Summary of Contents for Yamaha PLG150-DR

  • Page 2 If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate, please contact Yamaha Corporation of America, Electronic Service Divi- sion, 6600 Orangethorpe Ave, Buena Park, CA 90620 * This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.
  • Page 3 • Copying of the software or reproduction of this manual in whole or in part by any means is expressly forbidden without the written con- sent of the manufacturer. • Yamaha makes no representations or warranties with regard to the use of the software and documentation and cannot be held responsible for the results of the use of this manual and software.

  • Page 4: Table Of Contents

    Table of Contents Overview of the PLG150-DR/PLG150-PC Main Features of the PLG150-DR/PLG150-PC... 5 Included Items ... 5 Required and Recommended Items... 6 Installing the PLG150-DR/PLG150-PC ... 6 Specifications ... 6 Parameter Structure For Modular Synthesis Plug-in System Users Selecting DR/PC Voices... 8 Editing the DR/PC Native Part Parameters ...

  • Page 5: Overview Of The Plg150-Dr/Plg150-Pc

    User kits — all from your Windows computer. The PLG150-DR also features a special drum kit based on the stunning stereo drum kit of the pop- ular Yamaha MOTIF. (Not all of the sounds are exactly the same.) For MOTIF users, this means you can use the PLG150-DR to play high-quality drum tracks and free up maximum polyphony for other sounds on the MOTIF.

  • Page 6: Required And Recommended Items

    I Synthesizer/Tone Generator/Sound Card Compatible with the Modular Synthesis or XG Plug-in Systems In order to use the PLG150-DR/PLG150-PC, you’ll need a synthesizer, tone generator or sound card that is compatible with the Modular Synthesis Plug-in System or the XG Plug-in System. Compatible instruments include the MOTIF, MU128, and the SW1000XG.

  • Page 7: Parameter Structure

    Parameter Structure Plug-in Board System Parameters XG System Parameters DR/PC Native System Parameters Part Parameters XG Part Parameters Part Parameters Part Parameters DR/PC Native Part Parameters Part Parameters XG Part Parameters DR/PC Native Part Parameters DR/PC Voice Parameters Voice Edit Inst128 Parameters Voice Reverb...

  • Page 8: For Modular Synthesis Plug-In System Users

    When using the PLG150-DR in the Song mode on the MOTIF, make sure to make these settings: NOTE • Set the Receive Channel of the [PLG] part (the part to which the PLG150-DR has been assigned) to Channel 10. • On the MOTIF, set the internal part assigned to Channel 10 to off.

  • Page 9: Editing The Dr/Pc Native Part Parameters

    Editing the DR/PC Native Part Parameters The following explanations show how to edit the DR/PC native part parameters when creating PLG voices, using the MOTIF Control Synthesizer as an example. For information on storing the PLG voices with your particular Modular Synthesis Plug-in System compatible instrument, refer to the owner’s manual of that instrument.

  • Page 10: For Xg Plug-In System Users

    For XG Plug-in System Users The PLG150-DR/PLG150-PC voices can be selected just like the voices of the XG tone generator. Keep in mind, though, that they can only be selected when the Sound Module Mode is set to XG or Performance.
  • Page 11 Enable the PLG150-DR/PLG150-PC board for the desired Part. First, make sure that the appropriate Part is selected (using the [PART –/+] buttons), then press the [SELECT] button. The icon of the selected board appears in the display and the correspond- ing LED at the bottom of the panel (PLG-1, -2, or -3) flashes briefly.

  • Page 12: Editing The Dr/Pc Native Part Parameters

    Press the [EDIT] button to enter the Edit mode. Select the “PLUGIN” menu. Use the [SELECT >] button, then press the [ENTER] button. The PLG150-DR/PLG150-PC Edit menu appears. Select the desired parameter. Use the [SELECT </>] buttons.

  • Page 13: Parameters

    G Note Select 1 Rev Send - Note Select 4 Rev Send (Reverb Send) This determines the level of the selected note’s instrument that is sent to the PLG150-DR/PLG150- PC’s built-in Reverb effect. This parameter has no effect if the Insertion effect (above) is on.
  • Page 14 Settings/Range: -12 — +12dB, Vce (**** : Not available) G INS LFOFrq (Insertion Effect — LFO Frequency) This determines the frequency of LFO modulation for the PLG150-DR/PLG150-PC’s built-in Inser- tion effect. Range: -127 — +00 — +127 (**** : Not available) G INS LFODpt (Insertion Effect —...

  • Page 15: Native System Parameter

    G Part Assign This determines the Part to which the PLG150-DR/PLG150-PC voice is assigned. If a Part is not properly assigned here, none of the PLG150-DR/PLG150-PC voices can be selected for the Part. (This applies to XG Plug-in System compatible “mother” devices.)

  • Page 16: Reverb Return

    Parameters G Reverb Type G Reverb Parameter 1 - 16 This determines the Reverb type for the kit (voice) and allows you to set each of sixteen different parameters. For details, refer to the “DR/PC Voice Effect Parameter List” on page 53 in the Refer- ence section.
  • Page 17 G Inst (Instrument) Reverb Send This determines the level of the selected instrument that is sent to the Reverb effect. This parame- ter has no effect if the Insertion effect (below) is on. Range: 0 — 127 G Inst (Instrument) Insertion On/Off This determines whether the Insertion effect is applied to the selected instrument or not.

  • Page 18: About The Included Cd-Rom

    Track 3 : Demonstration song recorded on the PLG150-PC. For Windows Users The included CD-ROM contain editing software to make user voices for the PLG150-DR/PLG150- PC as well as demonstration songs and Voice data for the “mother” device. You can start the editing software as either a stand-alone software or a plug-in application in the Open Plug-in Technology compatible application (SQ01, etc.) You can save the user voice edited on this...
  • Page 19 *2 These applications are started as either a stand-alone application or a plug-in software in the Open Plug-in Technology compatible application. *3 Unfortunately, Yamaha makes no guarantee concerning the stability of these programs nor can it offer user sup- port for them.
  • Page 20 For information on using the Acrobat Reader, refer to the Reader Guide in the Help menu. G Plug-in Editor files for MOTIF Editor If you use the MOTIF, you can edit plug-in voices of the PLG150-DR/PLG150-PC on the Voice Edi- tor for MOTIF by installing this files.
  • Page 21 Editor Data transmission Plug-in voices for the CS6x/CS6R/S30/S80/MOTIF The included CD-ROM contains voice data for use with the Yamaha CS6x, CS6R, S30, S80, and MOTIF. This data features 64 Plug-in voices specially programmed for the PLG150-DR/PLG150-PC. About the Included CD-ROM...
  • Page 22 For SQ01 users NOTE By installing the Plug-in Board Editor, you can select PLG150-DR/PLG150-PC voices on your SQ01 or XG Editor. In order to use this function, make sure that the software is of the listed version (below) or higher. (The latest versions can be downloaded from the Yamaha website.) SQ01 : ver.
  • Page 23 NOTE CD-ROM included with the “mother” device. • When the “mother” device and your PC are connected with a USB cable, select “YAMAHA USB OUT xxx.” When they are connected with serial cable, select “YAMAHA CBX Driver.” For details, refer to the owner’s manual of the “mother” device.

  • Page 24: For Macintosh Users

    Demonstration song (XG) Plug-in Voice Data * When the PLG150-DR/PLG150-PC is installed to PLG1, select the file “**PlgVc1.mid” ; when the board is installed to PLG2, select the file “**PlgVc2.mid” ; when the board is installed to PLG3, select the file “**PlgVc3.mid.”...

  • Page 25: Demonstration Songs

    • Select the appropriate multi-timbral mode on the instrument (on the MOTIF, this would be the Song mode). • Set the Receive Channel of the [PLG] part (the part to which the PLG150-DR/PLG150-PC has been assigned) to Channel 1. • Set all other parts to channels other than Channel 1.

  • Page 26: Appendix

    *2 Drum voices in these kits are mapped to keys B2 and lower. *3 Percussion voices in these kits are mapped to keys C3 and higher. If you have both the PLG150-DR and the PLG150-PC installed, you can combine the relevant kits indicated by notes *2 and *3. I User Voice List...
  • Page 27 I DR Instrument Map Program No. Kit Name LiveRm A LiveRm B Note# Note Inst Name Inst Name C# -1 Surdo Mute Surdo Mute -1 Surdo Open Surdo Open D# -1 Hi Q Hi Q -1 Whip Slap Whip Slap -1 Scratch H Scratch H F# -1 Scratch L...
  • Page 28 Voice List DR Instrument Map MSB=79, LSB=0 Program No. Kit Name DryKit A Note# Note Inst Name Inst Name C# -1 Surdo Mute Surdo Mute -1 Surdo Open Surdo Open D# -1 Hi Q Hi Q -1 Whip Slap Whip Slap -1 Scratch H Scratch H F# -1 Scratch L...
  • Page 29 Rocky Trashed1 Inst Name Inst Name Surdo Mute Surdo Mute Dst Surdo Open Surdo Open Dst Hi Q Hi Q Dst Whip Slap Whip Slap Dst Scratch H Scratch H Dst Scratch L Scratch L Dst Finger Snap Finger Snap Dst Click Noise Click Noise Dst Metronome Click...
  • Page 30 Voice List DR Instrument Map MSB=79, LSB=0 Program No. Kit Name BriteBrk Note# Note Inst Name Inst Name C# -1 Surdo Mute BBk Surdo Mute RBk -1 Surdo Open BBk Surdo Open RBk D# -1 Hi Q BBk Hi Q RBk -1 Whip Slap BBk Whip Slap RBk -1 Scratch H BBk...
  • Page 31 BreakAmb Electron Inst Name Inst Name Surdo Mute BAmb Surdo Mute Elc Surdo Open BAmb Surdo Open Elc Hi Q BAmb Hi Q Elc Whip Slap BAmb on Whip Slap Elc Scratch H BAmb on Scratch H Elc Scratch L BAmb on Scratch L Elc Finger Snap BAmb on Finger Snap Elc...
  • Page 32 Voice List DR Instrument Map MSB=79, LSB=0 Program No. Kit Name AM/PM Note# Note Inst Name C# -1 Surdo Mute Trm on Surdo Mute APan -1 Surdo Open Trm on Surdo Open APan D# -1 Hi Q Trm on Hi Q APan -1 Whip Slap Trm on Whip Slap APan -1 Scratch H Trm...
  • Page 33 KitA/Ht1 KitB/Ht1 Inst Name Inst Name Surdo Mute Surdo Mute Surdo Open Surdo Open Hi Q Hi Q Whip Slap Whip Slap Scratch H Scratch H Scratch L Scratch L Finger Snap Finger Snap Click Noise Click Noise Metronome Click Metronome Click Metronome Bell Metronome Bell...
  • Page 34 Voice List DR Instrument Map MSB=79, LSB=0 Program No. Kit Name Spread3 Note# Note Inst Name Inst Name C# -1 Surdo Mute Surdo Mute -1 Surdo Open Surdo Open D# -1 Hi Q Hi Q -1 Whip Slap Whip Slap -1 Scratch H Scratch H F# -1 Scratch L...
  • Page 35 Cymbals A--PlgPC Inst Name Inst Name Surdo Mute Surdo Open Hi Q Whip Slap Scratch H Scratch L Finger Snap Click Noise Metronome Click Metronome Bell Seq Click L Seq Click H Brush Tap Brush Swirl Brush Slap Brush Tap Swirl Snare Roll Rock Hat 1/4-1/2 Brilliant Sw Snare Brass Piccolo Soft...
  • Page 36 Voice List DR Instrument Map MSB=79, LSB=0 Program No. Kit Name ABBA/Prc* Note# Note Inst Name C# -1 Surdo Mute Surdo Mute -1 Surdo Open Surdo Open D# -1 Hi Q Hi Q -1 Whip Slap Whip Slap -1 Scratch H Scratch H F# -1 Scratch L Scratch L...
  • Page 37 BBAB/Prc* BBBA/Prc* Inst Name Inst Name Surdo Mute Surdo Mute Surdo Open Surdo Open Hi Q Hi Q Whip Slap Whip Slap Scratch H Scratch H Scratch L Scratch L Finger Snap Finger Snap Click Noise Click Noise Metronome Click Metronome Click Metronome Bell Metronome Bell...
  • Page 38 Voice List DR Instrument Map MSB=79, LSB=0 Program No. Kit Name AAAA/Kk* Note# Note Inst Name C# -1 Surdo Mute Surdo Mute -1 Surdo Open Surdo Open D# -1 Hi Q Hi Q -1 Whip Slap Whip Slap -1 Scratch H Scratch H F# -1 Scratch L Scratch L...
  • Page 39 AABB/Cym* ABAB/Sn1* Inst Name Inst Name Surdo Mute Surdo Mute Surdo Open Surdo Open Hi Q Hi Q Whip Slap Whip Slap Scratch H Scratch H Scratch L Scratch L Finger Snap Finger Snap Click Noise Click Noise Metronome Click Metronome Click Metronome Bell Metronome Bell...
  • Page 40 Voice List DR Instrument Map MSB=79, LSB=0 Program No. Kit Name BBBA/Tom* Note# Note Inst Name C# -1 Surdo Mute Surdo Mute -1 Surdo Open Surdo Open D# -1 Hi Q Hi Q -1 Whip Slap Whip Slap -1 Scratch H Scratch H F# -1 Scratch L Scratch L...
  • Page 41 I PC Instrument Map Program No. Kit Name Afro Cubn Brazil Note# Note Inst Name Inst Name C# -1 D# -1 F# -1 G# -1 A# -1 SurdoL1 Sw SurdoL2 Sw SurdoLLH Sw SurdoLRM SurdoLRO SurdoM1 Sw SurdoM2 Sw SurdoMLH Sw G# 0 SurdoMRM SurdoMRO...
  • Page 42 Voice List PC Instrument Map MSB=79, LSB=1 Program No. Kit Name Br-PlgDR Lt-PlgDR Note# Note Inst Name Inst Name C# -1 D# -1 F# -1 G# -1 A# -1 G# 0 G# 1 G# 2 SurdoL1 Sw SurdoL1 Sw SurdoL2 Sw SurdoL2 Sw RepiniqueH1 Sw TriangleS1 Sw...
  • Page 43 BrzlHnd2 Bells Shakers Inst Name Inst Name Inst Name MenuTriangleL1 on MenuHandBellMO1 MenuShaker1 MenuTriangleL2 on MenuHandBellMO2 MenuShaker2 MenuTriangleL3 on MenuHandBellMM1 MenuShaker3 MenuTriangleL4 MenuHandBellMM2 MenuShaker4 MenuTriangleL5 MenuHandBellSO1 MenuShaker5 MenuTriangleL6 MenuHandBellSO2 MenuShaker6 MenuTriangleS1 on MenuHandBellSM1 MenuShaker7 MenuTriangleS2 on MenuHandBellSM2 MenuShaker8 MenuTriangleS3 on MenuHandBellSM3 MenuShaker9 MenuTriangleS4...
  • Page 44 Voice List PC Instrument Map MSB=79, LSB=1 Program No. Kit Name DlyGMPrc DlyGMLtn Note# Note Inst Name Inst Name C# -1 Dly GMSurdo1 Dly GMSurdo2 D# -1 Dly GMCuica1 Dly GMTamborim1 Dly GMCuica2 F# -1 Dly GMCuica3 Dly GMCabassa1 G# -1 Dly GMTamborim2 Dly GMCaixa1 A# -1...
  • Page 45 ODKk&Snr Dst1AfCb Dst1Brzl Inst Name Inst Name Inst Name Dist1 SurdoL1 Sw on on Dist1 GMClaves2 Dist1 SurdoL2 Sw on on Dist1 GMShaker1 Dist1 SurdoLLH Sw Dist1 SurdoLRM Dist1 SurdoLRO Dist1 SurdoM1 Sw Dist1 SurdoM2 Sw Dist1 SurdoMLH Sw Dist1 SurdoMRM Dist1 SurdoMRO Dist1 SurdoH1 Sw on on Dist1 GMCaixa5 Dist1 SurdoH2 Sw on on Dist1 GMSurdo4...
  • Page 46 Voice List PC Instrument Map MSB=79, LSB=1 Program No. Kit Name Dst2Kk&S FlgAfrCb Note# Note Inst Name Inst Name C# -1 D# -1 F# -1 G# -1 A# -1 G# 0 Dist2 SurdoL1 on on Flanger TumbaB Sw Dist2 SurdoL2 on on Flanger TumbaT Sw Dist2 SurdoL3 on on Flanger TumbaSC Sw...
  • Page 47 Rs2Kk&Sn Rs2Stick Inst Name Inst Name Resntr2 SurdoL1 on on Resntr2 SurdoL1 on on Mod1 TumbaB Sw Resntr2 SurdoL2 on on Resntr2 SurdoL2 on on Mod1 TumbaT Sw Resntr2 SurdoL3 on on Resntr2 SurdoL3 on on Mod1 TumbaSC Sw Resntr2 SurdoL4 on on Resntr2 SurdoL4 on on Mod1 TumbaM Resntr2 SurdoLLH1...
  • Page 48 Voice List PC Instrument Map MSB=79, LSB=1 Program No. Kit Name Md3Shkrs Md4BrHd1 Note# Note Inst Name Inst Name C# -1 D# -1 F# -1 G# -1 A# -1 G# 0 Mod3 Shaker1 on Mod4 Pandeiro1 Mod3 Shaker2 on Mod4 Pandeiro2 Mod3 Shaker3 on Mod4 Pandeiro3 Mod3 Shaker4...
  • Page 49 PchSkins PchStick RevAfrCb Inst Name Inst Name Inst Name Pitch TumbaB1 Pitch SurdoL1 on on Rev TumbaB Sw Pitch TumbaB2 Pitch SurdoL2 Rev TumbaT Sw Pitch TumbaT1 Pitch SurdoL3 on on Rev TumbaSC Sw Pitch TumbaT2 Pitch SurdoL4 Rev TumbaM Pitch TumbaSC1 Pitch SurdoLLH1 Rev TumbaO Sw...
  • Page 50 Voice List PC Instrument Map MSB=79, LSB=1 Program No. Kit Name RvACPgDR RvBrPgDR Note# Note Inst Name Inst Name C# -1 D# -1 F# -1 G# -1 A# -1 G# 0 G# 1 G# 2 Rev TumbaB Sw Rev SurdoL1 Sw Rev TumbaT Sw Rev SurdoL2 Sw Rev TumbaSC Sw...
  • Page 51 RevBrHd1 RevBrHd2 Inst Name Inst Name Rev MnPandeiro1 Rev MnTriangleL1 Rev MnHandBellMO1 Rev MnPandeiro2 Rev MnTriangleL2 Rev MnHandBellMO2 Rev MnPandeiro3 Rev MnTriangleL3 Rev MnHandBellMM1 Rev MnPandeiro4 Rev MnTriangleL4 Rev MnHandBellMM2 Rev MnPandeiro5 Rev MnTriangleL5 Rev MnHandBellSO1 Rev MnPandeiro6 Rev MnTriangleL6 Rev MnHandBellSO2 Rev MnPandeiro7 Rev MnTriangleS1...

  • Page 52: Dr/Pc Plug-In Voice List

    DR/PC Plug-in Voice List I DR/PC Plug-in Voice List G PLG150-DR DrPlgVc1.mid (Slot1) DrPlgVc2.mid (Slot2) DrPlgVc3.mid (Slot3) Plug-in Voice Name LiveRoom A LiveRoom B PoweredStd DryStandrd RockSt1 RockSt2 DryKit A DryKit B SmallRoom1 SmallRoom2 HeavyKit RingSnares Rocky Trashed1 Trashed2 Trashed3...

  • Page 53: Effect List

    Effect List I DR/PC Voice Effect Parameter List • DR/PC Native Part Parameter : This parameter can control the Voice Effect. NOTE • Dry/Wet (Parameter No.10) is available only on the Insertion Effect. HALL1,HALL2 / ROOM1,ROOM2,ROOM3 / STAGE1,STAGE2 / PLATE (Reverb, Insertion) Parameter Display...
  • Page 54 Effect List GATE REVERB / REVERSE GATE Parameter Display Type TypeA,TypeB Room Size 0.1...7.0 Diffusion 0...10 Initial Delay 0.1...99.3[ms] Feedback Level -63...+63 HPF Cutoff Thru...8.0k[Hz] LPF Cutoff 1.0k[Hz]...Thru 10 Dry/Wet D63>W...D=W...D<W63 11 Liveness 0...10 12 Density 0...3 13 High Damp 0.1...1.0 CHORUS1,2,3,4 / CELESTE1,2,3,4 Parameter...
  • Page 55 PHASER 2 (Insertion) Parameter Display Value LFO Frequency 0.00...39.7[Hz] 0 - 127 LFO Depth 0...127 0 - 127 Phase Shift Offset 0...127 0 - 127 Feedback Level -63...+63 1 - 127 EQ Low Frequency 50...2.0k[Hz] 8 - 40 EQ Low Gain -12...+12[dB] 52 - 76 EQ High Frequency...
  • Page 56 Effect List I Effect Default Data List Type HALL1 HALL2 ROOM1 ROOM2 ROOM3 STAGE1 STAGE2 PLATE WHITE ROOM TUNNEL BASEMENT KARAOKE1 KARAOKE2 KARAOKE3 DELAY L,C,R 3333 1667 DELAY L,R 2500 3750 ECHO 1700 CROSS DELAY 1700 1750 EARLY REF1 EARLY REF2 GATE REVERB REVERSE GATE CHORUS1...
  • Page 57 I Effect Data Assign Table table#1 table#2 LFO Frequency Modulation Delay Offset Data Value Data Value 0.00 0.69 0.04 2.77 0.08 2.86 0.12 2.94 0.16 3.02 0.21 3.11 0.25 3.19 0.29 3.28 0.33 3.36 0.37 3.44 0.42 3.53 0.46 3.61 0.50 3.70 0.54...
  • Page 58 Effect List table#5 Delay Time (200.0ms) Data Value Data Value 100.8 102.4 104.0 105.6 107.1 108.7 110.3 11.1 111.9 12.7 113.4 14.3 115.0 15.8 116.6 17.4 118.2 19.0 119.7 20.6 121.3 22.1 122.9 23.7 124.4 25.3 126.0 26.9 127.6 28.4 129.2 30.0 130.7...

  • Page 59: Parameter List (Xg/Modular Synthesis Plug-In System)

    Parameter List Modular Synthesis Plug-in System XG Plug-in System Parameter Name Parameter Name Volume VOLUME Reverb Send REVERB SEND Chorus Send CHORUS SEND LPF Cutoff Frequency LOW PASS FILTER CUTOFF FREQUENCY LPF Resonance LOW PASS FILTER RESONANCE Attack Time EG ATTACK TIME Decay Time EG DECAY TIME Release Time...

  • Page 60: Midi Data Format

    MIDI Data Format 1. Channel messages 1.1 Note on/note off These messages convey keyboard performance data. Range of note numbers received = C-2...G8 Velocity range = 1...127 (Velocity is received only for note-on) When the Multi Part parameter “Rcv NOTE MESSAGE” = OFF, that part will not receive these messages.
  • Page 61 The following NRPN messages can be received. NRPN Data Entry*1 Parameter Name and Data Range – *2 Vibrato rate mm: 00H - 40H - 7FH (-64 ...0...+63) – Vibrato depth mm: 00H - 40H - 7FH (-64 ...0...+63) – *3 Vibrato delay mm: 00H - 40H - 7FH (-64 ...0...+63) –...
  • Page 62 2.1.3.4 Part Assign parameter change This message sets the PART ASSIGN block (see Tables <1-1> and <1-4>). 2.1.4 PLG150-DR/PLG150-PC Native parameter change This message sets parameters unique to the PLG150-DR/PLG150-PC. Each message sets a single parameter. The message format is as follows. Exclusive status...
  • Page 63 This is not transmitted. After FE is received one time, if the MIDI signal does not come within 300 msec, PLG150-DR/PLG150-PC will act the same as when ALL SOUND OFF, ALL NOTE OFF, and RESET ALL CONTROLLERS are received, and return to the condition where has not been received once.
  • Page 64 MIDI Data Format <1-2> MIDI Parameter Change table (XG SYSTEM) Address Size Data 00 00 00 00 - 7F 00 - 7F 28 - 58 TOTAL SIZE 07 ** Processed on the platform side (Motif, MU128, 9000Pro, etc.) <1-3> MIDI Parameter Change table (MULTI PART) Address Size Data...
  • Page 65 Size Data Parameter 70 05 nn 00 - 0F,7F PLG150-DR PART ASSIGN 06 mm 00 - 0F,7F PLG150-PC PART ASSIGN nn = PLG150-DR SERIAL NUMBER mm = PLG150-PC SERIAL NUMBER MIDI Data Format Description Default -24...+24[semitones] -9600...+9450[cent] -100...+100[%] 0...127 0...127 0...127...
  • Page 66 USER VOICE (common) PLG150-DR NATIVE USER VOICE (instrument) PLG150-PC NATIVE USER VOICE (instrument) <2-2> MIDI Parameter Change Table (PLG150-DR/PLG150-PC NATIVE CURRENT VOICE) Address Size Data 1p 00 00 20 - 7F 20 - 7F 20 - 7F 20 - 7F...
  • Page 67 INSTRUMENT EG DECAY1 RATE 00 - 7F INSTRUMENT EG DECAY2 RATE TOTAL SIZE 10 p = PART NUMBER nn = INSTRUMENT NUMBER <2-3> MIDI Parameter Change Table (PLG150-DR/PLG150-PC NATIVE USER VOICE) Address Size Data Parameter 3v 00 00 20 - 7F...
  • Page 68 00 - 7F 00 - 7F 00 - 7F 00 - 7F TOTAL SIZE 10 v = PLG150-DR: USER VOICE NUMBER(1...8) - 1 PLG150-PC: USER VOICE NUMBER(1...8) + 7 nn =INSTRUMENT NUMBER(0...127) Parameter REVERB EFFECT TYPE MSB REVERB EFFECT TYPE LSB...
  • Page 69 <2-4> MIDI Parameter Change Table (PLG150-DR/PLG150-PC NATIVE MULTI PART) Address Size Data Parameter 5m 0p 00 00 - 01 NOTE SELECT1 MSB 00 - 7F NOTE SELECT1 LSB 00 - 01 NOTE SELECT2 MSB 00 - 7F NOTE SELECT2 LSB...

  • Page 70: Midi Implementation Chart

    MIDI Implementation Chart...
  • Page 71 MIDI Implementation Chart...
  • Page 72 5. LIMITED LIABILITY Your sole remedies and Yamaha’s entire liability are as set forth above. In no event will Yamaha be liable to you or any other person for any damages, including without limitation any incidental or consequential damages, expenses, lost profits, lost savings or other damages arising out of the use or inability to use such SOFTWARE even if Yamaha or an authorized dealer has been advised of the possibility of such damages, or for any claim by any other party.
  • Page 73 Daten (“SOFTWARE”) als Einzelperson auf jeweils einem Computer zu verwenden. Sie dürfen sie nicht auf mehr als einem Computer bzw. einer Computerstation verwenden. Die SOFTWARE bleibt im Besitz von Yamaha und ist durch japanische Copyrightgesetze sowie alle anwendbaren internationalen Vertragsbestimmungen geschützt. Sie haben ein Anspruchsrecht auf das Eigentum an den Medien, denen die SOFTWARE beiliegt.
  • Page 74 Ceci est un contrat entre vous-même, l’utilisateur final, et Yamaha Corporation (« Yamaha »). Le logiciel Yamaha ci-inclus est concédé sous licence par Yamaha à l’acheteur original et ne peut être utilisé que dans les conditions prévues aux présen- tes. Veuillez lire attentivement ce contrat de licence. Le fait d’ouvrir ce coffret indique que vous acceptez l’ensemble des ter- mes du contrat.
  • Page 75 For details of products, please contact your nearest Yamaha or the authorized distributor listed below. Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou au distributeur le plus proche de vous figurant dans la liste suivante. NORTH AMERICA CANADA Yamaha Canada Music Ltd.
  • Page 76 Auf Umweltpapier mit Sojatinte gedruckt. Ce document a été imprimé sur du papier non blanchi au chlore avec de l'encre d'huile de soja. M.D.G., Pro Audio & Digital Musical Instrument Division, Yamaha Corporation © 2002 Yamaha Corporation V938190 206POCP26.2-01A0 Printed in Japan...
