Instructions for Use
Thank you for your trust and for buying this appliance. We hope it will
successfully serve the purpose for many years.
Refrigerator with freezer is for domestic use only.
The lower part of the appliance is refrigerator and is used for
storing fresh foods at the temperature of 0°C and higher.
The upper part is freezer and is used for freezing fresh foods and
storing frozen foods for longer periods of time (up to one year,
depending on the kind of foods you store). The compartment is marked
with four stars.
Refrigerator - Freezer
Before Putting Into Use
Placing and Installation
Description of the Appliance
Operation Control
Use
Maintenance and Cleaning
Trouble-Shooting Guide
Instructions for Use
56-58
59
60-61
62
63-66
67-68
69-70
55
Advertisement
Table of Contents
Related Manuals for Smeg FI227B
Summary of Contents for Smeg FI227B
-
Page 1: Instructions For Use
Instructions for Use Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. Refrigerator with freezer is for domestic use only. The lower part of the appliance is refrigerator and is used for storing fresh foods at the temperature of 0°C and higher. -
Page 2: Before Putting Into Use
Before Putting Into Use • Before connecting the appliance to the mains supply, place it on the location where it will later on be installed and leave it for about 2 hours, which will reduce a possibility of malfunctions in the cooling system due to transport handling. - Page 3 • Ice and frost layer increase energy consumption, so do clean the appliance as soon as the layer is 3-5 mm thick. • If the gasket is damaged or if it turns out that the sealing is poor, the energy consumption is substantially higher. To restore efficiency, replace the gasket.
-
Page 4: Disposing Of The Worn Out Appliance
dispose it of in compliance with environmental protecting precautions. (See We Care for the Environment). • In the supply cord is damaged, it must be replaced by the manufacturer or his service agent or a qualified person in order to avoid hazard. -
Page 5: Placing And Installation
Placing and Installation Choosing the Right Place Place the appliance in dry and regularly ventilated room. Allowed ambient temperature depends on the model (class) of the appliance and is stated on the rating plate of the appliance. Class SN (sub-normal) N (normal) ST (sub-tropical) T (tropical) -
Page 6: Description Of The Appliance
Description of the Appliance Refrigerator (A) Refrigerator is used for storing fresh foods for few days. Freezer (B) Freezer is used for freezing fresh foods and for storing already frozen foods. Shelf (1) (number depends on the model) Shelf can be optionally placed on the guides inside the appliance. It is protected against pulling out. - Page 7 Bottle rack (in some models only) Bottle rack (number depends on model) is intended for storing the bottles. There are two installation positions available (horizontal or lifted in the front) thus enabling the positioning of bottles on the stopper as well.
-
Page 8: Operation Control
Operation Control The appliance is controlled with thermostat knob, situated in the right upper part inside the appliance. Turn the knob clockwise from STOP (0) position towards 7 and backwards. Temperature Selection • Higher settings on the knob (towards 7) mean lower temperatures (colder) in all three compartments of the appliance. -
Page 9: Storing Fresh Foods
Storing Fresh Foods Proper use of the appliance, adequately packed food, correct temperature and taking into account hygienic precautions will substantially influence the quality of the food stored. • Foods to be stored in the refrigerator should be properly packed as to prevent mixing various moisture degrees and odors (in polyethylene bags or sheet, aluminium foil, wax paper, or stored in covered containers or bottles). -
Page 10: Freezing Fresh Foods
Fresh Food Storage Time in the Refrigerator Article of food Butter Eggs Meat: fresh uncut chopped smoked Fish Marinade Root Cheese Sweets Fruit Prepared dishes Legend: + reccomended storage time = possible storage time Freezing Fresh Foods • Carefully select food you intend to freeze; it should be of adequate quality and suitable for freezing. -
Page 11: Storing Frozen Foods
• For freezing smaller amount of foods (up to 1 kg) there is no need to change the thermostat setting (see Temperature Selection). Storing Frozen Foods Frozen foods can be stored on the bottom of the appliance or on the shelf. -
Page 12: How To Make Ice Cubes
How to make ice cubes Recommended thermostat position for ice making is on the middle setting. Fill two thirds of the ice tray with cold water or any other liquid convenient for freezing. Insert the ice tray into the guides or on the cooling plate. -
Page 13: Maintenance And Cleaning
Maintenance and Cleaning Automatic Defrosting of the Refrigerator There is no need to defrost the refrigerator, because ice depositing on the inner back wall is defrosted automatically. Ice is depositing on the inner back wall during the compressor operation; later on, when the compressor is not operating ice is defrosting and water drops collect and drain through the outlet in the inner back wall into the drain pan situated above the compressor, from where it evaporates. -
Page 14: Switch Off The Appliance When Not In Use
• Every now and then wipe the condenser on the rear wall. Use soft non-metal brush or vacuum cleaner. • Clean the drain pan on the refrigerator compressor. Do not remove the drain pan! After cleaning, connect the appliance to power supply and reload the packages. -
Page 15: Troubleshooting Guide
Trouble-Shooting Guide During the service, you can come across some troubles that in most cases result from improper handling of the appliance and can easy be eliminated. The Appliance Fails to Operate After connecting to the Mains Supply • Check the supply in the outlet socket and make sure the appliance is switched on (thermostat in operating position). - Page 16 • Manually defrost the increased ice layer. See "Ice Formation on the Inner Back Wall". Noise Cooling in refrigerating-freezing appliances is enabled by the refrigerating system with compressor, which produces noise. How noisy the appliance is depends on where it is placed, how it is used and how old the appliance is.
-
Page 17: Mounting Instructions
Mounting Instructions Integrated Refrigerating and Mounting instructions for refrigerating and freezing appliances are for qualified technicians only. Appliance should be mounted and installed in compliance with these instructions, current standards and regulations. Mounting instructions were prepared for various types/models of appliances, therefore they may describe some procedures that do not apply to your appliance. - Page 18 Mounting Dimensions and Required Air Circulation The rear wall of the appliance is getting warm during the operation of the appliance (and water is evaporating from the drain pan on the compressor). You must therefore provide for adequate air circulation on the rear of the appliance. At the base of the kitchen unit intended for building in the integrated appliance, there should be at least 200 cm²...
-
Page 19: Changing The Direction Of Opening The Door
Changing the Direction of Opening the Door If you find the direction of opening the door on your appliance inconvenient, you can change it. Holes on the opposite side have already been prepared in the factory and are now plugged. Remove the cover of the upper hinge, unscrew the hinge and take off the door (the door is not fixed on the lower hinge). - Page 20 1 Cover for the upper hinge 2 Upper hinge 3 Upper rail 4 Slide guide 5 Lower hinge washer 10 Low temperature compartment 11 Blocking element 6 Lower hinge fastener 7 Lower hinge 8 Corner without a hole 9 Corner with a hole 12 Door hinge Mounting Instructions...
-
Page 21: Mounting The Appliance
Mounting the Appliance Push the appliance for some 38 mm into the kitchen unit and allow at least 4 mm free space on both sides between the appliance and the side walls of the kitchen unit (Fig. 1). Widely open the door and put it together with the kitchen unit door. - Page 22 Fig. 1 Fig. 2 Fig.3 Fig. 4 Fig. 5 Fig. 6 Mounting Instructions...
