User’s Guide 43.3.1 Set Port VID Syntax: pvid <VID> where Specifies the VLAN number between 1 and 4094. <VID> This command sets the default VLAN ID on the port(s). The following example sets the default VID to 200 on ports 1 to 5.
Page 303: Modify Static Vlan
ES-2724 User’s Guide 43.3.4 Modify Static VLAN Use the following commands in the config-vlan mode to configure the static VLAN table. Syntax: vlan <vlan-id> fixed <port-list> forbidden <port-list> name <name-str> normal <port-list> untagged <port-list> no fixed <port-list> no forbidden <port-list>...
Page 304: Delete Vlan Id
ES-2724 User’s Guide 3 The switch notes what the SVLAN table says (that is, the SVLAN tells the switch whether or not to forward a frame and if the forwarded frames should have tags). 4 Then the switch applies the port filter to finish the forwarding decision. This means that frames may be dropped even if the SVLAN says to forward them.
Page 305: Disable Vlan
ES-2724 User’s Guide 43.5 Disable VLAN Syntax: vlan <vlan-id> inactive This command disables the specified VLAN ID in the SVLAN (Static VLAN) table. 43.6 Show VLAN Setting Syntax: show vlan This command shows the IEEE 802.1Q Tagged SVLAN (Static VLAN) table.
Page 306 ES-2724 User’s Guide Chapter 43 IEEE 802.1Q Tagged VLAN Commands...
Page 307: Multicast Vlan Registration Commands
ES-2724 User’s Guide H A P T E R Multicast VLAN Registration Commands This chapter shows you how to use Multicast VLAN Registration (mvr) commands. 44.1 Overview Use the mvr commands in the configuration mode to create and configure multicast VLANs.
Page 308 ES-2724 User’s Guide A name to identify the MVR IP multicast group. group name <name-str> Specifies the starting IP multicast address of the multicast group in start-address <ip> dotted decimal notation. Specifies the ending IP multicast address of the multicast group in end-address <ip>...
Page 309: Routing Domain Command Examples
ES-2724 User’s Guide H A P T E R Routing Domain Command Examples 45.0.1 interface route-domain Syntax: interface route-domain <ip-address>/<mask-bits> where = This is the IP address of the switch in the routing domain. Specify the IP <ip-address> address is dotted decimal notation. For example, 192.168.1.1.
Page 310 ES-2724 User’s Guide Chapter 45 Routing Domain Command Examples...
Page 311: Chapter 46 Troubleshooting
ES-2724 User’s Guide H A P T E R Troubleshooting This chapter covers potential problems and possible remedies. 46.1 Problems Starting Up the Switch Table 97 Troubleshooting the Start-Up of Your Switch PROBLEM CORRECTIVE ACTION None of the LEDs Check the power connection and make sure the power source is turned on.
Page 312: Pop-Up Windows, Javascripts And Java Permissions
ES-2724 User’s Guide 46.2.1 Pop-up Windows, JavaScripts and Java Permissions In order to use the web configurator you need to allow: • Web browser pop-up windows from your device. • JavaScripts (enabled by default). • Java permissions (enabled by default).
Page 313: Figure 130 Internet Options
ES-2724 User’s Guide Figure 130 Internet Options 3 Click Apply to save this setting. 46.2.1.1.2 Enable pop-up Blockers with Exceptions Alternatively, if you only want to allow pop-up windows from your device, see the following steps. 1 In Internet Explorer, select Tools, Internet Options and then the Privacy tab.
Page 314: Figure 131 Internet Options
ES-2724 User’s Guide Figure 131 Internet Options 3 Type the IP address of your device (the web page that you do not want to have blocked) with the prefix “http://”. For example, http://192.168.1.1. 4 Click Add to move the IP address to the list of Allowed sites.
Page 315: Javascripts
ES-2724 User’s Guide Figure 132 Pop-up Blocker Settings 5 Click Close to return to the Privacy screen. 6 Click Apply to save this setting. 46.2.1.2 JavaScripts If pages of the web configurator do not display properly in Internet Explorer, check that JavaScripts are allowed.
Page 316: Figure 133 Internet Options
ES-2724 User’s Guide Figure 133 Internet Options 2 Click the Custom Level... button. 3 Scroll down to Scripting. 4 Under Active scripting make sure that Enable is selected (the default). 5 Under Scripting of Java applets make sure that Enable is selected (the default).
Page 317: Java Permissions
ES-2724 User’s Guide Figure 134 Security Settings - Java Scripting 46.2.1.3 Java Permissions 1 From Internet Explorer, click Tools, Internet Options and then the Security tab. 2 Click the Custom Level... button. 3 Scroll down to Microsoft VM. 4 Under Java permissions make sure that a safety level is selected.
Page 318: Figure 135 Security Settings - Java
ES-2724 User’s Guide Figure 135 Security Settings - Java 46.2.1.3.1 JAVA (Sun) 1 From Internet Explorer, click Tools, Internet Options and then the Advanced tab. 2 make sure that Use Java 2 for <applet> under Java (Sun) is selected. 3 Click OK to close the window.
Page 319: Problems With The Password
ES-2724 User’s Guide Figure 136 Java (Sun) 46.3 Problems with the Password Table 99 Troubleshooting the Password PROBLEM CORRECTIVE ACTION Cannot access the The password field is case sensitive. Make sure that you enter the correct switch. password using the proper casing.
Page 320 ES-2724 User’s Guide Chapter 46 Troubleshooting...
Page 321: Product Specifications
ES-2724 User’s Guide P P E N D I X Product Specifications This section describes the general software features of the switch. Table 100 Firmware Features FEATURE DESCRIPTION IP Routing Domain An IP interface (also known as an IP routing domain) is not bound to a physical port.
Page 322 ES-2724 User’s Guide Table 100 Firmware Features FEATURE DESCRIPTION Multicast VLAN Registration Multicast VLAN Registration (MVR) is designed for applications (such as (MVR) Media-on-Demand (MoD)) using multicast traffic across a network. MVR allows one single multicast VLAN to be shared among different subscriber VLANs on the network.
Page 323: Table 101 General Product Specifications
ES-2724 User’s Guide The following tables list the product specifications. Table 101 General Product Specifications Interface 24 10/100 Base-Tx ports 2 GbE Dual Personality interfaces (Each interface has one 1000Base-T copper port and one Small Form-Factor Pluggable (SFP) fiber port, with one port active at a time.)
Page 324: Table 102 Management Specifications
ES-2724 User’s Guide Table 101 General Product Specifications (continued) Layer 3 IP Capability IPV4 support Features 8 IP routing domains 4K IP address table Wire speed IP forwarding Routing Unicast: RIP-V1/V2 protocols Multicast: IGMP V1/V2 Static Routing IP services DHCP server/relay Security IEEE 802.1x port-based authentication...
Page 325: Table 103 Physical And Environmental Specifications
ES-2724 User’s Guide Table 103 Physical and Environmental Specifications LEDs Main switch: BPS, PWR, SYS, ALM, LNK/ACT, FDX Per Gigabit port: LNK/ACT, FDX Per mini-GBIC port: LNK, ACT Per Management port: 10, 100 Dimension Standard 19” rack mountable 438 mm (W) x 270 mm (D) x 44.45 mm (H) Weight 3.6 Kg...
Page 326 ES-2724 User’s Guide Appendix A Product Specifications...
Page 327: Ip Addresses And Subnetting
ES-2724 User’s Guide P P E N D I X IP Addresses and Subnetting This appendix introduces IP addresses, IP address classes and subnet masks. You use subnet masks to subdivide a network into smaller logical networks. Introduction to IP Addresses An IP address has two parts: the network number and the host ID.
Page 328: Table 104 Classes Of Ip Addresses
ES-2724 User’s Guide The following table shows the network number and host ID arrangement for classes A, B and Table 104 Classes of IP Addresses IP ADDRESS OCTET 1 OCTET 2 OCTET 3 OCTET 4 Class A Network number Host ID...
Page 329: Table 106 "Natural" Masks
ES-2724 User’s Guide Subnet Masks A subnet mask is used to determine which bits are part of the network number, and which bits are part of the host ID (using a logical AND operation). A subnet mask has 32 bits. If a bit in the subnet mask is a “1” then the corresponding bit in the IP address is part of the network number.
Page 330: Table 108 Two Subnets Example
ES-2724 User’s Guide Table 107 Alternative Subnet Mask Notation (continued) SUBNET MASK SUBNET MASK “1” BITS LAST OCTET BIT VALUE DECIMAL 255.255.255.240 1111 0000 255.255.255.248 1111 1000 255.255.255.252 1111 1100 The first mask shown is the class “C” natural mask. Normally if no mask is specified it is understood that the natural mask is being used.
Page 331: Table 109 Subnet 1
ES-2724 User’s Guide Table 109 Subnet 1 (continued) LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER VALUE Subnet Address: 192.168.1.0 Lowest Host ID: 192.168.1.1 Broadcast Address: Highest Host ID: 192.168.1.126 192.168.1.127 Table 110 Subnet 2 IP/SUBNET MASK NETWORK NUMBER LAST OCTET BIT VALUE IP Address 192.168.1.
Page 332: Table 112 Subnet 2
ES-2724 User’s Guide Table 111 Subnet 1 (continued) LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER VALUE Subnet Address: 192.168.1.0 Lowest Host ID: 192.168.1.1 Broadcast Address: Highest Host ID: 192.168.1.62 192.168.1.63 Table 112 Subnet 2 LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER...
Page 333: Table 115 Eight Subnets
ES-2724 User’s Guide The following table shows class C IP address last octet values for each subnet. Table 115 Eight Subnets BROADCAST SUBNET SUBNET ADDRESS FIRST ADDRESS LAST ADDRESS ADDRESS The following table is a summary for class “C” subnet planning.
Page 334: Table 117 Class B Subnet Planning
ES-2724 User’s Guide The following table is a summary for class “B” subnet planning. Table 117 Class B Subnet Planning NO. “BORROWED” HOST NO. HOSTS PER SUBNET MASK NO. SUBNETS BITS SUBNET 255.255.128.0 (/17) 32766 255.255.192.0 (/18) 16382 255.255.224.0 (/19) 8190 255.255.240.0 (/20)
Page 335: Index
ES-2724 User’s Guide Index Numerics 802.1P priority certifications viewing CFI (Canonical Format Indicator) changing the password Class of Service (CoS) classifier 135, 137 and QoS access control editing limitations example login account overview remote management setup 135, 137, 138 service port...
Page 336: Figure 113 Diagnostic
ES-2724 User’s Guide summary DSCP-to-IEEE802.1p mapping syntax conventions service level user mode details what it does using history DSCP (DiffServ Code Point) VLAN dynamic link aggregation config mode examples configuration change running config saving configuration file 54, 239 egress port...
Page 337 ES-2724 User’s Guide Rack-mounting installation freestanding GARP precautions GARP (Generic Attribute Registration Protocol) interface commands GARP terminology Internet GARP timer 74, 82 setting up your browser general features introduction general setup getting help address classes capability GMT (Greenwich Mean Time)
Page 338 ES-2724 User’s Guide configuration group configuration MAC (Media Access Control) network example MAC address 70, 227 MVR (Multicast VLAN Registration) maximum number per port MAC address learning 74, 89, 97, 132 specify limit MAC table how it works viewing natural mask, subnets...
Page 339 ES-2724 User’s Guide limit MAC address learning advantages MAC address learning and port authentication overview Network example setup server settings port setup RADIUS (Remote Authentication Dial In User Service) port status port VID Rapid Spanning Tree Protocol (RSTP). See STP...
Page 340 ES-2724 User’s Guide and MIB subnetting communities switch lockout management model switch reset manager switch setup switching network components syntax conventions object variables protocol operations syslog setup protocol traps server setup versions supported settings setup SNMP traps severity levels Spanning Tree Protocol (STP)
Page 341 ES-2724 User’s Guide web configurator getting help home user mode login examples logout navigation panel screen summary weight of the switch weight, queuing Weighted Round Robin Scheduling (WRR) Vendor Specific Attribute See VSA WFQ (Weighted Fair Queuing) ventilation holes WRR (Weighted Round Robin Scheduling...
