Care And Maintenance; Warranty; Specifications - LENCO IPD-5200 User Manual

Eng

Care and Maintenance

- Do not subject the unit to excessive force, shock, dust or extreme temperature.
- Do not tamper the internal components of the unit.
- Clean your unit with a damp (never wet) cloth. Solvent or detergent should never
be used.
- Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
- Keep your unit away from heating appliances and sources of electrical noise such
as fluorescent lamps or motors.
Resetting the Unit
If the unit experiences a power surge or electric shock, it is possible that the
internal micro-controller may lock up and the unit will not respond to any
commands from the front panel controls.
1.In this event, unplug and then reconnect the AC power plug into the wall outlet.
2.Use a straightened paper clip, toothpick or similar objects to press the RESET
button located at the rear of the main unit (see the below figure). The reset
operation clears the system memory and all of your previous settings will be
erased.
CAUTION: DO NOT USE SHARP, POINTED OBJECT TO PRESS THE RESET
BUTTON. IT MAY DAMAGE THE RESET SWITCH INSIDE THE UNIT.
RESET button

Warranty:

If you have questions regarding the warranty, the length of warranty and the
working method of it, you can find the information on our site www.lenco.eu or
you can directly contact your retailer.
14
IPD5200 iB.indd IPD5200 iB.indd EN114-EN115 EN114-EN115
size:105x146mm,material:80gms book paper,BK+BK
Eng

Specifications

Power Supply
Power Adaptor Input
Output
Battery Back-up for clock / memory: DC3V--- AAA (UM-4)type x 2 (not included)
Battery for operating the unit: DC9V --- AA (UM-3) type x 6 (not included)
Speaker Output 2W+2W (Max.)
Power consumption 1 W (Standby)
16 W (Max.)
Dimensions 298 x 210 x 91mm
Weight 959g
Operating Temperature -10 ~ + 45 C o
and Humidity 70%
THE SPECIFICATION AND EXTERNAL APPEARANCE OF THE SET ARE
SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
For information and support www.lenco.eu
15
AC 230V ~ 50Hz(For EU)
DC 9V 1250mA
