Hotwiret 7976 M/SDSL Standalone Termination Unit
with G.703 Interface

Installation Instructions

Document Number 7976-A2-GZ40-00
March 1999
Product Documentation on the World Wide Web

Installation Overview

7976-A2-GZ40-00
TM
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the
waste of surplus printing. It also helps us maintain competitive prices for our
products.
Complete documentation for this product is available at www.paradyne.com.
Select Library
Technical Manuals
Select the following document:
7976-A2-GB20
Hotwire 7976 M/SDSL Standalone Termination Unit, with G.703 Interface,
User's Guide
To request a paper copy of a Paradyne document:
H
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
H
Outside the U.S.A., call 1-727-530-8623
Installation and configuration of the Hotwiret 7976 Standalone Termination Unit
consists of:
H
Connecting power to the unit.
H
Connecting to the network.
H
Connecting to a DTE.
H
Connecting a system terminal.
H
Providing initial unit identity information or changing existing identity
information.
H
Configuring your unit using internal switchpacks or using the Configuration
Edit menus.
Before you install the Hotwire 7976 Standalone Termination Unit, read the
Important Safety Instructions on page 22.
Be sure to register your warranty at www.paradyne.com. Select Service &
Support
Warranty Registration.
March 1999
Hotwire DSL & MVL Systems.
1
