User Manual
Quick Installation Guide
Wireless N USB Adapter
Model # AWLL6077
Section 1
Install Utility Software
This Quick Installation Guide only provides the basic installation instructions.
For detailed installation instructions on advanced features, please refer to the
User's Manual that can be found on the provided CD.
Step 1.1
Insert the USB adapter into an available USB port of your computer.
Step 1.2
Windows 2000/XP
Users: Windows will launch the Found New Hardware
Wizard. The Found New Hardware Wizard appears differently depending on
your computer operating system, click Cancel to quit the wizard and insert the
Installation CD in the CD drive. Continue to Step 1.3.
Ver. 1.0
Package Contents:
• Wireless N USB Adapter
• USB Cable
• Driver & Utility CD
• Quick Installation Guide
Windows Vista
Users: Windows will install its built in drivers for this adapter.
Give permission to Windows to install the device driver software. After you see
the Windows message 'Device driver software installed successfully', insert the
Installation CD into the CD drive.
Step 1.3
The Autorun screen will pop up. Select Install Utility and Driver from
the menu.
Note: If the Autorun screen doesn't appear automatically go to Start, Run, and
type D:\Utility\Setup.exe (where D is the letter of your CD drive) and click OK.
Windows Vista
Users: When you get warning message(s), make sure that you
give permission to continue with the installation of the driver software.
Advertisement
Related Manuals for Airlink101 AWLL6077
Summary of Contents for Airlink101 AWLL6077
-
Page 1: Quick Installation Guide
Windows Vista Users: Windows will install its built in drivers for this adapter. Give permission to Windows to install the device driver software. After you see Ver. 1.0 the Windows message ‘Device driver software installed successfully’, insert the Installation CD into the CD drive. Quick Installation Guide Wireless N USB Adapter Model # AWLL6077... - Page 2 Step 1.4 The Airlink101 WLAN Monitor screen will popup. Click Next at the Step 1.6 Give Permission to Window to install the driver software screen. For Windows Vista, click the Install this driver software anyway. For Windows XP click Continue Anyway at the Windows Logo Screen.
- Page 3 Windows Vista will show: The Airlink101 Wireless Monitor of Windows XP gives you an option to Start or Stop the Wireless Zero Configuration. It is not recommended to check this Windows Zero Config box, if it is checked, you will be using the XP’s wireless utility instead of the Airlink101 Wireless Monitor utility to monitor the connection.
- Page 4 SSID (Network Name) of the wireless network that you wish to connect to, and click Add to Profile. 2. Push the WPS button of the Router. The picture shows Airlink101 AR670W router. If the network that you are attempting to connect does not have encryption enabled, you will receive a warning about connecting to an unsecured network.
-
Page 5: Troubleshooting
Troubleshooting If you are experiencing problems with the connection (unable to connect, low The Adapter may automatically detect the Network Authentication and the Data signal strength, slow connection speed, not working, unstable wireless encryption. You need to enter the security settings in the appropriate boxes connection) you may want to tune your router’s signal by changing the according to the settings of the router and then click OK to connect. -
Page 6: Technical Support
802.11n specification. Compatibility with draft 802.11n devices from other manufactures is not guaranteed. Specifications are subject to change without notice. Photo of product may not reflect actual content. All products and trademarks are the property of their respective owners. Copyright ©2009 Airlink101®...
