1.3.2 The Back Panel

The Router's ports, where the cables are connected, and RESET button are located on the back
panel.
LINE: Connect to the Modem Port of Splitter or to the telephone line.
Reset: There are two ways to reset the Router's factory defaults.
1) Use the Restore Default function on Management -> Settings -> Restore Default page in the
router's Web-based Utility.
2) Use the Factory Default RESET button: With the Router powered on, use a pin to press and
hold the RESET button for at least 5 seconds. And the Router will reboot to its factory default
settings.
POWER: The Power plug is where you will connect the power adapter.
ON/OFF: The switch for the power.
1, 2, 3, 4 (LAN): The ports (1, 2, 3, 4) connect the Router to the local PC(s).
Wireless Antennas: To receive and transmit the wireless data.
150Mbps Wireless Lite N ADSL2+ Modem Router User Guide
Figure 1-2
5
