Cylindrical Inductive Sensor for Explosive Environments
E2AX
• ATEX certification Group II category 3D
(94/9/EG Appendix VIII)
• Typically for explosive areas zone 22 with
non leading dust construction based on EN50014
and EN50281-1-1/2
Ordering Information
DC 3-wire models (NO + NC: DC 4-wire)
Sensing
Connec-
Size
distance
tion
Shiel-
M12
4.0 mm
ded
connector
M12
Non-
M12
shiel-
8.0 mm
connector
ded
Shiel-
M12
8.0 mm
ded
connector
M18
Non-
M12
shiel-
16.0 mm
connector
ded
Shiel-
M12
15.0 mm
ded
connector
M30
20.0 mm
Non-
M12
shiel-
connector
ded
30.0 mm
*1. Please contact your OMRON representative for DC 2-wire models.
*2. Stainless steel models are also available. Please contact your OMRON representative.
Note:
M30 non-shielded models with double sensing distance and short barrels cannot be mounted due to the necessary separation distance from the surrounding
metal. Standard sensing models are thus available.
E2AX
*1
Thread
Output
Body
length
confi-
material
(overall
guration
length)
PNP
E2AX-M12KS04-M1-B1
34 (48)
NPN
E2AX-M12KS04-M1-C1
*2
Brass
PNP
E2AX-M12LS04-M1-B1
56 (70)
NPN
E2AX-M12LS04-M1-C1
PNP
E2AX-M12KN08-M1-B1
34 (48)
NPN
E2AX-M12KN08-M1-C1
*2
Brass
PNP
E2AX-M12LN08-M1-B1
56 (70)
NPN
E2AX-M12LN08-M1-C1
PNP
E2AX-M18KS08-M1-B1
39 (53)
NPN
E2AX-M18KS08-M1-C1
*2
Brass
PNP
E2AX-M18LS08-M1-B1
61 (75)
NPN
E2AX-M18LS08-M1-C1
PNP
E2AX-M18KN16-M1-B1
39 (53)
NPN
E2AX-M18KN16-M1-C1
*2
Brass
PNP
E2AX-M18LN16-M1-B1
61 (75)
NPN
E2AX-M18LN16-M1-C1
PNP
E2AX-M30KS15-M1-B1
44 (58)
NPN
E2AX-M30KS15-M1-C1
*2
Brass
PNP
E2AX-M30LS15-M1-B1
66 (80)
NPN
E2AX-M30LS15-M1-C1
44 (58)
PNP
E2AX-M30KN20-M1-B1
(See
NPN
E2AX-M30KN20-M1-C1
note.)
*2
Brass
PNP
E2AX-M30LN30-M1-B1
66 (80)
NPN
E2AX-M30LN30-M1-C1
Operation mode NO
Operation mode NC
E2AX-M12KS04-M1-B2
E2AX-M12KS04-M1-C2
E2AX-M12LS04-M1-B2
E2AX-M12LS04-M1-C2
E2AX-M12KN08-M1-B2
E2AX-M12KN08-M1-C2
E2AX-M12LN08-M1-B2
E2AX-M12LN08-M1-C2
E2AX-M18KS08-M1-B2
E2AX-M18KS08-M1-C2
E2AX-M18LS08-M1-B2
E2AX-M18LS08-M1-C2
E2AX-M18KN16-M1-B2
E2AX-M18KN16-M1-C2
E2AX-M18LN16-M1-B2
E2AX-M18LN16-M1-C2
E2AX-M30KS15-M1-B2
E2AX-M30KS15-M1-C2
E2AX-M30LS15-M1-B2
E2AX-M30LS15-M1-C2
E2AX-M30KN20-M1-B2
E2AX-M30KN20-M1-C2
E2AX-M30LN30-M1-B2
E2AX-M30LN30-M1-C2
Operation mode NO + NC
E2AX-M12KS04-M1-B3
E2AX-M12KS04-M1-C3
E2AX-M12LS04-M1-B3
E2AX-M12LS04-M1-C3
E2AX-M12KN08-M1-B3
E2AX-M12KN08-M1-C3
E2AX-M12LN08-M1-B3
E2AX-M12LN08-M1-C3
E2AX-M18KS08-M1-B3
E2AX-M18KS08-M1-C3
E2AX-M18LS08-M1-B3
E2AX-M18LS08-M1-C3
E2AX-M18KN16-M1-B3
E2AX-M18KN16-M1-C3
E2AX-M18LN16-M1-B3
E2AX-M18LN16-M1-C3
E2AX-M30KS15-M1-B3
E2AX-M30KS15-M1-C3
E2AX-M30LS15-M1-B3
E2AX-M30LS15-M1-C3
E2AX-M30KN20-M1-B3
E2AX-M30KN20-M1-C3
E2AX-M30LN30-M1-B3
E2AX-M30LN30-M1-C3
D-9
