Installing a Supervisor Engine or a Module
Figure 3-4 Slot Numbers on Cisco 7609 Router and Cisco 7609-S Router
OSMs
assembly
Note Supervisor Engine 2 is installed in slot 1 and slot 2. Supervisor Engine 720s and Route Switch Processor
720s are installed in slot 5 and slot 6.
Book Title
3-6
FAN
STATUS
Fan
o
INPUT FAN
OK OK
Power supply 1
ESD ground strap
o
OUTPUT
FAIL
INPUT
FAN OUTPUT
OK
OK FAIL
Power supply 2
(redundant)
connection
Chapter 3 Installing Modules
Supervisor
engine
Redundant
supervisor
engine
Switch
Fabric
Module
Redundant
Switch
Fabric
Module
Slots 1-9
(right to left)
