APPLICATION
The Multiquip PRO12C hydraulic mixer is shipped
completely assembled, factory tested, and ready for use.
This mixer has a drum capacity of 340 liters (12.0 cubic feet)
and a batch capacity of 3-1/2 to 4-1/2 bags.
WARNING
This mixer is intended only for the mixing of plaster
and mortar. The mixer must be used for its intended
purpose and is not suitable for mixing flammable or
explosive substances. The mixer must not be used
in an explosive atmosphere.
POWER PLANTS
This hydraulic mixer is powered either by an 11.7-horsepower
Honda GX390RT2-QNB2 gasoline engine, or a
5-horsepower Teco Westinghouse electric motor. Refer
to Table 2 for engine specifications or Table 3 for electric
motor specifications.
ENGINE MAINTENANCE
For basic engine maintenance, refer to the engine
maintenance section in this manual. For more detailed
engine maintenance, refer to the Honda Engine Owner's
Manual provided with the engine.
ELECTRIC MOTOR
If the mixer is equipped with an electric motor, make sure
that the power being supplied to the motor corresponds to
the voltage rating label on the motor. Supplying the wrong
voltage to the electric motor will cause severe electrical
damage to the motor. Refer to Table 3 for electric motor
specifications.
Always make sure the ON/OFF switch on the electric motor
is in the OFF position before applying power.
PRO12C HYDRAULIC MIXER • OPERATION MANUAL — REV. #0 (07/16/20) — PAGE 13

GENERAL INFORMATION

EXTENSION CABLES
The extension cable should be a 3-wire configuration that
includes a ground wire that conforms to UL code. The wire
cross section must be a minimum of 2.5 mm². Choose an
extension cord of adequate current-carrying capacity as
referenced in Table 7. Remember, cable distance affects
the current-voltage capacity of the extension cable.
Ensure that the extension cable is carefully laid out,
avoiding wet areas, sharp edges, and locations where
vehicles might run over it. Avoid allowing the extension
cable to be trapped underneath the mixer.
Unroll the extension cable fully or it will overheat and could
catch fire. Make sure that all extension cable connections
are dry and safe. Replace any defective or badly worn
extension cables immediately.
HARDWARE
Check all hardware on the mixer before starting. Periodically
inspect all hardware. Loose hardware can contribute to
early component failure and poor performance. Keep all
mixer hardware components tight.
