Cisco 7600 Ethernet Services Plus Line Cards
Figure 1-38
7600-ES+ 20G3CXL
STATUS
ETHERNET SERVICES MODULE
There is one line card STATUS LED and twenty A/L (Active Loopback) LEDs.
descriptions.
Table 1-25
LED Label
STATUS
A/L

Cisco 7600 ES+ 40G3C, -40G3CXL Line Cards

The Cisco 7600 ES+ 40G3C, -40G3CXL line cards have 21 LEDs, as shown in
Figure
Figure 1-39
7600-ES+ 40G3C
STATUS
ETHERNET SERVICES MODULE
Figure 1-40
7600-ES+ 40G3CXL
STATUS
ETHERNET SERVICES MODULE
There is one line card STATUS LED and twenty A/L (Active Loopback) LEDs.
descriptions.
Book Title
1-36
Cisco 7600 ES+ 20G3CXL Line Card Faceplate
EXT CLK
Cisco 7600 ES+ 20G3C, -20G3CXL Line Card LEDs
Color
Red
Green
Yellow
Off
Amber
Green
Green and
Amber
Off
1-40.
Cisco 7600 ES+ 40G3C Line Card Faceplate
EXT CLK
Cisco 7600 ES+ 40G3CXL Line Card Faceplate
EXT CLK
CLASS 1 LASER
State Meaning
On The line card has encountered an error.
On The line card is online.
On The line card is loading.
Off The line card is powered off.
On The port is enabled but there is not a valid Ethernet
link.
On The port is enabled and a valid Ethernet link has been
established.
On Undefined condition.
Off The port is not enabled by software.
CLASS 1
LASER
CLASS 1
LASER
Chapter 1 Product Overview
Table 1-25 provides LED
Figure 1-39 and
Table 1-26 provides LED
OL-5077-7
