Evaluation Module Overview
1.3 Specification
INPUT PARAMETERS
V
dc
I
1.4 Device Information
The DLP660TEEVM, DLP470TEEVM, DLP780TEEVM and DLPC4420AEVM contain the electronics required
to drive either the DLP660TE, DLP470TE or DLP780TE DMD. The DLPC4420AEVM offers several interface
options for USB, I2C, and trigger inputs and outputs.
Table 1-2
shows the use of shared EVM designs. This guide relates to 4k UHD resolution DMDs only.
DMD Covered
DLP780TE
DLP470TE
DLP660TE
The system block diagram
DLPC4420AEVM.
4
DLP
®
Display ≥0.47-in Array 4K UHD Evaluation Module
Figure 1-4. DLP780TEEVM
Table 1-1.
CONDITIONS
Section 2.1
Table 1-2. 4K/UHD DMD EVMs
Figure 1-5
details the functionality and control when using the DLP660TEEVM and
Copyright © 2023 Texas Instruments Incorporated
MIN
TYP
11.4
12
Resolution
4k/UHD
4k/UHD
4k/UHD
www.ti.com
MAX
UNIT
13.2
V
7
A
DLP EVM #
DLP099
DLP104
DLP080
DLPU126 – DECEMBER 2023
