EMC immunity type tests per IEEE 1613
Environmental type tests
IEC 60068-2-14
IEC 60068-2-30
IEC 60068-2-78
IEC 60255-21-1
IEC 60255-21-2
RUGGEDCOM RST2228P
Equipment Manual, 10/2023, C79000-G8976-1403-17
Description
ESD
Radiated RFI
Fast transient
Oscillatory
HV impulse
Dielectric strength
Damped oscillating
magnetic field
Test
IEC 60068-2-1 Cold temperature
IEC 60068-2-2
Change of
temperature
Humidity (damp
heat, cyclic)
Humidity (damp
heat, steady state)
Enclosure contact
Enclosure air
Enclosure ports
Signal ports
DC power ports
AC power ports
Earth ground ports
Signal ports
DC power ports
AC power ports
Signal ports
DC power ports
AC power ports
Signal ports
DC power ports
AC power ports
Enclosure ports
Description
Test Ad
Dry heat Test Bd
Test Nb
Test Db
Test Cab
Vibration
Shock
Bump
6.2 EMC and environmental type tests
Test levels
± 8 kV
± 15 kV
35 V/m (80% modulation)
± 4 kV @ 2.5 kHz
± 4 kV
± 4 kV
± 4 kV
2.5 kV common mode
2.5 kV common and 1.0
kV Differential Mode
2.5 kV common and 1.0
kV Differential Mode
5 kV (failsafe relay)
5 kV
5 kV
2 kV (failsafe relay output)
2.9 kVdc
2 kV
100 A/m (peak) for 1 s
(100 kHz and 1 MHz)
Test levels
-40 °C (-40
°F), 16 Hours
85 °C (185
°F), 16 hours
5 Cycles, -40 to 85°
C (40 to 185° F)
93% upper
temperature, 97%
lower temperature
55 °C (131
°F), 6 Cycles
10 days @ 55 °C
(131 °F) and 93%
relative humidity
Level 2 (2 g @
10 to 150 Hz)
Level 2 (30
g @ 11 mS)
Level 1 (10
g @ 16 mS)
Certification
Severity
levels
5
Severity levels
Class 2
Class 2
Class 1
