Wall Mounting - VTech ip5856 User Manual

Wall Mounting

The Wall Mount bracket is designed for use on standard wall mount plates only.
Wall mounting is optional.
1. Plug the AC adapter into an electrical outlet. Then plug the DC connector of
the Base power adapter to the connector jack at the bottom of the Base Unit.
2. Connect the telephone line cord to the jack at the bottom of the Base Unit, and
the other end to the wall jack.
3. Line up the tabs on the wall mount adapter with the holes at the bottom of the
Base Unit. Snap the wall mount bracket firmly in place.
4. Mount the Base Unit on the wall. Position the Base Unit so that the mounting
studs will fit into the holes on the wall mount bracket. Slide Base Unit down on
the mounting studs until it locks into place.
9
