Descriptive diagram

A - Timer*
B - Locking button
C - Lid knob
D - Programme selector
E - Unlocking button
F - Control panel
G - Jaws
H - Stainless steel lid
I - Module retaining nut
J - Lid seal
K - Vitamin basket*
L - Steam basket*
Total Interior
Capacité Ø
22 cm 18 cm Stainless
4,5 L 5,3 L*
22 cm 18 cm Stainless
6 L 6,8 L*
25 cm 20 cm Stainless
4,5 L -
25 cm 20 cm Stainless
8 L 9,4 L*
10 L 11,4 L* 25 cm 20 cm Stainless
* Product capacity with the lid in position.
*depending on model
M - Fixed pan handle*
N - Integrated basket supports
O - Stainless steel pot
P - Handle release button*
Q - Folding pan handles*
R - Steam release outlet
S - Pressure indicator
T - Operating valve seal
U - Operating valve
V - Control module fixing screw
W- Safety valve
Pressure cooker base diameter
Material
Base Clipso Clipso
body
Ø
and lid
P41306 P41006
steel
steel
steel
steel
steel
Normative information:
Maximum operating pressure: 80kPa.
Maximum safety pressure: 140kPa.
Characteristics
Model
Clipso
Control Control
- P41007 P41107 P40807
- P41012
- P41014 P41114 P40814
- P41015 P41115 P40815
Clipso
Modulo
+
- -
- -
