Lennox EL195UHNE Installation Instructions Manual

Hide thumbs Also See for EL195UHNE:
Table of Contents

Advertisement

Quick Links

Download this manual
© 2022 Lennox Industries Inc.
Dallas, Texas USA
Contents
Unit Dimensions - inches (mm) ......................................2
EL195UHNE Gas Furnace .............................................3
Shipping and Packing List ..............................................3
Safety Information ..........................................................3
Use of Furnace as Construction Heater .........................4
General ...........................................................................4
Combustion, Dilution & Ventilation Air ............................5
Shipping Bolt Removal ...................................................8
Installation - Setting Equipment ......................................8
Filters ............................................................................13
Duct System .................................................................13
Pipe Fittings Specifications...........................................14
Joint Cementing Procedure ..........................................16
INSTALLATION
INSTRUCTIONS
EL195UHNE
ELITE
SERIES GAS FURNACE
®
UPFLOW / HORIZONTAL AIR DISCHARGE
507758-05
03/2022
Supersedes 10/2021
THIS MANUAL MUST BE LEFT WITH THE
HOMEOWNER FOR FUTURE REFERENCE
This is a safety alert symbol and should never be
ignored. When you see this symbol on labels or in man-
uals, be alert to the potential for personal injury or death.
IMPORTANT
DO NOT use the heat exchanger tubes to lift, drag or
pull the furnace to its installation location.
Doing so will damage the tubes causing noise and or
unsafe operation.
Heatexchanger Tubes
Venting Practices ..........................................................16
Vent Piping Guidelines .................................................17
Gas Piping ....................................................................36
Electrical .......................................................................39
Unit Start-Up .................................................................42
Gas Pressure Adjustment .............................................46
Proper Combustion.......................................................46
High Altitude Information ..............................................46
Testing for Venting and Combustion Air........................47
Service..........................................................................48
Repair Parts List ...........................................................50
Start-Up & Performance Check List .............................51
Blower Data ..................................................................53
