Rear Panel

16. DC Power Inlet
Connect only the included power adapter.
17. Aux In
Connect a line level stereo audio source here. This mono-summing input has no
separate volume control and is adjusted by using the master volume.

18. Headphone Output

When you plug in headphones here, the speakers shut off so you can play along
silently with pre-recorded music.
19. Mix D.I. (Post)
Plug in here when you wish to send signals from the mic, instrument, and aux
inputs to a mixing console or a recording device. This post-EQ output is always
ground isolated to prevent ground loop hum.
16
Use included
power supply
only
17 18
Aux In
12
19
Mix D.I.
Output
