Arrow Storage Products VM1010 Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
ACV01et
Model No.
718590915
Storage Area:
92 Sq. Ft.
8,5 m
BUILDING DIMENSIONS * Size rounded off to the nearest foot
*Approx.
Base
Size
Size
10' x 10'
121" x 114 1/2"
3,0 m x 2,8 m 307,3 cm x 290,8 cm
VM1010
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
580 Cu. Ft.
16,4 m
2
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
123 1/4"
117"
313,1 cm
297,2 cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Height
Width
86"
118 1/4"
111 3/4"
218,4 cm
300,4 cm
283,8 cm
Depth
Height
Width
84 3/4"
55 1/2"
215,3 cm 141,0 cm 163,8 cm
Door
Opening
Height
64 1/2"

Advertisement

loading

Related Manuals for Arrow Storage Products VM1010

Summary of Contents for Arrow Storage Products VM1010

  • Page 1 Owner's Manual & Assembly Instructions ACV01et Model No. VM1010 Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 718590915 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES Storage Area: 92 Sq.
  • Page 3 BEFORE YOU BEGIN..Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.
  • Page 4 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 CARE & MAINTENANCE..Finish: For long lasting fi nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 7 ACCESSORIES..FLOOR FRAME KITS ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof. BEFORE AFTER ANCHOR KITS Model No. AK4 MODELS FB47410, FB5465, FB106-A Anchor Kit contains heavy-duty steel FB109-A and FB1014-A augers, 60' (18 m) of steel cable and...
  • Page 8 ORDERING ACCESSORIES..02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is offering them to you on a direct basis. There are two ways to order Arrow Storage Building Accessories: Option 1 Option 2...
  • Page 9 Base The Base For Your Building No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
  • Page 10 Anchoring Anchoring Down The Building It is important that the entire fl oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
  • Page 11 Hardware ACV11 Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 65103 Black Screw (8) #8-32x3/8" (10 mm) #8Ax5/16" (8 mm) #8-32 Hex Nut (137) (Packed with Screws) Bolt (137) Screw (328) 66646 67468 67545...
  • Page 12 Parts List ACV12et Assembly Part Part Quantity Check Key No. Number Description in Carton List 3719 Door Handle Brace 5290 Front Siding (6 Board) 5291 Front Siding (3 Board) 5306 Rear Siding (6 Board) 5307 Rear Siding (3 Board) 5986 Rear Wall Angle 10497 Horizontal Door Brace...
  • Page 13 Assembly by Key No. ACV13et 23 23 23 23...
  • Page 14  8934 Ramp (1) Step 1  Parts Needed For   9367 Front Floor Frame (2) Floor Frame Assemblies  8936 Rear Floor Frame (2)  9299 Side Floor Frame (4) The front fl oor frame is made up of three pieces.
  • Page 15 Step 2  Parts Needed For   5986 Rear Wall Angle (2) Frame Assemblies 10521 Side Wall Angle (4) ACV15 The main frame pieces reinforce the walls. These pieces will later be installed at the top edge of the side walls and the rear wall.
  • Page 16 Step 3  Parts Needed For   10518 Roof Beam (8) Roof Beam Assemblies The roof beams join the two gables and support the roof panels. The main roof beam is made up of four 10518 pieces overlapped back to back at the center.
  • Page 17 Step 4  Parts Needed For   6403 Door Track Splice (1) Door Track Assembly  9366 Door Track (2) NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track...
  • Page 18 Step 5  Front Floor Assembly (1)  Parts Needed For   Side Floor Assembly (2) Floor Frame  Rear Floor Assembly (1) RIGHT REAR 9299 Assemble the four corners of the fl oor frame using two screws at each corner as shown.
  • Page 19  9196 Right Corner Post (2) Step 6  Parts Needed For   9197 Left Corner Post (2)  Door Track Assembly (1) Posts/Top Frames  Rear Wall Angle Assembly (1) ACV19  Side Wall Angle Assembly (2) NOTE The remainder of the building assembly requires many hours and more than one person.
  • Page 20 Step 7  9195 Splice Post (1)  Parts Needed For   9198 Side Splice Post (2) Splice Post/Door Jamb  9194 Door Jamb (2) STEP The door jambs reinforce the door opening and provide an attractive ANGLED END OF SPLICE POST MUST trim.
  • Page 21 Step 8  Parts Needed For   9199 Siding Stud (6) Studs ACV21 The studs provide a surface for attaching the siding panels. Following dimensions, measuring from the ends of angles, place a stud between each corner and splice post. Position stud inside top angle and fasten with a screw.
  • Page 22 Step 9  Parts Needed For   10724 Side Siding (5 Board) (4)  10722 Side Siding (3 Board) (4) Side Siding ACV22  10723 Side Siding (6 Board) (4) Each screw in the wall requires a washer. CORRECT INCORRECT (6 board) Slide side siding (5 board) into...
  • Page 23  8736 Rear Siding (5 Board) (2) Step 10  5307 Rear Siding (3 Board) (2)  Parts Needed For   5306 Rear Siding (6 Board) (2) Rear/Front Siding  8737 Front Siding (5 Board) (2)  5291 Front Siding (3 Board) (2) ...
  • Page 24 Step 11  Parts Needed For   8576 Right Gable (2)  8577 Left Gable (2) Gable Assemblies  6635 Roof Beam Bracket (4) G24et no hdw STEP The gables go on top of the front and Edge Trim rear walls to support the roof beams.
  • Page 25 Step 12  Parts Needed For   Left Gable Assemblies (2)  Right Gable Assemblies (2) Gables/Braces  9009 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the rear wall angel with screws. Hint: On the rear gable, use a bolt and nut at the overlapping rear wall angle.
  • Page 26 Step 13  Main Roof Beam (1)  Parts Needed For   Single Roof Beam (2) Roof Beam/Braces  9204 Roof Beam Brace (2) Apply the weather stripping along the mating edge of the left and right STEP gables as shown. Cut the weather stripping to length.
  • Page 27 Step 14  Parts Needed For   9086 Right Roof Panel (1) Right Roof Panel ACV27et STEP Installing the roof panels is best done with a step ladder. Begin installing roof panels at the back right corner of the building. Each screw and bolt 9087 9086 in the roof requires a washer.
  • Page 28 Step 15  Parts Needed For   9087 Left Roof Panel (1) Roof Assembly  7743 Roof Panel (4) ACV28 Install a left roof panel at the left 9087 9086 rear corner of the roof. Install 4 roof panels in the 7743 7743 sequence and positions shown.
  • Page 29 Step 16  Parts Needed For   6869 Ridge Cap (2)  9087 Left Roof Panel (1) Ridge Caps & Panels  9086 Right Roof Panel (1) ACV29 STEP Install 1 ridge cap on the com- Peak Cap pleted roof section using bolts and nuts.
  • Page 30 Step 17  Parts Needed For   6015 Side Roof Trim (4) Roof Trim ACV30 Attach the side roof trim to the lower end of the roof panels on each side of the building using screws at each panel overlap. NOTE STEP A single screw fastens both trim...
  • Page 31 Step 18  3719 Door Handle Brace (2)  Parts Needed For   10483 Right and Left Door (2) Door Assembly  10497 Horizontal Door Brace (4) ACV31  9202 Vertical Door Brace (2) The steps on this page tell how to assemble the right door.
  • Page 32 Step 19  Parts Needed For   Right Door Assembly (1) Door Installation & Adjustment  Left Door Assembly (1) ACV32 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the front frame track.
  • Page 33 Anchoring and Floor Frame ACV33 Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
  • Page 34 SOME FACTS ABOUT RUST XA35 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfi nished edges, or 2.
  • Page 35 NOTES GZ46...
  • Page 36 VM1010 ACV36et 718590915...
