Brass-nickel plated Note 1. The response frequency is an average value. Measurement conditions are as follows: standard sensing object, a distance of twice the standard sensing object length between sensing objects, and a set distance of half the sensing distance.
Engineering Data Operating Range (Typical) E2A3-M30KS20 E2A3-M18KS11 E2A3-M12KS06 E2A3-S08KS03 −30 −20 −10 Distance Y (mm) Influence of Sensing Object Size and Materials E2A3-S08KS03 E2A3-M12KS06 E2A3-M18KS11 t = 1 mm Iron t = 1 mm t = 1 mm Iron Iron...
Black Sensor main (See note 1.) circuits Load Blue Yellow indicator E2A3-@-@-B1 Note 1: With M8 Size Models, there is no output reverse Control output polarity protection diode. M12 Connector M8 Connector Pin Arrangement (3-pin) (See note 2.) Pin Arrangement Note 2: Terminal 2 of the M12 connector is not used.
Page 6
Proximity (See note 1.) Black Sensor main circuits Blue Yellow indicator E2A3-@-@-C1 Note 1: With M8 Size Models, there is no output reverse Control output polarity protection diode. M8 Connector M12 Connector Pin Arrangement (3-pin) Pin Arrangement (See note 2.) Note 2: Terminal 2 of the M12 connector is not used.
4 (*) 2.5 (*) 6 (*) 4 (*) E2A3 Shielded * Using the nuts provided with the E2A3 allows mounting in the way shown be- low. Nut provided with E2A3 = 0 mm E2A3 D-43...
150 N·m <SUITABILITY FOR USE> OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the combination of the products in the customer’s application or use of the products. Take all necessary steps to determine the suitability of the product for the systems, machines, and equipment with which it will be used.
