Traulsen RBC400 Specifications

Project
Model Specified:
400 lb. Capacity Roll-In & Roll-Thru
Blast Chiller Models
Model RBC400
High Quality Standard Features
• Stainless Steel Exterior & Interior Construction
• Communications Capable & NAFEM Data Protocol Compliant
• On-Board Batch Data Printer
• Three (3) Chilling Functions
1) Blast Chill (135° to below 41°F in approx. 90-minutes)
2) Soft Chill (for use with delicate products such as
fresh seafood and produce)
3) Freeze (target temp can be set for as low as -22°F)
• Three (3) Chilling Modes For Each Chilling Functions
1) By Temperature
2) By Product
3) By Time
• Automatic Refrigerated Hold Mode After Each Cycle
• Dual Self-Contained Refrigeration Systems (promotes energy
efficient operation and maximizes compressor life)
• Accommodates Two (2) Roll-In Rack2 With Maximum
Dimensions Each Of: H=72" x W=27" x D=29" (not supplied
standard, see "Options & Accessories")
• Magnetic Door Gasket(s)
• Stainless Steel Breaker Caps
• Stainless Steel Roll-In Ramp(s) & Rack Guides
• Self-Closing and Stay Open Door Features
• Rehingeable Door with Lock (Standard Left Hinging)
• Horizontal Work Flow Door Handle(s) Guaranteed for Life
• Automatic Defrost With On-Demand Feature
• Adjustable Product Chill Target Temperatures
• Adjustable Product Holding Temperature
• One Year Parts/Labor Warranty
• Five Year Compressor Warranty on
R
3 HP Holding Compressors
⁄
4
Listed by Underwriters Laboratories Inc.
and CSA certified by Underwriters
Laboratories Inc. and classified by
Underwriters Laboratories in accor-
dance with ANSI/NSF7.
TRAULSEN
4401 BLUE MOUND RD.
PHONE 1 (800) 825-8220
Website: www.traulsen.com
Quantity
RBC
Roll-In Model
Roll-Thru Model
SERIES
Like all blast chillers, Traulsen's model RBC400 and RBC400RT are
designed to quickly cool their respective capacity of hot product through the
HACCP danger zone as fast, or faster, than any other equivalent brand on
the market (approximately 90-minutes). However, in addition to the
outstanding cabinet construction synonomous with Traulsen, what
differentiates these models from competition is the operational flexibility and
labor savings inherent in their easy-to-use controls, automatic HACCP
documentation, and a variety of operator friendly features, such as our
exclusive "By-Product" chill mode.
Both models require provision of two (2) 4 HP remote condensing units for
blast chill operation (installation by others). If purchased from Traulsen, this
includes a five year warranty.
Exclusive Standard Features
• Easy-to-Use SmartChill
• One Button EZ-START
• Four (4) SmartProbes
Temperatures
• On-Board Label Printer (prints adhesive labels which can be
placed directly on to product containers)
• By Product Chill Mode (allows the operator to pre-program
into memory the individual chilling requirements of a variety
of different food products)
Options & Accessories
• Correctional Facility Package for Blast Chill
• For Other Voltage Options Consult Factory
• One or Two Day On-Site Blast Chill Training
• Two Year Service Labor Warranty Available
• BCACC-60111: 208-230/60/1 4HP Air-Cooled Remote
Condensing Unit (2 req'd.) - Includes 5 Year Warranty
• BCACC-60123: 208-230/60/3 4HP Air-Cooled Remote
Condensing Unit (2 req'd.) - Includes 5 Year Warranty
• BCACC-60121: 208-230/60/1 3HP Water-Cooled Remote
Condensing Unit (2 req'd.) - Includes 5 Year Warranty
• BCACC-OTRTR: Special Blast Chiller Roll-In Rack
(accommodates up to 26-12" x 20" pans)
• BCACC-60387: SmartChill
Package
• BCACC-NDPG1: Communications Gateway (required for
use within a NAFEM Data Protocol compliant network)
• BCACC-60122: Remote Condensing Unit Weather Housing
• BCACC-60073: Leg Kit For Remote Condensing Unit
• BCACC-FMCE: 115V Floor-Mounted Condensate Evaporator
Approval: __________________________________
FT. WORTH, TX 76106
FAX-MKTG. 1 (817) 624-4302
Item #
CSI Section 11400
RBC400
RBC400RT
® Control System
TM
Feature
TM
Automatically Register Product
® PC Communications Software
SECTION
6-4
