Category Problem/Possible Solution
TUNER Problems
Reception is noisy,
• Relocate your antenna.
FM stereo reception
• Move the receiver away from your TV or computer.
is noisy, or the FM
• Listen to the station in mono.
STEREO indicator
• When listening to an AM station, operating the remote
does not light
control may cause noise.
• Passing cars and airplanes can cause interference.
• Concrete walls weaken radio signals.
• If nothing improves the reception, install an outdoor
antenna.
WIRELESS Problems
Cannot connect to a
• If the joining process is failing, make sure that only one of
Rocketboost
your Rocketboost wireless devices has the Hub switch
network
enabled.
• Make sure that you have installed the RF-RBCARD (sold
separately).
• Make sure that the link is established by Rocketboost setup
menu. For more information, see "Establishing
communications with other Rocketboost products" on page
12.
• The maximum number of Rocketboost devices in a
Rocketboost Network is nine. If you already have nine
devices and attempt to join another one, then joining will
fail for the new device. Remove (power down) one of your
devices and try again.
REMOTE CONTROL Problems
The remote control
• Before operating this unit, be sure to press RECEIVER.
does not work
• Make sure that the batteries are installed with the correct
polarity.
• Install new batteries. Don't mix different types of batteries,
or old and new batteries.
• Make sure that the remote control is not too far away from
the receiver, and that there's no obstruction between the
remote control and the receiver's remote control sensor.
• Make sure that the receiver is not subjected to direct
sunshine or inverter-type fluorescent lights. Relocate if
necessary.
• If the receiver is installed in a rack or cabinet with
colored-glass doors, the remote control may not work
reliably when the doors are closed.
• Make sure you've selected the correct remote control mode.
• Make sure you've entered the correct remote control code.
• Make sure to set the same ID on both the receiver and
remote control.
Cannot control
• Make sure that you have selected the correct remote control
other components
mode.
• If you cannot operate it, you need to enter the appropriate
remote control code.
RECORDING Problems
Cannot record
• On your recorder, make sure the correct input is selected.
• To prevent signal loops and damage to the receiver, input
signals are not fed through to outputs with the same name
(for example, VCR/DVR IN to VCR/ DVR OUT).
MISCELLANEOUS Problems
The sound changes
• When a pair of headphones is connected, the listening
when I connect my
mode is set to Stereo, unless it's already set to Stereo, Mono,
headphones
or Direct.
Category
How do I change
the language of a
multiplex source
The following
settings can be
made for the
composite video
inputs

Specifications

Amplifier section

Element
Rated output power
All channels
THD (Total Harmonic
Distortion)
Input sensitivity and
impedance
Output level and
impedance
Frequency response
Tone control
Signal to Noise ratio
Speaker impedance

Video section

Element
Input sensitivity/
Output level and
impedance
Component video
frequency response
www.insigniaproducts.com
Problem/Possible Solution
• Use the Multiplex setting on the Audio Adjust menu to
select Main or Sub.
You must use the buttons on the unit to make these settings.
1. While holding down the input selector button for the input
source that you want to set, press SETUP.
2. Use / to change the setting.
3. Press the input selector button for the input source that you
want to set when you have finished.
Video Attenuation
This setting can be made for the BD/DVD, VCR/DVR, CBL/SAT,
GAME, or AUX input.
If you have a game console connected to the composite video
input, and the picture is not very clear, you can attenuate the
gain.
• Video ATT–0: (default).
• Video ATT–2: Gain is reduced by 2 dB.
Note
Design and specifications are subject to change
without notice.
Specification
90 watts minimum continuous power per channel, 8 ohm
loads, 1 channel driven at 1 kHz with a maximum total
harmonic distortion of 1%.
0.08% (1 kHz, 1 W)
200 mV/47 kohms (LINE)
200 mV/2.2 kohms (REC OUT)
20 Hz - 50 kHz/+1 dB - 3 dB (DSP bypass)
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
90 dB (LINE, IHF-A)
6 ohms - 16 ohms
Specification
1 Vp-p/75 ohms (Component)
0.7 Vp-p/75 ohms (Component PB/CB, PR/CR)
1 Vp-p/75 ohms (Composite)
5 Hz - 100 MHz/±0 dB, - 3 dB
31
