User Guide
DVI & HDMI
®
DFX 100 Series
DFX 100 Tx and DFX 100 Rx DVI Signal Extenders
68-2149-01 Rev. B
06 13

Advertisement

Table of Contents
loading

Summary of Contents for Extron electronics DFX 100 Rx

  • Page 1 User Guide DVI & HDMI ® DFX 100 Series DFX 100 Tx and DFX 100 Rx DVI Signal Extenders 68-2149-01 Rev. B 06 13...
  • Page 2 Safety Instructions Safety Instructions • English Chinese Simplified (简体中文) 警告: 产品上的这个标志意在警告用户该产品机壳内有暴露的危险 WARNING: This symbol, , when used on the product, is intended to alert the user of the presence of uninsulated dangerous voltage within 电压, 有触电危险。 the product’s enclosure that may present a risk of electric shock. 注...
  • Page 3 The product is intended to be used with the fiber optic cables fully installed. This product meets the applicable requirements of IEC 60825-1, Edition 1 (2007). Any service to this product must be carried out by Extron Electronics and its qualified service personnel.
  • Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: A warning indicates a situation that has the potential to result in death or WARNING: severe injury. CAUTION: A caution indicates a situation that may result in minor injury. ATTENTION: Attention indicates a situation that may damage or destroy the product or associated equipment.
  • Page 5: Table Of Contents

    Contents Introduction ............1 About the DFX 100 Tx and DFX 100 Rx ....1 Features ............. 1 Application Diagram ........... 2 Product Label ............. 2 Panels and Cables ..........3 Front Panel ............3 DFX 100 Tx Rear Panel ........3 DFX 100 Rx Rear Panel ........
  • Page 6 DFX 100 • Contents...
  • Page 7: Introduction

    This guide describes the function, installation and operation of the DFX 100 Tx transmitter and DFX 100 Rx receiver. Unless otherwise stated, the terms “DFX 100,” “DVI extender,” and “extender” refer to both units. The term “transmitter” refers to the DFX 100 Tx and the term “receiver”...
  • Page 8: Application Diagram

    DFX 100 Tx Transmitter W ER Fiber Up to 300m ( 984 ft ) on Multimode Fiber Extron DFX 100 Rx Receiver W ER Flat Panel Display Figure 1. Typical DFX 100 Application Label is 2.0" H x 1.5" W with 0.125"...
  • Page 9: Panels And Cables

    Extron Figure 2. DFX 100 Tx and DFX 100 Rx Front Panel Front Panel LED — lights amber if the unit (transmitter or receiver) is receiving power from the 12 VDC power supply. The Transmitter LED lights green if the unit is receiving a TMDS clock signal.
  • Page 10 12 VDC power input — Connect the provided 12 VDC power supply to the front panel captive screw connectors. When power is provided to the unit but there is no DVI input, the front panel lights amber. Back Panel Power Receptacle POWER 1.0A MAX DC Power Cord...
  • Page 11: Dfx 100 Rx Rear Panel

    Optical output connector — Connect one end of one multimode fiber optic cable (not provided) into this LC connector. The other end connects into the LC input connector on the DFX 100 Rx. The cable can be up to 984 feet (300 m) in length. CAUTION: •...
  • Page 12 Possible radiation exposure. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. When the DFX 100 Rx is receiving optical input, the front panel LED lights green. DFX 100 • Panels and Cabling...
  • Page 13: Installation

    DDC communication between the display and the source while the source device is booting up. When the DFX 100 Tx is receiving DVI-D input, the front panel lights green. When the DFX 100 Rx is receiving an optical input, the front panel lights green. DFX 100 • Installation...
  • Page 14: Reference Information

    Included Parts • Mounting Included Parts Because the DFX 100 Tx and DFX 100 Rx are compatible with other Extron products, they are sold as individual units. Mounting Desktop Placement Attach the four provided rubber feet to the bottom of the DFX 100 transmitter or receiver and place the unit in any convenient location.
  • Page 15 Rack Mounting Procedure The units can be mounted on any of the optional Extron rack systems. Follow the instructions provided with the mounting kit. DFX 100 • Reference Information...
  • Page 16 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
