Introduction

Introduction
1.1

Overview

®
The Intel NetStructure
intended for use with AdvancedTCA* PICMG* 3.0 platforms. This document details the software
features and specifications of the CMM. For information on hardware features for the CMM refer
®
to the Intel
specifications and other material can be found in
The CMM plugs into a dedicated slot in compatible systems. It provides centralized management
and alarming for up to 16 node and/or fabric slots as well as for system power supplies, fans and
power entry modules. The CMM may be paired with a backup for redundant use in high-
availability applications.
The CMM is a special purpose single board computer (SBC) with its own CPU, memory, PCI bus,
operating system, and peripherals. The CMM monitors and configures IPMI-based components in
the chassis. When thresholds (such as temperature and voltage) are crossed or a failure occurs, the
CMM captures these events, stores them in an event log, sends SNMP traps, and drives the Telco
alarm relays and alarm LEDs. The CMM can query FRU information (such as serial number,
model number, manufacture date, etc.), detect presence of components (such as fan tray, CPU
board, etc.), perform health monitoring of each component, control the power-up sequencing of
each device, and control power to each slot via IPMI.
Assumptions: This document assumes some basic Linux* knowledge and the ability to use Linux
text editors such as vi.
1.2

Terms Used in this Document

Table 1. Glossary (Sheet 1 of 2)
Acronym
BIST
CDM
CLI
CMM
DHCP
FFS
FIS
FPGA
FRU
HS
IPMI
IPMB
16 MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
TM
MPCMM0001 Chassis Management Module is a 4U, single-slot CMM
NetStructure™ MPCMM0001 Hardware Technical Product Specification. Links to
Built-In Self Test
Chassis Data Module
Command Line Interface
Chassis Management Module
Dynamic Host Configuration Protocol
Flash File System
Flash Image System
Field-Programmable Gate Arrays
Field Replaceable Unit
Hot Swap
Intelligent Platform Management
Intelligent Platform Management Bus
Appendix B, "Data Sheet Reference."
Description
