Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 368023 Cleveland, Ohio 44136-9722. CUB CADET CORP. P.O. BOX 368023 CLEVELAND, OHIO 44136-9722 PRINTED IN U.S.A.
Before you start assembling your new equipment, please locate the model plate on the equipment and copy the information from it in the space provided below. The information on the model plate is very important if you need help from your local authorized Cub Cadet dealer.
SECTION 1: IMPORTANT SAFE OPERATION PRACTICES WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
The clutch levers must operate easily in both directions and automatically return to the disengaged position when released. Never operate with a missing or damaged discharge chute. Keep all safety devices in place and working. Never run an engine indoors or in a poorly ventilated area.
SECTION 2: ASSEMBLING YOUR SNOW THROWER NOTE: Any reference in this manual to the left or right side of the snow thrower is observed from the operator’s position. Unpacking • Remove screws from the top sides and ends of the shipping crate.
Final Adjustments Auger Control Adjustment Check the adjustment of the auger control as follows: • Push forward on the auger control until the small rubber bumper contacts the upper handle. There should be slack in the cable. See Figure 5 . •...
• Recheck the adjustment and repeat adjustment as necessary. • Retighten the jam nut to secure the cable when correct adjustment is reached. SECTION 3: KNOW YOUR SNOW THROWER Traction Control / Auger Control Lock Heated Handles Switch Headlight Discharge Chute Auger WARNING: Read, understand, and follow...
Electric Chute-Rotation Switch The electric chute-rotation switch is located on the left side of the snow thrower dash panel. See Figure 7. To change the direction in which discharged snow is thrown, proceed as follows: • Push the toggle switch to the left to rotate the chute counterclockwise.
WARNING: electric equipped with a grounded three-wire power cord and plug and is designed to operate on 120 volt AC household current. It must be used with a properly grounded three-prong receptacle at all times to avoid the possibility of electric shock.
WARNING: The temperature of the muffler and the surrounding areas may exceed ° F. Avoid these areas. • For the most efficient snow removal, remove snow immediately after it falls. SECTION 5: MAKING ADJUSTMENTS WARNING: NEVER attempt to make any adjustments while the engine is running, except where specified in the operator’s manual.
• Reconnect the upper shift rod to the lower shift rod by reinserting the hairpin clip removed earlier and sliding the shift rod connector back down into place. Make certain to check for correct IMPORTANT: adjustment of the shift rod as instructed under Final Adjustments in the Assembly Section, before operating the snow thrower.
Lube Gear & Chute Base Figure 11 Gear Case The gear case is equipped with a grease fitting on the left housing and should be lubricated with Shell Alvania grease EPR00, part number 737-0168 every 25 hours. See Figure 12. Do not overfill the gear case.
Belt Cover Figure 13 • Remove the six self-tapping screws from the frame cover underneath the snow thrower. • Roll the front and rear auger belts off the auger drive pulley. See Figure 14. Auger Pulley Idler Pulley Support Bracket Rear Auger Belt...
Page 14
• Remove the six self-tapping screws from the frame cover underneath the snow thrower. • Remove the click pin that secures the left wheel to the axle and slide the wheel from the axle. • Remove the four screws securing the left drive cover to the frame.
SECTION 8: TROUBLE SHOOTING Problem Engine fails to start Fuel tank empty, or stale fuel. Blocked fuel line. Choke not in ON position Faulty spark plug. Safety key not in ignition switch on engine. Spark plug wire disconnected. Primer button not being used properly. Fuel shut-off valve closed.
Page 21
Models 826 SWE & 1130 SWE Ref. Part No. Part Description 712-0116 Lock Jam Nut 3/8-24 756-0178 Flat Idler 784-5632A Auger Idler Arm 710-0459A Hex Cap Screw 3/8-24 x 1.50 738-0281 Shoulder Screw 736-0167 Wave Washer 732-0611 Extension Spring 712-3068 Hex Nut 5/16-18 710-0276 Carriage Bolt, 5/16-18 x 1.00...
Page 22
Models 826 SWE & 1130 SWE IMPORTANT: For a proper working machine, use Factory Approved Parts. V-BELTS are specially designed to engage and disengage safely. A substitute (non OEM) V-Belt can be dangerous by not disengaging completely...
There is no other express warranty. Contact your authorized Cub Cadet servicing dealer who sold you your Cub Cadet equipment. If this dealer is not available, see the Consumer Yellow Pages under “lawn mowers” for the name of a dealer near you.
