Siemens SIMATIC NET RUGGEDCOM RX5000 Equipment Manual page 16

F24
F30
F31
F32
F33
Slot 4 options
G00
G01
G02
G04
G24
G30
G31
G32
G33
Slot 5 options
H00
H01
H02
H04
H24
H30
H31
H32
H33
Slot 6 options
J00
J01
J02
J04
J24
RUGGEDCOM RX5000
Equipment Manual, 11/2023, C79000-G8976-1058-15
Option
4CG01 = 4x 10/100/1000TX RJ45 require 88Gbps Switch module
4FG50 = 4x 1000LX SFP Blank (no transceivers) require 88Gbps Switch module
S01 = 8x RS232/RS422/RS485 via DB9
8FX50 = 8x 100FX SFP
PRP = 1x Pair (A/B) Gigabit PRP SFP Blank (no transceivers) require 88Gbps Switch
module
Option
XX = Blank Module
16TX01 = 16x 10/100TX RJ45
8FX01 = 8x 100FX multimode 1310nm ST 2km
8FX11 = 8x 100FX multimode 1310nm LC 2km
4CG01 = 4x 10/100/1000TX RJ45 require 88Gbps Switch module
4FG50 = 4x 1000LX SFP Blank (no transceivers) require 88Gbps Switch module
S01 = 8x RS232/RS422/RS485 via DB9
8FX50 = 8x 100FX SFP
PRP = 1x Pair (A/B) Gigabit PRP SFP Blank (no transceivers) require 88Gbps Switch
module
Option
XX = Blank Module
16TX01 = 16x 10/100TX RJ45
8FX01 = 8x 100FX multimode 1310nm ST 2km
8FX11 = 8x 100FX multimode 1310nm LC 2km
4CG01 = 4x 10/100/1000TX RJ45 require 88Gbps Switch module
4FG50 = 4x 1000LX SFP Blank (no transceivers) require 88Gbps Switch module
S01 = 8x RS232/RS422/RS485 via DB9
8FX50 = 8x 100FX SFP
PRP = 1x Pair (A/B) Gigabit PRP SFP Blank (no transceivers) require 88Gbps Switch
module
Option
XX = Blank Module
16TX01 = 16x 10/100TX RJ45
8FX01 = 8x 100FX multimode 1310nm ST 2km
8FX11 = 8x 100FX multimode 1310nm LC 2km
4CG01 = 4x 10/100/1000TX RJ45 require 88Gbps Switch module
Description
Description
Description
Description
Introduction
1.3 Article number
