Installation
If the appliance must be moved at any time, keep it
in an upright position; if absolutely necessary, it may be
tilted onto its back.
Positioning and levelling
1. Remove the appliance from all packaging and check that it
has not been damaged during transportation.
If it has been damaged, contact the retailer and do not proceed
any further with the installation process.
2. Check the dishwasher by placing it so that its sides or back
panel are in contact with the adjacent cabinets or even with
the wall. This appliance can also be recessed under a single
*
(see the Assembly instruction sheet).
worktop
3. Position the dishwasher on a level and sturdy floor. If the
floor is uneven, the front feet of the appliance may be adjusted
until it reaches a horizontal position. If the appliance is levelled
correctly, it will be more stable and much less likely to move or
cause vibrations and noise while it is operating.
*
4
. Adjust the height of the rear foot from the front of the
appliance on the central lower part of the dishwasher, turning
a hexagonal spanner (red color) with an opening of 8 mm in a
clockwise direction to increase the height or in an anticlockwise
direction to decrease the height.
The dishwasher meets the requirements set out by the
regulations in force concerning safety and electrical equipment.
Any technical checks should be conducted exclusively by
a trained and authorised technician: Repairs carried out by
unaithorised persons will invalidate the guarantee, as well as
posing a potential hazard to the user.
The manufacturer declines all responsibility for damage to
persons or property resulting from failure to observe the above
precautions, from tampering with even a single component or
from the use of non-original spare parts.
Electrical Connection
Before inserting the plug into the electrical socket, make sure
that:
• the socket is earthed and complies with current regulations;
• the socket can withstand the maximum load of the appliance,
which is indicated on the data plate located on the inside of
(see Description of the appliance);
the door
• the power supply voltage falls within the values indicated on
the data plate on the inside of the door;
• the socket is compatible with the plug of the appliance. If this
is not the case, ask an authorised technician to replace the
(see After Sales Service)
plug
or multiple sockets.
Once the appliance has been installed, the power supply
cable and the electrical socket should be easily accessible.
; do not use extension cables
The cable should not be bent or compressed.
If the power supply cable is damaged, it must be replaced
by the manufacturer or its Technical Assistance Service in order
to prevent all potential hazards.
This appliance must be earthed.
Fuses:your appliance comes fitted with a plug and a 13A fuse. If
you need to replace the fuse, only those rated at 13A and ASTA
approved to BS1362 should be used. If you lose the fuse cover, a
replacement may be obtained from your local authorised Service
Centre or Electrical company. Correct replacement is identified
by colour coding or the marking on base of plug.
DO NOT use the plug unless the fuse cover is fitted.
Changing the Plug
Cut off and dispose of the supplied plug if it does not fit your
socket.
To avoid a shock hazard DO NOT insert the discarded
plug into a socket anywhere else.
Wires in the mains lead are coloured accordance with the
following code:
Green/Yellow - Earth
Blue
-
Neutral
Brown
-
Live
If you change the plug, the colour of the wires in the mains lead
may not correspond with the terminal markings in the plug, which
if not coloured, could be:
EARTH 'E' or
NEUTRAL
'N'
LIVE
'L'
Changing the Mains Lead
A lead can be ordered from Hotpoint Service
UK: 08709 066 066 or
Republic of Ireland: 1850 302 220
- If you have damaged the existing lead or require a longer one
a charge will be made. It is strongly advised that this work is
carried out by a qualified electrician.
- If the domestic wiring includes a residual current-operated
circuit breaker, ensure that it conforms to the latest regulations.
The dishwasher must not be connected to the electricity supply
while installation is being carried out.
- This appliance should only be connected to a 230/240V AC
source, via a properly installed earthed socket.
- Use the dishwasher solely in a domestic environment.
- DO NOT stand or place heavy objects on the door when it is
open, this could damage the door or cause the appliance to
tip forward.
(See After Sales Service)
5
