Refrigerator - Freezer
Thank you for your trust and for buying this appliance. We hope it will
Refrigerator with freezer is for domestic use
only.
The lower part of the appliance is
refrigerator and is used for storing fresh foods
at the temperature of 0°C and higher.
Before Putting Into Use.......................30
Instructions for Use
Mounting Instructions
We Care for the Environment
Tips for Energy Savings
Important .............................................31
Disposing of the Worn Out Appliance
Placing and Installation ......................31
Choosing the Right Place
Connection to Power Supply
Description of the Appliance ..............32
Refrigerator (A)
Freezer (B)
Opening the freezer door
Before Putting Into Use
• Before connecting the appliance to the mains
supply, place it on the location where it will
later on be installed and leave it for about 2
hours, which will reduce a possibility of
malfunctions in the cooling system due to
transport handling.
• Clean the appliance, and be thorough,
especially in the interior (See Cleaning and
Maintenance).
• In case the interior accessories are not
correctly placed, rearrange them as
described in chapter Description of the
Appliance.
Instructions for Use
These instructions for use are intended for the
user. They describe the appliance and its
correct and safe use. They were prepared for
various types of refrigerators therefore you
might find in it some functions that do not apply
to your appliance and description of the
30
successfully serve the purpose for many years.
Instructions for Use
The upper part is freezer and is used for
freezing fresh foods and storing frozen foods
for longer periods of time (up to one year,
depending on the kind of foods you store). The
compartment is marked with four stars.
Operation Control ...............................33
Temperature Selection
Use.........................................................34
Storing Fresh Foods
Freezing Fresh Foods
Storing Frozen Foods
How to make ice cubes
Maintenance and Cleaning .................36
Automatic Defrosting of the Refrigerator
Manual Defrosting of the Frezing
Compartment
Cleaning the Appliance
Switch Off the Appliance When Not In Use
Trouble-Shooting Guide......................37
accesories that your appliance does not
include.
Mounting Instructions
Integrated appliances are equipped with
instructions for mounting the appliance into the
kitchen unit. The appliance should be mounted
by qualified technician and instructions are for
his use only.
We Care for the Environment
• Our products use environmentally friendly
packaging, which can be either recycled or
disposed of in an environmentally friendly
manner. To this end, individual packaging
materials are clearly marked.
• These instructions are printed either on
recycled paper or chlorine free bleached
paper.
• When your appliance finally wears out,
please try not to burden the environment with
EN
Advertisement
Table of Contents
Related Manuals for Smeg FL167AP
Summary of Contents for Smeg FL167AP
-
Page 1: Before Putting Into Use
Refrigerator - Freezer Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. Refrigerator with freezer is for domestic use only. The lower part of the appliance is refrigerator and is used for storing fresh foods at the temperature of 0°C and higher. - Page 2 it; call your nearest authorised service agent. (See Disposing of the Worn Out Appliance) Tips for Energy Savings • Try not to open the door too often, especially when the weather is wet and hot. Once you open the door, mind to close it as soon as possible.
-
Page 3: Placing And Installation
Placing and Installation Choosing the Right Place Place the appliance in dry and regularly ventilated room. Allowed ambient temperature depends on the model (class) of the appliance and is stated on the rating plate of the appliance. Never place the appliance near heat emitting devices (e.g. -
Page 4: Operation Control
Shelf (1) (number depends on the model) Shelf can be optionally placed on the guides inside the appliance. It is protected against pulling out. If you want to remove it, slightly lift up the back part and pull it out. Glass shelves (some models only have them) are protected with plastic spacers. - Page 5 • Temperature in the refrigerator and in freezing compartment depends on the frequency of opening the door as well. Storing Fresh Foods Proper use of the appliance, adequately packed food, correct temperature and taking into account hygienic precautions will substantially influence the quality of the food stored.
- Page 6 Fresh Food Storage Time in the Refrigerator Article of food Butter Eggs Meat: fresh uncut chopped smoked Fish Marinade Root Cheese Sweets Fruit Prepared dishes Legend: + reccomended storage time Freezing Fresh Foods • Carefully select food you intend to freeze; it should be of adequate quality and suitable for freezing.
-
Page 7: Maintenance And Cleaning
where the temperature is not higher than -18°C. Do not buy packages of food covered with frost layer. This indicates that the package was Approximate Storage Time for Frozen Foods Food Vegetable Fruit Braed, Pastries Milk Redy-made meals Meat: Beef Veal Pork Poultry... -
Page 8: Troubleshooting Guide
• Put a suitable vessel under the frezing compartment to collect the defrost water. Leave the door of the compartment open to accelerate defrosting. • Avoid using defrosting sprays, as they may cause damage to the plastic parts and may be hazardous to health. - Page 9 pan on the compressor, automatic defrosting of the appliance is assured. In case the ice formation on the inner back wall is increased (3-5 mm), ice should be manually defrosted. Set the thermostat knob to STOP (0) position and leave the door open. Never use electric devices for defrosting and do not scrape the ice or frost layer with sharp objects.
-
Page 10: Mounting Instructions
Mounting Instructions Integrated Refrigerating and Mounting instructions for refrigerating and freezing appliances are for qualified technicians only. Appliance should be mounted and installed in compliance with these instructions, current standards and regulations. Mounting instructions were prepared for various types/models of appliances, therefore they may describe some procedures that do not apply to your appliance. - Page 11 Mounting Dimensions and Required Air Circulation The rear wall of the appliance is getting warm during the operation of the appliance (and water is evaporating from the drain pan on the compressor). You must therefore provide for adequate air circulation on the rear of the appliance. At the base of the kitchen unit intended for building in the integrated appliance, there should be at least 200 cm²...
-
Page 12: Changing The Direction Of Opening The Door
Changing the Direction of Opening the Door If you find the direction of opening the door on your appliance inconvenient, you can change it. Holes on the opposite side have already been prepared in the factory and are now plugged. Remove the cover of the upper hinge, unscrew the hinge and take off the door (the door is not fixed on the lower hinge). - Page 13 1 Cover for the upper hinge 2 Upper hinge 3 Upper rail 4 Slide guide 5 Lower hinge washer 10 Low temperature compartment 11 Blocking element 6 Lower hinge fastener 7 Lower hinge 8 Corner without a hole 9 Corner with a hole 12 Door hinge Mounting Instructions...
-
Page 14: Mounting The Appliance
Mounting the Appliance Push the appliance for some 38 mm into the kitchen unit and allow at least 4 mm free space on both sides between the appliance and the side walls of the kitchen unit (Fig. 1). Widely open the door and put it together with the kitchen unit door. - Page 15 Fig. 1 Fig. 2 Fig.3 Fig. 4 Fig. 5 Fig. 6 Mounting Instructions...
