Summary of Contents for ViewSonic N2700w
- Page 1 N2700w Full 27.0" Wide-Screen Entertainment Display ViewSonic NextVision™ Wide-Screen Entertainment Display User Guide Guide de l’utilisateur Bedienungsanleitung Guía del usuario Användarhandbok English- 0 English N2700w...
-
Page 2: Table Of Contents
Audio Sources...40 POP Screen ...41 Other Information ... 42 Specifications ...42 Compatibility...43 Troubleshooting...45 Customer Support ...46 Cleaning the LCD TV ...47 Limited Warranty ...48 Appendix ... 49 Safety Guidelines ...49 Compliance Information for U.S.A..49 ViewSonic English- 1 English N2700w... -
Page 3: Product Registration
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic® Wizard CDROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic. -
Page 4: Installation
Important! Save the original box and all packing material for future shipping needs. The NextVision line of LCD TV is the next innovation from ViewSonic. Through the use of the new VXP port (located on the rear of the monitor) numerous expansion options are available for your NextVision LCD TV. - Page 5 English N2700w LCD TV Remote Control Power cord VGA Cable 3.5mm Stereo Audio cable AC/DC Adapter VXP TV (VXP 25) or Right Angle F-Connector (or Europe Video Adapter (VXP 10) Connector) (F-Connector) (Europe Connector) (VXP 25) (VXP 10) Wizard CD-ROM...
-
Page 6: Quick Installation
VXP 10 Video Adapter Module that allows connection to most AV Devices. NOTE: The VXP-25 TV and VXP-10 Video Adapter modules may also be purchased separately, please contact ViewSonic for more information (www.viewsonic.com). Further detail about AV connections are included within the VXP Package. - Page 7 2.2 Mount the VXP 25 TV module under the hood and put the adapter into the clips on the back of the TV as following picture. 2.3.Connect the output cable of the VXP25 to the VXP input located on the LCD TV monitor.
- Page 8 (NOTE: If Desired, the RCA L /R Jacks may be used as an audio input corresponding to the YPbPr input; however a change on the OSD is required. See page 39) 4.3 S-video input. SVIDEO is only available on the optional VXP10 module. Contact ViewSonic at www.viewsonic.com for ordering information.
- Page 9 6.Connect power cord and AC/DC adapter Connect the Power Plug form the DC power Supply to the Power Port on the back of the LCD TV. NOTE: always turn off the TV power when connecting the AC cords. Don’t use power supply voltage other than 100-240 VAC.
- Page 10 English 8. Plug into AC power source (wall outlet) ViewSonic English- 9 N2700w...
- Page 11 Connect the video cable (VGA or DVI port) from the LCD TV to the computer Macintosh users: Models older than G3 require a Macintosh adapter. Attach the adapter to the computer and plug the video cable into the adapter. To order a ViewSonic® Macintosh adapter, contact ViewSonic Customer Support.
- Page 12 Pressing SOURCES button on the top of panel or via remote control to show an Input Sources menu. Set TV for TV function or set CVBS for AV function. (also see page 10.Installation is complete. Enjoy your new ViewSonic, LCD TV.
-
Page 13: Getting Started
Getting Started Initial Setup 1. Power on 1.1 Switch the POWER button on the front of panel or via remote control to turn on the TV. Indicator Blue blinking The system is ready for Power on Blue Power on Amber blinking... -
Page 14: Input Sources
Source 4.Set Tuner Input 4.1 NTSC system Before using the built in TV tuner for the first time the following step must be completed. Please set TUNER INPUT to the appropriate RF system. Antenna: Select this for off-air use. CATV/ Japan CABLE: Select this if connected to the cable system. - Page 15 This function searches for and finds all available channels in your area. First time you turn on the TV, you must automatically search all active channels. Pressing MENU button on the top of panel or via remote control to show an OSD menu. Choose AUTO SCAN page of Tuner Setting tab and pressing OK to scan channels.
-
Page 16: Using The On Screen Display (Osd)
Use the buttons on the top panel or use the remote control to make all adjustments to the On Screen Display (OSD).The OSD controls are explained at the top of the next page and are defined in “Main Menu Controls” on page 19. Remote Control Menu Top panel Menu ViewSonic English- 15 N2700w... - Page 17 AUTO TUNE. Automatically adjusts Image Size, Position, and Phase in RGB mode. System Reset. (Including Parental Control Password reset) OSD LOCK TOGGLE Note: Hold for 5 sec to dismiss POWER LOCK Note: Hold for 5 sec to dismiss English- 16 English for detail) N2700w...
-
Page 18: Remote Controls
Remote Controls The N2700w remote control allows easy adjustment of all available options. The Remote Control is compatible with the LCD TV from up to 5m distance. NOTE: Additionally, when a VXP compatible adapter is installed, further utility is gained from the remote by allowing easy access to commonly used functions. -
Page 19: To Adjust The Screen Image
5. To save the adjustments and exit the marker, press button [ Menu ]. The following tips may help you optimize your LCD TV: Adjust your computer's graphic card so that it outputs a video signal 1280 x 720@ 60 Hz to the Display. -
Page 20: Main Menu Controls
NOTE: that the MARKER can be moved across the MAIN tabs horizontally. Please adjust the menu items shown below by using the up ↑ and down ↓ buttons. Picture Adjustment Tab In the Picture adjustment main page, pressing OK then the functional page shall be displays. ViewSonic English- 19 N2700w... -
Page 21: Contrast
If PC + PIP Window, only affects PIP Source. h. Only present if compatible VXP adapter is detected DEFAULT Shall restore all functions to the factory default. Press Ok to take effect. ViewSonic Explanation only affect the PIP. English- 20 English N2700w... -
Page 22: Colorv
Cool = PRESET WHITE POINT. More blue bias. COLOR c. Standard = PRESET WHITE POINT. “TV” standard color d. Warm = PRESET WHITE POINT. More “Red” bias. e. User color: RGB controls appear on the user color is scrolled to. -
Page 23: Lcd Adjust V V V Vv
The smoothing scroll will be appeared when the input sources is YPbPr mode. When the monitor is displaying a non-native (1280*720) signal. This control allows a Trade-ff between “smooth fonts” For Full Screen PC Source, acts as a ‘resolution smoothing’ filter for ViewSonic Explanation English- 22 English N2700w... -
Page 24: Autosync
This function will be active in PC mode. Attempts to automatically fine tune. The image for best picture quality. For best result set display card to 1280x720@60Hz. DEFAULT Restores all settings to default. Press Ok to take effect. ViewSonic English- 23 N2700w... -
Page 25: Display Adjustment Tab
Defines the source from where the Picture in Picture (PIP) is to be displayed when activated by the Remotes “PIP” button. Requires connection of compatible VXP adapter and the input sources must be set in RGB and DVI mode. ViewSonic Explanation English- 24 English N2700w... -
Page 26: Sleepv
“off” value is selected. 45 (minutes) CAPTION Allows the user to select the type (CC1, CC2, Text1, Text2) of closed caption required. Requires connection of compatible VXP adapter. DEFAULT Returns this page back to factory default settings. ViewSonic English- 25 N2700w... -
Page 27: Tv Setting Tab (Requires Connection Of Compatible Vxp Adapter)
Time out or MENU shall exit the OSD. Function TUNER INPUT Allows the user to select the type of signal applied to the TV INPUT. This controls options will vary by region. 1. B/G, I, D/K, L shall be selectable under PAL system that most be used in Europe, China and Singapore area. -
Page 28: Edit Chan. V * V * V * V
← , →, ↑ and ↓ keys shall be used to navigate to the selection Pressing OK to Add or Erase channel. Time out or MENU shall exit the OSD. Function EDIT CHAN. Allows the user to add/erase the current channel to the internal database of active channels. ViewSonic Explanation English- 27 English N2700w... -
Page 29: Chan. Labelv
Pressing # 0~9 buttons on remote control to enter numbers and letters. Pressing ok will bring you out so you can select the next channel label. Time out or MENU shall exit the OSD. [NOTE]: Only present if VXP TV Adapter or similar adapter is detected. Function CHAN. LABEL The Channel Label allows the user to enter in the current channel’s... -
Page 30: Manual Setup
You can choose one air system type that controls options will vary by region. B/G, I, D/K, L shall be selectable in PAL system. Normally not required to adjust as the audio input will automatically to carry out. SEARCH Search automatically to catch the correct frequency ViewSonic Explanation English- 29 English N2700w... -
Page 31: Audio Settings Tab
If you connect the VXP25 of NTSC system, the MTS controller will be shown. Allows selecting MTS (Multi-channel Television on Sound) Mode, (NTSC system) Stereo sound, Mono sound, or SAP (Secondary Audio Programs). SAP: listen to second language, supplementary commentary and other information ViewSonic Explanation English- 30 English N2700w... - Page 32 PC, but listen to audio from the PIP. Requires a compatible VXP adapter and PIP to be available. (see page for detail) AUDIO SOURCE Choose audio source from TV, on board, Audio in and CVBS Selection. But you can not store the setting. DEFAULT...
-
Page 33: Parental Lock Tab
1.Channel Lock This message would appear if the user tunes to a channel that is locked. You can bypass and unlock the channel immediately by entering your password. The channel will stay unlocked until the TV is power down. ViewSonic... - Page 34 This message would appear if the user enters the incorrect password. 3.Channel Unlocked Confirmation This message appears once the correct password has been entered and the channel has successfully unlocked. This message will time out after 3 seconds ViewSonic English- 33 English N2700w...
-
Page 35: Tv Ratingv
[NOTE]: This menu will appear if the Parental Lock is on. Function TV RATING Allows the user to select the TV rating of the Parental Control Connection. 1. TV-Y: Suggested for all children 2. TV-Y7: Directed to older children 3. TV-G: General audiences. -
Page 36: Movie Rating V V V Vv
10. R: Restricted. Under 17 requires accompanying parent or adult guardian (age varies in some jurisdictions) 11. NC-17: No one 17 and under admitted X: a rating that has now been superseded by NC-17 ViewSonic Explanation English- 35 English N2700w... -
Page 37: Passwordv
Passwords are 8 Digits, and consist of numeric characters only entered in via the Remote Control only. An entered password mismatch between the “NEW” Password and “CONFIRM PASSWORD” shall be rejected with an error message “Password not match”. ViewSonic Explanation English- 36 English N2700w... -
Page 38: Set Up Tab
← and → shall be used to change the selected bar’s option (English, Spanish, etc.). Time out or MENU shall exit the OSD. NOTE: Languages shall be defined by each region. Function LANGUAGE Shall select among available languages. DEFAULT English is the default language. ViewSonic Explanation English- 37 English N2700w... -
Page 39: System Info V V V Vv
CC: Closed Captioning Status. Valid Values “ON” or “OFF” f. SLEEP TIMER: Either “OFF” or the Number of Minutes before shutdown. g. VXP: Either “VXP 25”, “VXP 10” if detected or “NONE” or “ERROR” System version ViewSonic Explanation English- 38 English N2700w... -
Page 40: Input Sources
Press the SOURCE button via remote control to invoke the Audio Source Page. You can choose video input sources from VGA, DVI, YPbPr, TV and CVBS. If the image doesn’t come in clearly, you may need to change the input signal type setting. -
Page 41: Audio Sources
Audio Sources Press the AUDIO button via remote control to invoke the Audio Sources Page. You can choose audio input sources from On board, Audio in, TV and CVBS. Audio Source ↑ and ↓ shall be used to navigate across the vertical items. -
Page 42: Pop Screen
English POP Screen POP (picture outside picture) : Pressing POP button on the remote control to show additional pictures around on the screen that include current, go forward 4 channels and afterward 4 channels. Current channel ViewSonic English- 41 N2700w... -
Page 43: Other Information
786 mm (W) x 225 mm (H) x 526 mm (D) 31" (W) x 8.9" (H) x 20.7" (D) 30.8 lb (14.0 kgs) cULus, TUV/GS, CB Report, CE, FCC-B, CCC, BSMI, GOST-R, PCBC, C-Tick, NOM, PSB, SASO Normal <5W English- 42 English N2700w... -
Page 44: Compatibility
VXP25 NTSC VXP10 VXP25 VXP10 VXP25 SECAM VXP10 ViewSonic Frequency 70Hz 85Hz 70Hz 85Hz 70Hz 85Hz 60Hz 75Hz 60Hz 75Hz 60Hz 75Hz 43iHz 60Hz 75Hz 60Hz 75Hz 60Hz 75Hz Frequency (60Hz) (59 Hz) CVBS English- 43 English SVHS YPbPr/YCbCr N2700w... - Page 45 EDIT CHAN. CHAN. LABEL MANUAL SETUP Channel Air System Search Save Audio Settings BASS TREBLE BALANCE AUDIO SELECT AUDIO SOURCE Parental Lock PARENT LOCK TV RATING MOVIE RATING PASSWORD Set up LANGUAGE SYSTEM INFO ViewSonic YPbPr English- 44 English CVBS N2700w...
-
Page 46: Troubleshooting
Power is ON but no screen image Make sure the video cable supplied with the LCD TV is tightly secured to the video output port on the back of the computer. If the other end of the video cable is not attached permanently to the LCD TV, tightly secure it to the NextVision LCD TV. -
Page 47: Customer Support
F: +61 2 9929 8393 T: 65 273 4018 service.sg@viewsonic.com F: 65 273 1566 T: 886 2 2246 3456 service.ap@viewsonic.com F: 886 2 8242 3668 T: 886 2 2246 3456 service.ap@viewsonic.com F: 886 2 8242 3668 English- 46 English N2700w... -
Page 48: Cleaning The Lcd Tv
Disclaimer ViewSonic does not recommend the use of any ammonia or alcohol-based cleaners on the LCD TV screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the LCD TV. -
Page 49: Limited Warranty
2.To obtain service under warranty, you will be required to provide (a) the original dated sales slip, you’re your name, (c) your address, (d) a description of the problem, and (e) the serial number of the product. 3.Take or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic. -
Page 50: Appendix
• Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Warning To assure continued FCC compliance, the user must use grounded power supply cord and the provided shielded video interface cable with bonded ferrite cores. - Page 51 English ViewSonic Corporation ViewSonic English- 50 N2700w...
