Messages regarding paper

Paper Loaded / Crooked

The roll has been loaded askew.
Paper has been loaded in the Cassette askew.
Paper has been loaded in the tray askew.
Note
•
To disable this message (if it is displayed repeatedly despite reloading paper, for example), choose Off
or Loose in the Skew Check Lv.. setting of the printer menu. However, this may cause jams as paper
may be askew when it is printed. Also, the Platen may become soiled, which may soil the back of
the next document when it is printed.

Paper loaded askew.

A sheet has been loaded askew in the Top Paper
Feed Slot.
686 Error Message
Cause
Cause
Corrective Action
Follow these steps to reload the roll.
1.
Press the Online button to clear the error
message.
2.
Insert the edge of the roll straight into the Paper
Feed Slot.
Follow the steps below to reload the paper.
1.
After pressing the ▲ button to clear the error
message, remove any jammed paper from the
cassette.
(→P.169)
2.
Load sheets in the Cassette.
(→P.152)
Follow the steps below to reload the paper.
1.
After pressing the ▲ button to clear the error
message, remove any jammed paper from the
tray.
(→P.174)
2.
Load sheets manually.
(→P.155)
Corrective Action
Remove the sheet and reload it straight.
