MSPM0G3507-Q1, MSPM0G3506-Q1, MSPM0G3505-Q1
SLASF88 – OCTOBER 2023
– MSPM0G3507: 128KB flash, 32KB RAM
•
Development kits and software (also see
and
Software)
–
LP-MSPM0G3507 LaunchPad
kit
– MSP Software Development Kit (SDK)
•
Automotive qualification
– AEC-Q100 Grade 1 (-40°C to 125°C)
– 24 , 32 and 48 -pin QFN with wettable flanks
option
3 Description
MSPM0G350x microcontrollers (MCUs) are part of the MSP highly integrated, ultra-low-power 32-bit MCU
family based on the enhanced Arm
These cost-optimized MCUs offer high-performance analog peripheral integration, support extended temperature
ranges from -40°C to 125°C, and operate with supply voltages ranging from 1.62 V to 3.6 V.
The MSPM0G350x devices provide up to 128KB embedded flash program memory with built-in error correction
code (ECC) and up to 32KB SRAM with hardware parity option. These MCUs also incorporate a memory
protection unit, 7-channel DMA, math accelerator, and a variety of high-performance analog peripherals such
as two 12-bit 4-Msps ADCs, configurable internal shared voltage reference, one 12-bit 1-Msps DAC, three
high speed comparators with built-in reference DACs, two zero-drift zero-crossover op-amps with programmable
gain, and one general-purpose amplifier. These devices also offer intelligent digital peripherals such as two
16-bit advanced control timers, five general-purpose timers (with one 16-bit general-purpose timer for QEI
interface, two 16-bit general-purpose timers for STANDBY mode, and one 32-bit general-purpose timer), two
windowed-watchdog timers, and one RTC with alarm and calendar modes. These devices provide data integrity
and encryption peripherals (AES, CRC, TRNG) and enhanced communication interfaces (four UART, two I2C,
two SPI, CAN 2.0/FD).
The TI MSPM0 family of low-power MCUs consists of devices with varying degrees of analog and digital
integration allowing for customers find the MCU that meets their project's needs. The MSPM0 MCU platform
combines the Arm Cortex-M0+ platform with a holistic ultra-low-power system architecture, allowing system
designers to increase performance while reducing energy consumption.
MSPM0G350x MCUs are supported by an extensive hardware and software ecosystem with reference designs
and code examples to get the design started quickly. Development kits include a
purchase. TI also provides a free MSP Software Development Kit (SDK), which is available as a component of
Code Composer Studio
™
also supported by extensive online collateral, training with
E2E
™
support
forums.
For complete module descriptions, see the
Manual.
System-level ESD protection must be applied in compliance with the device-level ESD specification
to prevent electrical overstress or disturbing of data or code memory. See
ESD Considerations
MSPM0 MCUs.
2
Submit Document Feedback
Tools
™
development
®
®
Cortex
-M0+ 32-bit core platform operating at up to 80-MHz frequency.
IDE
desktop and cloud version within the
MSPM0 G-Series 80-MHz Microcontrollers Technical Reference
for more information. The principles in this application note are applicable to
Product Folder Links:
MSPM0G3507-Q1 MSPM0G3506-Q1 MSPM0G3505-Q1
2 Applications
•
Automotive body electronics and Lighting
•
Automotive Gateway
•
Steering Wheel Systems
•
Automotive Motor Control
•
DC to AC Inverters
•
Automotive Interior Lighting
•
Door handle modules
•
Kick to open modules
•
Vehicle Occupancy Detection
•
Seat Comfort Module
TI Resource
MSP
Academy, and online support through the
CAUTION
www.ti.com
LaunchPad
available for
Explorer. MSPM0 MCUs are
MSP430™ System-Level
Copyright © 2023 Texas Instruments Incorporated
