WALL MOUNTING

The Wall Mounting bracket is
designed to fit on standard Wall Mount-
ing plates
1. Choose a spot near an electrical
outlet and a telephone jack.
Your phone requires a modular
telephone jack and a standard
electrical outlet (120v AC). The power
cord is six feet long; make sure there
is an electrical outlet within reach of
the Base Unit. The outlet should not
be controlled by a wall switch. If the
switch is ever turned off, the phone
will not operate.
2. Position the wall mount bracket on
the base.
Line up the tabs on the wall mounting
bracket with the holes on the bottom
of the base. Snap the wall mounting
bracket firmly into place.
3. Mount the base on the wall.
Position the base so the mounting
studs will fit into the holes on the
bottom of the base. Position the
power cord to extend down the wall.
Slide the base down on the mounting
studs until it locks into place.
4. Connect the telephone line cord.
Insert one end into the TEL.LINE
jack on the back edge of the base.
Insert the other end into the wall
jack.
5. Plug the AC adapter into an electrical
outlet and the DC connector into the
power jack located on the back of
the Base Unit .
WALL
9
BASE UNIT
WALL MOUNT
