Omron CX-PROGRAMMER 5.0-FUNCTION BLOCK OPERATION Operation Manual page 92

Instruction Support and Operand Restrictions
Instruction Mnemonic
FLOATING TO 32- FIXL
BIT
@FIXL
16-BIT TO FLOAT- FLT
ING
@FLT
32-BIT TO FLOAT- FLTL
ING
@FLTL
FLOATING-POINT +F
ADD
@+F
FLOATING-POINT -F
SUBTRACT
@-F
FLOATING- POINT *F
MULTIPLY
@*F
FLOATING- POINT /F
DIVIDE
@/F
DEGREES TO RADI- RAD
ANS
@RAD
RADIANS TO DEG
DEGREES
@DEG
Function Symbol
code
451
FIXL
S
R
452
FLT
S
R
453
FLTL
S
R
454
+F
Au
Ad
R
455
-F
Mi
Su
R
456
* F
Md
Mr
R
457
/F
Dd
Dr
R
458
RAD
S
R
459
DEG
S
R
Operands Supported
variable
data types
S: 1st source word REAL
R: Result word DINT
S: Source word INT
R: 1st result word REAL
S: 1st source word DINT
R: Result word REAL
Au: 1st augend REAL
word
Ad: 1st addend REAL
word
R: 1st result word REAL
Mi: 1st Minuend REAL
word
Su: 1st Subtrahend REAL
word
R: 1st result word REAL
Md: 1st Multiplicand REAL
word
Mr: 1st Multiplier REAL
word
R: 1st result word REAL
Dd: 1st Dividend REAL
word
Dr: 1st Divisor word REAL
R: 1st result word REAL
S: 1st source word REAL
R: 1st result word REAL
S: 1st source word REAL
R: 1st result word REAL
Section 2-6
AT
setting or
array
variable
required
(Required
word data
size
shown in
parenthe-
ses.)
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
