Network Instructions - Omron CX-PROGRAMMER 5.0-FUNCTION BLOCK OPERATION Operation Manual

Instruction Support and Operand Restrictions

2-6-23 Network Instructions

Instruction Mnemonic
NETWORK SEND SEND
@SEND
NETWORK RECEIVE RECV
@RECV
DELIVER COMMAND CMND
@CMND
EXPLICIT MESSAGE EXPLT
SEND
EXPLICIT GET EGATR
ATTRIBUTE
Function Symbol
code
090
SEND
S
D
C
098
RECV
S
D
C
490
CMND
S
D
C
720
EXPLT
S
D
C
721
EGATR
S
D
C
Operands Supported
variable
data types
S: 1st source word UINT
D: 1st destination UINT
word
C: 1st control word WORD
S: 1st source word UINT
D: 1st destination UINT
word
C: 1st control word WORD
S: 1st command UINT
word
D: 1st response UINT
word
C: 1st control word WORD
S: 1st word of send WORD
message
D: 1st word of WORD
received message
C: 1st control word LWORD
S: 1st word of send ULINT
message
D: 1st word of WORD
received message
C: 1st control word LWORD
message
Section 2-6
AT
setting or
array
variable
required
(Required
word data
size
shown in
parenthe-
ses.)
Yes (not
fixed)
Specify
address at
remote
node with
AT setting.
Yes (5)
Specify
address at
remote
node with
AT setting.
Yes (not
fixed)
Yes (5)
Yes (not
fixed)
Yes (not
fixed)
Yes (6)
Yes (not
fixed)
Yes (not
fixed)
Yes (4)
WORD
must be
used
when
array vari-
ables are
required.
Yes (4)
WORD
must be
used
when
array vari-
ables are
required.
Yes (not
fixed)
Yes (4)
93
