2 Getting Started

Login Web-based Management Utility

In order to login and configure the switch via an Ethernet connection, the PC must have an IP address in the
same subnet as the switch. For example, if the switch has an IP address of 192.168.0.1, the PC should have
an IP address of 192.168.0.x (where x is a number between 2 and 254), and a subnet mask of
255.255.255.0. There are two ways to login the Web-based Management Utility, you may click the Web
Access button at the top of the SmartConsole Utility or open your web browser and enter 192.168.0.1 (the
factory-default IP address) in the address box. Then press <Enter>
The web configuration can also be accessed through the SmartConsole Utility. Open the SmartConsole
Utility and double-click the switch as it appears in the Monitor List. This will automatically load the web
configuration in your web browser.
When the following login box appears, enter the password then press OK to entering the Web-based
Management Utility. The default password is Admin.

Smart Wizard

Before entering the Web-based Management Utility, When The Smart Wizard will guide you to quick
configure the D-Link Web Smart Switch. Please refer to
configurations.

Web-based Management Utility

After clicking the Exit button in Smart Wizard, you will enter the Web-based Management Utility. Please refer
to Chapter 5 Configuration

SmartConsole Utility

The SmartConsole Utility included on the installation CD is a program for discovering Smart Switches with
the same L2 network segment connected to your PC. This tool is only for computers running Windows 2000,
Windows XP, and Windows Vista x64/86 operating systems. There are two options for the installation of
SmartConsole Utility, one is through the autorun program on the installation CD and the other is manual
installation.
Figure 6 –Enter the IP address 192.168.0.1 in the web browser
NOTE: The switch's factory default IP address is
192.168.0.1 with a subnet mask of 255.0.0.0 and
a default gateway of 0.0.0.0.
Figure 7 – Log in screen
for detail configurations.
NOTE: Please be sure to remove any existing
SmartConsole Utility
installing the latest SmartConsole Utility.
D-Link Web Smart Switch User Manual
Samrt Wizard Configuration
from your PC
5
5
section for detail
before
