Knob-type selector switch

Advertisement

Quick Links

Knob-type Selector Switch
A165S/W
Mounting Aperture of 16 mm
• Modular construction
• Oil-resistant IP65 models
• UL and cUL approved.
• Conforms to EN60947-5-1, IEC947-5-1
• Short mounting depth, less than 28.5 mm below panel
• Wide range of switching capacity from standard to microload
• Lighted and non-lighted models
• 2 and 3-notch models
• Manual and automatic reset models
Model Number Structure
■ Model Number Legend
Completely Assembled
The model numbers used to order sets of Units are illustrated below. One set comprises the Selector, Lamp (lighted models only), and Switch.
A 1 6 5 W - A 2A R - 24D - 1
(1) Lighted/Non-lighted
Symbol
Type
S
Non-lighted
W
Lighted
(2) Shape of Selector
Symbol
Shape
(3) Number of Notches/Resetting Method
J
Rectangular
Symbol
A
Square
2M
T
Round
2A
BA
Square
(24-mm square)
3M
3A
3MA
3AM
(1)
(2)
(3)
No. of notches
Reset method
Manual
2 notches
Automatic
Manual
Automatic
3 notches
CCW-manual,
CW-automatic
CCW-automatic,
CW-manual
(4)
(5)
(4) Color of Selector
Symbol
Color
No symbol
Black
(non-lighted
models only)
R
Red
G
Green
Y
Yellow
Voltage Reduction Unit (24-V Built-in LED)
Symbol
T1
T2
Note: 1. Solder terminals are only available with 100-V
Knob-type Selector Switch
(6)
(6) Contact Configuration
Symbol
Type
Terminal
1
SPDT
Solder
terminal
2
DPDT
1P
SPDT
PCB
terminal
2P
DPDT
2S
DPDT
Screw-Less
Clamp
Note: 1. Only DPDT contacts are availa-
ble with 3-notch models and
Screw-Less Clamp models.
2. PCB terminals are available
only with 2-notch models.
(5) Light Source
Symbol
Type
No symbol
Non-lighted
24D
24-V LED
Type
Operating voltage
90 to 121 VAC/VDC
110 VAC/VDC
LED
180 to 242 VAC/VDC
220 VAC/VDC
models.
2. The Voltage Reduction Unit is not available for
models with PCB terminals.
A165S/W
Rated
voltage
G-59

Advertisement

loading

Summary of Contents for Omron A165S

  • Page 1 ■ Model Number Legend Completely Assembled The model numbers used to order sets of Units are illustrated below. One set comprises the Selector, Lamp (lighted models only), and Switch. A 1 6 5 W - A 2A R - 24D - 1...
  • Page 2 3. Number of Notches/Reset Method 2 notches/Manual 2 notches/Automatic 3 notches/Manual 3 notches/Mixed-operation 3MA: 3 notches 3AM: 3 notches 2. Switch (Same as for Key-type Selector Switches) A16S-@-@@@ 1. Number of Notches 3. Lighted/Non-lighted 2 notches None: Non-lighted 3 notches Lighted 2.
  • Page 3: Ordering Information

    Ordering Information ■ List of Models Ordering as a Set The model numbers used to order sets of Units are given in the following tables. One set comprises the Selector, Lamp (lighted models only), and Switch. Solder Terminals A165@-J (Rectangular) Models IP65 Oil-resistant No.
  • Page 4 Non-lighted A165S-T2A-2 3 notches DPDT 24 VDC A165W-T3M@-24D-2 Manual Non-lighted A165S-T3M-2 Note: Enter the desired color symbol for the Selector in @: R (red); Y (yellow); G (green). The Selector for non-lighted models is black. A165S/W G-62 Knob-type Selector Switch...
  • Page 5 Ordering Individually Selectors, Lamps, and Switches (Sockets) can be ordered separately. Combinations that are not available as sets can be created using individual Units. Also, store the parts as spares for maintenance and repairs. Selector Selectors with Knobs Rectangular Models...
  • Page 6 Non-lighted A165S-T3MA 24 VDC A165W-T3AM@ Mixed- operation Non-lighted A165S-T3AM Note: 1. Enter the desired color symbol for the Selector in the @. 2. The selector for non-lighted models is black. Switches Appearance Classification Model Lighted Socket (without 2 notches...
  • Page 7 A16-12DSG A16-24DSG Accessories (Order Separately) Accessories Name Appearance Classification Model Remarks Panel Plugs Rectangular A16ZJ-3003 Used for covering the panel cutouts for future panel expansion. Square A16ZA-3003 Degree of protection: IP40 Round A16ZT-3003 Tools Name Appearance Model Applicable types Remarks...
  • Page 8: Specifications

    Dielectric strength 1,000 VAC, 50/60 Hz for 1 min between terminals of same polarity 2,000 VAC, 50/60 Hz for 1 min between terminals of different polarity and also between each ter- minal and ground 1,000 VAC, 50/60 Hz for 1 min between lamp terminals (see note 2)
  • Page 9 Operating force (OF) max. 9.8 N·m Set position (SP) 90 5 ■ Operation Angle Two notches Three notches Note: 1. The angle used for automatic reset is shown in parentheses. 2. FP: Free Position ■ Contact Form Name Contact SPDT Notch...
  • Page 10 Red, green, yellow Non-lighted models Rectangular (A165@-J) Black Lighting Method Lighted (LED) models Square (A165@-A) (The upper face of the knob is illuminated.) Non-lighted models Number of Notches and Reset Method Round (A165@-T) 2 Notches Manual reset Automatic reset 3 Notches...
  • Page 11 Dimensions Note: All units are in millimeters unless otherwise indicated. ■ Knob-type Selector Switches without Voltage Reduction Unit Rectangular A165@-J Solder terminals (tab terminals #110) Lamp terminal Model, standard, lot No., serial number Mounting nut Packing (t0.5) Lock ring Note: See page 14 for panel cutouts.
  • Page 12 The following diagrams show the rectangular model as a representative example. The lamp terminal is also provided with non-lighted models. Rectangular A165@-J PCB terminals Lamp terminal Lock ring Packing (t0.5) Mounting ring Note: See page 14 for panel cutouts. Rectangular...
  • Page 13 Side with TOP indicated Side with TOP indicated Eight, 1 dia. Eight, 1 dia. Two, 5 dia. Two, 5 dia. Note: For details of the terminal arrangement for Screw-Less Clamps, refer to the corresponding section for the A16. A165S/W G-71 Knob-type Selector Switch...
  • Page 14 19 min. Note: 1. Make sure the thickness of the mounting panel is 0.5 to 3.2 mm. 2. If the panel is to be finished with coating, etc., make sure that the panel meets the specified dimensions after coating. A165S/W...
  • Page 15: Installation

    Note: 1. Ensure that the variation in the distance between the centers of neighboring mounting holes is less than 0.1 mm. 2. Make sure the thickness of the mounting panel is 0.5 to 3.2 mm. If, however, a Switch Guard or Dust Cover is used, the thickness of the mounting panel must be 0.5 to 2 mm.
  • Page 16 ALL DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527. In the interest of product improvement, specifications are subject to change without notice. Cat. No. A125-E1-02 A165S/W G-74...
