Paradyne NP 100 User Manual And Installation Manual

Frame relay digital service unit
Hide thumbs Also See for NP 100:
Table of Contents

Advertisement

Quick Links

Download this manual

Frame Relay

Digital Service Unit
User's Manual - Installation Guide
Pub. No. 980-001-0210K
November 2000
The information in this manual pertains
to Base Software Revision 10.01.XX

Advertisement

Table of Contents
loading

Related Manuals for Paradyne NP 100

Summary of Contents for Paradyne NP 100

  • Page 1: Frame Relay

    Frame Relay Digital Service Unit User’s Manual - Installation Guide Pub. No. 980-001-0210K November 2000 The information in this manual pertains to Base Software Revision 10.01.XX...
  • Page 2 TRADEMARKS NetPath is a trademark of Paradyne Corporation. All other products, systems, or services mentioned in this document are trademarks, service marks, registered trademarks or registered service marks of their respective owners. COPYRIGHT NOTICE © Copyright 1996-2000 Paradyne Corporation. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without prior written permission of the copyright owner.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using your NetPath 100 equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning.

  • Page 4: Table Of Contents

    1 Preface About This Manual ..........1-1 Special Instructions .
  • Page 5 Table of Contents General Specifications ......... . 3-15 4 Operation Configuration .
  • Page 6 Alarms ............5-31 Fault Isolation .
  • Page 7 Table of Contents Appendix Fault & Test Screen Displays ........A-1 CSU Fault .
  • Page 8 Figure 5-2 Figure 5-3 980-001-0210K FrameSaver NP 100 User’s Manual - Installation Guide November 2000 List of Figures NetPath 100 Typical Network Application ....2-1 Typical Backup Configuration .
  • Page 9 None FrameSaver NP 100 User’s Manual - Installation Guide Auto Update Screen Change ......5-6 CSU Statistics Summary Screen .
  • Page 10 1 Preface Table 1-1 2 Description Table 2-1. 3 Installation Table 3-1 Table 3-2 Table 3-3 Table 3-4 Table 3-5 Table 3-6 Table 3-7 Table 3-8 Table 3-9 Table 3-10 Table 3-11 Table 3-12 Table 3-13 4 Operation Table 4-1 Table 4-2 5 Diagnostics Table 5-1...
  • Page 11 List of Tables Table 6-6 Table 6-7 Appendix Table A-1 Table A-2 Table A-3 Table A-4 Table A-5 Table A-6 Table A-7 Table A-8 Table A-9 Table A-10 System Test/Fault... A-9 Table A-11 Test/BKP (CSU) ... A-11 Table A-12 Test Status ... A-12 viii NetPath 100 User’s Manual - Installation Guide Traps - Private MIB Extension ...

  • Page 12: Preface

    1 Preface About This This manual provides basic installation, operation and troubleshooting information for the NetPath 100 Frame Relay Channel Service Unit (FSU). The information is directed Manual to the installer who has a working knowledge of telecommunication systems and net- works.

  • Page 13: Special Instructions

    1 Preface Special The following are to be performed by qualified service personnel ONLY. Instructions When installing NetPath 100 equipment, observe the following precautions: 1. Never install telephone wiring during a lightning storm. 2. Never install telephone jacks in wet locations unless a jack is specifically designed for wet locations.

  • Page 14: Equipment Attachment Limitations

    Equipment Certain equipment attachment limitations apply when installing and operating this equipment. Attachment The limitations for use in Canada and the U. S. (FCC Part 68) are described below. Limitations Canadian NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements.

  • Page 15: Fcc Part 68 (U.s.)

    1 Preface FCC Part 68 This equipment complies with Part 68 of the FCC Rules. On the underside of this equipment is a label that contains, among other information, the FCC registration num- (U.S.) ber and Ringer Equivalence Number (REN) for this equipment. If requested, this in- formation must be provided to the telephone company.

  • Page 16: Software Revision History

    Software This manual pertains to NetPath 100 Base Software Revision 10.01.xx. Revision changes for this and previous versions are listed below. Revision History Current This revision incorporates the following operational additions and/or changes: Revision Rev. 10.01.xx from Rev. 9.01.xx • •...
  • Page 17 1 Preface • • Rev. 8.01.xx from Rev. 7.01.xx • • Download Notes Downloading Revision 8.01.xx software to a NetPath 100 unit currently running with a prior version may result in some configuration changes which will have to be re- stored (via remote management accessed reconfiguration).
  • Page 18 stored (via remote management accessed reconfiguration). Specific configuration items affected are: • • Rev. 6.01.xx from Rev. 5.01.xx • • Download Notes Downloading Revision 6.01.xx software to a NetPath 100 unit currently running with a prior version may result in some configuration changes which will have to be re- stored (via remote management accessed reconfiguration).
  • Page 19 1 Preface • Rev. 4.01.xx from Rev. 3.01.xx • • • Download Notes Downloading Revision 4.01.xx software to a NetPath 100 unit currently running with a prior version may result in some configuration changes which will have to be re- stored (via remote management accessed reconfiguration).

  • Page 20: Description

    2 Description The NetPath 100 Frame Relay Channel Service Unit (FSU) is a special purpose T1/FT1 CSU/DSU which provides management and diagnostic functions through Simple Network Management Protocol (SNMP), transported over a Frame Relay network. It also includes an integral modem which supports access to the CSU/DSU as well as other co-located equipment such as routers.

  • Page 21: Isdn Adapter Option

    2 Description NetPath NP 100 provides a configuration option to capture and rank IP Traffic in either Top Conversation Pair or Top Talker/Listener mode. By examining Top IP Traffic sta- tistics, the network manager can determine the local device or the host/client connec- tions sending and receiving excessive traffic.

  • Page 22: Isdn Bandwidth On-Demand

    • • • ISDN Bandwidth Bandwidth On-Demand provides an additional network connection for a second DTE On-Demand (router) port based on a request from the DTE. In this configuration the NetPath 100 ISDN Adapter is protocol-transparent. The Router determines the protocol used. A typical network configuration showing simultaneous Bandwidth On-Demand and Backup connections is shown in Figure 2-3.

  • Page 23: Netpath 100

    2 Description NetPath 100 The basic NetPath 100 includes a T1 interface, network-compliant Fractional Rate to Full Rate CSU/DSU, a Frame Relay switch function, a Frame Relay management module, and an SNMP Agent. The unit also includes two Auxiliary ports and may be factory-optioned to include an internal V.32bis or V.34-compliant modem.

  • Page 24: Power Control Unit Option

    Power Control The optional Model 467 Power Control Unit (PCU) provides a mechanism for reboo- ting an external device by momentarily interrupting its AC power source. Unit Option The PCU is a separate unit which consists of an AC power relay, relay control circuit, power transformer, and connectors/cables for: AC IN, SWITCHED AC OUT and Control/Power.

  • Page 25: Operating Features

    2 Description Operating This section contains operation information about the following: Features • • • • Management Management access for control sessions or to retrieve alarm status is provided to the NetPath 100 via in-band Telnet, dial-in VT-100 console connection or direct-connect- Access ed VT-100 terminal.

  • Page 26: Wan Dlci

    WAN DLCI The in-band Frame Relay Management Channel WAN address is defined by the DLCI (Data Link Connection Identifier). The WAN DLCI can be configured for a Dedicated PVC, or as a Tunneled channel within a Payload PVC. During initial installation the WAN DLCI can be set via the unit’s rear panel Configuration DIP Switches, Local Console Port or Dial-In Console Port.

  • Page 27: Figure 2-8 Payload / Cpe Management

    2 Description NetPath 100 also provides expanded management access to the FSU through the fol- lowing features: • • • These optional management paths are shown in Figure 2-8. Custom er D ata Center C us to m er L AN R ou te r F ram e R elay B ack bo ne...
  • Page 28 With these features, NSP and/or customer management of the FSU can be accom- plished through three basic management modes: • • • 980-001-0210K NetPath 100 User’s Manual - Installation Guide November 2000 The primary IP Address is associated with the network-facing dedicated PVC or Tunneled payload PVC.

  • Page 29: Wan Management Ip Address

    2 Description WAN Management NetPath 100 utilizes one IP Address on the dedicated, network-facing Wide Area Net- IP Address work (WAN) management channel. This address is embedded within the various com- munications protocol stacks used for SNMP, Telnet and PPP. The unit’s WAN Management IP Address may be automatically learned from the first message received on the management PVC, or it can be set via the local or remote Console Port.

  • Page 30: Software Download

    Software The NetPath 100 system software (firmware) is stored in flash memory. A new version of the software can be downloaded to the unit for software upgrade, or for restoration Download in the event an error is detected in the flash storage. A description of the software download process is provided in Section 5, “Diagnos- tics,”...

  • Page 31: Modem & Call Director

    2 Description Modem & The integral on-board modem can be switched to any one of the interfaces of the Net- Path 100 by the call director. The call director connects the modem to the Base module, Call Director Optional ISDN Adapter module, AUX 1 Port, or AUX 2 Port. In this way, the modem is used for out-of-band trap reporting (NetPath 100 Base mod- ule, Option module or DTE device connected to an AUX Port) and accepts incoming calls for management access of the NetPath 100, DTE device or any other device con-...

  • Page 32: Installation

    3 Installation This section contains information to complete the physical installation of a NetPath 100 which includes: mounting the unit, power connection, and input/output connections. Mounting NetPath 100 comes equipped with rubber feet for table or shelf-top placement. Option- al adapter brackets are available for wall mounting and standard 19" or 24" rack mounting.

  • Page 33: Figure 3-1 Power Control Unit Mounting

    3 Installation Mounting If this installation includes an optional NP 467 Power Control Unit, this may be wall- mounted using the four keyhole mounts provided on its base (refer to Figure 3-1). Optional NP 467 Power Control Unit Keyhole M ounts NOTE: Use wall fasteners appropriate for the wall’s surface material, i.e.

  • Page 34: Connections

    Connections NetPath 100 has connectors on the rear panel for power and input/output connections. Rear panel connectors and controls are shown and described in Figure 3-2 and Table 3-1. 90-250 V AC 50-60 Hz FUSE 2A/250V SLOW BLOW 5x20m m "CAUTIO N"...

  • Page 35: Power Connections

    3 Installation Power Connections NetPath 100 Power 1. The NetPath 100 includes an internal universal Power Supply. Plug the IEC 320 end of the Power Cord into the connector on the rear of the NetPath 100, shown in Figure 3-3. Power On 2.
  • Page 36 If the LED indications are not as described above, refer to section 5 Diagnostics of this manual. If operation looks normal, unplug the NetPath 100 and make the required data input/ output connections. If an optional Power Control Unit is to be installed with this Net- Path 100, proceed to the next page of this manual.

  • Page 37: Figure 3-4 Power Control Unit Connections

    Plug the other end of this cable into the AC outlet. Control / Pow er Cable Connect to: NP 64 Pow er Connector NP 100, 120 Control O utput Connector Figure 3-4 Power Control Unit Connections Continue the installation by making Input/Output connections and Configuring the NetPath 100 as described in the following sections of this manual.

  • Page 38: Input/Output Connections

    Input/Output Basic NetPath 100 has input/output connectors for the T1 Line, Data Port (DTE), two AUX ports, and Modem Line. Pinouts for each of the these ports are provided in the Connections tables that follow. NOTE: Refer to Section 6, “Options” of this manual for a description of additional connectors for options such as ISDN Adapter.

  • Page 39: Data Port Pinout

    3 Installation Data Port Pinout Table 3-3 shows the pinout for the Data Port connector. Table 3-4 through Table 3-7 show the pin connections for the adapter cables for each of the interface types. Notes: *CBC = Cable Code pin. (s) = single ended.

  • Page 40: Itu-V.35 Adapter Cable

    ITU-V.35 Adapter Use cable assembly # 135-001-0400, or per pinout shown in Table 3-4. Cable Table 3-4 ITU-V.35 Interface Adapter Cable (CBC=1) M-34F DB-44M Signal Shield Sig. Gnd. RTS(s) CTS(s) DSR(s) DCD(s) DTR(s) TD-A RD-A TD-B RD-B Notes: *CBC = Cable Code pin. (s) = single ended.

  • Page 41: Adapter Cable

    3 Installation EIA-530 Adapter Use cable assembly # 135-002-0400, or per pinout shown in Table 3-5. Cable Table 3-5 EIA-530 Interface Adapter Cable (CBC=2) DB-25F DB-44M Signal Shield TD-A RD-A RTS-A CTS-A DSR-A Sig. Gnd. DCD-A RC-B DCD-B TCE-B TC-B CTS-B Notes: *CBC = Cable Code pin.

  • Page 42: Eia-530-A Adapter Cable

    EIA-530-A Adapter Use cable assembly # 135-003-0400, or per pinout shown in Table 3-6. Cable Table 3-6 EIA-530-A Interface Adapter Cable (CBC=3) DB-25F DB-44M Signal Shield TD-A RD-A RTS-A CTS-A DSR(s) Sig. Gnd. DCD-A RC-B DCD-B TCE-B TC-B CTS-B Notes: *CBC = Cable Code pin. (s) = single ended.

  • Page 43: Itu-X.21-Ns Adapter Cable

    3 Installation ITU-X.21-NS Use cable assembly # 135-005-0400, or per pinout shown in Table 3-7. Adapter Cable ITU-X.21-NS (NS indicates Non-Switched) Table 3-7 ITU-X.21-NS Interface Adapter Cable (CBC=4) DB-15F DB-44M Signal Shield TD-A Control-A RD-A Indication-A TC-A Sig. Gnd. Notes: *CBC = Cable Code pin. (s) = single ended.

  • Page 44: Table 3-8 Aux 1 Pinout, 8 Pin Modular Connector

    The AUX 1 and AUX 2 Port pinouts are shown in Table 3-8 and Table 3-9. A U X C o n n . NOTES: Electrical Interface = EIA-232 A U X C o n n . NOTES: Electrical Interface = EIA-232 CAUTION: Pin 8 is not used.

  • Page 45: Console Cabling

    3 Installation Console Cabling In Console Mode, the AUX 2 port is configured as a VT-100 interface, 9.6Kbps, asyn- chronous, 8 data bits, one start bit, one stop bit, and no parity. The Console Mode is enabled on the AUX 2 port when the “Console” Pin (#5) on the AUX 2 connector is asserted (connect the Console pin to the terminal’s DTR).

  • Page 46: General Specifications

    General Specifications NetPath 100 Specifications Table 3-11 NetPath 100 General Specifications Item Dimensions Table Top (with rubber feet): 3.5" H x 10.5" W x 12.0"D. Wall Mount (with removable wall mounting bracket): 10.5" H x 12.0" W x 3.5" D. Rack Mount (with removable rack mounting adapter): 5.25"...

  • Page 47: Power Control Unit Specifications

    3 Installation Power Control Unit Specifications Table 3-12 Model 467 Power Control Unit General Specifications Item Dimensions 2.5" H x 7.25" W x 4.6" D Weight As packaged including carton: 4.5 lbs. Unit alone: 3.5 lbs. Operating Range Temperature: 0 to 50 degrees C. operating. Relative Humidity: 5 to 95% non-condensing.

  • Page 48: Cisco Hd-60 Adapter Cable Specifications

    Cisco HD-60 To connect a Cisco* router to a NetPath 100 Data Port configured for ITU-V.35, use cable assembly # 135-006-0400, or per pinout shown in Table 3-13. Adapter Cable Specifications Cisco HD-60M Shield NOTES: * Cisco is a registered trademark of Cisco Systems, Inc. 980-001-0210K NetPath 100 User’s Manual - Installation Guide November 2000...
  • Page 49 3 Installation 3-18 NetPath 100 User’s Manual - Installation Guide 980-001-0210K November 2000...

  • Page 50: Operation

    4 Operation This section contains configuration and operation information for basic NetPath 100. Refer to Section 6, “Options” of this manual for installation, configuration and opera- tion information for NetPath 100 Options such as the ISDN Adapter. Configuration NetPath 100 configuration consists of initially setting the T1, CSU parameters and the WAN Management Channel’s DLCI address via the rear panel DIP Switches, via dial- in VT-100 console connection or via direct connected VT-100 terminal.

  • Page 51: Power On

    4 Operation Power On With all the connections completed, the NetPath 100 is ready to be powered on. Proceed by holding in the recessed push button switch labeled “NVM RESET / CONFIG” on the unit’s rear panel while plugging in the power cord and continue to hold the button for approximately four (4) seconds.

  • Page 52: Csu Parameters

    To set the T1 Line configuration and CSU operating mode: Parameters 1. Set the two-position DIP Switch - 1 = ON, 2 = OFF. 2. Set the 12-position DIP Switch to select the configuration. 3. Depress the NVM RESET / CONFIG push button for at least one second to enter the parameters in the unit’s NVM.

  • Page 53: Time Slot Configuration

    4 Operation Time Slot To set the T1 Time Slot configuration: Configuration 1. Set the two-position DIP Switch - 1 = OFF, 2 = ON. 2. Set the 12-position DIP Switch to select the configuration. 3. Depress the NVM RESET / CONFIG push button for at least one second to enter the parameters in the unit’s NVM.

  • Page 54: Operation

    An example DLCI switch setting is shown in Figure 4-4. The DLCI is a three-digit decimal number, with each digit represented in binary format (BCD - Binary Coded Decimal) by four DIP switch positions. The DLCI DIP Switches are set for the desired value using the switch positions shown in Table 4-2 to represent each of the decimal digits.

  • Page 55: Establish Management Session

    VT-100 terminal), provided that another management session is not already in Session use. Login The startup display and prompt are: FrameSaver NP 100 - Frame Relay Service Unit (C) Copyright Paradyne Corporation 1996-2000. All Rights Reserved Base:00.13/09.01.95.05 Please enter your SYSTEM access password:...

  • Page 56: Block Mode

    Block Mode NetPath 100 supports Block as well as Character mode management access. To enable Block mode, set the VT-100 terminal (or emulator) to “LOCAL ECHO.” When logging in, along with entering the password, type “ \VT100” (include a space between the last character of the password and the “\”...
  • Page 57 4 Operation This page intentionally left blank. NetPath 100 User’s Manual - Installation Guide 980-001-0210K November 2000...

  • Page 58: Management Command Flow

    Management Figure 4-5 shows the general flow for management access for the basic NetPath 100. Command Flow It shows each of the screen displays and the general function for that screen. - LO GO UT - - SYSTEM VIE W - Login Prom pt or Logout / AutoUpdate In Use...

  • Page 59: Parameter Setting

    The System View screen presents an overview of the system and provides access to configuration, test, and other status screens. The System View screen is shown in Figure 4-6. *********************** FrameSaver NP 100 - System View ************************ Name: F@43802 Location: Fair Lawn, N.J.
  • Page 60 Modem Status - Aux Port Status - High Speed Interface Status - Commands: DevConfig [DC] - Advances to Device Configuration Screen. CsuConfig [CC] - Advances to CSU / DTE Configuration Screen. FrameConfig [FC] - Advances to Frame Manager Configuration Screen. PvcConfig [PC] - Advances to PVC Performance Configuration Screen.

  • Page 61: Device Configuration

    4 Operation Device The Device Configuration screen allows you to view and alter parameters for System Configuration and Modem operations. The Device Configuration screen is shown in Figure 4-7. ***************************** Device Configuration ***************************** Name [N=]: F@43802 Location [L=]: Fair Lawn, N.J. Contact [C=]: J.

  • Page 62: Modem Setup

    If either WAN or Payload/CPE Mgmt “IP Address” or “Encap” (see next page) settings are altered, any in-band management session (Telnet) will be terminated after the Save (SA) command is issued, and will have to be reestablished. 5. Frame Mgr - Select “FrRelay” to configure for normal Frame Manager function. Setting the Frame Manager to “ClrChan”...
  • Page 63 4 Operation NOTES: 5. AUX 2 Setup - Functions the same as AUX 1 above, but without RTS sensing. NOTE: AUX 2 Contact Sense Alarm feature has been obsoleted. Entering “CS” for the first two characters of the AUX 2 Setup string will cause the “Aux2 Alm” label to be displayed on the System View Screen.
  • Page 64 MTU Size - Sets the maximum size (Maximum Transmit Unit) for any IP packet sent by the unit via any management route (dedicated, backup, or PPP dial session.) NOTE: Setting the MTU Size to less than 120 could prohibit the generation of the “Power Loss”...

  • Page 65: Csu / Dte Configuration

    8. DTE TxD Clk - Configure the DTE to clock in the Tx data based on either the DCE (NP 100) supplied clock, or the DTE (cable loop or router) supplied clock. 9. Link Err Thres - Disables or sets the threshold of Rx Errored Seconds plus Unavailable Seconds which when reached or exceeded will cause an alarm to be declared.
  • Page 66 Commands: Help [?] - Advances to “Help” for CSU / DTE Configuration screen. Save [SA] - Saves parameters and returns to System View screen. Cancel [X] - Returns to System View screen without saving changes. Save the CSU / DTE Configuration changes when they are all set correctly by entering “SA”...

  • Page 67: Frame Manager Configuration

    4 Operation Frame Manager The Frame Manager Configuration screen allows you to view and alter parameters for Frame Manager operations. Configuration The Frame Manager Configuration screen is shown in Figure 4-9. ************************** Frame Manager Configuration ************************* Name: F@43802 WAN Mgmt DLCI [D=#,T#orD#]: Disabled P/C Mgmt DLCI [E=P#orC#]: Disabled X to Disable or 16 thru 991 ------------- Network ------------...
  • Page 68 4. Network (DTE) - Consists of the settings required for the various protocols. These include T391, N392, N393 and N391. T391/Status Enquiry Rate - Interval in seconds between the LMI Status Enquiries issued by the NetPath 100 to the Network (Frame Switch). The ratio of N392 to N393 defines the rate of Bad/No LMI responses to Count of events, beyond which the Network link is declared Out-of-Service.

  • Page 69: Snmp Community Access Configuration

    4 Operation SNMP Community The SNMP Community Access Configuration screen allows you to view and alter pa- rameters for SNMP community access operations. Access Configuration The SNMP Community Access Configuration screen is shown in Figure 4-10. ********************** SNMP Community Access Configuration ********************* Name: F@43802 Community #1 Name [C1=]: public Community #2 Name [C2=]:...
  • Page 70 4 Operation This page intentionally left blank. 980-001-0210K NetPath 100 User’s Manual - Installation Guide 4-21 November 2000...

  • Page 71: Snmp Trap Manager Configuration

    4 Operation SNMP Trap The SNMP Trap Manager Configuration screen allows you to view and alter parame- Manager ters for the SNMP Trap Manager operations. Configuration The SNMP Trap Manager Configuration screen is shown in Figure 4-11. *********************** SNMP Trap Manager Configuration ************************ Name: F@43802 Mgr ------ IP Address ----- ---------------- Name ---------------- ---- Path --- #1 [T1=]:0.0.0.0...
  • Page 72 2. Disable Traps - Selects Traps to be disabled. Can be selected individually, or in groups. Selected (disabled) items are bracketed by “>>”...“<<” characters as shown in item #1 on the example screen above. 3. Clear Holdoff - Sets the number of minutes that a trap condition must remain clear, before it is declared clear.

  • Page 73: Pvc Performance Configuration

    4 Operation PVC Performance The PVC Performance Configuration Screen allows you to view and alter parameters Configuration for Network Performance measurement operations on a per PVC basis. The PVC Performance Configuration Screen is shown in Figure 4-12. ************************* PVC Performance Configuration ************************ Name: F@43802 Desired Delay Mon Rate [R=#]: 10 X to Disable or 1 thru 240 Seconds...
  • Page 74 Desired Loss Mon Rate - Setting for the rate at which a Loss measurement packet (Packet-Counting packet) is injected on each PVC in the list specified at the bottom of this screen. Default value (60) dictates that within each 60-second period, every PVC in the list is measured once.
  • Page 75 4 Operation 10. Auto & Manual - Specifies the Tx and Rx CIR value and Mon (monitoring packet(s)) type to be used when PVCs are added to the statistics list. Valid CIR values are 0 through 1536, default value is zero. Auto - When a non-configured PVC is detected, the indicated settings are used un- Manual - For PVCs manually added (using the AddPVC command), the param- Mon - Selects the Monitor setting for PVCs added automatically and manually.
  • Page 76 4 Operation This page intentionally left blank. 980-001-0210K NetPath 100 User’s Manual - Installation Guide 4-27 November 2000...

  • Page 77: Protocol Monitor Configuration

    4 Operation Protocol Monitor The Protocol Monitor Configuration Screen allows you to view and alter parameters for Protocol Monitor operations. Configuration The Protocol Monitor Configuration Screen is shown in Figure 4-13. ************************ Protocol Monitor Configuration ************************ Name: F@43802 Percentage of Sorting Resources Required: Protocols [P=] ([P=m,n,...r] and/or [P=m-n] for up to 7 selections) >>...

  • Page 78: Configuration Completed

    3. Top Statistics - Selection determines whether the Top IP Traffic collection will be based on the top User “Talker” and “Listener,” or the top “Conversation” Pair in each direction. Top Talker/Listeners are determined by separately tracking, in the send and re- ceive direction, the IP address and the total traffic of the most prolific transmitters and receivers of IP traffic within the measurement interval.

  • Page 79: Test Installation

    4 Operation Test The final step of the NetPath 100 installation is to verify operations. This is done through the Network Control Center (NCC). Installation 1. Contact the Network Control Center and inform the Operator that the physical installation and initial configuration are completed. 2.

  • Page 80: Diagnostics

    5 Diagnostics This section contains general diagnostic information for basic NetPath 100. Refer to Section 6, “Options” of this manual for additional diagnostic information regarding optional features such as the ISDN Adapter. NetPath 100 diagnostic features include; Front Panel LED Indicators, BER Testing, Statistic gathering and reporting, and Alarm reporting.

  • Page 81: Table 5-1 Netpath 100 Front Panel Indicators

    5 Diagnostics Table 5-1 NetPath 100 Front Panel Indicators Nomenclature Description POWER Green LED READY Green LED T1 ALARM Red LED HS PORT TxD Green LED HS PORT RxD Green LED FR MGMT. Green LED MODEM IN USE Green LED * See Software Download at the end of this section for description.

  • Page 82: Testing

    Testing NetPath 100 provides management access diagnostic test support. Diagnostic Test NetPath 100 responds to and can issue T1 loopback codes, set operator-initiated loop- backs, source BER Tests directed toward the T1 circuit or toward the DTE, and source Support Frame Relay Test Packets toward the T1 circuit.

  • Page 83: Device Status / Test

    5 Diagnostics Device The Device Status / Test screen provides base module status and access to system tests. Status / Test The Device Status / Test screen is shown in Figure 5-2. ***************************** Device Status / Test ***************************** Name: F@43802 CSU Fault: Netw Set Loop: Test Mode [T=]...
  • Page 84 BER Testing: Loop to User - Sets a DTE Loopback at the Data Port toward the User. Test Pkts to Netw - Sends Link Test Packets (40 -1590 octets) toward the network (T1 Facility). Displayed test results include selected DLCI, packets sent, packets dropped, percent received, octets sent, test duration and;...

  • Page 85: Figure 5-4 Auto Update Screen Change

    5 Diagnostics Commands: ResetTest [RT] - Resets BERT or PVC result counters without disrupting the test operation and refreshes all dynamic information contained on the screen. InjectErr [IE secs] - Injects a single bit error into the BERT stream. When issued without the “secs,”...

  • Page 86: Statistics

    Statistics NetPath 100 provides current and historical performance statistics for the following: • • • CSU and Frame Manager statistics are accumulated in 15-minute intervals for the last 24 hours. PVC and Protocol monitoring statistics are accumulated in user-defined in- tervals (1 - 15 minutes).
  • Page 87 5 Diagnostics States are: ON, OFF or (blank) if Power OFF. Power: ON or OFF based on sensing voltage on Tx data lead(s) from the DTE. T1 ID - T1 ID in unit’s configuration. Interval Count: Totals for the following performance parameters are displayed for the Current interval and the 24Hr Total (Rx and Tx are displayed in ANSI mode).

  • Page 88: Csu Statistics History

    CSU Statistics The CSU Statistics History screen displays all performance parameters for the CSU for each of the 96 possible, 15-minute intervals. History The first history screen (1 of up to 6) is accessed by selecting ViewHistory [VH] from the CSU Statistics Summary screen. The first page of the CSU History screen is shown in Figure 5-6.

  • Page 89: Frame Manager Statistics Summary

    5 Diagnostics Frame Manager The Frame Manager Statistics Summary screen provides summary performance infor- mation and access to detailed performance history displays for general Frame Relay Statistics Traffic. Summary The Frame Manager Statistics Summary screen is accessed from the System View screen, selecting [FS] by typing “FS”...
  • Page 90 Network and User (headings): Network - Statistics representing traffic received from the frame switch. User - Statistics representing traffic received from the DTE (router). The Frame Relay traffic parameters displayed for Network and User are: LTO: LMI Timeouts - Count of LMI timeouts detected for the interval. LFE: LMI Frame Errors - Count of LMI Frame Errors detected for the interval.

  • Page 91: Frame Manager Statistics History

    5 Diagnostics Frame Manager The Frame Manager Statistics History screen displays all performance parameters for the Frame Manager for each of the 96 possible, 15-minute intervals. Statistics The first history screen (1 of up to 6) is accessed by selecting ViewHistory [VH] from History the Frame Manager Statistics Summary screen.

  • Page 92: Figure 5-9 Pvc Statistics Summary Screen (Packet Mode)

    PVC Statistics The PVC Statistics Summary screen provides summary performance information and access to detailed performance history displays for the Frame Relay Traffic on a per- Summary PVC basis. The PVC Statistics Summary screen is accessed from the System View screen, select- ing [PS] by typing “PS”...
  • Page 93 5 Diagnostics Packet Mode The Frame Relay traffic parameters displayed for each DLCI are: DLCI - The DLCI to which this line of statistics applies. “Etc” is the summation RxPkts & TxPkts - Count of packets received (Rx) and of packets sent (Tx). BECN &...
  • Page 94 n Minute Interval History - Displays the number of valid intervals that have been ac- cumulated since the last reset of the counters. (“n” value is Interval Period set on the PVC Performance Configuration screen.) History statistics are total counts for each performance parameter over all valid intervals up to 96 intervals.

  • Page 95: Pvc Statistics Summary

    5 Diagnostics Octet Mode The Octet Mode screen display is shown in Figure 5-10. **************************** PVC Statistics Summary **************************** Name: F243802 (P=Pkt,O=Oct,TC=TxCir,RC=RxCir,TL=TxLoss,RL=RxLoss,FD=FullDlay,orND=NetwDlay) First DLCI [P=#]: 16 DLCI RxPkts -- 15 Min Interval History: 96 Valid -- Past Summary for DLCI [D=#orSum]: Sum -- RxPkts 10 Second: History:...

  • Page 96: Txcir & Rxcir Modes

    TxCir & RxCir The TxCir Mode screen display is shown in Figure 5-11. Modes **************************** PVC Statistics Summary **************************** Name: F243802 (P=Pkt,O=Oct,TC=TxCir,RC=RxCir,TL=TxLoss,RL=RxLoss,FD=FullDlay,orND=NetwDlay) First DLCI[P=#]: 16 DLCI |1-25 | -35 | -50 | -71 | -100| -141| >141%(ofCIR) 100.0 100.0 100.0 100.0 100.0 100.0...

  • Page 97: Txloss & Rxloss Modes

    5 Diagnostics TxLoss & RxLoss TxLoss Mode screen display is shown in Figure 5-12. Modes **************************** PVC Statistics Summary **************************** Name: F243802 (P=Pkt,O=Oct,TC=TxCir,RC=RxCir,TL=TxLoss,RL=RxLoss,FD=FullDlay,orND=NetwDlay) First DLCI[P=#]: 16 DLCI NonDEPkts/-DEPkts-/Sta 25 Origin: NNI-1: 33 Origin: 234 Origin: 341 Origin: 464 Origin: 531 Origin: 793 Origin: 795 Origin: 942 Origin:...

  • Page 98: Fulldlay & Netwdlay Modes

    FullDlay & Full Delay screen display is shown in Figure 5-13. NetwDlay Modes **************************** PVC Statistics Summary **************************** Name: F243802 (P=Pkt,O=Oct,TC=TxCir,RC=RxCir,TL=TxLoss,RL=RxLoss,FD=FullDlay,orND=NetwDlay) First DLCI[P=#]: 16 DLCI Delay(mS): Delay(mS): Delay(mS): Delay(mS): Delay(mS): Delay(mS): Delay(mS): Delay(mS): Delay(mS): -- 15 Min Interval History: 96 Valid -- Past Summary for DLCI [D=#orSum]: LstPkt: Delay(mS): History:...

  • Page 99: Pvc Statistics History

    5 Diagnostics PVC Statistics The PVC Statistics History screen displays all performance parameters for the Frame Relay Traffic on a per-PVC and per-interval basis for each of the 96 possible intervals. History The first history screen is accessed by selecting ViewHistory [VH] from the PVC Sta- tistics Summary screen.
  • Page 100 DLCI [D=#,All,or Sum] - selects the PVC(s) for which the historical statistics will be produced. Choices are: Specific PVC or “Etc”- Enter DLCI number for the desired PVC (or “Etc”). Pro- All PVCs - Enter All (or only “A”). Displays a listing by intervals providing an in- Sum - Enter Sum (or only “S”).

  • Page 101: Protocol Monitor Statistics Summary

    5 Diagnostics Protocol The Protocol Monitor Statistics Summary screen displays summary performance in- formation and provides access to detailed performance information for the Frame Re- Monitor lay Traffic for each protocol specified. Statistics The Protocol Monitor Statistics Summary screen is accessed from the System View Summary screen, selecting [MS] by typing “MS”...
  • Page 102 RxBps & TxBps - Data rate calculated from the total count of octets counted for the particular protocol category and specified PVC. Additional commands on this screen are: ResetStats [RS] - Clears all Protocol Monitoring and PVC Monitoring statistics ViewHistory [VH current_time (optional)] - Advances to Page 1 of the Protocol Monitor Statistics History screen.

  • Page 103: Protocol Monitor Statistics History

    5 Diagnostics Protocol Monitor The Protocol Monitor Statistics History screen displays all performance parameters for Statistics History the Frame Relay Traffic on a per-interval basis for each of the 96 possible intervals for each protocol specified. The first history screen is accessed by selecting ViewHistory [VH] from the Protocol Monitor Statistics Summary screen.
  • Page 104 5 Diagnostics This page intentionally left blank. 980-001-0210K NetPath 100 User’s Manual - Installation Guide 5-25 November 2000...

  • Page 105: ***************** Top Talker / Conversation Statistics Summary

    5 Diagnostics Top Talker/ The Top Talker/Conversation Statistics Summary screen displays summary perfor- mance information and provides access to detailed performance information for the Conversation Top IP Traffic irrespective of PVC divisions. Statistics The Top Talker/Conversation Statistics Summary screen is accessed from the System Summary View screen, selecting [TS] by typing “TS”...
  • Page 106 Rank - Number 1 to 6, showing the rank (with 1 being the highest) the line of statistics holds compared to other talkers/conversations. For Rank by Octet, the following are displayed: Bps - The displayed Bps is calculated from the total count of Octets for the Octets - Count of bytes within packets for that particular talker/conversation.

  • Page 107: Rx Conversation Mode

    5 Diagnostics Rx Conversation An example of a Top Talker/Conversation Statistics Summary screen, in Rx Conver- Mode sation mode ranked by Octet, is shown in Figure 5-18. ***************** Top Talker / Conversation Statistics Summary ***************** Name: F243802 -------------- Most Recent Completed Interval -------------- Rank ResetStats[RS] Help[?]...

  • Page 108: Rx Listener Mode

    Rx Listener Mode An example of a Top Talker/Conversation Statistics Summary screen, in Rx Listener mode ranked by Packet, is shown in Figure 5-19. ***************** Top Talker / Conversation Statistics Summary ***************** Name: F243802 -------------- Most Recent Completed Interval -------------- Rank ResetStats[RS] Help[?]...

  • Page 109: Top Talker/Conversation Statistics History

    5 Diagnostics Top Talker/ The Top Talker/Conversation Statistics History screen displays detailed performance information for the Top Talker/Conversation of IP Traffic irrespective of PVC divi- Conversation sions. Statistics The Top Talker/Conversation Statistics History screen is accessed from the Top Talk- History er/Conversation Statistics Summary screen, selecting [VH] by typing “VH”...

  • Page 110: Alarms

    Alarms NetPath 100 generates “traps” (SNMP alarms or alerts) in response to certain detected network conditions. The traps are reported either In-band utilizing the Management PVC, or via Dial-Out utilizing the internal Modem. Alarm conditions are also dis- played on NetPath 100 status screens and on front panel indicators. Traps The conditions (objects) which generate traps are included in the NetPath 100 Private MIB Extension and are listed in Table 5-2.

  • Page 111: Fault Isolation

    5 Diagnostics Fault Isolation Figure 5-21 shows a typical application with potential fault locations marked ( a ) through ( i ). Table 5-3 describes the corresponding indications, reporting mech- anisms including the traps for each fault, and suggested test options. F ram e S w itch Fault...

  • Page 112: Led Indicator Troubleshooting

    LED Indicator The NetPath 100 front panel LED indicators may also be used to troubleshoot a prob- lem. Table 5-4 describes the LED indicator’s normal states, and some possible causes Troubleshoot- for abnormal indications. NetPath 100 LED Status HS PORT POWER READY ALARM...

  • Page 113: Additional Descriptions

    5 Diagnostics Additional The paragraphs in this section provide additional information, notes, or tips about some of the specific operating features of the NetPath 100. Descriptions This information is intended to assist anyone in the use of these features or in trouble- shooting problems concerning these features.

  • Page 114: Dte Dialing Using Netpath 100 Aux Ports & Internal Modem

    DTE Dialing In addition to the internal CSU and Option modules, the NetPath 100’s internal modem may be shared by external devices, which interface the NetPath 100 through AUX Using ports 1 and 2. The modem sharing process is controlled by the DTR lead of each con- NetPath 100 nected device.

  • Page 115: Management Access

    5 Diagnostics Management Access Dial-In When using a PC (desktop or laptop) to establish management access to a NetPath 100, ensure that the VT-100 configuration is set to use flow control, and that the BAUD rate does not exceed 57600 (56Kbps). Some emulation programs will automatically configure to the highest rates available (such as 115200), and this may cause the dropping of characters while NetPath is re- turning a screen to the PC terminal.
  • Page 116 Set the “SNMPSetExecution” object to a value of “accept.” Note: While a login session is established, if this object is not set to “accept,” “cancel,” or “none” within five minutes, the login session will be automatically terminated. (The “SNMPSetInactivity” object maintains the elapsed time since the last SetExecution command.) 10.
  • Page 117 5 Diagnostics 5-38 NetPath 100 User’s Manual - Installation Guide 980-001-0210K November 2000...

  • Page 118: Options

    6 Options This section contains installation, operation and diagnostic information specific to fac- tory Options which are available with NetPath 100 units. The Options currently available and covered in this manual are: • 980-001-0210K NetPath 100 User’s Manual - Installation Guide November 2000 ISDN Adapter Option...
  • Page 119 6 Options This page intentionally left blank. NetPath 100 User’s Manual - Installation Guide 980-001-0210K November 2000...

  • Page 120: Isdn Adapter Option

    ISDN Adapter This section contains installation, operation and diagnostic information specific to the ISDN Adapter option for NetPath 100. Option The front panel of NetPath 100 with the ISDN Adapter option is shown in Figure 6-1. Figure 6-1 NetPath 100 Front Panel with ISDN Adapter Installation Installation for the ISDN feature for NetPath 100 consists of making the Data Port and ISDN Line connections.

  • Page 121: Table 6-1 Netpath 100 Isdn Input/Output Connectors And Specifications

    6 Options NetPath 100 ISDN connectors are described in Table 6-1. Table 6-1 NetPath 100 ISDN Input/Output Connectors and Specifications Connectors ISDN Data Port ISDN Line The ISDN Data Port supports the same electrical interface types as the base unit Data Port (except for ITU-X.21-NS), and the connector pinouts are also identical.

  • Page 122: Configuration

    Configuration With the ISDN connections and base unit connections completed, the NetPath 100 is ready to be powered on and the ISDN Adapter configured for operation. Power On with Power the unit on by connecting the power cord and plugging it into an appropriate AC Connections outlet.

  • Page 123: Establish Management Session

    VT-100 terminal), provided that another management session is not already in Session use. Login The startup display and prompt are: FrameSaver NP 100 - Frame Relay Service Unit (C) Copyright Paradyne Corporation 1996-2000. All Rights Reserved Base:00.13/09.01.95.05i Opt:01.29.04 Please enter your SYSTEM access password:...

  • Page 124: Figure 6-3 Management Control Flow For Netpath 100 With Isdn Option

    Management Figure 6-3 shows the general flow for management access for NetPath 100 with the Command Flow ISDN Option. It shows the screen displays and the general function for that screen. The ISDN related screens are at the bottom of the flow chart. - LO G O U T - Login P rom pt or In U se...

  • Page 125: Parameter Setting

    Section 4, “Operation,” in this manual. System View The System View screen for NetPath 100 with ISDN Adapter is shown in Figure 6-4. Screen *********************** FrameSaver NP 100 - System View ************************ Name: F@43802 Location: Fair Lawn, N.J. Contact: J. Jones...
  • Page 126 ISDN Backup - State as reported by ISDN Adapter module. On-Demand Interface Status - If the ISDN Adapter is not configured for ISDN Commands: IsdnConfig [IC] - Advances to ISDN Adapter Configuration Screen. BkupConfig [BC] - Advances to Backup / On-Demand Configuration Screen. IsdnTest [IT] - Advances to ISDN Status / Test Screen.

  • Page 127: Isdn Adapter Configuration

    6 Options ISDN Adapter The ISDN Adapter Configuration screen allows you to view and alter parameters for Configuration the ISDN Adapter related operations. To proceed to ISDN Adapter Configuration, from the System View Screen, type “IC” and press ENTER. The ISDN Adapter Configuration screen is shown in Figure 6-5. ************************** ISDN Adapter Configuration ************************** Name: F@43802 Bkp: Rate [R1=]...
  • Page 128 Dmd: Parameters to be selected for On-Demand operation. Rate - Select the data rate to be used when establishing On-Demand ISDN connections. IMUX - Select the method of inverse multiplexing to be used for On-Demand Dwnspd - Disable will not allow a multi-B Channel On-Demand connection to TxD Clk - Selects the clock source for aligning Tx Data input;...

  • Page 129: Backup / On-Demand Configuration

    6 Options Backup / On- The Backup / On-Demand Configuration screen allows the user to view and alter pa- Demand rameters for the ISDN Backup or On-Demand operations. Configuration To proceed to Backup/On-Demand Configuration, from the System View Screen, type “BC”...
  • Page 130 Learn IP Add - Selects IP Address to “Learning Mode,” where unit will learn its IP Address from the first valid Frame received after connecting. Set to “1” for learning on “Every Connection.” Set to “2” for learning only if “Bkp # n WAN IP Add”...
  • Page 131 6 Options Commands Help [?] - Advances to “Help” for Backup / On-Demand Configuration screen. Save [SA] - Saves parameters and returns to System View screen. Cancel [X] - Returns to System View screen without saving changes. Save the Backup / On-Demand Configuration changes when they are all set correctly by entering “SA”...

  • Page 132: Management Ip Address Per Connection

    This approach is practical because the management PVC is dedicated to one NetPath 100 and it will only carry traffic for that NP 100. In this arrangement static routing is typically used, and the first message is either a manual PING initiated by an NCC op- erator or an automatic status POLL from the SNMP manager.

  • Page 133: Diagnostics

    6 Options Diagnostics This section contains diagnostic information specific to the ISDN Adapter option. Refer to section 5 Diagnostics of this manual for diagnostic information regarding ba- sic NetPath 100 features. ISDN Adapter option diagnostic features include; ISDN Adapter Status information and Tests, Alarm reporting, and Front Panel LED Indicators.

  • Page 134: Isdn Tests

    ISDN Tests ISDN testing features include Network Loopback, User Loopback and Adapter Status information and Tests. Network Loopback The ISDN “B” channels may be looped back (toward the Network) for external testing. Configured for Backup operation Loopback of a B-Channel is automatically initiated when connection is made to a Dial- In call, provided the B-Channel is currently configured for Backup operation.

  • Page 135: Isdn Status /Test

    6 Options ISDN Status /Test The ISDN Status / Test screen provides ISDN Adapter status and test capability. The ISDN Status / Test screen is accessed from the System View screen, selecting [IT] by typing “IT” followed by ENTER. The ISDN Status / Test screen is shown in Figure 6-8. ****************************** ISDN Status / Test ****************************** Name: F@43802 CSU Fault:...
  • Page 136 Backup Setup - Selects the current state for backup operations. Selections are as follows: Reset/Arm - Terminates any current activity and clears any Failed or Disabled Activate -Initiates backup connection process. Service Disable -Terminates and/or disables all backup activity to prevent Time Disable - Terminates and/or disables all backup activity for the specified High Speed Interface Status - ISDN Backup - Displays current status as reported by ISDN Adapter module.
  • Page 137 6 Options Demand Setup - Selects the current state for demand operations. Reset/Arm - Terminates any current activity and clears any Failed condition so Call Out/Loop - Initiates Bandwidth On-Demand (BOD) call-out and sets a loop- Loop to User - Loops data back toward the User at the ISDN Data Port. If a Band- On - Demand Interface Status - Displays current state or activity for the interface.
  • Page 138 Line n / Bn: Displays current status of each ISDN line and B Channel. NOTE: An ISDN switch will return a “Cause Code” indicating a status for the latest Commands Help [?] - Advances to “Help” for ISDN Status / Test screen. Close [X] - Returns to System View screen without saving changes.

  • Page 139: Table 6-4 Isdn Connection Cause Codes

    6 Options Table 6-4 ISDN Connection Cause Codes Code Cause Unallocated (unassigned) number. No route to specified transit network. No route to destination. Send special information tone. Misdialed trunk prefix. Channel unacceptable. Call awarded and being delivered in an established channel. Preemption.

  • Page 140: Table 6-5 Ml-Ppp Connection Codes

    Auth 980-001-0210K NetPath 100 User’s Manual - Installation Guide November 2000 Table 6-5 ML-PPP Connection Codes Code Status Link Configuration Protocol negotiation failure. Authentication (PAP or CHAP) failure. Network Configuration Protocol failure. ML-PPP connection established successfully. 6 Options 6-23...

  • Page 141: Isdn Statistics

    6 Options ISDN Statistics The ISDN Statistics screen displays summary performance information of ISDN con- nection activity. The ISDN Statistics screen is accessed from the ISDN Status / Test screen, selecting [VS] by typing “VS” followed by ENTER. The ISDN Statistics screen is shown in Figure 6-9. ******************************** ISDN Statistics ******************************* Name: F@43802 --------------------Channel Connection Attempts / Failures -------------------...

  • Page 142: Ml-Ppp Diagnostic Trace Feature

    Attempt - Counted from time a bundle level action is initiated and includes the entire operation (retries are not counted as separate attempts). Failure - Counted only when a bundle is not established after all retries fail. Time Since Last Attempt - A count of Days, Hours, Minutes, and Seconds shows the time since the most recent attempt occurred for each bundle.
  • Page 143 B-Channel MP-PPP connection. Establish dial-in connection. atdt(dial number)w,,,4 CONNECT 9600/ARQ FrameSaver NP 100 - FSU/ISDN Version 01.29 - May 25 2000 - 18:50:45 (C) Copyright Paradyne Corporation, 1997-2000. All Rights Reserved Enter any character followed by ENTER.

  • Page 144: Figure 6-10 Mlppp Trace

    Initiate an On-Demand ML-PPP connection, and a sequence of messages similar to those shown in Figure 6-10 will be displayed as the connection is established. OCP-ISDN>DIAG Entering Diagnostic Mode - Press Esc to go back to OCP Mode OCP-ISDN> User : LCP: Phase is Establishing Netw/0: LCP:...

  • Page 145: Alarms

    6 Options Alarms NetPath 100 generates “traps” (SNMP alarms or alerts) in response to certain detected network conditions. Specific Traps apply to the ISDN Adapter option. Traps ISDN-related conditions (objects) which generate traps are listed in Table 6-6. Table 6-6 Traps - Private MIB Extension Component Object ISDN...

  • Page 146: Led Indicator Troubleshooting

    LED Indicator The ISDN Adapter front panel LED indicators may also be used to troubleshoot a Troubleshooting problem. Table 6-7 describes the ISDN Adapter LED indicator’s normal states, and some possible causes for abnormal indications. Table 6-7 NetPath 100 ISDN Adapter LED Diagnostics NetPath 100 ISDN Adapter LED Status...

  • Page 147: Additional Descriptions

    6 Options Additional This (these) paragraphs provide additional information, notes, or tips about some of the Descriptions specific operating features of the ISDN Adapter option. This information is intended to assist anyone in the use of these features or in trouble- shooting problems concerning these features.

  • Page 148: Appendix

    Appendix Fault & Test NetPath 110 screen displays include status fields which indicate Fault and/or Test con- ditions that relate to the selected screen. These fields are indicated on the screens by a Screen title such as “System Test/Fault”. After the title, the highest priority fault or test cur- rently active is displayed, if any.

  • Page 149: Csu Fault

    Appendix CSU Fault CSU Fault shows the highest priority CSU fault currently detected. This is displayed on the Device Status / Test and ISDN Status / Test screens. Display CSU Fault Failure of CSU related hardware detected by the unit. CSU CFA/Red Alarm Detected loss of T1 facility.

  • Page 150: Isdn Backup

    ISDN Backup ISDN Backup shows the highest priority ISDN Backup related fault, test or status cur- rently detected. This is displayed on the System View and ISDN Status / Test screens. Table A-3 ISDN (Backup, User Circuit) Display ISDN Adapt Fault The ISDN hardware has failed (backup cannot be accomplished) Primary On Line Backup connection in place using Primary Dials.

  • Page 151: Isdn Demand

    Appendix ISDN Demand ISDN Demand shows the highest priority ISDN On-Demand related fault, test or status currently detected. This is displayed on the System View and ISDN Status / Test screens. Display ISDN Adapt Fault The ISDN hardware has failed (call cannot be accomplished) Connecting On-Demand connection in place using Primary Dials.

  • Page 152: Line N/Bn (Isdn

    Line n /B n Line n/Bn shows the highest priority fault, test or status currently detected for each ISDN Line (1-4) and B-Channel (1-2). This is displayed on the ISDN Status / Test (ISDN) screen. Display ISDN Adapt Fault The ISDN hardware has failed. ISDN Line Failure The ISDN line of this B-Channel is faulty.

  • Page 153: Table A-6 Isdn Connection Cause Codes

    Appendix Table A-6 ISDN Connection Cause Codes Code Cause Unallocated (unassigned) number. No route to specified transit network. No route to destination. Send special information tone. Misdialed trunk prefix. Channel unacceptable. Call awarded and being delivered in an established channel. Preemption.

  • Page 154: Table A-7 Ml-Ppp Connection Codes

    980-001-0210K NetPath 100 User’s Manual - Installation Guide November 2000 Table A-7 ML-PPP Connection Codes Code Line Configuration Protocol negotiation failure. Auth Authentication (PAP or CHAP) failure. Network Configuration Protocol failure. ML-PPP connection established successfully. Appendix Status...

  • Page 155: Modem Status, Fault

    Appendix Modem Status, Modem Status shows the highest priority internal modem related fault currently detect- ed. This is displayed on the System View screen. Fault Display Modem Failure Failure of Modem hardware detected by the unit. Dial Line Failure Failure of routine Dial Line test detected. Network Set Network Set Loop shows the highest priority externally initiated loopback currently running.

  • Page 156: System Test/Fault

    System System Test / Fault shows the highest priority System related test or fault currently de- tected. This is displayed on the System View, CSU Statistics Summary and Frame Test/Fault Manager Statistics Summary screens. Display Improper Aux2 Cable Improper cable connection has been detected (Pin 8 may not be used.) NVM Failure Failure of NVM (Non-Volatile Memory) detected by the unit and the latest configuration may not have been saved.
  • Page 157 Appendix Display PVC Dlvd Pkt Alarm Percentage of delivered packets for a PVC, has fallen below the PVC Dlvd Pkt Threshold value. DS0s must be assigned to the User Port. PVC Delay Alarm PVC Delay Threshold reached or exceeded. DS0s must be assigned to the User Port. BECN/FECN Alarm BECN/FECN Error Threshold reached or exceeded.

  • Page 158: Test/Bkp (Csu

    Test/BKP Test/BKP shows the highest priority CSU related test or Backup (ISDN) condition de- tected within the interval. This is displayed on the CSU Statistics Summary screen. (CSU) Display Netw Set Line Externally initiated (Network sent code) Full T1 Line loopback in place at Network Port toward Network Circuit.

  • Page 159: Test Status

    Appendix Test Status Test Status shows the highest priority test currently running. This is displayed on the ISDN Status / Test screens. Display Lp to User Loopback is in place at the User Port toward the User Circuit. 2047 Payld to User 2047 pattern BERT is being sent toward the User Circuit.

This manual is also suitable for:
