OPERATION AND PARTS MANUAL
SERIES
EM120P Series
POLYETHYLENE DRUM
EM120S Series
STEEL DRUM
HYDRAULIC PLASTER/MORTAR MIXERS
(HONDA GASOLINE ENGINE/ELECTRIC MOTOR)
Revision #6 (09/15/11)
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
