Vulcan-Hart GHX45 Specifications

Model GHX45 shown
with 17" Backguard
SPECIFICATIONS:
17" wide heavy duty expando gas range, Vulcan-Hart Model No.
___________. Stainless steel front, front top and 6" adjustable
legs. Sides finished in heat resistant paint. 1
gas manifold.
GHX45
Two 30,000 BTU/hr. heavy cast two piece "Flame Retention"
burners with individual pilots and control valves. Total input
60,000 BTU/hr. Heavy cast iron aeration plates with deep bowls
and removable cast top grates.
GHX60
3
⁄ " polished steel griddle plate with front grease trough and
4
removable grease collector. 4" side splashers and 5
splasher. Two 20,000 BTU/hr. burners and one manual control
valve. Total input 40,000 BTU/hr. Pilot ignition system. Heat
absorbent fire brick and griddle leveling bolts. NOTE: For
thermostatic griddle control, specify model number GHXM60T.
GHX72
One polished cast iron hot top section measures 17"w x 23
Ceramic fire brick under hot top. Two 20,000 BTU/hr. burners
and one manual control valve. Total input 40,000 BTU/hr. Pilot
ignition system.
Exterior dimensions: 17"w x 39
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32238 (10-03)
Model GHX60 shown
with 17" Backguard
1 ⁄ " diameter front
4
5 ⁄ " rear
8
13 ⁄ "d.
16
1 ⁄ "d x 36" working height.
8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
GHX SERIES
HEAVY DUTY EXPANDO GAS RANGE
GHX45 Two 30,000 BTU/hr. open burners
GHX60 17" wide griddle top
GHX72 17" wide even heat top
STANDARD FEATURES
Stainless steel front and front top. Sides finished in heat
resistant paint.
1
1 ⁄ " diameter front gas manifold.
4
17" wide cabinet storage base with door.
One year limited parts and labor warranty.
OPTIONS
Stainless steel side(s).
Stainless steel back finishing panel.
Common front top ledge up to 68" wide. (Not for use on
griddle tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s). (No charge.)
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Rear gas connection. (Reference spec sheet F31525.)
Second year extended limited parts and labor warranty.
C.S.I. Section 11420
Model GHX72 shown
with 17" Backguard
