D-Link DES-1228P User Manual

24-port 10/100mbps poe web smart switch with 4-port 10/100/1000base-t and 2-port combo sfp
Hide thumbs Also See for DES-1228P:
Table of Contents

Advertisement

Quick Links

Download this manual
DES-1228P
24-Port 10/100Mbps PoE Web Smart Switch
with 4-Port 10/100/1000Base-T
and 2-Port Combo SFP
User Manual
V1.20

Advertisement

Table of Contents
loading

Related Manuals for D-Link DES-1228P

Summary of Contents for D-Link DES-1228P

  • Page 1 DES-1228P 24-Port 10/100Mbps PoE Web Smart Switch with 4-Port 10/100/1000Base-T and 2-Port Combo SFP User Manual V1.20...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS About This Guide................. 1 Purpose .................... 1 Terms/Usage ..................1 Introduction..................2 Gigabit Ethernet Technology ............2 Fast Ethernet Technology ..............3 Switching Technology ..............4 Power over Ethernet (PoE) .............. 4 Features.................... 5 Technical Specifications ..............6 Unpacking and Installation ..............
  • Page 3 Installing the SmartConsole Utility..........22 SmartConsole Utility Features ............23 Menu Toolbar................23 Discovery List................25 Monitor List ................26 Device Setting................28 Web-based Utility ................30 Login..................30 Tool Menu.................. 32 Setup Menu ..................33 System > System Setting ............34 System >...
  • Page 4 Security > Broadcast Storm Control .......... 54 Security > 802.1X Setting............54 Security > Mac Address Table > Static Mac ......56 Security > Mac Address Table > Dynamic Forwarding Table .. 57 Monitoring > Statistics............... 58...

  • Page 5: About This Guide

    ABOUT THIS GUIDE Thank you and congratulations on your purchase of the DES-1228P 24-Port 10/100Mbps Fast Ethernet + 4 10/100/1000Base-T Ports and 2 Combo SFP PoE Web-Smart Switch. This device integrates 1000Mbps Gigabit Ethernet, 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible package. Since Ports 1~24 of this Switch are Power over Ethernet (PoE) ports, it will automatically detect the presence of IEEE 802.3af compliant devices...

  • Page 6: Introduction

    INTRODUCTION This chapter will describe the features of the DES-1228P and provide some background information about Ethernet/Fast Ethernet/Gigabit Ethernet switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and support for CSMA/CD protocol,...

  • Page 7: Fast Ethernet Technology

    In addition, the phenomenal bandwidth delivered by Gigabit Ethernet is the most cost-effective method to take advantage of today and tomorrow’s rapidly improving switching and routing internetworking technologies. And with expected advances in the coming years in silicon technology and digital signal processing that will enable Gigabit Ethernet to eventually operate over unshielded twisted-pair (UTP) cabling, outfitting your network with a powerful 1000-Mbps- capable backbone/server connection which will create a flexible...

  • Page 8: Switching Technology

    Switching Technology Another approach to push beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. Switching is a cost-effective way of increasing the total network capacity available to users on a local area network.

  • Page 9: Features

    ♦ IEEE802.1x Port-based Access Control ♦ Supports Broadcast Storm Control ♦ Supports Static MAC setting ♦ D-Link Safeguard Engine support ♦ Supports Simple Network Management Protocol(SNMP) ♦ MIB support for: RFC1213 MIB II, Private MIB ♦ Supports DHCP client ♦...

  • Page 10: Technical Specifications

    ♦ Easy configuration via Web Browser　 ♦ Easy setting via SmartConsole Utility ♦ Firmware backup and upload via Web GUI ♦ System reboot via Web GUI ♦ Provides parallel LED display for port status such as link/act, speed, etc. ♦ Reset configuration (hardware and Web GUI) Technical Specifications Key Components / Performance...
  • Page 11 1. IEEE 802.3u compliance 2. Supports Full-Duplex operations at 10/100Mbps, and 1000Mbps only on SFP ports - 2 Combo 1000Base-T/SFP ports -1000Base-T ports compliant to the following standards: 1. IEEE 802.3 compliance 2. IEEE 802.3u compliance 3. IEEE 802.3ab compliance 4.
  • Page 12 4. DEM-331R (TX-1310/RX-1550nm), up to 40km, Single-Mode Compliant to following standards: 1. IEEE 802.3z compliance 2. IEEE 802.3u compliance 000Base-T ports 1000Base-T ports compliant to following 1000Mbps Copper standards: ports in the front 1. IEEE 802.3 compliance panel 2. IEEE 802.3u compliance 3.
  • Page 13 4.0W Optional 7.0W Optional 15.4W Reserved 15.4W 7. DES-1228P follow the PSE pinout standard of Alternative A which is sending out power over number 1,2,3,6 pins of 8 wires of CAT5 UTP cable Chassis 19-inch, 1U Rack-mount size Dimensions 440mm x 210mm x 44mm...
  • Page 14 Operation: 10%~90% RH Humidity Storage: 5%~90% RH Power consumption 222 watts Heat Dissipation 750.2 btu/hr MTBF 149,676 (hours) Emission (EMI) and Safety Certifications EMI-EMC Compliance: FCC class A, CE Class A, VCCI Class A Safety Compliance: cUL, UL...

  • Page 15: Unpacking And Installation

    Unpacking Carefully unpack the contents of the Web-Smart Switch from the box and locate the following items: One DES-1228P Web-Smart Switch One AC power cord, suitable for the local electrical power voltage requirements Four rubber feet to be used for shock cushioning...

  • Page 16: Rack Mounting

    Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration, dust, and direct exposure to sunlight. Leave at least 10cm (about 4 inches) of space to the front and rear of the Switch for ventilation. Install the Switch on a sturdy, level surface that can support its weight, or in an EIA standard-size equipment rack.

  • Page 17: Connecting Network Cables

    Figure 3 – Mount the Switch in the rack or chassis Connecting Network Cables The DES-1228P has 24 ports that support 10/100Mbps Fast Ethernet; it also has 4 10/100/1000Base-T Ports and 2 Combo SFPs. Each port on the DES-1228P supports Auto-MDI/MDI-X.

  • Page 18: Ac Power

    AC Power The Switch utilizes an AC power supply 100~240V AC, 50~60Hz. The power switch is located at the rear of the unit adjacent to the AC power connector and the system fan. The switch’s power supply will adjust to the local power source automatically and may be turned on without having any or all LAN segment cables connected.

  • Page 19: Identifying External Components

    (see the Understanding LED Indicators section). 10/100 BASE-TX Twisted Pair Ports (Port 1~24) The DES-1228P is equipped with 24 Fast Ethernet twisted pair ports that are auto-negotiable 10/100Mbps and also support auto MDI/MDIX crossover detection. All these 24 ports can operate in half- and full- duplex modes, and will be automatically activated when a compatible terminal is identified.
  • Page 20 10/100/1000 BASE-T / Mini GBIC Combo Ports (Option Port 25~26) The Switch is also equipped with two combo 10/100/1000 Base-T / Mini GBIC ports, supporting optional 100BASE-FX or 1000BASE- SX/LX Mini GBIC modules for fiber uplinks. 10/100/1000 BASE-T Twisted Pair Ports (Port 27~28) Finally there are 2 Gigabit twisted pair ports that are auto negotiable 10/100/1000Mbps with auto MDI/MDIX crossover detection support that can also operate in half- and full- duplex modes.
