Page 1: Installation Guide
Installation Guide CO2175DWR — ® Combo Drawer Refrigerator/Freezer/Ice Maker www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2006 U-Line Corporation 06/2006... -
Page 2: Table Of Contents
CO2175DWR — Ice Maker/Refrigerator Contents Exterior Cleaning ......Cut-Out Dimensions ...... -
Page 3: Inspect And Plan
CO2175DWR — Ice Maker/Refrigerator 2 Inspect and Plan You have received a carton containing your CO2175DWR Combo Drawer Model Ice Maker/Refrigerator with a package inside containing a Use and Care Guide, a Product Registration Card, water connection parts and Anti-Tip Kit. -
Page 4: Exterior Cleaning
3 Prepare Site Your U-Line product has been designed for built-in installation. Your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for water and electrical connections in the rear. -
Page 5: Product Dimensions
Please note that the unit has adjustable feet that can add one additional inch to height during leveling or to match adjacent cabinets (see Figure 28 on Page 13). 06/2006 CO2175DWR — Ice Maker/Refrigerator Clearances Information The unit must be installed in a wall or under a counter- 25-13/16"... -
Page 6: Other Site Requirements
The unit requires a 1/4-inch OD water supply line and a shut-off valve. For more information see Page 12. Environmental Requirements Many U-Line models are designed to operate in harsh outdoor/marine environments. Special considerations include the following: • The units are designed to operate between 50°F (10°C) and 110°F (40°C). -
Page 7: No Custom Drawer Panels
Height: 12-15/32" The door panels must not have a total weight of more than 20 lbs. 06/2006 CO2175DWR — Ice Maker/Refrigerator Drawer Panel Installation Install the insert as follows: Use care when handling the insert. Insert edges may be sharp. -
Page 8: Full Overlay Drawer Panels
CO2175DWR — Ice Maker/Refrigerator Full Overlay Drawer Panels Drawer Panel Preparation Full overlay drawer panels completely cover the drawer fronts and handles to give a built-in appearance. Black units are shipped ready for full overlay installation. Note: For standard installations, both drawers mount the same and a 1/2"... -
Page 9: Checking Drawer Alignment
3. Starting at the corners and working toward the center, push the drawer gasket back into place. Go on to 5 Adjust Drawers. 06/2006 CO2175DWR — Ice Maker/Refrigerator 5 Adjust Drawers Checking Drawer Alignment The unit’s drawers are aligned at the factory before shipment. -
Page 10: Adjusting Drawer Alignment
CO2175DWR — Ice Maker/Refrigerator Adjusting Drawer Alignment WARNING SHOCK HAZARD — The unit must be unplugged from the wall outlet during drawer removal, adjustment and re-installation. Drawer Removal 1. Confirm that the unit is unplugged from wall outlet. 2. Unplug the drawer’s connection wiring (top drawer only). - Page 11 Viewed from the top, one side will protrude. This is caused by one of the slides being mounted higher than the other slide on the unit’s liner. 06/2006 CO2175DWR — Ice Maker/Refrigerator Minor Adjustment: Note: The mounting holes Screws Should...
-
Page 12: Water Supply Connection
(see Figure 25). However, make certain that the tubing is not pinched or damaged during installation. Note: U-Line recommends the use of copper tubing for installation. The use of other types of tubing is not recommended due to potential aftertaste & deterioration over time. -
Page 13: Electrical Specifications
• Never use an extension cord to connect power to the unit. Go on to 8 Level the Unit. 06/2006 CO2175DWR — Ice Maker/Refrigerator 8 Level the Unit Leveling Information It is extremely important that the unit is level. If it is not level, the ice mold will not fill evenly. -
Page 14: Installation Of The Co2175Dwr
CO2175DWR — Ice Maker/Refrigerator 9 Install the Unit Installation of the CO2175DWR 1. Plug in the power cord. 2. Open the top drawer.Press and hold the POWER icon to turn the unit OFF. (see Figure 31,1) Note: If the unit is NOT turned OFF, water will immediately start flowing into unit when it is first plugged into the electrical outlet and water supply is on. -
Page 15: Installation Troubleshooting
CO2175DWR — Ice Maker/Refrigerator 10 Start-Up for the First Time Initial Start-Up All U-Line units are shipped from the factory with the controls that are preset. No initial adjustments are required. Once installation and leveling is complete, the unit is ready for initial start-up and operation. -
Page 16: Start-Up Troubleshooting
CO2175DWR — Ice Maker/Refrigerator Electronic Control Panel The electronic control with digital display (Figure 31) is located in the top drawer. It is configured to show a single temperature continuously. This set-point temperature is a base number used by the controller to maintain the temperature zone in your unit. -
Page 17: Service Information
For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in ®...
