Listening to iPod

This model adopts different iPod models. Following steps guide you
listening to iPod music.
1. Press the OPEN button to open the iPod docking compartment door.
2. Your iPod can now be inserted into the docking port by placing the
connector on the bottom of the iPod onto connector in the docking bay.
Caution: Please be careful when seating the iPod into the docking to avoid
damaging the 30-pin connector on the iPod or in the docking system.
3. Slightly push the iPod compartment door upward by hand until it closed
and locked.
4. Press the POWER button once to turn on the unit and the power status
indicator lights on.
5. Press the FUNC button to select iPod mode.
In iPod mode :
- To start playback music, press the iPod
- To pause the music , press the iPod
- To resume music , press the iPod
- You may press the V / button to adjust the volume to a desired level.
- When a song playback, press and hold the T/CH
to perform high speed search forward / backward.
- To skip to next or previous song, press the T/CH
To turn off the unit, press the POWER
indicator will light off.
When the unit is powered by external DC adaptor and once the iPod
connected to the docking station, the unit recharges the iPod battery.
Note:
(1) Before docking, set your iPod to album menu or to the shuffle play mode selection.
Once your play mode is set insert the iPod into docking compartment.
You must operate your music selection by using the front right hand side control panel.
(2) Music from the iPhone can also be played in docking compartment. Once iPhone is
placed in docking compartment the iPhone screen will display the following message:
This accessory is not made to work with iPhone
Would you like to turn on Airplane Mode to reduce audio interference?
You will not be able to make or receive calls.
YES
- The above message will disappear from the iPhone screen after few seconds. The
iPhone is still able to receive incoming calls while inserted in docking compartment.
- The iPhone music selection can be operated by using the front right hand side
control panel.
8
IPD5200 iB.indd IPD5200 iB.indd EN18-EN19 EN18-EN19
size:105x146mm,material:80gms book paper,BK+BK
button once.
button.
button again.
/ button
/ button.
button and the power status
NO
Eng

Radio Tuner Operation

FM Antenna
Fully extend the FM rod antenna for the best FM radio reception.
Radio Tuning
1. Press the POWER button to turn on the unit, where the power
status indicator light on.
2. Press the FUNC button to select FM stereo or FM mono radio receiving
mode.
3. To manually tune to a desired station, repeatedly press the T/CH
/ button.
4. To automatically search for stations with strong signals, press and hold
the T/CH / button until the frequency digits on display begins to
scan then release the button. The tuner will stop on the first strong
signal it finds.
Notes :
- Manual tune to select weaker stations that might be skipped during
automatic tuning.
- If the automatic tuning does not stop on the exact frequency of the station,
for example , it stops on 100.9 MHz instead of 100.8 MHz, use the manual
tuning method to "fine tune" to the exact frequency of the desired station.
Radio Preset Stations
The units allows you to store up to 20 FM stations for easy recall at any time.
Preset Stations
1. Press the POWER button to turn on the unit, where the power status
indicator light on.
2. Press the FUNC button to select FM stereo or FM mono radio receiving
mode.
3. Tune to the radio station you want to store in memory by using the T/CH
/ button.
4. Press the MEM button. The preset channel number appears on display
and blinking.
5. To select desired preset station number, press the T/CH
6. To confirm preset location, press the MEM button.
7. Repeat steps 3 to 6 to store other stations, if apply.
9
/ button.
