- Page 1 SETUP INSTRUCTIONS 2009 250 EXC‑F EU 250 EXC‑F SIX DAYS EU 250 XCF‑W USA 250 XC‑F USA ART. NO. 3211404en...
- Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.
-
Page 4: Means Of Representation
MEANS OF REPRESENTATION Symbols used The symbols used are explained in the following. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Identifies a page reference (more information is provided on the specified page). Formats used The typographical and other formats used are explained in the following. - Page 5 SET‑UP Unpacking and setting up the vehicle – Remove the box and the plastic packaging. Info To avoid damaging the motorcycle during assembly, leave the protective film on the vehicle until you have finished. – Check the vehicle for transport damage. –...
- Page 6 Read the accompanying KTM PowerParts installation instructions. – Position all operating elements exactly on the handlebar. Tighten all screws. 600810-10 – Fill up with fuel. ( p. 7) – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection.
- Page 7 WORK Removing the seat – Remove screw . Lift up the seat at the rear, pull it back and then remove from above. 500080-10 Mounting the seat – Hook in the front of the seat at the collar sleeve of the fuel tank, lower it at the rear and simultaneously push it forward.
- Page 8 WORK Installing the front fender – Ensure that the spacing sleeves are mounted in the fender. – Position the front fender. Mount and tighten screws Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) Info Take care with the contact between the holding lugs and the start number plate or headlight mask.
- Page 9 WORK – Switch off the charger after charging. Disconnect the battery. Guideline The charge current, charge voltage and charge time must not be exceeded. Charge the battery regularly when the 3 months motorcycle is not in use. – Mount the seat. ( p.
- Page 10 WORK – Switch off the engine. – Open the filler cap. ( p. 7) – Fill the fuel tank with fuel up to measurement Guideline Measurement of 35 mm (1.38 in) Total fuel tank 9.2 l Super unleaded (ROZ 95 / RON 95 / capacity, approx.
-
Page 11: Technical Data - Tightening Torques For Chassis
TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS – Spoke nipple, front wheel M4.5 5 Nm (3.7 lbf ft) – Spoke nipple, rear wheel 5 Nm (3.7 lbf ft) – Remaining nuts, chassis 15 Nm (11.1 lbf ft) – Remaining screws, chassis 10 Nm (7.4 lbf ft) –... - Page 12 SUBSTANCES Super unleaded (ROZ 95 / RON 95 / PON 91) According to – DIN EN 228 (ROZ 95 / RON 95 / PON 91)
-
Page 13: Auxiliary Substances
AUXILIARY SUBSTANCES Long-life grease Specification – ® KTM recommends Motorex products. Supplier ® Motorex – Fett 2000... - Page 14 *3211404en* 3211404en KTM-Sportmotorcycle AG 5230 Mattighofen/Austria http://www.ktm.com...
