Start up Creating a
CX-D new project
Transferring project data
Transferring project data
1. Transferring project data via serial cable(RS232C)
1. Transferring project data via serial cable(RS232C)
Click
Click the Setting button.
Select "Serial" from the
Comms. Method pull-
down menu.
Click the Set... button.
Project
property
Transferring projects created on CX-Designer to the NS hardware.
There are six ways to transfer a project: serial cable, Modem, Ethernet,
Controller link, USB and Memory card.
In this manual, you will transfers project data via serial cable and using a memory card.
Before you start...
Connect the NS hardware to the personal computer with the communication cable
(XW2Z-S002).
System Creating
setting a screen
Transferring
Validation
a project
