Miniature Cylindrical Proximity Sensor
E2E
High performance in
small sizes
• pre-wired and M8 connector models
• 3 mm, 4 mm, 5.4 mm and M5 sizes
• response frequency up to 3 kHz
Ordering Information
Size
dia 3 mm
shielded
dia 4 mm
M5
dia 5.4 mm
E2E
Sensing
Connection
Distance
0.6 mm
pre-wired
0.8 mm
pre-wired
M8 connector
1 mm
pre-wired
M8 connector
pre-wired
Housing
Output
Material
stainless steel
PNP
NPN
PNP
NPN
PNP
NPN
brass
PNP
NPN
PNP
NPN
PNP
NPN
Operation
Operation
mode NO
mode NC
E2E-CR6B1
E2E-CR6B2
E2E-CR6C1
E2E-CR6C2
E2E-CR8B1
E2E-CR8B2
E2E-CR8C1
E2E-CR8C2
E2E-CR8B1-M5 E2E-CR8B2-M5
E2E-CR8C1-M5 E2E-CR8C2-M5
E2E-X1B1
E2E-X1B2
E2E-X1C1
E2E-X1C2
E2E-X1B1-M5
E2E-X1B2-M5
E2E-X1C1-M5
E2E-X1C2-M5
E2E-C1B1
E2E-C1B2
E2E-C1C1
E2E-C1C2
1
