Instruction Support and Operand Restrictions
Instruction Mnemonic
AND NOT AND NOT
!AND NOT
@AND NOT
%AND NOT
!@AND NOT
!%AND NOT
OR OR
@OR
%OR
!OR
!@OR
!%OR
OR NOT OR NOT
!OR NOT
@OR NOT
%OR NOT
!@OR NOT
!%OR NOT
AND LOAD AND LD
OR LOAD OR LD
NOT NOT
CONDITION UP
ON
CONDITION DOWN
OFF
BIT TEST LD TST
BIT TEST LD TSTN
54
Function Symbol
code
Bus bar
Bus bar
Logic block Logic block
Logic block
Logic block
520
NOT
521
UP
522
DOWN
350
TST
S
N
351
TSTN
S
N
Operands Supported
variable
data types
--- BOOL
--- BOOL
--- BOOL
--- ---
--- ---
--- ---
--- ---
--- ---
S: Source word WORD
N: Bit number UINT
S: Source word WORD
N: Bit number UINT
Section 2-6
AT setting or
array variable
required
(Required word
data size
shown in
parentheses.)
---
---
---
---
---
---
---
---
---
---
---
---
