The power socket, device and rack are well grounded.
■
The device is correctly connected to other network devices.
■
3.4
Power On
Plug the negative connector of the provided power cord into the power socket of the device and plug
the positive connector into a power outlet as the following figure shows.
Figure 3-3
Connecting to Power Supply
Note:
The figure is to illustrate the application and principle. The provided plug and the socket in
your region may differ from the figures above.
3.5
Initialization
After the device is powered on, it begins the Power-On Self-Test. A series of tests run automatically
to ensure the device functions properly. During this time, the LED indicators will respond as follows:
1. The PWR/Power LED indicator will light up.
2. The LED indicators of all the ports will flash momentarily and then turn off again after the
initialization.
Unmanaged Rackmountable Switch
Connection
9
