300N Draft 802.11n Wireless USB Adapter
Model # AWLL6080
User's Manual
Rev. 1.1

Advertisement

Table of Contents
loading

Summary of Contents for Airlink101 AWLL6080

  • Page 1 300N Draft 802.11n Wireless USB Adapter Model # AWLL6080 User’s Manual Rev. 1.1...
  • Page 2: Table Of Contents

    1. Introduction... 3 1.1 Package Contents ... 3 1.2 Features ... 3 2. Installation... 4 2.1 Install Driver & Utility... 4 2.2 Verify Driver Installation... 12 3. Configuring the Adapter ... 14 4. Wireless Monitor ... 19 4.1 Wireless Information ... 19 4.2 AP List ...
  • Page 3: Introduction

    1. Introduction Congratulations on your purchase of the 300N Draft 802.11n Wireless USB Adapter. The 300N USB Adapter provides wireless data rate of up to 300 Mbps* when used with other AirLink101® 300N wireless products. The high bandwidth combined with extended wireless coverage delivers fast and reliable connection for all of your networking applications.
  • Page 4: Installation

    2. Installation 2.1 Install Driver & Utility This section provides instructions on how to install the 300N Draft 802.11n Wireless USB Adapter. The driver is installed along with the utility. Step 1 Insert the USB adapter into an available USB port and turn on your computer. Step 2 After turning on the computer, Windows will launch the Found New Hardware Wizard.
  • Page 5 Note: If the Autorun screen doesn’t appear automatically, or if you get a blank white screen, go to Start, Run, and type D:\Utility\Setup.exe (where D is the letter of your CD drive) and click OK. Windows Vista users: At this point, you may get a warning message like the one below.
  • Page 6 Step 4 Click Next at the welcome screen. Step 5 Click Next to accept the default destination folder.
  • Page 7 Step 6 Click Continue Anyway at the Windows Logo Screen. (For Windows 2000, click Yes at the Digital Signature Not Found prompt). For Windows Vista, click the Install this driver software anyway button when the security warning appears.
  • Page 8 Step 7 Click Yes, I want to restart my computer now and then Finish to restart your computer. Step 8 After the computer is restarted, Windows will ask to connect to Windows...
  • Page 9 Update, select No, not this time and click Next. If this screen does not appear, you can skip to section 2.2. Step 9 Select Install the software automatically and click Next.
  • Page 10 Step 10 Click Continue Anyway at the Windows Logo Screen. (For Windows 2000, click Yes at the Digital Signature Not Found prompt).
  • Page 11 For Windows Vista, click the Install this driver software anyway button when the security warning appears. Step 11 Click Finish.
  • Page 12: Verify Driver Installation

    2.2 Verify Driver Installation To verify if the driver has been installed successfully, please perform the following steps. Step 1 Right-click on My Computer from your desktop and select Properties. Step 2 If you are using Windows XP/2000 select the Hardware tab, then click on Device Manager.
  • Page 13 Step 3 Expand Network adapters from the list and verify that AirLink101 300N Wireless USB Adapter is listed and no yellow question mark is beside it. If AirLink101 300N Wireless USB Adapter is not listed, or you see a yellow question mark beside it, you will need to reinstall the driver.
  • Page 14: Configuring The Adapter

    3. Configuring the Adapter This section describes how to connect your wireless adapter to a wireless network. Note to Windows XP Users: You must disable the Wireless Zero Configuration Utility in order to use the bundled Wireless Utility. Please follow the steps below to disable XP’s wireless utility. Windows Vista users can skip the following instructions and go to Step 1 Double-click on the Wireless Network Connection Icon in the system tray and then...
  • Page 15 Step 1 To open the utility, double click on the Wireless Monitor icon in the system tray at the bottom right-hand corner of your screen. Step 2 Go to the AP List tab, select the SSID (Network Name) of the wireless network you wish to connect to, and click Connect.
  • Page 16 If the network you are attempting to connect to is configured for encryption, you will see an orange lock icon next to the network.
  • Page 17 When you click on it and click connect, a box will pop up requesting the wireless encryption key for the router. Enter the encryption key into the box and click OK.
  • Page 18 Step 3 You should now be connected. You should see “Connected” in the top, right hand corner, and there will be a blue circle around the antenna icon next to the network name. Troubleshooting: If you are experiencing problems with the connection (unable to connect, low signal strength, slow connection speed, not working, unstable wireless connection) you will want to tune your router’s signal by changing channels on the router.
  • Page 19: Wireless Monitor

    4. Wireless Monitor This section describes the various functions of the Wireless Monitor that you can configure, including the settings of wireless encryption. 4.1 Wireless Information The Wireless Information box at the top of the window provides you with the status of the current connection, including signal, network name (SSID), IP Address and router channel.
  • Page 20: Ap List

    4.2 AP List The AP List tab displays all the available wireless networks detected by the Wireless Adapter. Simply select the wireless network you wish to connect to and click Connect. If you have created multiple profiles, you can use the profile chooser at the bottom to select the specific profile you want to use.
  • Page 21: Profile Settings

    4.3 Profile Settings This section provides instructions on using the Profile Settings section of the wireless monitor. The My Wireless Networks box lists the different profiles you’ve created for the different networks that you use. Profiles are automatically created and added to this list when you connect to new networks.
  • Page 22 The Profile Settings box will appear allowing you to specify the settings for your new profile or change settings for your existing profile. Once you are finished entering the settings, click OK to save the changes.
  • Page 23: Configuring Encryption

    4.4 Configuring Encryption This section describes the different types of encryption available and how to configure them. In most cases, encryption will be automatically configured and all that will need to be entered is the key, as described in Section 3 Step 2.
  • Page 24 These three are meant for the home user: None: No encryption in use WEP: The most popular but least secure form of encryption WPA/WPA2-PSK: The most secure and recommended level of encryption The remaining two are for use in a corporate environment that utilizes authentication servers.
  • Page 25 Configuring WEP encryption Select WEP from the Set Security Option box. Under Wired Equivalent Privacy (WEP), you will want to select Shared or Open, depending on the router settings. In the Key box, you will want to type in the encryption key for the router. If you check the Show text in the password field box, your key will appear in the box as you are typing it instead of showing only asterisks.
  • Page 26 Configuring WPA/WPA2-PSK Encryption (for home users) Select WPA/WPA2-PSK from the Set Security Option box. Under Passphrase Settings select either TKIP or AES depending on the settings for your router. Enter the encryption key into the KEY box.
  • Page 27 Configuring WPA/WPA2 Encryption (for corporate networks) Select WPA/WPA2 from the Set Security Option box. Under Advanced Security Settings select either TKIP or AES depending on the settings for your router. Click on Advanced Config to enter your authentication settings. The adapter supports EAP-TLS, LEAP, EAP-TTLS, and PEAP authentication methods. Refer to your system administrator for information about what settings you should enter here.
  • Page 28 Configuring 802.1x authentication (for corporate networks) Select 802.1x from the Set Security Option box. Click on Advanced Config to enter your authentication settings.
  • Page 29: Ad-Hoc And Peer-To-Peer Wireless Networks

    The adapter supports EAP-TLS, LEAP, EAP-TTLS, and PEAP authentication methods. Refer to your system administrator for information about what settings you should enter here. 4.5 Ad-hoc and Peer-to-Peer Wireless Networks Ad-hoc networking is used when you want to connect two or more computers together but you don’t have a router.
  • Page 30 Open the Wireless Monitor. Click on Profile Setting, then click on New. The profile settings box will appear. First change the network type to Adhoc. (Infrastructure is for when you are using a router). Enter a profile name into the Profile Name box so that you can identify the profile. Type in a network name (SSID) into the SSID box Select your desired Channel You can also choose between no security or WEP security.
  • Page 31 Once that is done, click on the AP List. Select your new profile from the profile chooser and click Activate to enable the profile. You will need to configure all other computers that you are planning on connecting to your ad-hoc network with the same settings that you input on this screen. Every computer has to be set up exactly the same.
  • Page 32: Wi-Fi Protected Setup (Wps)

    In the instructions below, we are going to use the utility, Wireless Monitor that comes with the Airlink101 300N Wireless Adapters, AWLC6080, AWLH6080, and AWLL6080 with the AR680W AirLink101 300N Wireless router as the example.
  • Page 33 Write down the PIN if you are using Pin Code method and click next.
  • Page 34 If you choose Push Button method, make sure that you click on the Wi-Fi Protected Setup button.
  • Page 35 Go to your routers configuration screen and click on Wireless. Then click Wireless security. Make sure that the Wi-Fi Protected Setup Enable box is checked. Then click the Add Wireless Device Wizard button. If you are using Pin Code method, enter the Pin Code in the Pin Number box and click connect.
  • Page 36 After a few moments both the router configuration screen and the adapter configuration screen should show a message telling you that you are connected. Click Finish on the adapter screen.
  • Page 37 Click Continue on the router configuration screen.
  • Page 38: About

    4.7 About The About tab shows the Utility, Driver, and Firmware version as well as the MAC address of the adapter.
  • Page 39: Appendix A - Specifications

    Appendix A – Specifications Frequency Band • 2.4~2.5Ghz Standards • IEEE 802.11b / 802.11g • IEEE 802.11n draft Chipset • Ralink Interface • USB 2.0 Antenna type • Integrated antenna Security • WPA-PSK(TKIP) • WPA2-PSK (AES) • WEP 64/128 bits •...
  • Page 40: Appendix B - Information

    Appendix B – Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 41 Radio products with the CE marking comply with the R&TTE Directive (1999/5/EC), the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms: EN 60950 Product Safety EN 300 328 Technical requirement for radio equipment EN 301 489-1/-17 General EMC requirements for radio equipment...
  • Page 42: Technical Support

    Technical Support E-mail: support@airlink101.com Toll Free: 1-888-746-3238 Web Site: www.airlink101.com *Theoretical maximum wireless signal rate derived from IEEE 802.11g standard and IEEE 802.11n draft specification version 1.0. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, mix of wireless products used, radio frequency interference (e.g., cordless telephones and microwaves) as well as network overhead lower actual data throughput rate.
