Instructions for Use
Thank you for your trust and for buying this appliance. We hope it will
successfully serve the purpose for many years.
Refrigerator with freezer is for domestic use only.
The lower part of the appliance is refrigerator and is used for
storing fresh foods at the temperature of 0°C and higher.
The upper part is freezer and is used for freezing fresh foods and
storing frozen foods for longer periods of time (up to one year,
depending on the kind of foods you store). The compartment is marked
with four stars.
Refrigerator - Freezer
Before putting into use
Placing and installation
Description of the appliance
Operation control
Use
Maintenance and cleaning
Trouble-shooting guide
Instructions for Use
58-60
61
62-63
64
65-68
69-70
71-73
57
Advertisement
Table of Contents
Related Manuals for Smeg FL281A
Summary of Contents for Smeg FL281A
-
Page 1: Instructions For Use
Instructions for Use Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. Refrigerator with freezer is for domestic use only. The lower part of the appliance is refrigerator and is used for storing fresh foods at the temperature of 0°C and higher. -
Page 2: Before Putting Into Use
Before Putting Into Use • Before connecting the appliance to the mains supply, place it on the location where it will later on be installed and leave it for about 2 hours, which will reduce a possibility of malfunctions in the cooling system due to transport handling. - Page 3 • Ice and frost layer increase energy consumption, so do clean the appliance as soon as the layer is 3-5 mm thick. • If the gasket is damaged or if it turns out that the sealing is poor, the energy consumption is substantially higher. To restore efficiency, replace the gasket.
-
Page 4: Disposing Of The Worn Out Appliance
• If the supply cord is damaged, it must be replaced by the manufacturer or his service agent or a qualified person in order to avoid hazard. • The rating plate is inside the appliance or outside on the rear wall. Storing Time During Power Supply Interruption Do not open the freezer in case of failure or power supply interruption! In case the interruption is extended over longer period of time (16... -
Page 5: Placing And Installation
Placing and Installation Choosing the Right Place Place the appliance in dry and regularly ventilated room. Allowed ambient temperature depends on the model (class) of the appliance and is stated on the rating plate of the appliance. Class SN (sub-normal) N (normal) ST (sub-tropical) T (tropical) -
Page 6: Description Of The Appliance
Description of the Appliance Refrigerator (A) Refrigerator is used for storing fresh foods for few days. Freezer (B) Freezer is used for freezing fresh foods and for storing already frozen foods. Shelf (1) (number depends on the model) Shelf can be optionally placed on the guides inside the appliance. It is protected against pulling out. -
Page 7: Door Liner
Bottle rack (in some models only) Bottle rack (number depends on model) is intended for storing the bottles. There are two installation positions available (horizontal or lifted in the front) thus enabling the positioning of bottles on the stopper as well. It is protected against pulling out. -
Page 8: Operation Control
Operation Control The appliance is controlled with thermostat knob, situated in the right upper part inside the appliance. Turn the knob clockwise from STOP (0) position towards 7 and backwards. Temperature Selection • Higher settings on the knob (towards 7) mean lower temperatures (colder) in all compartments of the appliance. -
Page 9: Storing Fresh Foods
Storing Fresh Foods Proper use of the appliance, adequately packed food, correct temperature and taking into account hygienic precautions will substantially influence the quality of the food stored. • Foods to be stored in the refrigerator should be properly packed as to prevent mixing various moisture degrees and odours (in polyethylene bags or sheet, aluminium foil, wax paper, or stored in covered containers or bottles). -
Page 10: Freezing Fresh Foods
Fresh Food Storage Time in the Refrigerator Article of food Butter Eggs Meat: fresh uncut chopped smoked Fish Marinade Root Cheese Sweets Fruit Prepared dishes Legend: + reccomended storage time = possible storage time Freezing Fresh Foods • Carefully select food you intend to freeze; it should be of adequate quality and suitable for freezing. -
Page 11: Storing Frozen Foods
• If you have a model with integrated switch for intensive cooling, switch it on some 24 hours before loading the appliance with larger amounts of fresh foods and turn the thermostat knob to position 4-7. After 24 hours load the appliance with fresh food packages. After loading, wait for another 24 hours and switch off the switch and turn the thermostat knob to required position (see "Temperature selection"). -
Page 12: Defrosting Frozen Food
Approximate Storage Time for Frozen Foods Food Vegetable Fruit Braed, Pastries Milk Redy-made meals Meat: Beef Veal Pork Poultry Game Minced meat Smoked sausages Fish: lean Offal Defrosting Frozen Food Partially thawed or defrosted foods should be used as soon as possible. -
Page 13: Maintenance And Cleaning
Maintenance and Cleaning Automatic Defrosting of the Refrigerator There is no need to defrost the refrigerator, because ice depositing on the inner back wall is defrosted automatically. Ice is depositing on the inner back wall during the compressor operation; later on, when the compressor is not operating ice is defrosting and water drops collect and drain through the outlet in the inner back wall into the drain pan situated above the compressor, from where it evaporates. -
Page 14: Switch Off The Appliance When Not In Use
• Every now and then wipe the condenser on the rear wall. Use soft non-metal brush or vacuum cleaner. • Do not forget to clean also the defrost water receptacle above the refrigerator compressor (do not remove the receptacle). After cleaning, connect the appliance to power supply and reload the packages. -
Page 15: Troubleshooting Guide
Trouble-Shooting Guide During the service, you can come across some troubles that in most cases result from improper handling of the appliance and can easy be eliminated. The Appliance Fails to Operate After connecting to the Mains Supply • Check the supply in the outlet socket and make sure the appliance is switched on (thermostat in operating position). -
Page 16: Bulb Replacement
• Clean the clogged opening, for example with a plastic straw. • Manually defrost the increased ice layer. See "Ice Formation on the Inner Back Wall". The Freezer Door is Hard to Open If you want to open the door that has just or recently been closed, you may find it hard to open. - Page 17 Don't forget: the old bulb does not belong to organic waste. Light bulb is consuming good therefore our in-guarantee service does not relate to it. WE RESERVE THE RIGHT TO ALTER THE SPECIFICATIONS WITH NO INFLUENCE ON THE OPERATION OF THE APPLIANCE. Instructions for Use...
- Page 18 Integrated Refrigerator with Freezer Mounting instructions for refrigerating and freezing appliances are for qualified technicians only. Appliance should be mounted and installed in compliance with these instructions, current standards and regulations. Mounting instructions were prepared for various types/models of appliances, therefore they may describe some procedures that do not apply to your appliance.
-
Page 19: Changing The Direction Of Opening The Door
Changing the Direction of Opening the Door If you find the direction of opening the door on your appliance inconvenient, you can change it. Holes on the opposite side have already been prepared in the factory and are now plugged. •... -
Page 20: Mounting The Appliance
Mounting the Appliance • Push the appliance for some 38 mm into the kitchen unit and allow at least 4 mm free space on both sides between the appliance and the side walls of the kitchen unit (Fig. 1). • Widely open both the doors and put them together with the door of the kitchen unit. The procedure is as follows: −...
