True TDB-24-48G Specifications

St. Charles Industrial Center • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# (636)272-9471
Model:
TDB-24-48G
Shown with optional TrueTrac 12oz. (355 ml) bottle organizers.
ROUGH-IN DATA
Model Doors Shelves
TDB-24-48G 2
* Height does not include 15
† 3
Depth does not include 1 /
8
T R
RUE EFRIGERATION
TM
MADE IN
U.S.A. U.S.A. .S.A.
®
SINCE 1945
2/06
TRUE FOOD SERVICE
EQUIPMENT, INC.
24" Underbar Refrigerator:
Glass Door Back Bar/Direct Draw Beer Dispenser
Capacity
Cans
Half (12 oz.)
Barrels
(355 ml)
(left door) (right door)
2 1 245
1 / " (388 mm) for draft arm.
4
" (35 mm) for door handle.
APPROVALS:
R
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
Chart dimensions rounded up to the nearest 1/8"
Cabinet Dimensions
(inches)
(mm)
† *
L D H
1 1 5
49 / 24 / 35 /
8 4 8
1248 616 905
Qty:
TDB-24-48G
True's back bar/direct draw combination
coolers are designed with enduring
quality and value. Our commitment to
using the highest quality materials and
oversized refrigeration assures colder
product temperatures and years of
trouble free service.
Oversized, factory balanced,
refrigeration system holds 33°F to 38°F
(.5°C to 3.3°C).
Exterior - heavy duty, wear resistant
laminated black vinyl front and sides.
Matching black aluminum back. All
stainless steel counter top.
Interior - 300 series stainless steel fl oor
1
with / " (13 mm) reinforced lip and
2
heavy gauge galvanized steel walls.
NSF approved for pre-packaged and
bottled product.
3" (77 mm) diameter stainless steel
insulated beer column. Cold air is
channeled directly into beer column
to reduce foaming and maximize draft
beer profi ts.
Positive seal doors.
"Low-E", double pane thermal
glass door assemblies with extruded
aluminum frames. The latest in energy
effi cient technology.
Patented intergrated door light (IDL)
system on glass doors provides brighter,
shadow free illumination.
Entire cabinet structure is foamed-
in-place using high density, CFC free,
polyurethane insulation.
Specifi cations subject to change without notice.
(millimeters rounded up to next whole
NEMA
HP Voltage Amps Confi g.
1
/ 115/60/1 7.6 5-15P
3
AVAILABLE AT:
AIA #
SIS #
number).
Crated
Cord
Weight
Length
(lbs.)
(feet)
(kg)
(m)
7 290
2.1 132
